Lumineux Leighton 14W User manual

READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
Leighton
Bollards
14W & 24W
Technical Helpline: [phone]
www.lumineux.co.uk
Leighton
Bollard
Ground Fixing - Option 1
Screw all 3 anchors provided into the base
 xing plate
Concrete  xing plate into ground ensuring
supply cable is directed through the
centre hole
Secure the base using M8 nuts provided
Ground Fixing - Option 2
Direct cable through centre hole of base plate
Mark and drill holes as required
Secure using suitable M8 Anchor bolts or resin
 xings (not supplied)
INSTALLATION INSTRUCTIONS
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
• Light Head / Post
• Instruction Manual
• Post Mount Kit (with Post)
• Fixing Kit (with Post)
TOOLS REQUIRED
BOX CONTENTS
• Drill
• Screwdriver
• Cable
This lighting  xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
luminaire to con rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the  xture
or any of its components.
IP66
Warranty
5 YR
Lm/W
80
IK10 110º
FF
A
G
GROUND FIXING - (OPTION 1)
Hole diameter Ø30- 55mm
Suggested concrete size:
250mm x 250mm x 300mm
GROUND FIXING - (OPTION 2)
M8 Anchor bolts
(not supplied)
Fitting the Head
to the Post - See overleaf

Leighton Bollards
Technical Helpline: [phone]
LEIGHTON BOLLARD DIMENSIONS
This luminaire is warranted for a
period of 5 years from the date of
purchase**. The warranty could be
invalidated should the light tting
not be installed according to these
instructions, outside the scope of
the specication or the product
has been altered or tampered with
in any way. Please see website for
terms and conditions.
Standard -30 to +50ºC
DISPOSAL
WARRANTY
PRODUCT TEMP SPECIFICATION
Revision 1.0 - September 2022
Disassembly instructions for end of
life disposal available on website.
Disposal of Electronic Equipment
WEEE Directive 2002/96/EC This
product falls within the scope of
the Waste Electrical & Electronic
Equipment Directive (WEEE), which
means the product should not be
disposed of as normal household
waste. Please recycle where
facilities exist or check with your
Local Authority. RoHS – All
components and materials used in
this product are RoHS 2002/95/EC
compliant.
Specications may change from time
to time. The information contained
in this leaet is for guidance only
and should not be considered as
always accurate and should be
treated as not representative.
This product contains a light source of energy efciency Class F.
** Please see our website for more detailed information on warranty.
Total height:
Small Bollard = 500mm
Large Bollard = 900mm
HEAD FIXING
on
off
Part No. Description Watts Diameter W (mm) H (mm) Weight
430690 Leighton Bollard Head 14W 165 165 145 5.2Kg
inc post
430691 Leighton Bollard Head 24W 165 165 145 7.2Kg
inc post
Part No. Description Watts Diameter W (mm) H (mm) Weight
430688 Leighton Bollard Post 500mm - 165 165 355 -
430689 Leighton Bollard Post 900mm -165 165 755 -
H
H
W
W
Diameter
Diameter
Head Fixing
1. Secure the head to the post
using xings provided
2. Wire as per diagram ensuring
a suitable connection method
and or junction box is used
3. Secure the post to base plate
using the screws provided.
Switch on mains power
Electrical connection wiring
LIVE (L) = Brown
NEUTRAL = Blue
EARTH = Green/Yellow
1 2 3
