Ltech DX Series User manual

1
warranty
5 years
DX62 Color Temperature Knob Panel
Color Temperature Knob Panel
Input Voltage:
Output Signal:
Working Temp.:
Dimensions:
Package Size:
Weight(G.W.):
100~240Vac
RF 2.4GHz, DMX512
-30℃~55℃
L86×W86×H50(mm)
L106×W106×H60(mm)
235g
DX62
R4-CC
Input Voltage:
Output Voltage:
Output Current:
Output Power:
Wireless Signal:
Working Temp.:
Dimensions:
Package Size:
Weight(G.W.):
12~48Vdc
3~46Vdc
CC 350/700/1050mA×4CH
1.05W~48.3W×4CH Max 193.2W
2.4GHz
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
165g
R4-5A CV Receiver (receiver is sold separately)
Input Voltage:
Current Load:
Output Power:
Wireless Signal:
Working Temp.:
Dimensions:
Package Size:
Weight(G.W.):
5~24Vdc
5A × 4CH Max. 20A
Max.100W/240W/480W(5V/12V/24V)
2.4GHz
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
150g
CC Receiver (receiver is sold separately)
1. Technical Specs:

2
DX62 Color Temperature Knob Panel
86mm
86mm
25mm
50mm
44mm
30mm
170mm
175mm
2
2. Product Size:
Knob Panel
R4-5A/R4-CC Receiver
3
DX62 Color Temperature Knob Panel
3. Installation Instruction:
Install Uninstall
4. Key Functions: 5. Terminals:
100-240Vac
Power Input
DMX Signal
Output
Short press: On/Off.
Long press: Switch CT/dimming mode.
Spin: Adjust CT / brightness.
When powered off, long press the knob for
5 seconds to turn on (off) the key tone.
www.ltech-led.com

5 4
DX62 Color Temperature Knob PanelDX62 Color Temperature Knob Panel
6. Operating Instruction for Receiver:
7. Match / Clear code between knob panel & receivers
Clear Code:
Match Code: Short press “ID learning button” on the R4-5A/R4-CC receiver, the running light
keeps on. Then press or spin the knob on the DX62 panel, the buzzer long beep,
match successfully.
Long press “ID learning button” on the R4-5A/R4-CC receiver for 5S, the buzzer
long beep, deactivate the matching successfully.
8. Wireless Wiring:
RUN
RUN
LED Lamp
Connection
LED Lamp
Connection
Current Selection
Switch
The Running Light
The Running Light
ID Learning Button
ID Learning Button
5~24Vdc
Power Input
12~48Vdc
Power Input
(Operation Table）
5~24Vdc
CV power supply
5~24Vdc
CV power supply
5~24Vdc
CV power supply
5~24Vdc
CV power supply
White/Warm White Strip
White/Warm White Strip
White/Warm White Strip
White/Warm White Strip
Receiver
Receiver
Receiver
Receiver
100-240Vac
LN
…
w
ww
w
ww
w
ww
w
ww

6
DX62 Color Temperature Knob Panel
9. DMX :Wiring
…… …… ……
7
DX62 Color Temperature Knob Panel
10. System Connection Diagram:
Update Time: 2016.10.21
www.ltech-led.com
Please refer to the relevant product for detailed information.manual
M12
Phone/Pad Wireless router
WiFi-104
R4-5A/R4-CC
DX62
V2
12~24Vdc
CV power supply
12~24Vdc
CV power supply
12~24Vdc
CV power supply
12~24Vdc
CV power supply
White/Warm White Strip
White/Warm White Strip
White/Warm White Strip
White/Warm White Strip
100-240Vac
LN
DMX
DMX Address=1
DMX Address=1
DMX Address=1
DMX Address=1
w
ww
w
ww
w
ww
w
ww
DMX
Decoder
DMX
Decoder
DMX
Decoder
DMX
Decoder
