MASSEY FERGUSON 9831 User manual

© AGCO Corporation, 2013 All rights reserved.
Part Number 4283532M1 (English)
Printed in U.S.A.
September 2013
Massey Ferguson®
9831
Planter
SERVICE MANUAL
4283532M1
CONTENTS
GENERAL INFORMATION ....................................................................................................................................01
ROW UNIT..............................................................................................................................................................02
DRIVE SYSTEMS...................................................................................................................................................03
AIR SYSTEM..........................................................................................................................................................04
HYDRAULICS ........................................................................................................................................................05
ELECTRICAL .........................................................................................................................................................06
FRAME.....................................................................................................................................................................07
ADJUSTMENTS.....................................................................................................................................................08
CONSOLES AND MONITORS..................................................................................................................................09

4283532M1 01-i
Contents
Massey Ferguson®
9831
Planter
SERVICE MANUAL
4283532M1
01 - General Information
Contents
GENERAL INFORMATION
General Information ....................................................................................................................................... 01-1
Serial Number Plate Location ........................................................................................................................ 01-2
SAFETY
Safety Alert Symbol ....................................................................................................................................... 01-3
Safety Messages ........................................................................................................................................... 01-3
Informational Messages ................................................................................................................................. 01-4
Safety Signs ................................................................................................................................................... 01-4
General Operation And Service ..................................................................................................................... 01-5
Operating ................................................................................................................................................. 01-5
Agricultural Chemicals ............................................................................................................................. 01-6
Transporting ............................................................................................................................................ 01-6
Servicing .................................................................................................................................................. 01-7
SPECIFICATIONS
Specifications ................................................................................................................................................. 01-9
9831 ........................................................................................................................................................ 01-9
Frame ...................................................................................................................................................... 01-9
Tires and Wheels .................................................................................................................................... 01-9
Markers ................................................................................................................................................... 01-9
Row Units .............................................................................................................................................. 01-10
Air System ............................................................................................................................................. 01-10
Tractor Requirements ............................................................................................................................ 01-10
Hydraulic System .................................................................................................................................. 01-10
Shear Pins ............................................................................................................................................. 01-11
Electronic Seed Drive Controller ........................................................................................................... 01-11
Frame Fold Control ............................................................................................................................... 01-11
Approximate Shipping Weights ............................................................................................................. 01-11
FIELD OPERATIONS AND ADJUSTMENTS
Tractor Preparation ...................................................................................................................................... 01-13
General .................................................................................................................................................. 01-13
Recommended Tractor Horsepower ..................................................................................................... 01-13
Wheel Tread Spacing ............................................................................................................................ 01-13
Electrical Requirements ........................................................................................................................ 01-13
Tractor Preparation ............................................................................................................................... 01-14
Tractor PTO ........................................................................................................................................... 01-14
Tire Inflation ........................................................................................................................................... 01-14
Front Weights ........................................................................................................................................ 01-14
Hydraulic Requirements ........................................................................................................................ 01-14
Planter Preparation ...................................................................................................................................... 01-14
Lubrication ............................................................................................................................................. 01-14
Find manuals at https://best-manuals.com

01-ii 4283532M1
Contents
Bolt Torque ............................................................................................................................................ 01-14
Tire Inflation ........................................................................................................................................... 01-14
Markers ................................................................................................................................................. 01-14
Chains ................................................................................................................................................... 01-14
Seed Discs ............................................................................................................................................ 01-14
Hydraulic Seeding Monitor .................................................................................................................... 01-15
Connecting the Planter to the Tractor .......................................................................................................... 01-16
Hydraulic Hose Connections ................................................................................................................. 01-17
Seed Meter Blower/Meter Drive Hoses ....................................................................................................... 01-19
Adjusting Tractor Remote Valve Flow ................................................................................................... 01-19
Hitch Height ................................................................................................................................................. 01-20
Hitch Height Adjustment ........................................................................................................................ 01-20
Disconnecting the Planter from the Tractor ................................................................................................. 01-20
Frame Control System ................................................................................................................................. 01-23
Control Box Switches ............................................................................................................................ 01-23
Operating Notes .................................................................................................................................... 01-24
Raise and Lower .......................................................................................................................................... 01-24
Raise Procedure .................................................................................................................................... 01-24
Lower Procedure ................................................................................................................................... 01-24
Folding And Unfolding ................................................................................................................................. 01-25
General .................................................................................................................................................. 01-25
Safety .................................................................................................................................................... 01-25
Folding Procedure ................................................................................................................................. 01-25
Unfolding Procedure .............................................................................................................................. 01-26
Markers ........................................................................................................................................................ 01-28
Operation ............................................................................................................................................... 01-28
Marker Sequence Valve ........................................................................................................................ 01-28
Marker Position Switch .......................................................................................................................... 01-29
Tri-fold Breakaway Marker .................................................................................................................... 01-29
Shear Bolts ............................................................................................................................................ 01-29
Split row Units .............................................................................................................................................. 01-30
General .................................................................................................................................................. 01-30
Split Row Unit Disengagement .............................................................................................................. 01-30
Split Row Unit Engagement .................................................................................................................. 01-31
Planting Rates ............................................................................................................................................. 01-32
Wheat Conversion Chart ....................................................................................................................... 01-32
Checking Population .................................................................................................................................... 01-33
Initial Pressure Settings ............................................................................................................................... 01-35
Seed Disc Identification Chart ..................................................................................................................... 01-36
Large Bean Disc .......................................................................................................................................... 01-39
Snap Bean Disc ........................................................................................................................................... 01-39
Treated Seed ............................................................................................................................................... 01-39
Seed Recommendations ............................................................................................................................. 01-40
Chemical Attachment ................................................................................................................................... 01-41
General .................................................................................................................................................. 01-41
Cleaning Hoppers and Meters ............................................................................................................... 01-42
Application Rate .................................................................................................................................... 01-42
Checking Application Rate .................................................................................................................... 01-42
Insecticide Rate Chart - Clay Granules ....................................................................................................... 01-43
Approximate rate in lb/acre @ 5 mph with 7 inch or 14 inch banders ................................................... 01-43
Narrow Row Calculations ...................................................................................................................... 01-43
Insecticide Rate Chart - Sand Granules ...................................................................................................... 01-44
Approximate rate in lb/acre @ 5 mph with 7 inch or 14 inch banders ................................................... 01-44
Narrow Row Calculations ...................................................................................................................... 01-44
Herbicide Rate Chart ................................................................................................................................... 01-45
Approximate rate in lb/acre @ 5 mph with 7 inch or 14 inch banders ................................................... 01-45
Narrow Row Calculations ...................................................................................................................... 01-45
General Maintenance .................................................................................................................................. 01-46
Beginning of Day ................................................................................................................................... 01-46
End of Day ............................................................................................................................................. 01-46
Beginning of Season ............................................................................................................................. 01-46
End of Season ....................................................................................................................................... 01-47
Lubrication Chart ......................................................................................................................................... 01-48
Find manuals at https://best-manuals.com

4283532M1 01-iii
Contents
Clutch Alignment .......................................................................................................................................... 01-49
Hydraulic Drive ............................................................................................................................................ 01-49
Radar Device ......................................................................................................................................... 01-49
ISOBUS Planter Controller .................................................................................................................... 01-49
Test Button ............................................................................................................................................ 01-50
Control Installation ....................................................................................................................................... 01-50
Test Switch Storage Tube ..................................................................................................................... 01-50
Bolt Torque Values ...................................................................................................................................... 01-52
Special Torque Values .......................................................................................................................... 01-52
Metric Bolts ............................................................................................................................................ 01-53
INSTALLATION INSTRUCTIONS
Installation Instructions ................................................................................................................................ 01-55
INDEX ............................................................................................................................................................. 01-57
Find manuals at https://best-manuals.com

01-iv 4283532M1
Contents
NOTES
Find manuals at https://best-manuals.com

4283532M1 01-1
General Information
GENERAL INFORMATION
GENERAL INFORMATION
FIG. 1: The Model 9831 31-Row Narrow Transport
Forward Fold with Central Fill System.
9831 Series Narrow Transport Forward Fold Planters are
designed, built and tested to make sure high quality,
maximum strength and long service life. All models
feature positive air metering and hydraulic seed drive for
accurate seed spacing.
The Central Fill System planter is designed for planting
corn, soybeans, milo, popcorn, and oil crop sunflowers.
mWARNING: Pictures in this manual can
show protective shields and guards opened
or removed for illustration purposes. BE
SURE ALL SHIELDS AND GUARDS ARE IN
PLACE DURING OPERATION.
This manual was prepared from the latest information
available at publication time. The Company reserves the
right to make changes at any time without notice or
obligation.
FIG. 1
L070409
9831 31-Row 15 inch Narrow Transport
Forward Fold Planter
Find manuals at https://best-manuals.com

General Information
01-2 4283532M1
SERIAL NUMBER PLATE LOCATION
FIG. 2: The serial number plate (1) is found on the
left-hand side of the hitch.
FIG. 2
1
L830560
Find manuals at https://best-manuals.com

4283532M1 01-3
Safety
SAFETY
SAFETY ALERT SYMBOL
FIG. 1: The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this manual and
on safety signs on this machine. The safety alert symbol
will direct your attention to information that involves your
safety and the safety of others.
SAFETY MESSAGES
FIG. 2: The words DANGER, WARNING or CAUTION
are used with the safety alert symbol. Learn to recognize
these safety alerts and follow the recommended
precautions and safety practices.
mDANGER: Indicates an imminently
hazardous situation that, if not avoided, will
result in DEATH OR VERY SERIOUS
INJURY.
mWARNING: Indicates a potentially
hazardous situation that, if not avoided,
could result in DEATH OR SERIOUS
INJURY.
mCAUTION: Indicates a potentially
hazardous situation that, if not avoided,
may result in MINOR INJURY.
FIG. 1
Saf
FIG. 2
WC1957
Find manuals at https://best-manuals.com

01-4 4283532M1
Safety
INFORMATIONAL MESSAGES
The words IMPORTANT and NOTE are not related to
personal safety, but are used to give additional
information and tips for operating or servicing this
equipment.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly observed, could
result in damage to or destruction of the
machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more
efficient and convenient repair or operation.
SAFETY SIGNS
mWARNING: DO NOT remove or obscure
safety signs. Replace any safety signs that
are not readable or are missing.
Replacement signs are available from your
dealer in the event of loss or damage. The
actual location of the safety signs is
illustrated at the end of this section.
If a used machine has been purchased, make sure all
safety signs are in the correct location and can be read.
Replace any safety signs that can not be read or are
missing. Replacement safety signs are available from
your dealer.
Find manuals at https://best-manuals.com

4283532M1 01-5
Safety
GENERAL OPERATION AND SERVICE
Operating
• Read and understand all the operating and safety
precautions before operating the machinery.
• In addition to the equipment configuration and
design, hazard control and accident prevention
depend on awareness, concern, prudence and
proper training of the personnel in the operation,
maintenance, transport and storage of the
equipment.
• Always raise the implement, shut off the tractor
engine, set the brakes, shift to park position (or
neutral) and install the cylinder lockup channels
before working around the machine.
• Avoid working under the planter. However, if it
becomes unavoidable to do so, make sure the planter
is securely blocked and the cylinder lockup channels
are in place.
• Do not attempt to lubricate or adjust the planter while
the machine is in operation.
• The machinery operation must be performed only by
persons who are responsible and delegated to do so.
• Only the operator must be permitted on the tractor
(unless tractor has a factory-installed instructor seat)
when the tractor and the planter are moving. Never
permit anyone to ride on the planter.
• Avoid wearing loose-fitting clothing and jewelry.
Always tie up long hair that can be caught in the
moving parts.
• Wear personal protective equipment (PPE) such as,
but not limited to, protection for eyes, lungs, ears,
head, hands and feet when operating, servicing or
repairing the equipment.
• Make sure all persons are clear before operating the
tractor or machine.
• Do not leave the tractor or implement unattended
with the engine running.
• Never attempt to operate the planter unless seated in
the operator’s seat on the tractor with the seat belt
fastened.
• The tractor must be equipped with rollover protective
structure (ROPS), and a seat belt. Use the seat belt
during operation.
• Make sure the tractor is in good operating condition,
and has adequate braking capabilities.
• Do not dismount from a moving tractor.
• Regulate the ground speed to field conditions, and
maintain control at all times.
• When working around discs, be careful to not get cut
on the sharp edges.
• Watch for overhead wires or other obstructions when
raising markers, and when moving the planter with
the marker(s) raised.
• Disconnect the planter. Store the planter where
children do not normally play. Stabilize the planter by
using suitable supports, and block the wheels.
• Always lower the planter when not in use and relieve
pressure in the hoses and cylinders.
• Do not allow children to ride on, play on, or operate
equipment. Always keep children away from the
equipment operating, servicing, and storage areas.
• Do not stand between the tractor and planter to install
the hitch pin when the tractor engine is running.
Find manuals at https://best-manuals.com

01-6 4283532M1
Safety
Agricultural Chemicals
• Ag chemicals can be very hazardous. Improper use
of fertilizer, fungicides, herbicides, insecticides and
pesticides can injure people, plants, animals, soil and
other people's property.
• Always read and follow all manufacturers' instructions
before opening any chemical container.
• Even if you think you know them, read and follow
instructions each time you use a chemical.
• Use same precautions when adjusting, servicing,
cleaning or storing the planter as used when
installing chemicals into the hoppers or tanks.
• Inform anyone who comes in contact with chemicals
of the potential hazards involved and the safety
precautions required.
• Stand upwind and away from the smoke from a
chemical fire.
• Store or dispose of all unused chemicals only in a
manner as specified by the chemical manufacturer.
Transporting
• Do not transport planter in excess of 24 km/h (15
mph).
• Use a tractor with a minimum weight of at least 2/3 of
the fully loaded planter.
• Use good judgment when transporting the planter on
the highway. Maintain complete control of the
machine at all times.
• Comply with the state and local laws governing
highway safety and regulations when moving the
machinery.
• Always make the necessary safety precautions prior
to transporting the machine on public roads.
• Make sure SMV (Slow Moving Vehicle) emblem is
clean and visible.
• Use flashing warning lights except when prohibited
by law.
• Watch for overhead wires or other obstructions when
transporting the planter with markers raised.
• Make sure the markers are completely folded before
transporting or parking the planter.
• Install the transport cylinder lockup devices before
transporting the planter.
• For Drawbar Hitch Models: Always fasten the
transport safety chain to the tractor drawbar and use
the retainer on the hitch pin.

4283532M1 01-7
Safety
Servicing
• Always raise the implement, shut off the tractor
engine and install cylinder lockup channels before
working around the machine.
• After repairing or adjusting the planter, remove all of
the tools and parts from the machine before
operating the planter.
• Tire changing can be very hazardous and must be
done by trained personnel using the proper tools and
equipment.
• Do not inflate the tire that was seriously under-inflated
or run flat. Have it checked by qualified personnel.
• Lower the planter to the ground before attempting to
remove a wheel for tire repair.
FIG. 3: Fluid Leak Detection
Correct the hydraulic leaks immediately. All the fittings
must be tight and all the lines and hoses in good
condition. Escaping hydraulic fluid, under extremely high
pressure, can penetrate the skin and cause blood
poisoning. Use a piece of wood or cardboard to detect
fluid leaks. If injured by escaping fluid, see a doctor
immediately.
FIG. 3
D-5842a

Safety
01-8 4283532M1
NOTES

4283532M1 01-9
Specifications
SPECIFICATIONS
SPECIFICATIONS
9831
Rows..............................................................................................................................................................................31
Row Spacing................................................................................................................................................38 cm (15 in)
Transport Width............................................................................................................................................3.96 m (13 ft)
Transport Length..........................................................................................................................................8.84 m (29 ft)
Transport Height ...................................................................................................................................3.86 m (12 ft 8 in)
Operating Length..................................................................................................................................8.64 m (28 ft 4 in)
Operating Width................................................................................................................................12.45 m (40 ft 10 in)
Transport Wheels.............................................................................................................................................................4
Gauge Wheels.................................................................................................................................................................2
Frame
Main Frame Size.................................................................................................................. 17.78 x 17.78 cm (7 x 7 in)
Flexibility............................................................................................................... +/- 20 degrees over total frame width
NOTE: Planter flex can be limited by row unit position.
Fold Cylinders................................................................................................................ One, 4 x 75 inch double acting
Lift Cylinders................................................................................................. Two, 4 x 28 inch double acting, rephasing
Wheel Lift Cylinders................................................................................ Two, 4 x 10.75 inch double acting, rephasing
Wheel Fold Cylinders ..................................................................................................... Two, 3 x 10 inch double acting
Hitch Cylinder........................................................................................................... One, 3-1/2 x 10 inch double acting
Tires and Wheels
Tires ..................................................................................................... Four, (Early Production) 32/15.5 x 16.5, 14-ply
...........................................................................................................................(Late Production) 33/15.5 x 16.5, 14-ply
Tire Pressure (maximum)......................................................................792 kPa (115 psi) or max indicated on sidewall
Tires ....................................................................................................................................... Two, 31.5/15.5 x 15, 8-ply
Tire Pressure (maximum)........................................................................310 kPa (45 psi) or max indicated on sidewall
Wheel Bearings ........................................................................................................................................ Tapered roller
Wing Caster and Pivot Bearings.............................................................................................................. Tapered roller
Markers
Type............................................................. Automatic sequencing, tri-fold arms with break away and gauge wheels
Disc Size....................................................................................................................................35.6 cm (14 in) diameter
Disc Type..................................................................................................................................Notched with Depth Band
Cylinder Sizes 31R-15 inch........................................................................................................76 x 508 mm (3 x 20 in)
Gauge Wheel.............................................................................................................................................. 13 x 6.50 to 6

Specifications
01-10 4283532M1
Row Units
Seed Hoppers..................................................................................................Two 1585.8 L (45 bu) central fill hoppers
Seed Discs.........................................Corn, soybeans, sunflower, sugar beet, cotton, sorghum, milo, maize, popcorn
Seed Drive System.........................................................................................................Electronic controlled hydraulics
Seed Disc-to-Metering Unit Clearance.................................................................0.254 to 1.27 mm (0.010 to 0.050 in)
Herbicide/Insecticide Hoppers .....................................................................................................................70 lb per row
Metering Unit Drives.............................................................................. Sprocket, chain and shaft with hydraulic motor
Shaft and Disc Bearings.............................................................................. Permanently sealed and lubricated for life
Gauge Wheel Tire Size..................................................................................................... 11.4 x 40.6 cm (4.5 x 16 in)
Single Closing Wheel Tire Size............................................................................................. 10.3 x 30.1 cm (4 x 12 in)
Dual Closing Wheel Tire Size .................................................................................................... 30.8 cm dia (12 in dia)
Single Closing Wheel Down Pressure............................................................................... 4.5 to 50.0 kg (10 to 130 lb)
Dual Closing Wheel Down Pressure................................................................................... 6.8 to 107 kg (50 to 230 lb)
Air System
Seed Meter Blowers...................................................................................................................................................Two
Max. Blower Speed.............................................................................................................2600 rpm @ rated PTO rpm
Operating Air Pressure (Min)....................................................................................................12.7 mm (0.5 in) of water
Operating Air Pressure (Max) ......................................................................................................102 mm (4 in) of water
Tractor Requirements
Horsepower (minimum)
Model 9831............................................................................................................................................ 168 kW (225 hp)
Weight (minimum)..........................................................................................................................12 125 kg. (26 730 lb)
Hydraulic System
Tractor Remote Valve Requirements......................................................................................................... Three or Four
Frame Lift - Fold System Capacity................................................................................................. Approx. 45 L (12 gal)
PTO Pump Circuit
Return Line Filter..................................................................................................10 micron,spin-oncartridge-type
Suction Screen .......................................................................................................................................... 100 mesh
Reservoir Capacity............................................................................................................................20.1 L (5.3 gal)
Fluid Cooler...............................................................................................................................Standard Equipment
Blower Motor
Fluid Requirement (Max).............................................................................................3.8 to 11.3 Lpm (1 to 3 gpm)
Operating Pressure (Min)..............................................................................3445 kPa (500 psi) @ rated PTO rpm
Operating Pressure (Max)......................................................................17 238 kPa (2500 psi*) @ rated PTO rpm
* Maintained by relief valve in planter proportional flow divider valve block.

4283532M1 01-11
Specifications
Shear Pins
Metering Unit Shaft.....................................................................................................................3/16 x 1-1/2 inch roll pin
Main Drive Shaft Sprockets......................................................................................................1/4 x 1 inch bolt, Grade 2
Herbicide/Insecticide Meter Shaft ..............................................................................................5/32 x 1-1/4 inch roll pin
Marker.......................................................................................................................................3/8 x 3 inch bolt, Grade 5
Electronic Seed Drive Controller
ISOBUS Planter Controller..............................................................................................................Standard Equipment
Voltage...........................................................................................................................12 VDC, w/ nonvolatile memory
Fuse................................................................................................15 amp Blue ATO, 5 amp Tan ATO 1/4 x 1-1/4 inch
Program Capability.........................................................................................................Seed population, seed spacing
Frame Fold Control
box fuse............................................................................................................................................30 amp Green MAXI
Approximate Shipping Weights
9831-15..............................................................................................................................................9916 kg (21 860 lb)

Specifications
01-12 4283532M1
NOTES

4283532M1 01-13
Field Operations and Adjustments
FIELD OPERATIONS AND ADJUSTMENTS
TRACTOR PREPARATION
General
Before operating the planter, refer to your tractor Operator
Manual for operating information about hydraulics, tire
inflation, Connecting the Tractor, weights and wheel
adjustments.
Recommended Tractor Horsepower
Wheel Tread Spacing
IMPORTANT: Dual rear wheels are recommended for
tractor stability and for load carrying capacity
when the planter is folded.
31-Row, 15 inch Models
Set inner wheel tread to 153 cm (60 in).
Set outer wheel tread to 305 cm (120 in).
NOTE: Set all wheels equally from the tractor centerline.
When operating on hill sides or steep slopes, set the
wheels as wide as possible for maximum stability and
steering control. If the front axle is adjustable, set the
wheels at the outside edge of the inner rear wheels.
Electrical Requirements
The tractor electrical system must provide 12 volts DC to
operate the seed monitor, highway lamp system, frame
fold control system, and hydraulic seed drive controller.
IMPORTANT: Connect electrical equipment only to 12
volts DC.
The transport lamp system is connected to the tractor with
a standard 7-pin connector.
Planter Model Minimum
PTO
Required
Planter
Weight
(dry)
Total
Planter
Weight
Desired
Tractor
Weight
9831 225 hp
168 kw 21 860 lb 9916 kg 40 075 lb 18 178 kg 26 730 lb 12 125 kg

01-14 4283532M1
Field Operations and Adjustments
Tractor Preparation
Adjust tractor drawbar to between 36 cm (14 in) and 51
cm (20 in) off the ground and position so hitch pin hole is
36 cm (14 in) from the end of the PTO shaft.
Tractor PTO
The planter hydraulic pump requires a 1000 rpm tractor
PTO shaft of either size: 21-spline, 1-3/8 inch diameter
20-spline, 1-3/4 inch diameter
Tire Inflation
Inflate tires as recommended in tractor Operator Manual.
Front Weights
Install as many weights as required for front end stability
when planter is folded.
Hydraulic Requirements
Three or four remote valves are required:
1. One valve controls the frame lift/lower circuit.
2. A second valve controls the tongue
height/marker/fold circuits.
3. A third valve controls the central fill seed hopper
pressure.
4. A fourth valve controls the hydraulic seed drive and
blower, if the PTO pump is not utilized.
Minimum available tractor system pressure must be
15,502 kPa (2250 psi).
PLANTER PREPARATION
Lubrication
Lubricate planter as shown in the Lubrication and
Maintenance Section. Also, check the fluid level in the
PTO pump reservoir. Add fluid if required.
Bolt Torque
Tighten all bolts according to the chart. Make sure all
bolts nuts and screws are tight and all cotter pins are
spread.
Tire Inflation
Inflate 31.5/15.5 x 15, 8-ply tires to 310 kPa (45 psi) or
maximum pressure shown on tire side wall.
Galaxy (Early Production): Inflate 32/15.5 x 16.5, 14-ply
tires to 792 kPa (115 psi) or maximum pressure shown on
tire side wall.
Titan (Late Production): Inflate 33/15.5 x 16.5, 14-ply tires
to 482.6 kPa (70 psi)
Markers
Adjust markers to correct length.
Chains
Make sure all drive chains are installed with proper
tension, alignment, and lubrication.
Seed Discs
Install the correct seed discs in all metering units. Adjust seed gates as needed.

4283532M1 01-15
Field Operations and Adjustments
Hydraulic Seeding Monitor
Program the ISOBUS planter controller for the crop to be
planted. Make sure the radar device is in the correct
position.
