Ltech TY-300-D2Z1 User manual

Tuya Zigbee
<0.28A
<0.5W
2
ta: -30~55°C
20~95%RH, non-condensing
-40~80°C, 10~95%RH
+15mA/-25mA
94%
100~300mA
(Default is 300mA and it can be set to another voltage based on customers’ lights.)
Zigbee
TY-300-D2Z1
10~42Vdc (Default is 36 Vdc and it can be set to another voltage based on customers’ lights.)
1W~12.6W (Default is 12.6W)
48Vdc±5% (No polarity)
0~100%, down to 0.1%
- Support iOS or Android devices to control .
- No input polarity .
- DC to DC constant current output .
- Ultra-small size , suitable for STUCCHI standard housings .
- Magnetic installation is quiet without high-frequency sound .
- Smooth dimming curves without flicker .
- Short circuit, overload and anti-reverse protection.
- 5 year warranty.
3.5W~25.2W (Default is 25.2W)
±5%
<0.57A
92%
TY-600-D2Z1
TY-300-D2Z1
TY-600-D2Z1
1
Flicker-free
IEEE 1789
Zigbee LED Driver
Special for magnetic & linear lamp
Suitable for STUCCHI standard housings
- 9519-166-K
- B 9519-166-K/W
No noise, no flicker Installation guide
OUTPUT
MODEL
INPUT
ENVIRONMENT
PROTECTION
Output Voltage
Output Power
Output Current
Channel
Working Temperature
Current Accuracy
Overload Protection
Dimming Range
Storage Temperature
Working Humidity
Short Circuit Protection
The load voltage is out of range,the current drops until the power is turned on again.
Close output and automatically recover once the fault is removed.
Input Anti -reverse Protection No input polarity , able to output normally.
Efficiency(Typ)
Standby Power
Dimming Interface
Input Voltage
Input Current
350~600mA
(Default is 600mA and it can be set to another voltage based on customers’ lights.)
|
Strategic Partnership
DIM/CT
www.ltech-led.com
Technical Specs

2
V1
V2
C LED+
65
13.5
13
W
Tuya Zigbee
Terminal Description
Main view
PCB board
Side view
Unit:mm
Dimensions
Power supply
Lamp terminal
Input voltage
（No polarity）
LED lamp Connection
www.ltech-led.com

L
N
48Vdc
220V/110Vac
…
3
48Vdc 48Vdc
Tuya Zigbee
Wiring Diagram
Power
LED lamp LED lamp LED lamp
1.Register an account
App Operating Instructions
Tuya Smart App is compatible with iOS and Android systems. Scan the QR code below with you mobile phone and follow the prompts to complete the
app installation. After installation being completed, you can log in or register an account.
App download
APP support
2. Paring instructions
A new user clicks "Me" →”Home Management"→"createa home ", give a name to your home and confirm your home location, then add the rooms
you need. Click “Add Device” - “Auto Scan” and enable permissions for automatically scanning Bluetooth/Wi-Fi/Zigbee/wired devices. Follow the
prompts to add the device (Ensure that the device is ready for network connection).
www.ltech-led.com

4
Tuya Zigbee
3. Lighting control settings
After paring up your device, click the device you add and adjust to your desired lighting status by brightness changing and color temperature adjustment.
In “Settings”, there are also lighting alarm clock (Tuya Zigbee Gateway needs to be added) and countdown functions.
4.2 Automation settings: After adding Tuya Zigbee Gateway , you’ll be able to control the lighting remotely by clicking ”Automation” in the “Smart” menu.
In “Automation”, set up conditions from weather, location and timing to other device status so as to trigger the lighting effects you preset and realize the
lighting automation.
4. Remote control and automation
4.1 Remote control: Add Tuya Zigbee Gateway by search , and follow the prompts to configure the gateway to the network. After configuring the
network, access the gateway interface and click "Add to the list" or "Search for new devices" to add the device to the gateway, and then the device
can be controlled remotely.
www.ltech-led.com

5
Tuya Zigbee
Reset The Device (Reset to factory defaults)
When the driver is power-on, turn it off and after 5s turn it on. After 2s, turn it off again. Repeat the same operation 5 times and then turn on the driver again. When the lamp is
breathing, reset the device successfully.
Turn it on 2s
Turn it off 5s (Repeat 5 times)
Turn it off Turn it on ......
5s 2s
Under the driver being power-on
29.7×22×11.7mm（L×W×H）
Packaging Specifications
Model
Carton Dimension
Quantity
Weight
240 PCS/Carton
0.008 kg/PC； 2.72 kg/Carton
Packaging Image
Carton Packaging
Transportation and Storage
1.Transportation
Products can be shipped via vehicles, boats and planes.During transportation, products should be protected from rain and sun. Please avoid severe shock and
vibration during the loading and unloading process.
2.Storage
The storage conditions should comply with the Class I Environment Standards. The products that have been stored for more than six months are recommended
to be re-inspected and can be used only after they have been qualified.
TY-300-D2Z1、TY-600-D2Z1
www.ltech-led.com

6
Tuya Zigbee
Attentions
Products shall be installed by qualified professionals.
Products are non-waterproof (special models excepted). Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water
proof enclosure.
Good heat dissipation will extend the working life of products. Please ensure good ventilation.
Please check if the working voltage used complies with the parameter requirements of products.
The diameter of wire used must be able to load the light fixtures you connect and ensure the firm wiring.
This manual is subject to changes without further notice. Product functions depend on the goods. Please feel free to contact our official distributors if you
have any question.
Before you power on products, please make sure all the wiring is correct in case of incorrect connection that causes damage to light fixtures.
If a fault occurs, please do not attempt to fix products by yourself. If you have any question, please contact your suppliers.
Warranty Agreement
Warranty exclusions below:
No any contract signed by LTECH.
Warranty labels and barcodes have been damaged.
Damage caused by natural disasters and force majeure.
Products with severe physical damage.
Beyond warranty periods.
Warranty periods from the date of delivery : 5 years.
Free repair or replacement services for quality problems are provided within warranty periods.
Any artificial damage caused by high voltage, overload, or improper operations.
1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for any incidental or consequential damage unless it is within the law.
2. LTECH has the right to amend or adjust the terms of this warranty, and release in written form shall prevail.
Update Log
Version Update Content
Updated Time
A0 Original version
2021.09.28
Updated by
Xu Shujun
