MASSEY FERGUSON 1373 User manual

Operator's Manual
Rotary Disc Mower
1373
1376
North America
4205 River Green Parkway, Duluth GA 30096 USA
© AGCO 2019
Original Operator's Manual
January 2019
700751490C
NA
English

CALIFORNIA
Proposition 65 Warning
WARNING: Diesel engine exhaust and some of its constituents are known to the State of
California to cause cancer, birth defects, or other reproductive harm.
WARNING: Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to the State of California to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling.
Congratulations on your selection of an AGCO®Product. We believe you
have exercised excellent judgment in the purchase of your AGCO®
machine. We are most appreciative of your patronage.
Your Dealer has performed the pre-delivery service on your new
machine.
He will discuss with you the operating and maintenance instructions
given in this manual, and instruct you in the correct and varied
applications of this machine. Call on him at any time when you have a
question or need equipment related to the use of your machine.
We recommend that you carefully read this entire manual before
operating the machine. Also, time spent in becoming fully acquainted
with its performance features, adjustments, and maintenance schedules
will be repaid in a long and satisfactory life of the product.
This equipment is covered by a written warranty which will be provided
to you by your AGCO®Dealer at time of purchase.
AGCO®reserves the right to make changes or add improvements to its products at any time
without incurring any obligation to make such changes to products manufactured previously. AGCO
®, or its dealers, accept no responsibility for variations which may be evident in the actual
specifications of its products and the statements and descriptions contained in this publication.
Find manuals at https://best-manuals.com

Rotary Disc Mower
1 Safety .................................................................... 7
1.1 Introduction ......................................................... 9
1.1.1 Safety symbol ................................................... 9
1.1.2 Safety messages ................................................. 9
1.1.3 Information messages ............................................. 9
1.1.4 Safety signs ..................................................... 9
1.1.5 A word to the operator ............................................ 10
1.1.6 This manual .................................................... 11
1.1.6.1 Operator manual holder .................................. 11
1.2 Operation .......................................................... 12
1.2.1 Prepare for operation ............................................. 12
1.2.2 General information .............................................. 12
1.2.3 Personal protective equipment ...................................... 13
1.2.4 Seat instructions ................................................ 14
1.2.5 Shield and guards ................................................ 14
1.2.6 Exhaust warning .................................................15
1.2.7 Flying debris ................................................... 15
1.2.8 Agricultural chemicals ............................................. 15
1.3 Travel on public roads ............................................... 16
1.4 Maintenance ........................................................17
1.4.1 General maintenance information .................................... 17
1.4.2 Fire prevention and first aid ......................................... 19
1.4.3 High pressure leaks .............................................. 20
1.4.4 Replacement parts ............................................... 20
1.4.5 Tire safety ..................................................... 21
1.4.6 Weld on the machine precautions .................................... 21
1.5 Cylinder stops ...................................................... 22
1.5.1 Lift cylinder lockout valves ......................................... 22
1.5.1.1 Engage the lift cylinder lockout valves ....................... 22
1.5.1.2 Disengage the lift cylinder lockout valves ..................... 23
1.5.2 Steering cylinder lockout valves ..................................... 23
1.5.2.1 Engage the steering cylinder lockout valves ................... 24
1.5.2.2 Disengage the steering cylinder lockout valves ................. 24
1.6 Safety and informational signs ....................................... 25
1.6.1 Driveline entanglement ............................................28
1.6.2 Flying objects hazard ............................................. 28
1.6.3 Crush hazard ................................................... 28
1.6.4 Explosion hazard ................................................ 28
1.6.5 Shear hazard ................................................... 29
1.6.6 Shear hazard ................................................... 29
1.6.7 Entanglement hazard ............................................. 29
1.6.8 Operators manual ............................................... 29
1.6.9 Shear hazard ................................................... 30
1.6.10 540 RPM ...................................................... 30
1.6.11 1000 RPM ..................................................... 30
1.6.12 Drawbar hitch .................................................. 30
1.6.13 Drawbar hitch .................................................. 31
1.6.14 Oil notice ...................................................... 31
1.6.15 Drawbar notice ................................................. 31
1.6.16 Cylinder lockout decal .............................................32
1.6.17 Cylinder lockout decal .............................................32
Table of contents
Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

1.6.18 Jack storage decal ............................................... 32
1.6.19 Grease decal ................................................... 32
1.6.20 California Proposition 65 ........................................... 33
2 Introduction .............................................................. 35
2.1 Introduction ........................................................ 37
2.1.1 Units of measurement ............................................ 37
2.1.2 Replacement parts ............................................... 37
2.1.3 Intended use ................................................... 37
2.1.4 Proper disposal of waste .......................................... 37
2.2 Machine identification ...............................................38
2.2.1 Serial number plate .............................................. 38
2.2.2 Serial number description .......................................... 38
2.3 Description of a pull type rotary mower conditioner ................... 40
2.3.1 Cutterbed ..................................................... 40
2.3.2 Conditioner .................................................... 40
2.3.3 Swathboard .................................................... 40
2.3.4 Forming shields ................................................. 40
2.3.5 Component access .............................................. 41
2.3.6 Component location ............................................. 42
3 Operation ................................................................ 47
3.1 Checklists .......................................................... 49
3.1.1 Examine the machine for daily operation ............................... 49
3.1.2 Examine the machine at the end of the day ............................. 49
3.1.3 Examine the machine at the end of the season .......................... 49
3.1.4 Examine the machine at the start of the season ..........................50
3.2 Tractor connection .................................................. 51
3.2.1 Connect the side pull hitch ......................................... 51
3.2.2 Connect the 3-point swivel hitch ..................................... 52
3.2.3 Connect the drawbar swivel hitch .................................... 54
3.2.4 Connect the hydraulic connections ................................... 56
3.2.5 Connect the electrical connection .................................... 56
3.3 Tractor disconnect .................................................. 58
3.3.1 Disconnect the side pull hitch ....................................... 58
3.3.2 Disconnect the 3-point swivel hitch ................................... 58
3.3.3 Disconnect the drawbar swivel hitch .................................. 59
3.4 Field operation ......................................................60
3.4.1 Crop conditioning ................................................ 60
3.4.2 Cuto quality and windrow formation ................................. 60
3.4.3 Power take-o and ground speed .................................... 60
3.4.4 Hay drying time ................................................. 61
3.4.5 Engage the header ............................................... 61
3.4.6 Header lift ..................................................... 61
3.4.7 Header steering - center pivot ....................................... 62
3.4.7.1 Cut back and forth ...................................... 63
3.4.7.2 Cut a square corner ..................................... 64
3.4.8 Cut height ..................................................... 64
3.4.8.1 Change the header angle - manual .......................... 65
3.4.8.2 Change the header angle - hydraulic ......................... 65
3.4.9 Unplug the header ............................................... 66
3.5 Conditioner adjustments - Roll ....................................... 67
3.5.1 Conditioner .................................................... 67
3.5.2 Conditioner spacing .............................................. 67
3.5.2.1 Adjust the conditioner roll spacing .......................... 67
3.5.3 Conditioner roll pressure ...........................................67
3.5.4 Adjust the conditioner roll pressure ................................... 68
Table of contents
Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

3.5.5 Conditioner roll timing ............................................ 68
3.5.5.1 Adjust the conditioner roll timing ........................... 69
3.6 Conditioner adjustment - Tine ....................................... 70
3.6.1 Adjust the tine conditioner ......................................... 70
3.7 Swathboard ........................................................ 71
3.7.1 Adjust the swathboard ............................................ 71
3.8 Forming shield adjustment .......................................... 72
3.8.1 Adjust the windrow forming shields .................................. 72
3.9 Header flotation .................................................... 73
3.9.1 Adjust the header flotation ......................................... 73
3.10 Travel on the road ................................................... 74
4 Maintenance ............................................................. 77
4.1 Service schedule .................................................... 79
4.2 Lubrication details .................................................. 81
4.2.1 Inspection during lubrication ........................................ 81
4.2.2 Sealed bearings ................................................. 81
4.2.3 Grease fittings .................................................. 81
4.2.4 Gearboxes ..................................................... 89
4.2.4.1 Plug location - swivel gearboxes ............................ 89
4.2.4.2 Plug location - header drive gearbox ......................... 89
4.2.4.3 Plug location - cutterbed drive gearbox ....................... 89
4.2.4.4 Examine the gearbox oil level .............................. 89
4.2.4.5 Change the gearbox oil .................................. 90
4.2.5 Conditioner gearcases ............................................ 91
4.2.5.1 Plug location - conditioner gearcases ........................ 91
4.2.5.2 Examine the gearcase oil level ............................. 91
4.2.5.3 Change the gearcase oil ................................. 92
4.2.6 Cutterbed ..................................................... 92
4.2.6.1 Cutterbed oil level ...................................... 92
4.2.6.2 Change the cutterbed oil ................................. 92
4.2.7 Lubricate the wheel bearings ....................................... 94
4.3 Replace a bearing ................................................... 96
4.4 Cutterbed inspection ................................................ 97
4.5 Discs ............................................................... 98
4.5.1 Disc maintenance ............................................... 98
4.5.2 Replace a disc .................................................. 98
4.6 Knives .............................................................100
4.6.1 Knife wedging under disc ......................................... 100
4.6.2 Knife inspection ................................................ 100
4.6.3 Disc rotation ................................................... 101
4.6.4 Replace a fixed blade knife ........................................ 101
4.6.5 Replace a quick change knife .......................................102
4.6.6 Replace a knife quick change spring ..................................103
4.6.7 Knife type .................................................... 103
4.6.8 Knife hardware inspection ......................................... 104
4.7 Belts ..............................................................105
4.7.1 Belt maintenance ............................................... 105
4.7.2 Adjust the conditioner belt ........................................ 105
4.7.3 Replace the conditioner belt ....................................... 105
4.7.4 Adjust the header drive belt ........................................107
4.7.5 Replace the header drive belt ...................................... 107
4.8 Slip clutch ......................................................... 109
4.8.1 Run in the slip clutch ............................................ 109
4.9 Install the wheels .................................................. 110
Table of contents
Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

4.10 Storage ............................................................ 111
5 Troubleshooting ......................................................... 113
5.1 Header troubleshooting .............................................115
5.2 Cutterbed troubleshooting .......................................... 116
5.3 Conditioner troubleshooting ........................................ 117
5.4 Crop conditioning and windrow formation ........................... 118
5.5 Cuto quality ...................................................... 119
6 Specifications ........................................................... 121
6.1 Specifications ......................................................123
6.1.1 Dimensions and weights ..........................................123
6.1.2 Header specifications ............................................ 123
6.1.3 Cutterbed specifications .......................................... 123
6.1.3.1 Cutterbed bolt torque .................................. 123
6.1.4 Drive system specifications ........................................124
6.1.5 Tire specifications ...............................................124
6.1.6 Tractor specifications ............................................ 124
6.1.7 Maximum roading speed ......................................... 124
6.1.8 Conditioner specifications ........................................ 125
6.1.9 Lubrication specifications ......................................... 125
7 Accessories ..............................................................127
7.1 Accessories and options ............................................ 129
7.1.1 Hydraulic header tilt kit ........................................... 129
7.1.2 Weight kit .................................................... 129
7.1.3 Aggressive cage kit ............................................. 130
7.1.4 Drawbar hitch ..................................................130
7.1.5 3-point hitch ................................................... 130
7.1.6 Bumper kit .................................................... 131
8 Assembly ............................................................... 133
8.1 General information ................................................ 135
8.1.1 Shipping damage and missing parts ..................................135
8.1.2 Safety precautions .............................................. 135
8.2 Assembly ..........................................................136
8.2.1 Prepare the header for assembly .................................... 136
8.2.2 Install the tongue ............................................... 138
8.2.3 Install the wheels ............................................... 140
8.2.4 Install the clutch shaft and the steering arm ............................ 141
8.2.5 Install the curtain magnets ........................................ 142
8.2.6 Install the 3-point hitch ........................................... 143
8.2.7 Install the drawbar hitch .......................................... 145
8.2.8 Finish the assembly ............................................. 147
8.2.9 Examine the cutterbed for lubricant .................................. 147
8.3 Checklists ......................................................... 148
8.3.1 Pre-delivery checklist ............................................ 148
8.3.2 Delivery checklist ............................................... 148
9 Index ................................................................... 149
Table of contents
Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

1 Safety
1.1 Introduction ............................................................. 9
1.1.1 Safety symbol ....................................................... 9
1.1.2 Safety messages ..................................................... 9
1.1.3 Information messages ................................................. 9
1.1.4 Safety signs ........................................................ 9
1.1.5 A word to the operator ................................................ 10
1.1.6 This manual ........................................................ 11
1.1.6.1 Operator manual holder ...................................... 11
1.2 Operation .............................................................. 12
1.2.1 Prepare for operation ................................................. 12
1.2.2 General information .................................................. 12
1.2.3 Personal protective equipment .......................................... 13
1.2.4 Seat instructions .................................................... 14
1.2.5 Shield and guards ................................................... 14
1.2.6 Exhaust warning .................................................... 15
1.2.7 Flying debris ....................................................... 15
1.2.8 Agricultural chemicals ................................................ 15
1.3 Travel on public roads ................................................... 16
1.4 Maintenance ........................................................... 17
1.4.1 General maintenance information ........................................ 17
1.4.2 Fire prevention and first aid ............................................ 19
1.4.3 High pressure leaks .................................................. 20
1.4.4 Replacement parts ...................................................20
1.4.5 Tire safety ......................................................... 21
1.4.6 Weld on the machine precautions ........................................ 21
1.5 Cylinder stops .......................................................... 22
1.5.1 Lift cylinder lockout valves ............................................. 22
1.5.1.1 Engage the lift cylinder lockout valves ........................... 22
1.5.1.2 Disengage the lift cylinder lockout valves ......................... 23
1.5.2 Steering cylinder lockout valves ......................................... 23
1.5.2.1 Engage the steering cylinder lockout valves ....................... 24
1.5.2.2 Disengage the steering cylinder lockout valves ..................... 24
1.6 Safety and informational signs ...........................................25
1.6.1 Driveline entanglement ............................................... 28
1.6.2 Flying objects hazard ................................................. 28
1.6.3 Crush hazard ....................................................... 28
1.6.4 Explosion hazard .................................................... 28
1.6.5 Shear hazard ....................................................... 29
1.6.6 Shear hazard ....................................................... 29
1.6.7 Entanglement hazard ................................................. 29
1.6.8 Operators manual ................................................... 29
1.6.9 Shear hazard ....................................................... 30
1.6.10 540 RPM ..........................................................30
1.6.11 1000 RPM ......................................................... 30
1.6.12 Drawbar hitch ...................................................... 30
1.6.13 Drawbar hitch ...................................................... 31
1.6.14 Oil notice ......................................................... 31
1.6.15 Drawbar notice ..................................................... 31
1.6.16 Cylinder lockout decal ................................................ 32
1.6.17 Cylinder lockout decal ................................................ 32
Table of contents
Rotary Disc Mower 7
700751490C
Find manuals at https://best-manuals.com

1.6.18 Jack storage decal ................................................... 32
1.6.19 Grease decal ....................................................... 32
1.6.20 California Proposition 65 ...............................................33
Table of contents
8 Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

1.1 Introduction
1.1.1 Safety symbol
The safety symbol tells you about a potentially
hazardous area!
Look for the safety symbol in this manual and on
the machine. The safety symbols tell you that
there is important safety instructions in the
manual.
GUID-4C201302-DBD2-4BFB-8D98-1DDED263BD6E-high.jpg [High]
Fig. 1
1.1.2 Safety messages
The words DANGER, WARNING or CAUTION are
used with the safety symbol. Learn these safety
messages and obey the recommended
precautions and safety instructions.
DANGER:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY will occur.
WARNING:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY can occur.
CAUTION:
If you do not obey the recommended
precautions and safety instructions,
INJURY can possibly occur.
GUID-73F05026-C37B-415A-8140-AD939A283378-high.jpg [High]
Fig. 2
1.1.3 Information messages
The words important and note are not related to personal safety, and are used to give information about
the operation and servicing of the machine.
IMPORTANT: Identifies special instructions or procedures which, if not followed, can cause damage to the
machine, the process, or the area around the machine.
NOTE: Information to make procedures easier.
1.1.4 Safety signs
WARNING:
Do not remove the safety signs. Replace safety signs that you cannot read, are damaged,
or are missing.
Clean the machine surface with a weak soap and water solution before you replace the safety signs.
Replacement safety signs are available from your dealer.
[V]
GUID-5D9F270E-D748-4741-82B1-BE49B78685F2 [V5]
GUID-E54F7740-C021-42A8-8784-4287BE4356C8 [V4]
GUID-9A909F52-D57E-4C30-8CC7-6FDB6D7E9982 [V3]
GUID-2FB17168-6A01-47C5-B298-234AF171520B [V6]
1. Safety
Rotary Disc Mower 9
700751490C
Find manuals at https://best-manuals.com

Always make sure that safety signs are in the correct locations and that you can read the safety signs.
Illustrations of safety sign locations are at in this section.
Keep the safety signs clean. If necessary, use a weak soap and water solution.
1.1.5 A word to the operator
It is your responsibility to read and understand the
safety section in this manual and the manual for all
implements before you operate this machine. You
are responsible for your safety. Good safety
procedures prevent injury to you and the persons
around you.
Make the information in the safety section of this
manual a part of your safety procedure. This safety
section is written only for this type of machine.
Safety is your responsibility. You can prevent injury
and death.
This safety section gives basic safety examples
that can occur during the operation and
maintenance of your machine. This safety section
is not a replacement for safety instruction in other
sections of this manual.
Injury or death can occur if the safety instruction is
not obeyed.
Learn how to operate the machine and how to use
the controls correctly.
Do not operate the machine if you do not know
how to operate the machine. Do not let persons
operate the machine that do not know how to
operate the machine.
Follow all safety instructions in the manuals and on
the safety signs on the machine, the implements,
and the attachments.
Use only approved attachments and implements.
Make sure that your machine has the correct
equipment that is necessary by the local
regulations.
WARNING:
Do not use alcohol or drugs that can
have an eect on alertness or
coordination. If you use prescription
or 'over the counter' drugs, get
medical advice about the safe
operation of machines.
CAUTION:
If attachments or implements used
with this machine have a dierent
operator manual, see that operator
manual for other important safety
instructions.
GUID-AC91CCF6-1FF8-4A85-97A1-2D1562806825-high.jpg [High]
Fig. 3
GUID-F38BCC9A-5A98-41F3-BA3C-2C5AB224EDFB [V6]
1. Safety
10 Rotary Disc Mower
700751490C
Find manuals at https://best-manuals.com

1.1.6 This manual
This manual covers general safety practices for this machine. The operator manual must always be kept
with the machine.
Right-hand and left-hand, as used in this manual, are determined by facing the direction the machine will
travel when in use.
The photos, illustrations, and data used in this manual were current at the time of printing, but due to
possible in-line production changes, your machine can vary slightly in detail. The manufacturer reserves the
right to redesign and change the machine as necessary without notification.
WARNING:
In some of the illustrations and photos used in this manual, shields or guards may have
been removed for clarity. Never operate the machine with any shields or guards removed.
If the removal of shields or guards is necessary to make a repair, they must be replaced
before operation.
The Operator Manual is stored in the holder on the machine. After using the Operator Manual, return the
manual to the storage location.
1.1.6.1 Operator manual holder
The operator manual holder (1) holds the operator
manual.
After you use the operator manual, put the
operator manual back into the operator manual
holder.
1
HAJHE0110252601
Original art: /s/Creo Illustrate/Images/Steve/1373 Om holder.svg
GUID-894587AE-8173-4862-B198-699E4B30BA28-low.svg [Low]
Fig. 4
GUID-F180C720-C8A9-4411-AA97-B6147E05E2A0 [V1.3.2]
GUID-D61C240D-9317-41F4-8BC2-E3B75BC5B472 [V3]
1. Safety
Rotary Disc Mower 11
700751490C

1.2 Operation
1.2.1 Prepare for operation
Read and understand all operation instructions and precautions in this manual before you operate the
machine or do the servicing.
Make sure that you know and understand the positions and operations of all controls. Make sure that all
controls are in neutral and that the parking brake is applied before you start the machine.
Make sure that all persons are away from your area of work before you start and operate the machine.
Examine and learn the controls in an area that is clear of persons and obstacles before you start work.
Know the machine dimensions and make sure that you have sucient space available to operate the
machine. Do not operate the machine at high speeds in crowded areas.
It is important to know and use the correct procedures when you do work around and operate the
machine. Do not let children or unqualified persons operate the machine. Keep others, especially children,
away from your area of work. Do not let others to ride on the machine.
Make sure that the machine is in good condition for operation. Refer to the operator manual. Make sure
that the machine has the correct equipment required by local regulations.
All equipment has a limit. Make sure you understand the speed, brakes, steering, stability and load
characteristics of this machine and the tractor before you start.
1.2.2 General information
When you park the machine, park the machine and
the tractor on a solid level surface. Put all controls
in neutral and apply the tractor parking brake. Stop
the tractor engine and take the key with you.
WARNING:
Do not let the machine be unattended
with the header in the up position.
Lower the header fully before you go
away from the machine. A sudden
loss of hydraulic pressure can cause
the header to fall without warning.
Make sure that the machine is in
good condition for operation. Refer to
the operator manual. Make sure that
the tractor brakes and the machine
brakes are adjusted correctly.
The tractor must have sucient weight and
braking capacity, especially when you operate on
roads and terrain that is not smooth. Use a tractor
of sucient dimensions and weight to tow the
machine.
The tractor must have a rollover protective
structure (ROPS) and a seat belt. Use the seat belt
during operation.
WARNING:
Only use a tractor with a ROPS cab
and seat belt. The machine can throw
stones and other debris during
operation.
GUID-E77631FB-0DC0-4637-9090-88018315176E-high.jpg [High]
Fig. 5
[V]
GUID-A25B667B-D7CF-4C75-8AED-C10113104322 [V5]
GUID-687F04C0-4367-426F-A558-DD2B192A898B [V2]
1. Safety
12 Rotary Disc Mower
700751490C

Do not move o the machine before the machine stops.
Always operate the machine with the terminal on.
Do not start the tractor with the PTO engaged or terminal on.
Stay o slopes that are too steep for operation.
Where possible do not operate the machine near ditches, embankments, and holes. Slowly decrease
ground speed when you operate on rough, slippery, or muddy surfaces and when you turn or go across
slopes.
Know the dimensions of the machine and have sucient area available for operation.
Make sure that the top shields are closed before you move the tongue.
Stay away from the area between the tractor and the implement when the tractor engine is running.
Do not let the machine contact electrical power
lines. Contact with electrical power lines can cause
electrical shock, that results in very serious injury
or death.
Always disengage the tractor power take-o, put
the tractor transmission in PARK and apply the
parking brake before you move o of the tractor.
Stop the tractor engine and remove the key before
you do servicing or maintenance on the machine.
GUID-DB0A93E4-AEB5-49D5-AC5F-DD1454F1CFC6-high.jpg [High]
Fig. 6
Related Links
Tractor specifications page 124
1.2.3 Personal protective equipment
Put on all personal protective equipment (PPE) and
protective clothes that are supplied to you or that
are necessary for the conditions and by applicable
laws. PPE includes equipment to prevent injury to
your eyes, lungs, ears, head, hands and feet.
Always keep hands, feet, hair, and your clothes
away from parts that move. Do not put on loose
clothing, jewelry, watches, or other items that can
tangle in parts that move. Tie up long hair that can
also tangle in moving parts.
GUID-1AEEBD1D-C71B-432C-9D23-52467D7C0BBF-high.jpg [High]
Fig. 7
GUID-7FEFA67B-E06F-4EFE-A23E-738FE96997E9 [V3]
1. Safety
Rotary Disc Mower 13
700751490C

1.2.4 Seat instructions
Put on the seat belt before you operate the
machine. Always sit in the seat and have the seat
belt on while you operate the machine. Replace
the seat belts when they become worn or broken.
Do not use a seat belt loosely. Make sure that
there is some tension on the seat belt. Do not
wear the seat belt in a twisted condition or
pinched between the structural parts of the seat.
Put on the seat belt if the instructional seat is
used. Use the instructional seat only to train new
operators or to find a problem. The instructional
seat is only for short periods of use.
Do not let children use the instructional seat or be
in the cab. Do not let other persons use the
instructional seat or be in the cab.
Drive the machine at slower speed and on level
ground when the instructional seat is used. Do not
start, stop, or turn quickly when the instructional
seat is used. Do not drive on highways or public
roads when the instructional seat is used.
GUID-5BA328EA-7732-4CE8-97B2-6511151E943C-high.jpg [High]
Fig. 8
1.2.5 Shield and guards
WARNING: Entanglement hazard.
Belts and components that rotate.
Severe personal injury or death can
occur.
Do not open, remove, or put your
hand behind shields if the engine is
running. Stop the machine before
doing service to the machine.
All shields and guards must be in the correct
position and in good condition. Keep away from
the components that rotate.
GUID-6163F2D6-39D6-48BF-871C-AC346EE022D2-high.jpg [High]
Fig. 9
DANGER: Entanglement hazard.
Rotating components.
Severe personal injury or death can
occur.
Do not make adjustments or repairs
to components while they are
moving. Stop the machine before
doing service to the machine.
Do not operate the machine with the drive shaft
shields open or removed.
Keep away from the components that turn.
Make sure guards that turn are free.
GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High]
Fig. 10
Do not make adjustments to the roll tension with the header engaged.
GUID-F38524AD-E24F-4FCC-9154-E5357EFDE9D2 [V3]
GUID-9398BDE6-F83A-4855-B266-E86D0B48B9D7 [V9]
1. Safety
14 Rotary Disc Mower
700751490C

When you make adjustments to the roll pressure, stop the header. Engage the parking brake.
1.2.6 Exhaust warning
WARNING: Inhalation hazard. Exhaust
gases.
Death or serious illness can occur.
Do not operate the engine in a closed
building unless the exhaust is
ventilated to the outside.
Do not tamper with or modify the exhaust system
with unapproved extensions.
GUID-55072A39-D882-4355-8ABA-05660F3F6EDA-high.jpg [High]
Fig. 11
1.2.7 Flying debris
WARNING:
Be careful when you operate along
the side of a road or structures. Rocks
and other materials can be thrown
from the machine during operation
and can cause injury.
If there are rocks and unwanted
objects in a field, tilt the header up.
This will lift the knives and reduce
other materials thrown by the knives.
Stay away from the machine during operation.
Some materials can be thrown from the machine
during operation and cause injury. GUID-1D480E10-339B-427D-9D05-37E84CC7A29A-high.jpg [High]
Fig. 12
1.2.8 Agricultural chemicals
Agricultural chemicals are very dangerous. Incorrect procedures with fertilizer, fungicides, herbicides,
insecticides and pesticides can cause injuries to plants, animals, soil and other persons property.
Always read and follow all manufacturers instructions before you open chemical containers.
Read and follow instructions each time you use a chemical.
Use the same precautions when you do adjustments, do servicing, clean or store the machine as used
when you put chemicals into the hoppers or tanks.
Tell all persons who are near chemicals of the possible dangerous results and the safety precautions that
are necessary.
Stay upwind and away from smoke from a chemical fire.
Keep or discard all chemicals that are not used as specified by the chemical manufacturer.
GUID-AC6BA923-B398-43F4-BFAE-5130AFED6FC5 [V4]
GUID-3910D764-BEA7-4A1B-80BF-946E438C6212 [V5]
GUID-A494D2FA-1956-40C4-9743-052166A2A431 [V4]
1. Safety
Rotary Disc Mower 15
700751490C

1.3 Travel on public roads
Make sure that you understand the speed, brakes,
steering, load characteristics, and how to keep the
machine stable before you operate on public
roads.
Use good judgment when you operate the
machine on public roads. Keep complete control of
the machine at all times. Do not coast on
downhills.
The maximum speed of farm equipment is set by
local regulations. Adjust speed to keep control at
all times.
Make sure that the machine is in good condition
for operation. Refer to the operator manual.
GUID-657D3002-48DB-436B-9B56-D3750095397D-high.jpg [High]
Fig. 13
The tractor must have sucient weight and braking capacity, especially when you operate on roads and
terrain that is not smooth. Use a tractor of sucient dimensions and weight to tow the machine.
Make sure that you understand and obey all road regulations that apply to your machine. See your local law
enforcement agency for local regulations about movement of farm equipment on public roads. Use head
lamps, flashing warning lamps, rear lamps and turn signals, day and night, unless prohibited by local law.
Make sure that all the flashers are operate before you drive on the road. Make sure that reflectors are
correctly installed, in good condition, and can be seen. Make sure that the Slow Moving Vehicle (SMV)
emblem is clean, can be seen, and correctly installed on the rear of the machine.
Pay attention to other trac on the road. Keep to your side of the road and pull to the side of the road
whenever possible to let faster trac pass.
Know the overall width, length, height, and weight of the machine. Be careful when you drive the machine
on narrow roads and across narrow bridges.
If equipped, always install the safety transport chain between the implement and the tractor drawbar.
Put the tongue in roading position and close the steering cylinder lockout valves. Lift the header fully and
close the lift cylinder lockout valves.
Watch for overhead wires and other obstructions.
Do not let the machine touch electrical power
lines. If the machine touches electrical power
lines, electrical shock can occur. Electrical shock
can result in very severe injury or death.
GUID-DB0A93E4-AEB5-49D5-AC5F-DD1454F1CFC6-high.jpg [High]
Fig. 14
Related Links
Maximum roading speed page 124
Tractor specifications page 124
GUID-FE6F4C1C-E54F-4F8A-B0DD-7BB1FFF31C41 [V4]
1. Safety
16 Rotary Disc Mower
700751490C

1.4 Maintenance
1.4.1 General maintenance information
Before you do maintenance, lubricate, do
servicing, clean, or make adjustments:
• Park the machine on a solid, level surface.
• Disengage the tractor power take-o.
• Make sure that all the controls are in the
neutral position and apply the parking brake.
• Make sure that the machine and the
attachments are lowered to the ground.
• Stop the engine and take the key with you.
• Look and Listen! Make sure that all parts that
move are stopped.
• Put chocks in front of and behind the wheels of
the machine before you do work on or below
the machine.
GUID-DB4C2E27-9DAC-4734-83E4-BC4BB5C26EAF-high.jpg [High]
Fig. 15
Stay near the machine when the tractor is in operation.
Know the dimensions and the weights of parts when you do the servicing. Do not stand below or near a
part while it is moved with a hoist or other lift equipment.
Do a check on the disc and knife bolts torque regularly, and when you hit objects in the field.
After you do work on the machine, remove all tools from the machine.
Make sure that electrical connectors are clean before you connect them.
Do a check for loose, broken, missing, or damaged parts. Make sure that the machine is in good repair.
Make sure that all guards and shields are in position.
Do not do the servicing, examine or adjust chains
or belts while the engine is in operation.
GUID-7D1C9640-D737-4F38-8886-F1D2280DF613-high.jpg [High]
Fig. 16
[V]
GUID-93C8628D-B392-4191-80DB-7D54BDAAF61B [V18]
1. Safety
Rotary Disc Mower 17
700751490C

Do not operate the machine with the drive shaft
shields open or removed. Entanglement in drive
shafts that rotate can cause injury or death.
Stay clear of components that rotate.
Make sure that guards that rotate can rotate freely.
A loose yoke can come o a shaft and result in
injury to persons or damage to the machine.
When you install a quick disconnect yoke, the
spring activated locking pins must move freely and
be in the groove on the shaft. Pull on the driveline
to make sure that the quick disconnect yoke can
not be pulled o the shaft. GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High]
Fig. 17
Remove spilled oil, antifreeze or fuel immediately
from the steps, platform, and other access areas.
Keep all access areas clean of unwanted materials.
GUID-3B306DB1-0777-4FA6-86F1-895652B4C1DB-high.jpg [High]
Fig. 18
When you do work on the machine, make sure
that the header is lowered.
When it is necessary for the header to be in the up
position, lift the header to the full up position and
engage the lift cylinder lockout valves.
GUID-353ABA0B-44F7-4320-8E22-3E3CA612BD91-high.jpg [High]
Fig. 19
Related Links
Cutterbed bolt torque page 123
1. Safety
18 Rotary Disc Mower
700751490C

1.4.2 Fire prevention and first aid
Be prepared for emergencies.
Keep a first aid kit available for use on small cuts
and scratches.
Keep one or more fire extinguishers of the correct
type. Examine fire extinguishers regularly as stated
by the manufacturer. Make sure that the fire
extinguishers are charged and in operating
condition.
Crop material is flammable, there is a risk of fire.
Use a water type fire extinguisher or other water
source for a fire in crop.
For fires in material other than crop, such as oil or
electrical components, use a dry chemical fire
extinguisher with an ABC rating.
Keep fire extinguishers easy to access where fires
can occur.
Frequently remove crop material from the machine
and examine for components that are too hot. Do
checks on the machine each day for noises that
are not usual. Unusual noises can indicate a worn
out component that can cause too much heat.
If flame cutting, welding, arc welding, or grinding
is to be done on the machine or attachments, clear
crop material and unwanted material from around
the area. Make sure that the area below the work
area is clear of flammable material because falling
molten metal and sparks can cause ignition in the
material.
GUID-FF34ACC9-D080-4CD5-9528-F426605803FF-high.jpg [High]
Fig. 20
If fire occurs, move upwind and away from the
smoke from the fire.
GUID-8FDCA67C-244A-40BA-967B-3FA4E7667A7E-high.jpg [High]
Fig. 21
GUID-9D716526-CF1A-4CD9-89A6-FD350D1B1E7A [V7]
1. Safety
Rotary Disc Mower 19
700751490C

1.4.3 High pressure leaks
WARNING: Hydraulic fluid under
pressure can penetrate the skin or
eyes.
Serious personal injury, blindness, or
death can occur.
Relieve the pressure from the system
or component before disconnecting
components. Wear personal
protective gear while working on the
machine or equipment. Use a piece of
cardboard to check for leaks. Never
use your hand.
Fluid that leaks from the hydraulic system or the
fuel injection system is high pressure and is not
easily seen. The fluid can go into the skin causing
injury.
Fluid that is injected into the skin must be
surgically removed immediately. If not removed
immediately, infection and reaction can occur. Go
immediately to a physician who knows about this
type of injury.
GUID-CB450E2E-50DF-4D16-9E59-21C0B3E5B026-high.jpg [High]
Fig. 22
Use a piece of cardboard or wood to look for
possible leaks. Do not use your bare hand. Wear
leather gloves for hand protection and safety
goggles for eye protection.
Remove all pressure before you loosen hydraulic
lines. Lower equipment in the up position, close
the accumulator valve, and stop the engine.
Tighten all connections before you apply pressure.
GUID-9A83C5CD-95EC-445B-A3A7-1DCF8FACFE45-high.jpg [High]
Fig. 23
1.4.4 Replacement parts
Where replacement parts are necessary for
machine maintenance and servicing, you must use
original equipment replacement parts.
The manufacturer will not accept responsibility for
installation of unapproved parts and/or accessories
and damages as a result of their usage.
GUID-FA132350-A260-454E-8B83-2C8533C34BC4-high.jpg [High]
Fig. 24
GUID-68111A90-0641-4B8F-9AB9-A5B05A044C46 [V4]
GUID-6AE94B75-99EC-4885-8B3D-0F13F3053F2B [V3]
1. Safety
20 Rotary Disc Mower
700751490C
