Maytronics MBC2 User manual

Robot Pool Cleaner MBC2
User Instructions
MBC2
8151254
by

Robot Pool Cleaner MBC2 | User Instructions 1
Robot Pool Cleaner MBC2 User Instructions
1
WARNINGS AND CAUTIONS
Warnings
• Use the originally supplied power supply only
• Ensure the electrical outlet is protected by a ground fault interrupter (GFI) or an earth
leakage interrupter (ELI)
• Keep the power supply out of standing water
• Position the power supply at least 3m away from the edge of the pool
• Do not enter the pool while the Pool Cleaner is working
• Unplug the power supply before servicing
Cautions
When not in use store the Pool Cleaner in a shaded area, upside down (not on its brushes).
Use the Pool Cleaner in the following water conditions only:
Chlorine Max 4 ppm
pH 7.0 - 7.8
Temperature 6 – 34°C
NaCl Maximum = 5000 ppm
Specifications
Motor protection: IP 68
Minimum depth: 0.80m
Maximum depth: 5m
GFI/ELI
40°C Max
1
A
2
Set-up

2Robot Pool Cleaner MBC2 | User Instructions
• If Wonder brush rings are dry,
soak them in water until soft.
• Shake robot from side to side or
turn it upside down to release
trapped air.
• Attach the oating cable to the power
supply by inserting it with the notch
on the connector (1) lined up with the
groove in the socket on the power
supply and turning clockwise (2).
2
3
• Turn the power supply ON.
The Pool Cleaner will now
operate until it has reached
the end of the cleaning cycle.
Into the Pool
Operation
1
2

Robot Pool Cleaner MBC2 | User Instructions 3
4
OFF
• The Robot will perform automatic shut-off at the
end of the cleaning cycle.
5
Out of the Pool
10 cm
Out of the Pool
• Using the oating cable, bring the Pool Cleaner to the pool's edge.
Using the handles remove the Pool Cleaner from the pool.
• Do not pull the Pool Cleaner from the pool using the cable.

4Robot Pool Cleaner MBC2 | User Instructions
6
Maintenance
• Place the Pool
Cleaner on the
edge of the pool
and let the water
drain out.
A
B

Robot Pool Cleaner MBC2 | User Instructions 5
7
• Clean the lter bag with a hose.
It is recommended to periodically wash the
lter bag in a washing machine. Use gentle
cycle cleaning program.
• Periodically clean the brushes with a hose.
Maintenance
• Ret the lter bag with
the tag on the outside
positioned centrally
along the length side
of the bottom lid.

6Robot Pool Cleaner MBC2 | User Instructions
8
9
Maintenance
Maintenance
• Place the impeller cover
at an angle so that the
notch is on the second
ring of the spring.
Press down on the
impeller cover in the
direction of the spring,
pushing it into place.
Replace the screws.

Robot Pool Cleaner MBC2 | User Instructions 7
10
Off season storage:
If the Pool Cleaner will not be in use for an extended period, perform the following storage steps:
•Make sure that no water is left in the Pool Cleaner.
• Thoroughly clean the lter bag and insert in place.
• Roll up the cable so that it has no kinks.
•Store the Pool Cleaner in a protected area upside down (not on its brushes).
Storage

Robot Pool Cleaner MBC2
MBC2
8151254
