Ltech LM-100-24-U2A2 User manual

LM-100-24-U2A2
— 01 — www.ltech-led.com
Intelligent Tunable White LED Driver (Constant Voltage)
DIM /CT
Class 2
PUSH
0-10V
Flicker-free
IEEE 1789
Dimmable：
0.1%~100%
Overheat
protection
V
The certification icon represents on-going certification applications only, and final certification qualification is subject to actual products.
Over voltage
protection Overload protection Short circuit protection
0-10V
Push DIM/CCT
The driver is suitable for connecting resistor current-limiting LED fixture (e.g. LED strip). The inrush current will be dozens of times increased if connecting built-in constant current IC current-limiting LED fixtures, the driver will activate the overloaded
protection (hiccups flickering). When you order, please remark controlling the constant current LED fixture (e.g. MR16 lamp, underground light, LED wall washer, constant current LED strip, etc.), so that we can prepare them with special procedures.
Technical Specs
OUTPUT
Model
INPUT
ENVIRONMENT
PROTECTION
SAFETY
&
EMC
OTHERS
LM-100-24-U2A2
I/P-O/P: 100MΩ/500VDC/25°C/70%RH
50/60Hz
Dimming Interface
Frequency
Input Current
Power Factor
Max. 1A/120Vac, 0.55A/230Vac, 0.45A/277Vac
93%
Efficiency (typ.)
120-277Vac
Input Voltage
Inrush Current
Anti Surge
Leakage Current
Output Voltage
Output Power
Output Current
Output Voltage Range 24Vdc±0.5Vdc
Working Temperature
Working Humidity
Storage Temperature,Humidity
Temperature Coefficient
Vibration
ta: -20~50°C tc: 85°C
20-95%RH, non-condensing
-40~80°C, 10-95%RH
±0.03%/°C(-20~50°C)
10~500Hz, 2G 12min/1cycle, 72 min for X, Y and Z axes respectively
Dimming Range 0~100%, down to 0.1%
High frequency exemption level
Withstand Voltage
Isolation Resistance
I/P-O/P: 3750Vac
EN61000-4-2,3,4,5,6,8,11, EN61547
IEEE 1789
Safety Standards
EMC Emission
EMC Immunity
Strobe Test Standard
Ripple & Noise
THD
PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
120Vac@THD＜5%, 230Vac@THD＜8%, 277Vac@THD＜11% (at full load)
Cold start 45A/230Vac (Test twidth = 840us under 50% Ipeak)
L-N: 2KV
Max. 0.5mA
Max. 4.17A
24Vdc
Switch ripple≤150mV, noise≤500mV
Max. 100W
Dimensions 352×43×30mm(L×W×H)
Package size 355×44×33mm(L×W×H)
Gross weight(G.W) 430g
Output Power Range 0-100W
Overload Power Limitation ≥102%
Overheat Protection
Overvoltage Protection
Overload Protection
Short Circuit Protection
Shut down the output when non-load voltage≥28V, and recover automatically
Shut down the output when current load≥102%, and recover automatically
Enter hiccup mode if short circuit occurs, and recover automatically
0-10V(1-10V/10V PWM/RX), Push DIM/CCT
Strobe Level
Intelligently adjust or turn off the output current if the PCB temperature ≥110°C, and recover automatically
Standby Power Loss <0.5W
PWM Frequency 3600Hz
Carton Size 370×340×93mm(L×W×H) 20pcs/ctn 9.4kg±5%/ctn
EN55015, EN61000-3-2, EN61000-3-3, EN61547
America
Canada
European Union
America
European Union
UL8750
CSA C22.2 NO. 250. 13
EN61347-1, EN61347-2-13, EN62384
FCC part 15
UL
CUL
CE
CE
UL
Small size and light weight. The housing is made from V0 flame retardant PC
materials that SAMSUNG/COVESTRO uses.
With soft-on and fade-in dimming function, enhancing your visual comfort.
High frequency exemption level.
Dimming from 0~100%, down to 0.1%.
Automatically recognize 0-10V and 1-10V input signals.
Ultra-low consumption of 0-10V ports < 0.05mA.
Innovative thermal management technology intelligently protects the power life.
Overheat, over voltage , overload, short circuit protection and automatic recovery.
Suitable for indoor light applications ofⅠ /Ⅱ/Ⅲ type.
Up to 50,000-hour life time.
5-year warranty (Rubycon capacitor).
The secure and reliable design for signal isolation.
The clamshell design and screwless type for strain-relief. The design of
dismountable end cap allows you to adjust the length of housing depending
on your needs.
Adopt constant power program design and it keeps the same brightness in color
temperature adjustment.
2-CH SELV output channel with common anode.
Use only within an enclosure.

352
43
30
300
312
35
1. Brightness adjustment
N
L
N
L
W
C
N
L
0-10V CCT
W
C
0···5···10V
N
L
W
C
0-10V CCT
0-10V DIM
LM-100-24-U2A2
www.ltech-led.com
Unit: mm
Product Size
Wiring Diagram
0-10V Connection
Wire diameter: 0.75-1.5
Strip length: 8-9mm
0-10V DIM
Brightness 0···5···10V
0.1%-100%
2. Color temperature adjustment
Color temperature
0-10V CCT 0···5···10V
Color temperature
0-10V DIM
Brightness 0···5···10V
0.1%-100%
3. Adjust brightness and color temperature separately
4. Adjust brightness and color temperature simultaneously
0···5···10V
0.1%-100%
Simultaneous adjustment
0-10V
Push DIM/CCT
— 02 —
SCENE
SCENE
SCENE
Wire diameter: 0.5-0.75 (22-20AWG)
Strip length: 8-9mm
Wire diameter: 1.5-2.5 (14-22AWG)
Strip length: 6-7mm

Adopt constant power program design and it keeps the same brightness in color temperature adjustment.
Twice the rated power load can be connected to the driver. A 100W driver can connect to 100W X 2CH load
and the total power of the 2 channels will be kept within 100W.
N
N
L
L
Push DIM
N
N
L
L
Push CCT
W
C
N
L
L
Push DIM
Push CCT
N
L
W
C
N
L
N
L
W
C
W
C
Max. 100W
Max. 100W
W
-
-
+
+
C
LM-100-24-U2A2
www.ltech-led.com
Push DIM/CCT Connection
1. Brightness adjustment
2. Color temperature adjustment
3. Adjust brightness and color temperature separately
0-10V DIM
Brightness 0···5···10V
0.1%-100%
0-10V CCT
0···5···10V
Color temperature
0-10V CCT
0···5···10V
Color temperature
0-10V DIM
Brightness 0···5···10V
0.1%-100%
Push DIM
Push CCT
Dimming interface priority: 0-10V first , Push DIM/CCT next.
…
0···5···10V
0.1%-100%
0···5···10V
0.1%-100%
0···5···10V
0.1%-100%
Short press to turn off the light,
then long press the button, the
direction of CT is changed.
Short press and long press the
button again, the direction of CT
is changed again.
Four-wire LED connection
0-10V
Push DIM/CCT
— 03 —
4. Adjust brightness and color temperature simultaneously

Push DIM/CCT
DIM CCT
Applicable to brightness adjustment, color temperature adjustment and separate brightness/CT adjustment in Push DIM/CCT connection.
LM-100-24-U2A2
www.ltech-led.com
Reset switch
• On/off control: Short press.
• Stepless dimming: Long press.
• With every other long press, the brightness level goes to the opposite direction.
• Dimming memory: Go to the brightness level adjusted previously when lights
are turned on.
Reset switch
DIM/CCT
• On/off control: Short press.
• Stepless dimming and color adjustment: long press.
• With every other long press, color temperature go to the opposite direction.
• Dimming memory: Go to the brightness level adjusted previously when lights are turned on.
• Color temperature adjustment: Long press.
• With every other long press, color temperature go to the opposite direction.
• Color temperature memory: Color temperature will be the same as previously
adjusted when lights are turned on.
Applicable to simultaneous brightness and CT adjustment in Push DIM/CCT connection.
Tension plate Remove the protective housing
Push the tension plate down to fix the electric wires. Pull the housing left and right from the bottom to remove it.
Push the side plate outwards and remove the tension
plate by prying it up with a tool at the same time.
Protective Housing Application Diagram
0-10V
Push DIM/CCT
— 04 —
Installation Precautions
≥15cm
≥15cm
≥15cm ≥15cm
Please do not stack the products. The distance between two products should be ≥15cm so as not
to affect heat dissipation and the lifespan of the products.
≥15cm
Please not place the products on LED drivers. The distance between the product and the driver
should be ≥15cm so as not to affect heat dissipation and shorten the lifespan of the products.

LM-100-24-U2A2
www.ltech-led.com
Flicker Test Table Exemption assessment
(High frequency exemption)
f ≤ 8Hz
Waveform frequency of Optical output (f)
Limit Value of Modulation in Low Risk Areas
IEEE 1789 Brightness
0.1%
1%
5%
30%
40%
70%
90%
100%
10%
20%
50%
60%
80%
Marks in the right chart are tested results of different current levels.
The output frequency is 0Hz in 100% brightness and its corresponding
modulation is 0%, which could not be shown in the right chart.
IEEE 1789
100%
10%
1%
0.1%
110 100 1000 10000
3600Hz
Modulation(%)
Frequency(Hz)
High Risk
No Effect(green)
Low Risk(yellow)
Limit Value of Modulation in No Effect Areas
8Hz < f ≤ 90Hz
90Hz < f ≤ 1250Hz
f > 1250Hz
0.2
0.025 × f
0.08 × f
Limit value (%)
Exemption assessment
Waveform frequency of Optical output (f)
f ≤ 10Hz
10Hz < f ≤ 90Hz
90Hz < f ≤ 3125Hz
f > 3125Hz
0.1
0.01 × f
(0.08/2.5) × f
Limit value (%)
Exemption assessment
(High frequency exemption)
0-10V
Push DIM/CCT
— 05 —
Relationship Diagrams
Load【%】
Efficiency vs Load Power Factor Characteristic
THD VS Load Over Load Diagram
50 60 70 80 90 100
85
87
89
91
93
95
AC120V/60HZ
AC277V/60HZ
Efficiency【%】
50 60 70 80 90 100
PF
0.75
0.80
0.85
0.90
0.95
1.00
0
4
8
12
16
20
THD
24
4.16 4.35 4.55 4.80 4.90 5.00
IO【A】
-2
2
6
10
18
22
26
V0【V】
AC120V/60HZ
AC277V/60HZ
AC120V/60HZ
AC277V/60HZ
50 60 70 80 90 100
AC120V/60HZ
AC277V/60HZ
14
Load【%】
Load【%】

LM-100-24-U2A2
www.ltech-led.com
0-10V
Push DIM/CCT
— 06 —
Products shall be installed by qualified professionals.
LTECH products are non-waterproof (special models excepted). Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof enclosure.
Good heat dissipation will extend the working life of products. Please ensure good ventilation.
Please check if the working voltage used complies with the parameter requirements of products.
The diameter of wire used must be able to load the light fixtures you connect and ensure the firm wiring.
Before you power on products, please make sure all the wiring is correct in case of incorrect connection that causes damage to light fixtures.
If a fault occurs, please do not attempt to fix products by yourself. If you have any question, please contact your suppliers.
This manual is subject to changes without further notice. Product functions depend on the goods. Please feel free to contact our official distributors if you have any question.
Attentions
Warranty periods from the date of delivery：5 years.
Free repair or replacement services for quality problems are provided within warranty periods.
Warranty Agreement
Warranty exclusions below:
Beyond warranty periods.
Any artificial damage caused by high voltage, overload, or improper operations.
Products with severe physical damage.
Damage caused by natural disasters and force majeure.
Warranty labels and barcodes have been damaged.
No any contract signed by LTECH.
1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for any incidental or consequential damage unless it is within the law.
2. LTECH has the right to amend or adjust the terms of this warranty, and release in written form shall prevail.
Update Log
Version Update Content
Updated Time
A0 Original version
2021.05.31
Updated by
Liu Weili
A1 Update product silk screen
2021.12.10 Liu Weili

0-10V
Push DIM/CCT
LM-100-24-U2A2
— 01 — www.ltech.cn
体积小、重量轻; 外壳采用科思创/三星PC阻燃V0级原料
免螺丝压线翻盖设计，可拆卸端盖, 按需调节壳体长度
恒功率设计, 调节不同色温保持亮度一致
色温调节范围2700-6500K
带软启动渐亮功能, 让人眼视觉更舒适
高频豁免考核级别
调光范围0-100%, LED从0.1%开始调光
共阳极两路SELV输出通道
自动识别0-10V、1-10V输入
0-10V端口超低消耗<0.05mA
安全可靠的信号隔离设计
创新的热管理技术, 智能保护电源寿命
过温、过压、过载、短路保护, 可自动恢复
适合室内Ⅰ、Ⅱ、Ⅲ类灯具应用
高达50,000小时的额定寿命
5年保修期 (采用红宝石电容)
LED智能色温驱动器 (恒压型)
调光调色温
无频闪
IEEE 1789
Class 2
过温保护 短路保护
过载保护
V
过压保护
PUSH
0-10V
认证图标仅代表产品正在进行这一系列的认证申请，认证资质以产品实物为准。
本款驱动器适合连接电阻限流的LED灯具 (如LED灯条)。如果连接内置恒流IC限流的灯具,会产生几十倍的瞬间浪涌电流, 导致驱动器会执行过载保护(打嗝频闪)。下单时这类内置恒流IC限流的灯具需要注明 (如MR16灯杯
地埋灯、洗墙灯、恒流硬灯条等), 以便烧写特殊程序。
技术参数
输出
型号
输入
环境
保护
安规
和
电磁
规格
其他
LM-100-24-U2A2
输入对输出: 100MΩ/500VDC/25℃/70%RH
50/60Hz
调光接口
频率范围
输入电流
功率因数
Max. 1A/120Vac, 0.55A/230Vac, 0.45A/277Vac
93%
效率(Typ.)
120-277Vac
输入电压
浪涌电流
抗浪涌
漏电流
输出电压
输出功率
输出电流
输出电压范围 24Vdc±0.5Vdc
工作温度
工作湿度
储存温度/湿度
温度系数
耐振动
ta: -20~50°C tc: 85°C
20-95%RH, 无冷凝
-40~80°C, 10-95%RH
±0.03%/°C(-20~50°C)
10-500HZ, 2G 12分钟/周期, X, Y, Z轴各72分钟
调光范围 0~100%, 调光深度: 0.1%
无可视频闪/高频豁免考核级别
耐压
绝缘阻抗
输入对输出: 3750Vac
EN61000-4-2,3,4,5,6,8,11, EN61547
IEEE 1789
安全规范
电磁兼容发射
电磁兼容抗扰度
频闪测试
纹波与噪声
谐波THD
PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (满载)
120Vac@THD＜5%, 230Vac@THD＜8%, 277Vac@THD＜11% (满载)
冷启动45A/230Vac (在50%Ipeak下测试twidth=840us)
L-N: 2KV
Max. 0.5mA
Max. 4.17A
24Vdc
开关纹波≤150mV, 噪声≤500mV
Max. 100W
产品尺寸 352×43×30mm(L×W×H)
包装尺寸 355×44×33mm(L×W×H)
产品毛重 430g
输出功率范围 0-100W
过载功率限制 ≥102%
过温保护
过压保护
过载保护
短路保护
空载电压≥28V, 关闭输出, 可自动恢复
负载电流≥102%, 关闭输出, 可自动恢复
输出线路短路进入打嗝模式, 可自动恢复
0-10V(1-10V/10V PWM/RX) Push DIM/CCT
频闪级别
根据PCB温度超标情况(≥110°C), 智能调节电流输出或关闭, 可自动恢复
待机功耗 <0.5W
PWM频率 3600Hz
外箱规格 L370×W340×H93mm 20个/箱 9.4kg±5%/箱
EN55015，EN61000-3-2，EN61000-3-3 , EN61547
美国
加拿大
欧盟
美国
欧盟
UL8750
CSA C22.2 No. 250. 13
EN61347-1，EN61347-2-13，EN62384
FCC part 15
UL
CUL
CE
CE
UL
Use only within an enclosure.

单位: mm
尺寸图
连接应用图
0-10V 连接方式
352
43
30
300
312
35
www.ltech.cn
LM-100-24-U2A2
1. 亮度调节
2. 色温调节
3. 亮度和色温分别调节
4. 亮度和色温同时调节
N
L
亮度调节
0-10V DIM
0···5···10V
N
L
W
C
色温调节
0-10V CCT
N
L
色温调节
0-10V CCT
W
C
0···5···10V
亮度和色温同时调节
N
L
W
C
0-10V CCT
0-10V DIM
0···5···10V
亮度调节
0-10V DIM
0···5···10V
0···5···10V
0-10V
Push DIM/CCT
— 02 —
线径: 0.75-1.5 (20-16AWG)
剥线长度: 8-9mm
线径: 0.5-0.75 (22-20AWG)
剥线长度: 8-9mm
线径: 1.5-2.5 (14-12AWG)
剥线长度: 6-7mm
SCENE
SCENE
SCENE

www.ltech.cn
LM-100-24-U2A2
1. 亮度调节
2. 色温调节
3. 亮度和色温分别调节
4. 亮度和色温同时调节
Push DIM/CCT 连接方式
采用恒功率程序设计, 色温调节全程能保持亮度一致, 电源可连接额定功率两倍的负载。
100W电源, 可连接100WX2CH的负载, 两路总功率会保持在100W以内。
W
C
Max. 100W
Max. 100W
N
N
L
L
Push DIM
亮度调节
Push DIM
0···5···10V
N
N
L
L
Push CCT
W
C
色温调节
Push CCT
0···5···10V
N
L
L
Push DIM
Push CCT
N
L
W
C
色温调节
Push CCT
亮度调节
Push DIM
0···5···10V
0···5···10V
调光接口优先级为: 首先0-10V, 然后Push DIM/CCT
N
L
Push DIM
Push CCT
N
L
W
C
短按关灯后, 长按按键,
色温方向转换
再次短按并长按按键
色温方向将再次转换
…
0···5···10V0···5···10V0···5···10V
W
-
-
+
+
C
四线LED灯接法
0-10V
Push DIM/CCT
— 03 —

www.ltech.cn
LM-100-24-U2A2
Push DIM/CCT
DIM/CCT
• 开关控制: 短按.
• 无级调光调色: 长按.
• 短按关灯后, 长按按键, 色温向相反方向调整。
• 调光记忆: 当再次开关时, 灯光会回到先前调整的亮度水平.
DIM
• 开关控制: 短按.
• 无级调光: 长按.
• 每隔一次长按, 明暗度会向相反方向调整.
• 调光记忆: 当再次开关时, 灯光会回到先前调整的亮度水平.
CCT
• 色温调节: 长按.
• 每隔一次长按, 色温会向相反方向调整.
• 色温记忆: 当再次开关时, 灯光会回到先前调整的色温水平.
适用于Push DIM/CCT连接方式的亮度调节、色温调节及亮度与色温单独调节
适用于Push DIM/CCT连接方式的亮度与色温同时调节
复位开关
复位开关
压线板 保护盖的拆装
向下推压线板, 可固定住线。 在底部左右掰动, 即可将保护盖拆下。
向外推侧板的同时, 用工具撬即可拆下压线板。
保护盖应用图
0-10V
Push DIM/CCT
— 04 —
安装注意事项
≥15cm
≥15cm
≥15cm
≥15cm ≥15cm
请勿将产品堆叠摆放，产品与产品间隔距离应≥15cm，避免影响产品散热和使⽤寿命。 请勿将产品置于电源上⽅，与电源间隔距离应≥15cm，避免影响产品散热⽽减少使⽤寿命。

www.ltech.cn
LM-100-24-U2A2
频闪测试表
IEEE 1789
右图标识为不同电流档的测试结果。
100%亮度时输出频率为0Hz, 对应波动深度为0%, 无法在右图中示意。
免除考核 (高频豁免)
亮度
0.1%
1%
5%
30%
40%
70%
90%
100%
10%
20%
50%
60%
80%
IEEE 1789
100%
10%
1%
0.1%
110 100 1000 10000
3600Hz
Modulation(%)
Frequency(Hz)
High Risk
No Effect(green)
Low Risk(yellow)
f ≤ 8Hz
光输出波形频率 (f)
8Hz < f ≤ 90Hz
90Hz < f ≤ 1250Hz
f > 1250Hz
0.2
0.025 × f
0.08 × f
限值 (%)
f ≤ 10Hz
10Hz < f ≤ 90Hz
90Hz < f ≤ 3125Hz
f > 3125Hz
0.1
0.01 × f
(0.08/2.5) × f
低风险区域（Low Risk ) 的波动深度（Modulation）限值
无风险区域（No Effect ) 的波动深度（Modulation）限值
免除考核
光输出波形频率 (f) 限值 (%)
免除考核(高频豁免)
0-10V
Push DIM/CCT
— 05 —
关系图表
负载【%】 负载【%】
效率与负载关系图 功率因数特征图
THD与负载关系图
50 60 70 80 90 100
85
87
89
91
93
95
AC120V/60HZ
AC277V/60HZ
效率【%】
50 60 70 80
PF
0.75
0.80
0.85
0.90
0.95
1.00
0
4
8
12
16
20
THD
24
负载【%】
AC120V/60HZ
AC277V/60HZ
50 60 70 80 90 100
90 100
AC120V/60HZ
AC277V/60HZ
过载曲线
4.16 4.35 4.55 4.80 4.90 5.00
电流【A】
-2
2
6
10
18
22
26
电压【V】
AC120V/60HZ
AC277V/60HZ
14

www.ltech.cn
LM-100-24-U2A2
0-10V
Push DIM/CCT
— 06 —
请由具有专业资格的人员进行调试安装;
雷特产品 (专有型号除外) 不能防水, 需避免日晒雨淋, 如安装在户外, 请用防水箱;
良好的散热条件会延长产品的使用寿命, 请把产品安装在通风良好的环境;
请检查使用的工作电压是否符合产品的参数要求;
使用的电线直径大小必须能足够负载连接的LED灯具, 并确保接线牢固;
通电调试前, 应确保所有接线正确, 以避免因接线错误而导致灯具损坏;
如果发生故障, 请勿私自维修; 如果有疑问, 请联系供应商。
本说明书的内容如有变更, 恕不另行通知。若内容与您使用的功能有所不同, 则以实物为准。如有疑问, 欢迎向我司授权的经销商咨询。
注意事项
自出厂之日起保修服务期为5年。
在保修服务期内出现产品质量问题雷特将给予免费修理或更换服务。
保修条例
非保修条例:
属下列情况不在免费保修或更换服务范围之内:
已经超出保修服务期;
过高电压、超负载、操作不当等人为造成的损坏;
产品外形严重损坏或变形;
自然灾害以及人力不可抗拒原因造成的损坏;
产品保修标签和产品唯一条形码损坏;
无雷特签订的合同或发票凭证。
1. 修理或更换是雷特对客户的唯一补救措施。雷特不承担任何附带引起的损害赔偿责任, 除非在适用法律范围之内。
2. 雷特享有修正或调整本保修条款的权利, 并以书面形式发布为准。
更新日志
版本 更改内容
更改日期
A0 正稿
2021.03.25
更改人
刘伟丽
A1 更新产品丝印
2021.12.10 刘伟丽
