Ltech LT-800 User manual

LTECH
LTECH
LT-800 DMX controller
LT-800 DMX controller
1
2
[e-mail]
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD.
Tel: [phone]
Fax: [phone]
WWW.LTECHONLINE.COM
LT-800
Working Voltage
DC12 (with an adapter to convert AC100-240V to DC12V)
Power Consumption
<2W
Output Signal
DMX512/1990
Output Loop
1 Port
Transmission Speed
250Kbps
Function Mode
39 modes
Control Quantity
51 2 DM X channels ( 17 0 pixels)
Working Temperature
-30℃~65℃
Product Dimensions
L163×W108×H40mm
Package Dimensions
L260×W132×H46mm
Weight(G.W)
760g
LT-800
DMX controller 2. Function
features
1. Wit h LCD sc reen , eas y to opera t e in showin g all functions.
2. Buil t-i n perpetua l calenda r, real -tim e displa y syste m c l oc k , can be set up to pla y diffe ren t program s in any time,
Monda y to Sun da y or holiday.
3. 30 lightin g mode s . Such as, 7 colo r, skippin g synch ronism , smoot h synch ronism , colo r flo w, colo r chasing , color
smoot h and flo w and Meteo r showe r trailing , etc.
4. Multile vel changi n g spee d , brightnes s and R GB g re y sca l e adj ustmen t fo r you r choices.
5. Feel fre e to de fi n e man y c hangi n g m ode s i n to a step , 8 inde pend en t cy cl e s t ep s maximum.
6. Outpu t wit h internationa l Standa rd signa l DMX512/1990 , can cont ro l 512 DM X channel s (17 0 ful l colo r RG B pixels)
7. Supp o r t diffe ren t outpu t p o r ts li k e standa r d XLR - 3 , R J4 5 and Eu r opea n t erminals . Etc.
8. wit h the fu nction s of an ti - i n t e r fe renc e and au t omati c b rea k dow n r eco v e r y.
3. Construction
drawing
163mm
LCD screen 153mm
ISO9001:2008
R o H S
COMPLIAN T
warranty
3 years
L T - 800 W E L C O M E
2 0 1 2 - 0 1 - 0 1 12
:
00
LT-800 DMX512 controller is the output signal of international standard DMX/1990.It not only can control all the LED lights in
the market as long as can receive the standard DMX signal, but also can work with our DMX Decoder to control general LED
lights without DMX512.
LT-800 DMX512 Controller is easy to operate with a LCD screen. Available with wireless control and keying control on the
changing modes, speed and brightness, automatic timing and more than 30 modes for your choices, Supporting pause in
Changing modes and very easy to keep the specific color.
108mm
1. Product parameter
HOTKEY
Upper surface Control button
Front
Mode+/Mode
33mm
40mm
Speed +/Speed –
BRT +/ BRT –
Setup 85mm
Powe r
switc h
Power
input Infrared
interface Manufacturers
spare USB
interface
Green
terminal RJ45 interface XLR-3
DIY Scene
Provide three kinds of interface,
connect one of them
IR remote control

LTECH
LTECH
LT-800 DMX controller
LT-800 DMX controller
3
4
[e-mail]
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD.
Tel: [phone]
Fax: [phone]
WWW.LTECHONLINE.COM
No.
DisplayInstruction
Instruction
No.
DisplayInstruction
Instruction
1
BL ACK
16
WHIT E FADE
SPEED/BRIGHTNESS
ADJUSTMENT
2
STATIC RED
SPEED/BRIGHTNESS
ADJUSTMENT
17
COLOR FADE
SPEED/BRIGHTNESS
ADJUSTMENT
3
STATIC GREEN
SPEED/BRIGHTNESS
ADJUSTMENT
18
COLOR COVER
SPEED/BRIGHTNESS
ADJUSTMENT
4
STATIC BLUE
SPEED/BRIGHTNESS
ADJUSTMENT
19
COLOR SPLIT
SPEED/BRIGHTNESS
ADJUSTMENT
5
STATIC YELLOW
SPEED/BRIGHTNESS
ADJUSTMENT
20
COLOR CLOSE
SPEED/BRIGHTNESS
ADJUSTMENT
6
STATIC PURPLE
SPEED/BRIGHTNESS
ADJUSTMENT
21
RGB CHAS E F
SPEED/BRIGHTNESS
ADJUSTMENT
7
STATIC CYAN
SPEED/BRIGHTNESS
ADJUSTMENT
22
RGB CHAS E R
SPEED/BRIGHTNESS
ADJUSTMENT
8
STATIC WHITE
SPEED/BRIGHTNESS
ADJUSTMENT
23
COLOR CHAS E F
SPEED/BRIGHTNESS
ADJUSTMENT
9
RGB CHANGE
SPEED/BRIGHTNESS
ADJUSTMENT
24
COLOR CHAS E R
SPEED/BRIGHTNESS
ADJUSTMENT
10
COLOR CHANGE
SPEED/BRIGHTNESS
ADJUSTMENT
25
WHIT E METE O F
SPEED/BRIGHTNESS
ADJUSTMENT
11
RG SMOOTH
SPEED/BRIGHTNESS
ADJUSTMENT
26
WHIT E METE O R
SPEED/BRIGHTNESS
ADJUSTMENT
12
RB SMOOTH
SPEED/BRIGHTNESS
ADJUSTMENT
27
COLOR METEO F
SPEED/BRIGHTNESS
ADJUSTMENT
13
GB SMOOTH
SPEED/BRIGHTNESS
ADJUSTMENT
28
COLOR METEO R
SPEED/BRIGHTNESS
ADJUSTMENT
14
RGB SMOOTH
SPEED/BRIGHTNESS
ADJUSTMENT
29
COLOR FLOW F
SPEED/BRIGHTNESS
ADJUSTMENT
15
COLOR SMOOTH
SPEED/BRIGHTNESS
ADJUSTMENT
30
COLOR FLOW R
SPEED/BRIGHTNESS
ADJUSTMENT
P I X E L NUMBE R
:
03 2
RANG E
:
4 - 1 7 0
RU N T I M E S
:
2 55
000
=
NO T R UNN I N G
RG B B R I G H T A D J
R 2 55
G 2 55
B 2 55
No.
Submenu function
(Press MODE+/-
to change menu below)
LCD display condition
Settin g methods
1
PIXEL QUANTITY
ADJUSTMENT
Press BRT+/- increase or
decrease pixel quantity
2
OPERATION TIMES
ADJUSTMENT
Press BRT+/- increase or decrease
operation times (only work between
mode 31-38)
3
RGB OUTPUT GREY
LEVELADJUSTMENT
Pr es s BRT+/ - to adjus t each RGB
level, press SPEED+/ - to
chang e R, G, or B
4
MODE RECOVER
DEFAULT
LOA D DEFAUL T S E T
PRES S BRT + - K E Y
Press BRT+/- to recove r dafault
4. Operating
instructions
8 function keys on the controller, MODE+/MODE-(mode),SPEED+/SPEED-(speed),
BRT+/BRT-(brightness),SETUP(setup),HOTKEY(function)
Following form is general change functional modes.
Note: For mode 2-8, static color will be showed when minimum speed 1 and maximum speed 8,
and speed 2-7 is strobe speed.
1. Basic Control
1) Pressing MODE+/MODE- button, to switch general change modes1-30, automatic change
modes 31-38 and automatic timing run change modes 39.
01 B L A C K
:
30 COLO R F L O W R
SPEE D
:
8 BR T
:
8
(general change modes1-30 )
2 0 1 2 - 0 1 - 0 1 14 17
31 PLAY1 O FF
2 0 1 2 - 0 1 - 0 1 12
:
00
38 PLAY8 O FF
2 0 1 2 - 0 1 - 0 1 12
:
00
(Automatic combination change modes
31-38)
39 P L A Y 1 - P L A Y 8
2 0 1 2 - 0 1 - 0 1 12
:
00
(automatic timing run change modes 39)
At status of Mode 1-30, press button SETUP for 3 seconds to enter submenu,
see the form below.
2) Under the general change modes, pressing SPEED+/SPEED- button to adjust the speed of the change
modes; Pressing BRT+/BRT- button to adjust the brightness of the change modes.
3) Pressing SETUP button for 3 seconds, then enter into the submenu setting surface of general change
modes or automatic change modes .Pressing MODE+/MODE- button to switch the submenu page.
Pressing SPEED+/SPEED- button to sway the configuration item .Pressing BRT+/BRT- to change the
parameter values of the configuration item. Pressing SETUP button to Exit the submenu of setting surface.
4) Pressing HOTKEY button for 3 seconds, enter into the submenu of address operation, pressing HOTKEY
to Exit the submenu of address operation.
2. Submenu operational approach of general change modes 1-30
01 B L A C K
2 0 1 2 - 0 1 - 0 1 14 :17 30
COLO R F L O W R
SPEE D
:
8 BR T
:
8
(general change modes1-30 )
Finish each parameter setting, then press button SETUP to exit.

LTECH
LTECH
LT-800 DMX controller
LT-800 DMX controller
5
6
[e-mail]
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD.
Tel: [phone]
Fax: [phone]
WWW.LTECHONLINE.COM
31 P L AY 1
O F F
OPEN 1 SAV E 1
31 PLAY 1 O FF
O P EN 1
SAV E 1
RU N W EE K
:
M T W TF SS
T I M E
:
18
:
00 - 0 6
:
00
DATE0 1
:
0 1 0 1 - 0 1 03
T I M E
:
00
:
00 - 00
:
00
RG B ORDE R
:
R G B
No.
1
setting switch state
Press “BRT+/-”to set the switch state,
Select “ON” to 39 automatic
circle modes
store the times of operating
(it is convenient to set basic
on the last time setting)
31 PLAY 1 O FF
OPEN 1 SAV E 1
Press ” SPEED+/- ” enter into “OPEN”
(turn out the operation times of 1-30
modes ), then Press “BRT+” to confirm.
save the setting about the
operation time
Press “SPEED+/-” enter into “SAVE”
(save the setting about the operation
time), Press “BRT+/-” to confirm.
2
Setting operation week
Press “SPEED+/-” then you can see the
“MTWTFSS”(Monday to Sunday) and
00:00 00:00(time),press “BRT+/-” to
choose(if you do not choose the Monday
to Sunday, the screen will appear _ the
one mark)
3
Operate time and date 1
Press “SPEED+/-” you can press
“BRT+/-” choose 0101-0103(date) and
00:00-00:00(time) to adjust date and
time.
4
Operate time and date 2
Press “SPEED+/-” you can press
“BRT+/-” choose 0101-0103(date) and
00:00-00:00(time) to adjust date and
time.
5
Operate time and date 3
Press “SPEED+/-” you can press
“BRT+/-” choose 0101-0103(date) and
00:00-00:00(time) to adjust date and
time.
6
System clock setting
D AT E / T I M E S E T U P
20 1 2 - 0 1 - 0 1 12
:
00
Press “SPEED+/-” to choose
“2012-01 01”(date), 12:00(time),
press ”BRT+/-” to adjust date and time.
7
RGB sequence setting
Press “BRT+/-” to adjust the RGB
brightness sequence, for example:
RGB, RBG, GRB, GBR, BRG, BG.
8
Modes restore default
value
LOA D DEFAUL T S E T
PRES S BRT + - K E Y
Press “BRT+/-” restore the
automatic default value.
DMX spot light
3. Sub Menu of Automatic change modes 31-38 4. Automatic timing run mode 39
When set to the 39th mode, according to the preset switch condition and running time of
automatic change modes 31-38 to run the corresponding mode. The submenu only has the
31 PLAY1 O FF
2 0 1 2 - 0 1 - 0 1 12
:
00
38 PLAY8 O FF
2 0 1 2 - 0 1 - 0 1 12
:
00
(Automatic combination change
modes 31-38)
items that restore to default status (Please Carefully Choose this item)
When you in the situation of 31-38 modes, press set up key for 3 seconds entering into the
Submenu, such as below: 5. Connection
schemes
1. Connect to the LED Lamps with DMX chip inside
adap t e r
AC100 -240V
DMXsignal output
connect to the power supply
adap t e r
AC100 -240V
DMXsignal output
DMXwall washe r DMXwall washe r
DATE0 1
:
0 1 0 1 - 0 1 03
T I M E
:
00
:
00 - 00
:
00
connect to the power supply
DATE0 1
:
0 1 0 1 - 0 1 03
T I M E
:
00
:
00 - 00
:
00
adap t e r
AC100 -240V
DMXsignal output
LED DMX digital tube LED DMX digital tube
connect to the power supply
Finish each parameter setting, then press button SETUP to exit. 【Note】please confirm the LED lamp you connected can receive standard DMX512 signal, otherwise, it can’t work properly

LT-800 DMX controller
LT-800 DMX controller
7
8
DMX signal input
Outpu t
Input Outpu t
Input Outpu t
Input Outpu t
IN RI R R
104 ROUT IN RI R
R
104 ROUT
RS
RS
+VC
BRG
+VC
BRG
+12V GND C I DI
+12V +12V GND
GND DG N G
DGNG
DO D I
+12V GND
DGNG
DO
CI RI UI
CI RI UI
2. connect to the DMX driver
ad a p t e r
AC100-240V
DMX signal output
powe r
DMX-PW M CV driver
3AX3CH
power
supply
DMX-PW M CC driver
DC12V-DC48V
350mAx3CH
power
supply
DMX-SPI signal dr iver
512CHANNEL
power
supply
DMX-SPI signal dr iver
DC12V-24V
512CHANNEL
AC D C
L N
DC12V
CV PW M outp ut AC DC
L N
DC48 V CC PW M outp ut
AC DC
L N
DC12 V
SPI s igna l outpu t
AC DC
L N
电源输入
DC5V -24V
GND SPI s ignal ou tput
LED SMD R GB strip hi –power p rojection lamp
511
471
511
471
511
471
471
LD P6 8 0 3 dr i vi n g IC L ED s tr i p
( DA T A ,C L K t w o s ig na l c a b l es )
GND
GND TM1 809 dri vin g I C LED str ip
511
471
511
471
511
471
471
RGBGND
5. Attention
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3. Good heat dissipationwill prolong the working life of the controller. Please ensure goodventilation.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connectorto avoid the accidents due to overheatand
poor contact on the wire.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
6. Warranty Agreement
1. We provide lifelong technical assistance with this product:
A 3 year warranty is given from the date of purchase. The warranty is for free repair or replacement and covers
manufacturing faults only.
For faults beyond the 3 year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Ltech shall not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by Ltech only.
★This manual only applies to this model. Ltech reserves the right to make changes without prior notice.
