GB Cordless Metal Shear INSTRUCTION MANUAL
SI Akumulatorske kovinske škarje NAVODILO ZA UPORABO
AL Prerës metali me bateri MANUALI I PËRDORIMIT
BG Акумулаторна ножица за метал
РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ
HR Bežične škare za metal PRIRUČNIK S UPUTAMA
MK Безжични ножици за метал
У
ПАТСТВО ЗА УПОТРЕБА
RO Foarfecămetalicăfărăfir MANUAL DE INSTRUCŢIUNI
RS Бежичне маказе за лим
У
ПУТСТВО ЗА УПОТРЕБУ
RUS
Аккумуляторные листовые ножницы РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
UA
Бездротові ножиці для різання металу ІНСТРУКЦІЯ ЗЕКСПЛУАТАЦІЇ
DJS160
DJS161
DJS100
DJS101

2
1
2
3
1 014128
1
2 012128
1
3 010088
1
4 010089
12
5 010085
1
2
3
4
5
6 010086
1
7 010087
1
2
3
8 010084 9 010090
10 010091
1
11 001145
1
2
3
12 010092
12
13 010093

3
ENGLISH (Original instructions)
Explanation of general view
1-1. Button
1-2. Red indicator
1-3. Battery cartridge
2-1. Star marking
3-1. Switch lever
4-1. Indicating lamp
5-1. Hex wrench
5-2. Screw
6-1. Center blade
6-2. Thickness gauge
6-3. Side blade
6-4. Hex wrench
6-5. Hex socket head bolt
7-1. Hex wrench
8-1. Oil supply
8-2. Center blade
8-3. Pin
11-1. Limit mark
12-1. Brush holder cover
12-2. Notch
12-3. Screwdriver
13-1. Brush holder cap
13-2. Screwdriver
SPECIFICATIONS
Model DJS160 DJS161 DJS100 DJS101
Steel up to 400 N/mm21.6 mm (16 ga) 1.0 mm (20 ga)
Steel up to 600 N/mm21.2 mm (18 ga) 0.7 mm (23 ga)
Max. cutting capacities
Aluminum up to 200 N/mm22.5 mm (13 ga) 2.5 mm (12 ga)
Min. cutting radius 250 mm 30 mm
Strokes per minute (min-1) 4,300 4,300
Overall length 362 mm 364 mm
Net weight 1.9 kg 2.0 kg 1.9 kg 2.0 kg
Rated voltage D.C. 14.4 V D.C. 18 V D.C. 14.4 V D.C. 18 V
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
ENE037-1
Intended use
The tool is intended for cutting sheet steel and stainless
sheet steel.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Model DJS100, DJS101, DJS161
Sound pressure level (LpA) : 71 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Model DJS160
Sound pressure level (LpA) : 74 dB (A)
Uncertainty (K) : 3 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Model DJS100
Work mode : cutting sheet metal
Vibration emission (ah) : 12.5 m/s2
Uncertainty (K) : 1.5 m/s2
Model DJS101, DJS161
Work mode : cutting sheet metal
Vibration emission (ah) : 13.0 m/s2
Uncertainty (K) : 1.5 m/s2
Model DJS160
Work mode : cutting sheet metal
Vibration emission (ah) : 12.0 m/s2
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.

4
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
ENH101-16
For European countries only
EC Declaration of Conformity
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):
Designation of Machine:
Cordless Metal Shear
Model No./ Type: DJS100, DJS101, DJS160, DJS161
are of series production and
Conforms to the following European Directives:
2006/42/EC
And are manufactured in accordance with the following
standards or standardised documents:
EN60745
The technical documentation is kept by:
Makita International Europe Ltd.
Technical Department,
Michigan Drive, Tongwell,
Milton Keynes, Bucks MK15 8JD, England
31.7.2009
000230
Tomoyasu Kato
Director
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, 446-8502, JAPAN
GEA010-1
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for
future reference.
GEB067-1
CORDLESS SHEAR SAFETY
WARNINGS
1. Hold the tool firmly.
2. Secure the workpiece firmly.
3. Keep hands away from moving parts.
4. Edges and chips of the workpiece are sharp.
Wear gloves. It is also recommended that you
put on thickly bottomed shoes to prevent
injury.
5. Do not put the tool on the chips of the
workpiece. Otherwise it can cause damage
and trouble on the tool.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Always be sure you have a firm footing.
Be sure no one is below when using the tool
in high locations.
8. Do not touch the blade or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
9. Avoid cutting electrical wires. It can cause
serious accident by electric shock.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.
ENC007-8
IMPORTANT SAFETY
INSTRUCTIONS
FOR BATTERY CARTRIDGE
1. Before using battery cartridge, read all
instructions and cautionary markings on (1)
battery charger, (2) battery, and (3) product
using battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical
attention right away. It may result in loss of
your eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any
conductive material.
(2) Avoid storing battery cartridge in a
container with other metal objects such
as nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current flow,
overheating, possible burns and even a
breakdown.

5
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 ﾟC (122 ﾟF).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a fire.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. Follow your local regulations relating to
disposal of battery.
SAVE THESE INSTRUCTIONS.
Tips for maintaining maximum battery life
1. Charge the battery cartridge before
completely discharged.
Always stop tool operation and charge the
battery cartridge when you notice less tool
power.
2. Never recharge a fully charged battery
cartridge.
Overcharging shortens the battery service life.
3. Charge the battery cartridge with room
temperature at 10 ﾟC - 40 ﾟC (50 ﾟF - 104 ﾟF).
Let a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge once in every six
months if you do not use it for a long period
of time.
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before adjusting or
checking function on the tool.
Installing or removing battery cartridge
Fig.1
CAUTION:
• Always switch off the tool before installing or
removing of the battery cartridge.
• Hold the tool and the battery cartridge firmly
when installing or removing battery cartridge.
Failure to hold the tool and the battery cartridge
firmly may cause them to slip off your hands and
result in damage to the tool and battery cartridge
and a personal injury.
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION:
• Always install the battery cartridge fully until the
red indicator cannot be seen. If not, it may
accidentally fall out of the tool, causing injury to
you or someone around you.
• Do not install the battery cartridge forcibly. If the
cartridge does not slide in easily, it is not being
inserted correctly.
Battery protection system
The tool is equipped with a battery protection system.
This system automatically cuts off power to the motor to
extend battery life.
The tool will automatically stop during operation if the
tool and/or battery are placed under one of the following
conditions:
• Overloaded:
The tool is operated in a manner that causes
it to draw an abnormally high current.
In this situation, turn the tool off and stop the
application that caused the tool to become
overloaded. Then turn the tool on to restart.
If the tool does not start, the battery is
overheated. In this situation, let the battery
cool before turning the tool on again.
• Low battery voltage:
The remaining battery capacity is too low
and the tool will not operate. In this situation,
remove and recharge the battery.

6
NOTE:
The overheat protection works only with a battery
cartridge with a star mark.
Fig.2
Switch action
Fig.3
CAUTION:
• Before inserting the battery cartridge into the tool,
always check to see that the switch lever actuates
properly and returns to the "OFF" position when
the rear of the switch lever is depressed.
• Switch can be locked in "ON" position for ease of
operator comfort during extend use. Apply caution
when locking tool in "OFF" position and maintain
firm grasp on tool.
To start the tool, slide the switch lever toward the "I
(ON)" position. For continuous operation, press the front
of the switch lever to lock it.
To stop the tool, press the rear of the switch lever, then
slide it toward the "O (OFF)" position.
Indication lamp with multi function
Fig.4
Indication lamps are located in two positions.
−Battery cartridge replacing signal
−When the battery power is almost used up
during operation, the red lamp lights up and
the tool stops immediately. Replace the
battery with fully charged one when the red
lamp lights up.
−Accidental re-start preventive function
−Even if the battery cartridge is inserted on
the tool with the slide switch in the "I (ON)"
position, the tool does not start. At this time,
the lamp flickers slowly and this shows that
the accidental re-start preventive function is
at work.
−To start the tool, first slide the slide switch
toward the "O (OFF)" position and then slide
it toward the "I (ON)" position.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before carrying out
any work on the tool.
Adjusting the blade clearance
For DJS160 and DJS161 only
Adjust the clearance between the side blade and the
center blade according to the thickness of the workpiece.
Fig.5
First use a hex wrench to loosen the screw.
Fig.6
Then use the hex wrench to adjust the clearance by
tightening or loosening the bolt. There may be a slight
difference between clearance of both sides of the center
blade.
Check the smaller clearance with the thickness gauge
and adjust it.
When using the thickness gauge to adjust the blade
clearance, refer to the table.
Workpiece thickness (mm) Marking on thickness gauge
Less than 0.8 0.5
0.8 - 1.3 1.0
More than 1.3 1.5
006428
After adjusting the clearance, tighten the screw securely.
Storing hex wrench
Fig.7
Store the hex wrench as shown in the figure when not in
use.
OPERATION
Lubrication
Fig.8
Before operation, lubricate the contact point of the
center blade and the pin. To keep good cutting
performance, also use a cutting lubricant from time to
time during operation.
OPERATION
Fig.9
Turn the tool on and set front ends of the side blades on
the workpiece. Now simply move the tool forward,
keeping the side blades flush with the workpiece
surface.
Fig.10
CAUTION:
• When cutting a small portion of the workpiece, you
may have difficulty completing the end of the cut.
In that case, try to cut it again, pulling the
workpiece back slightly.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before attempting to
perform inspection or maintenance.
NOTICE:
• Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
The tool and its air vents have to be kept clean.
Regularly clean the tool's air vents or whenever the
vents start to become obstructed.

7
Replacing carbon brushes
Fig.11
Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Insert the top end of slotted bit screwdriver into the
notch in the tool and remove the holder cap cover by
lifting it up.
Fig.12
Use a screwdriver to remove the brush holder caps.
Take out the worn carbon brushes, insert the new ones
and secure the brush holder caps.
Fig.13
Reinstall the holder cap cover on the tool.
Replacing blades
The service life of the blades varies in terms of the
workpiece to be cut. The following reference tables
indicate the approximate service life of the blades.
When the blades become dull, ask Makita Authorized
Service Centers to replace the blades.
For DJS160 and DJS161
MaterialCutting thickness
(mm)
Lifeof blades
(m)
Mild steel plate 2001.6
1.2
Stainless steel plate 150
Aluminum plate 4002.5
(SPCC)
(SUS304)
(A-5052)
010094
For DJS100 and DJS101
Material Cutting thickness
(mm)
Life ofblades
(m)
Mildsteel plate 1201.0
0.7
Stainless steel plate 50
(SPCC)
(SUS304)
010739
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized Service Centers,
always using Makita replacement parts.
OPTIONAL ACCESSORIES
CAUTION:
• These accessories or attachments are
recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or
attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Thickness gauge
• Center blade
• Side blade R
• Side blade L
• Hex wrench
• Makita genuine battery and charger
NOTE:
• Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.

8
SLOVENŠČINA (izvirna navodila)
Razlaga splošnega pogleda
1-1. Gumb
1-2. Rdeči indikator
1-3. Baterijski vložek
2-1. Oznaka z zvezdico
3-1. Preklopna ročica
4-1. Opozorilna lučka
5-1. Inbus ključ
5-2. Vijak
6-1. Sredinsko rezilo
6-2. Merilnik debeline
6-3. Stransko rezilo
6-4. Inbus ključ
6-5. Matični vijak s šestrobo torx glavo
7-1. Inbus ključ
8-1. Zaloga olja
8-2. Sredinsko rezilo
8-3. Zatič
11-1. Meja obrabljenosti
12-1. Pokrov držala za ščetke
12-2. Zareza
12-3. Izvijač
13-1. Pokrov krtačke
13-2. Izvijač
TEHNIČNI PODATKI
Model DJS160 DJS161 DJS100 DJS101
Jeklo do 400 N/mm21,6 mm (16 ga) 1,0 mm (20 ga)
Jeklo do 600 N/mm21,2 mm (18 ga) 0,7 mm (23 ga)
Maks. zmogljivost rezanja
Aluminij do 200 N/mm22,5 mm (13 ga) 2,5 mm (12 ga)
Min. radij rezanja 250 mm 30 mm
Rezi na minuto (min-1) 4.300 4.300
Skupna dolžina 362 mm 364 mm
Neto teža 1,9 kg 2,0 kg 1,9 kg 2,0 kg
Nazivna napetost D.C. 14,4 V D.C. 18 V D.C. 14,4 V D.C. 18 V
• Zaradi našega nenehnega programa raziskav in razvoja si pridržujemo pravico do spremembe tehničnih podatkov brez obvestila.
• Tehnični podatki in baterijski vložki se lahko razlikujejo od države do države.
• Teža z baterijskim vložkom je v skladu z EPTA-postopkom 01/2003
ENE037-1
Namen uporabe
Orodje je namenjeno za rezanje pločevine in nerjaveče
jeklene pločevine.
ENG905-1
Hrup
Tipični, z A ocenjeni vrednosti hrupa glede na EN60745:
Model DJS100, DJS101, DJS161
Raven zvočnega tlaka (LpA): 71 dB (A)
Odstopanje (K): 3 dB (A)
Nivo hrupa med delom lahko preseže 80 dB (A).
Model DJS160
Raven zvočnega tlaka (LpA): 74 dB (A)
Odstopanje (K): 3 dB (A)
Nivo hrupa med delom lahko preseže 80 dB (A).
Uporabljajte zaščito za sluh
ENG900-1
Vibracije
Skupne vrednosti vibracij (vektorska vsota treh osi) po
EN60745:
Model DJS100
Delovni način: rezanje pločevine
Oddajanje tresljajev (ah): 12,5 m/s2
Odstopanje (K): 1,5 m/s2
Model DJS101, DJS161
Delovni način: rezanje pločevine
Oddajanje tresljajev (ah): 13,0 m/s2
Odstopanje (K): 1,5 m/s2
Model DJS160
Delovni način: rezanje pločevine
Oddajanje tresljajev (ah): 12,0 m/s2
Odstopanje (K): 1,5 m/s2
ENG901-1
• Navedena vrednost oddajanja vibracij je bila
izmerjena v skladu s standardnimi metodami
testiranja in se lahko uporablja za primerjavo orodij.
• Navedena vrednost oddajanja vibracij se lahko
uporablja tudi pri predhodni oceni izpostavljenosti.
OPOZORILO:
• Oddajanje vibracij med dejansko uporabo električnega
orodja se lahko razlikuje od navedene vrednosti
oddajanja, odvisno od načina uporabe orodja.
• Upravljavec mora za lastno zaščito poznati
varnostne ukrepe, ki temeljijo na oceni
izpostavljenosti v dejanskih pogojih uporabe
(upoštevajočceloten delovni proces v trenutkih, ko
je orodje izključeno in ko deluje v prostem teku z
dodatkom časa sprožitve).

9
ENH101-16
Samo za evropske države
ES Izjava o skladnosti
Makita Corporation kot odgovorni proizvajalec
izjavlja, da je naslednji stroj Makita:
Oznaka stroja:
Akumulatorske kovinske škarje
Št. modela / tip: DJS100, DJS101, DJS160, DJS161
del serijske proizvodnje in
Je skladen z naslednjimi evropskimi direktivami:
2006/42/ES
In je izdelan v skladu z naslednjimi standardi ali
standardiziranimi dokumenti:
EN60745
Tehnično dokumentacijo hrani:
Makita International Europe Ltd.
Tehnični oddelek,
Michigan Drive, Tongwell,
Milton Keynes, Bucks MK15 8JD, England
31.7.2009
000230
Tomoyasu Kato
Direktor
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, 446-8502, JAPAN
GEA010-1
Splošna varnostna opozorila za
električno orodje
OPOZORILO Preberite vsa varnostna opozorila
in navodila. Neupoštevanje opozoril in navodil lahko
vodi do električnega udara, požara, in/ali hudih telesnih
poškodb.
Shranite vsa opozorila in navodila za
kasnejšo uporabo.
GEB067-1
VARNOSTNA OPOZORILA PRI
UPORABI AKUMULATORSKIH
ŠKARIJ
1. Trdno držite orodje.
2. Trdno pritrdite obdelovanec.
3. Ne približujte rok premikajočim se delom.
4. Robovi in ostružki obdelovanca so ostri.
Nosite rokavice. Prav tako je priporočljivo, da
nosite čevlje z debelim podplatom, da
preprečite poškodbe.
5. Ne vlecite orodja po ostružkih obdelovanca. V
nasprotnem primeru lahko pride do poškodb
in težav z orodjem.
6. Orodja ne pustite delovati brez nadzora.
Dovoljeno ga je uporabljati samo ročno.
7. Vedno zagotovite, da imate trden oprijem na
podlagi, kjer stojite.
Kadar uporabljate orodje na višini, se
prepričajte, da spodaj ni nikogar.
8. Takoj po končani obdelavi se ne dotikajte
rezila ali obdelovanca; lahko sta zelo vroča in
povzročita opekline kože.
9. Izogibajte se rezanju električnih žic. Pride
lahko do resne nezgode zaradi električnega
udara.
SHRANITE TA NAVODILA.
OPOZORILO:
NE dopustite si, da bi zaradi udobnejšega dela ali
poznavanja izdelka (pridobljenega z večkratno
uporabo) opustili striktno upoštevanje varnostnih
pravil pri uporabi stroja. ZLORABA ali
neupoštevanje varnostnih pravil v teh navodilih za
uporabo lahko povzroči hude telesne poškodbe.
ENC007-8
POMEMBNA VARNOSTNA
NAVODILA
ZA BATERIJSKE VLOŽKE
1. Pred uporabo baterijskega vložka preberite
vsa navodila in opozorilne oznake na (1)
polnilniku akumulatorja, (2) akumulatorju in
(3) izdelku, ki uporablja akumulator.
2. Ne razstavljajte baterijskega vložka.
3. Če se je čas delovanja občutno skrajšal, takoj
prekinite z uporabo. V nasprotnem primeru je
lahko rezultat pregretje, morebitne opekline in
celo eksplozija.
4. Če pride elektrolit v oči, jih sperite s čisto
vodo in takoj poiščite zdravniško pomoč.
Posledica je lahko izguba vida.
5.
Ne povzročite kratkega stika baterijskega vložka:
(1) Ne dotikajte se priključkov s kakršnim
koli prevodnim materialom.
(2) Izogibajte se shranjevanju baterijskega
vložka v posodo z drugimi kovinskimi
predmeti kot so žeblji, kovanci itn.
(3) Ne izpostavljajte baterijskega vložka vodi
ali dežju.
Kratek stik akumulatorja lahko povzroči velik
tok, pregretje, morebitne opekline in celo
eksplozijo.
6. Ne shranjujte orodja in baterijskega vložka na
lokacijah, kjer lahko temperatura doseže ali
preseže 50 ﾟC (122 ﾟF).
7. Ne sežigajte baterijskega vložka, tudi če je
hudo poškodovan ali v celoti izpraznjen.
Baterijski vložek lahko v ognju eksplodira.

10
8. Bodite previdni, da vam akumulator ne pade
in ga ne udarjajte.
9. Ne uporabljajte poškodovanih akumulatorjev.
10. Upoštevajte lokalne uredbe glede odlaganja
akumulatorja.
SHRANITE TA NAVODILA.
Nasveti za maksimalno življenjsko dobo
akumulatorja
1. Napolnite baterijski vložek preden se v celoti
izprazni.
Ko opazite, da ima orodje manjšo moč, vedno
ustavite delovanje orodja in napolnite
baterijski vložek.
2. Nikoli znova ne polnite popolnoma
napolnjenega baterijskega vložka.
Prenapolnjenje skrajša življenjsko dobo
akumulatorja.
3. Napolnite baterijski vložek pri sobni
temperaturi med 10 ﾟC in 40 ﾟC (50 ﾟF - 104 ﾟ
F). Počakajte, da se vročbaterijski vložek
pred polnjenjem ohladi.
4. Napolnite baterijski vložek enkrat vsakih šest
mesecev, če ga ne uporabljate dlje časa.
OPIS DELOVANJA
POZOR:
• Pred vsako nastavitvijo ali pregledom delovanja
orodja se prepričajte, da je le to izključeno in da je
akumulatorska baterija odstranjena.
Nameščanje ali odstranjevanje
akumulatorske baterije
Sl.1
POZOR:
• Vedno izklopite orodje, preden namestite ali
odstranite akumulatorsko baterijo.
• Kadar nameščate ali odstranjujete
akumulatorsko baterijo, trdno držite orodje in
akumulatorsko baterijo. Če orodja in
akumulatorske baterije ne držite trdno, se lahko
zgodi, da vam zdrsneta iz rok, posledica pa je
poškodba orodja in akumulatorske baterije ter
telesna poškodba.
Za odstranitev akumulatorske baterije iz orodja jo
premaknite iz orodja, ob tem pa premaknite gumb na
sprednji strani akumulatorske baterije.
Pri vstavljanju akumulatorske baterije poravnajte jeziček
na akumulatorski bateriji z utorom na ohišju in ga
potisnite v ležišče. Akumulatorsko baterijo vstavite do
konca, da se razločno zaskoči. Če vidite rdeči indikator
na zgornji strani gumba, ta ni popolnoma zaklenjen.
POZOR:
• Vedno namestite akumulatorsko baterijo, tako da
rdeči indikator ni večviden. Če tega ne upoštevate,
lahko akumulator nepričakovano izpade iz orodja
in poškoduje vas ali osebe v neposredni bližini.
• Ne nameščajte akumulatorske baterije s silo. Če
se akumulatorska baterija ne zaskoči zlahka, ni
pravilno vstavljena.
Sistem za zaščito akumulatorja
Orodje je opremljeno s sistemom za zaščito
akumulatorja. Sistem samodejno prekine napajanje
motorja, da se podaljša življenjska doba akumulatorja.
Orodje se bo samodejno zaustavilo med delovanjem, če
sta orodje in/ali baterija zamenjana pod naslednjimi
pogoji:
• Preobremenjeno:
Orodje deluje na način, ki povzroča, da
povleče nenormalno visok tok.
V tem primeru izklopite orodje in prenehajte
z izvajanjem dela, ki je povzročilo
preobremenitev orodja. Nato vklopite orodje
za vnovični zagon.
Če se orodje ne zažene, se je akumulator
pregrel. V tem primeru pred vnovičnim
vklopom orodja počakajte, da se akumulator
ohladi.
