Lumineux Redbrook 421065 User manual

Redbrook
Emergency
Exit Box
READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualied electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
• Light Fitting
• Instruction Manual
• Fixing Kit
5W
Technical Helpline: [phone]
www.lumineux.co.uk
1 2 3
5
on
off
4
Redbrook
Emergency
1. Isolate mains supply
2. Unscrew side panel and remove legend screen
3. Place housing to wall and mark mounting positions
 andxusingadequatewallplugsandscrews
as shown
4. Feed mains input cable through knockout you
desire as show
5. Power on mains supply when deemed safe
TOOLS REQUIRED
BOX CONTENTS
• Drill
• Screwdriver
• Cable
INSTALLATION INSTRUCTIONS
Thislightingxturehasbeenproperly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
luminairetoconrmthereisno
damage. DO NOT INSTALL if any
damagehasoccurredtothexture
or any of its components.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
on
off
Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
IP20
Warranty
5 YR
Battery
Warranty
2 YR
6000K
GG
A
G
Mounting positions
Side screws
L - LIVE (SW) = Brown
N - NEUTRAL = Blue
L1 - PERMANENT LIVE (PL) = Black
- EARTH = Green/Yellow

ROUTINE TEST RECORD
Type Test Year 1 Year 2 Year 3 Year 4 Year 5
Signed Date Signed Date Signed Date Signed Date Signed Date
Functional 1
Functional 2
Functional 3
Functional 4
Functional 5
Functional 6
Functional 7
Functional 8
Functional 9
Functional 10
Functional 11
3hr Duration 12
Installation Engineers Contact Details: Luminaire Reference / Location
Name: Tel:
Luminaire Details: Full Recharge Duration 24 Hours Emergency Duration 3 Hours Lamp Type LED
Redbrook Emergency Exit Box
This luminaire is warranted for a
period of 5 years from the date of
purchase**. The backup battery
pack in the emergency version
is warranted for a period of 24
months. The warranty could be
invalidatedshouldthelighttting
not be installed according to these
instructions, outside the scope of
thespecicationortheproduct
has been altered or tampered with
in any way. Please see website for
terms and conditions.
Emergency 0º to +30ºC
1. Connect incoming earth cable to ‘Earth’ terminal on connector block.
2. Connect incoming neutral cable to ‘Neutral’ terminal on connector block.
3. For the emergency unit to work correctly, please ensure that an
uninterrupted permanent live feed is present and is connected directly
to the ‘Permanent Live’ terminal of the mains terminal block. Please
ensure there are no switches, PIRs etc within the permanent live feed,
constant switching of the emergency pack could result in premature
battery failure.
4. Connect incoming switched live cable to the terminal marked
“Switched Live”
NOTE: If there is no switch live feed and the unit has a microwave sensor,
simply bridge across from the “Permanent Live” to the Switch Live” on the
mains terminal block.
5. Thereshouldbealooseyingleadconnectedtothebattery.Thisneeds
 tobeattachedtotheyingleadfromtheemergencycontrolunit.
6. Following power up the green LED indicator should illuminate to indicate
charging. If power to the unit is disrupted or isolated, the unit indicating
green LED will switch off, triggering the emergency LEDs to illuminate.
7.Pleaseallow24hourschargebeforerstemergencytest.
Technical Helpline: [phone]
Wiring instructions for units equipped
an with EMERGENCY function
DISPOSAL
WARRANTY
PRODUCT TEMP SPECIFICATION
REDBROOK EMERGENCY EXIT BOX DIMENSIONS
Emergency lighting luminaries must be installed and maintained in
accordance with the emergency lighting standard BS 5266-1
Revision 2 - September 2022
Disassemble instructions for end of
life disposal available on website.
DisposalofElectronicEquipment
WEEE Directive 2002/96/EC This
product falls within the scope of
the Waste Electrical & Electronic
EquipmentDirective(WEEE),which
means the product should not be
disposed of as normal household
waste. Please recycle where
facilities exist or check with your
Local Authority. RoHS – All
components and materials used in
this product are RoHS 2002/95/EC
compliant.
Specicationsmaychangefromtime
to time. The information contained
inthisleaetisforguidanceonly
and should not be considered as
always accurate and should be
treated as not representative.
** Please see our website for more detailed information on warranty.
ThisproductcontainsalightsourceofenergyefciencyClassG.
L H
Part No. Description Watts L(mm) W (mm) H (mm) Weight
421065 Redbrook Emergency
Exit Box 5W 390 190 60 0.92Kg
W
