Lumineux Wraysbury User manual

READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
• Light Fitting
• Instruction Manual
• LED Driver
Wraysbury
600 x 600
Panel
36W Panel
Technical Helpline: [phone]
www.lumineux.co.uk
Wraysbury
Panel
TOOLS REQUIRED
BOX CONTENTS
• Screwdriver
• Cable
This lighting  xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
luminaire to con rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the  xture
or any of its components:
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
2
1
54
3
INSTALLATION INSTRUCTIONS
IP40
Warranty
5 YR
Flicker
Free
Hours
50,000
120º
3000K 4000K 6000K
Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
EE
A
G
1. Isolate the circuit
2. Connect the driver cable to the mains as per
image (1). (Terminal block not included).
For emergency, see overleaf.
3. Connect the LED driver to the panel using the
Twist-N-Lock jack connector
4. CCT models only: Select the desired colour
temperature using the in-line switch
5. Fit the panel into desired location
6. Re-connect the mains supply
on
off
on
off
CAUTION
Do not hot plug when live.
Electrical connection wiring
LIVE (L) = Brown
NEUTRAL (N) = Blue

ROUTINE TEST RECORD
Type Test Year 1 Year 2 Year 3 Year 4 Year 5
Signed Date Signed Date Signed Date Signed Date Signed Date
Functional 1
Functional 2
Functional 3
Functional 4
Functional 5
Functional 6
Functional 7
Functional 8
Functional 9
Functional 10
Functional 11
3hr Duration 12
Installation Engineers Contact Details: Luminaire Reference / Location
Name: Tel:
Luminaire Details: Full Recharge Duration 24 Hours Emergency Duration 3 Hours Lamp Type LED
Wraysbury 600 x 600 Panel
Technical Helpline: [phone]
Part No. Description Watts L(mm) W(mm) H(mm) Weight
430057 Wraysbury 600 x 600
TP(b) - 4000K 36W 595 595 38 2.17Kg
430059 Wraysbury 600 x 600
TP(b) - 6000K 36W 595 595 38 2.17Kg
430115 Wraysbury 600 x 600
TP(a) - 3CCT 36W 595 595 38 2.17Kg
WRAYSBURY DIMENSIONS
L (mm)
H (mm)W (mm)
1. The installation of an emergency tting MUST BE
CONNECTED AS SHOWN in diagrams below.
2. For the emergency unit to operate correctly the permanent
live feed must not be interrupted. Note: Ensure no lighting
controls are on the permanent Live feed, such as PIR’s or
SWITCHES, failing to observe this will reduce the batteries
lifetime of the emergency pack considerably.
3. After switching on an emergency equipped unit, the LED
indicator should illuminate this is to indicate battery
charging.
4. Should power to an emergency equipped unit be
disrupted or isolated, the indicating LED will switch off,
triggering the emergency function illuminating the LED’s
5. The backup battery must be charged for 24 hours before
a full duration test.
Wiring instructions for units equipped
an with EMERGENCY function
If the LED Driver & Downlight jack leads do not match the gender as in
diagram, please use provided gender changing leads to correct.
Emergency lighting luminaries must be installed and
maintained in accordance with the emergency lighting
standard BS 5266-1
This product contains a light source of energy efciency Class E.
The self-test version of emergency is tted with control gear that will carry out
periodic functional tests every 1 month and full duration test every 12 months.
Self-Test EMERGENCY function
Fault/Test/Status Reason
Battery fully charged
and operational Standard daily use
Battery Charging Initial charge /
battery topping up
Battery Failure Battery is disconnected or
damaged/faulty
Duration Test Failure Maintenance check required
by qualied engineer
Automatic Testing - Function
5 minute test (Every 30 days)
Self-testing in
operation
Automatic Testing -
Duration test is 3 hours
(every 12 months)
Self-testing in
operation
Charge Indicator Status
Battery Fully Charged
and Operational
Battery Charging
Auto Test 5 Min
(every 30 days)
Auto Test 3 Hours
(every 12 months)
Duration Test Failure
1 Sec ON
1 Sec OFF
3 Sec ON
3 Sec OFF
3 Sec ON
1 Sec OFF
0.5 Sec ON
0.5 Sec OFF
Battery
Disconnected/Faulty
This luminaire is warranted for a
period of 5 years from the date of
purchase**. The backup battery
pack in the emergency version
is warranted for a period of 12
months. The warranty could be
invalidated should the light tting
not be installed according to these
instructions, outside the scope of
the specication or the product
has been altered or tampered with
in any way. Please see website for
terms and conditions.
Standard 0 to +40ºC
Emergency 0 to +30ºC
DISPOSAL
WARRANTY
PRODUCT TEMP SPECIFICATION
Revision 2 - February 2022
The light source of this unit is not
replaceable; when the light source
reaches its end of life the whole
luminaire shall be replaced.
Disassemble instructions for end of
life disposal available on website.
Disposal of Electronic Equipment
WEEE Directive 2002/96/EC This
product falls within the scope of
the Waste Electrical & Electronic
Equipment Directive (WEEE), which
means the product should not be
disposed of as normal household
waste. Please recycle where
facilities exist or check with your
Local Authority. RoHS – All
components and materials used in
this product are RoHS 2002/95/EC
compliant.
Specications may change from time
to time. The information contained
in this leaet is for guidance only
and should not be considered as
always accurate and should be
treated as not representative.
** Please see our website for more detailed information on warranty.
