Mazda 0000 8C Z01 User manual

Page: 1 of 10 11/5/2012
PART NUMBER:
0000 8C Z01
APPLICABLE MODELS:
2013 > MAZDA 6
REQUIRED COMPONENTS:
INSTALLATION KIT:
ITEM QTY DESCRIPTION Usage Chart
2 1 EC Harness - A-Pillar T-Harness
3 6 Wire Ties
4 1 Wire Cover
5 1 A-Pillar Tether Clip (D651-68-162A)
6 3 Foam Tape
7 1 User Guide
8 1 Installation Instructions
HOMELINK® AND THE HOMELINK HOUSE® ARE REGISTERED TRADEMARKS OF JOHNSON CONTROLS, INC.
2
1
3
4
5
6
7
8
TOOLS REQUIRED:
10mm Socket Ratchet Fiberstick Needle Nose Pliers
4mm Flat Screwdriver #T20 Torx Driver Torque Wrench Wire Cutters
Clean Rag
GENUINE ACCESSORIES
INSTALLATION INSTRUCTIONS
**Installation kit may have more components than necessary. Please refer to the chart above and the instructions for required components.
1 1 Mirror Assembly w/ Compass & HomeLink®
MIRROR ASSEMBLY:
1
3
3
1
1
550-0583 Rev. AAA
*550-0583-000*
1
1
1

Page: 2 of 10 11/5/2012
WIRE CODES
Two-color wires are indicated by a two-letter
symbol. The first indicates the base color of the
wire, the second indicates the color of the stripe.
For example:
W/R = White wire with a red stripe
BR/Y = Brown wire with a yellow stripe
Symbol (Example):
BW/R
Solid Color Wire Striped Wire
Black
White
(Base Color)
Red
(Stripe Color)
CONNECTOR DIAGRAMS
Connector diagrams show connectors on the
harness side. The terminal indicates the view
from the harness side.
Example:
Connector on Harness Side
View from
harness side
Unused terminals are indicated by .
“*”
*
DISCONNECTING CONNECTORS
When disconnecting the wires, grasp the
connectors, not the wires.
Example:
CORRECT
INCORRECT
“Click”
LOCKING CONNECTORS
When locking connectors, listen for a click,
indicating they are securely locked.
Example:
IDC WIRE TAP PROCEDURE
Place IDC on Vehicle
Wire.
Close side of IDC. Insert EC Mirror Harness
wire into IDC.
Crimp IDC metal tab
over both wires until
flush with top of IDC.
Close top of IDC.
Tapered End Wire Tie Head
WIRE TIE PROCEDURE
Wrap wire tie around the
harness you wish to secure
together.
Insert the Tapered End of
the wire tie into the Wire Tie
Head.
Trim wire tie end after
tightening.
Pull the Tapered End
through the Wire Tie Head
until the wire tie is snug.

Page: 3 of 10 11/5/2012
1. Place kit components on a clean, padded surface, and inspect for
damage, defects, or missing components.
2. Record customer’s programmed Radio - AM/FM/SAT stations and
trip computer (if applicable).
3. Disconnect negative battery terminal.
a) Remove relay cover and then remove battery cover in order to gain
access to battery terminals.
b) Using 10mm socket, remove negative battery terminal. (Fig. 1-1)
4. Remove driver-side door seal.
a) Pull back past top of A-pillar trim. (Fig. 1-2)
5. Remove driver-side A-pillar trim.
a) Pull out the top portion of A-pillar trim towards passenger-side of
vehicle until A-pillar connector is extended approximately ½”.
b) Use needle nose pliers to grasp tab of A-pillar connector. Rotate tab
90 degrees and push down through slot in A-pillar trim. (Fig. 1-3)
c) After A-pillar trim is detached from connector, pull A-pillar firmly to
detach lower clips.
Fig. 1-1
Preparation
10mm
Socket
C A U T I O N
!
Fig. 1-3
Fig. 1-2
Do not use excessive force. A-pillar could be damaged.
!
NOTE
INSTALLATION PRECAUTIONS / NOTES:
• Ifusingshwire,usecautiontoavoiddamagetoexistingcomponents.
• Donotplacewireharnessagainstobjectswithsharpedgesthatmaycauseelectricalshorting.
• Verifythatpowerharnesspathwillnotinterferewithbrake,clutch,emergencybrakeorairbagop-
eration.Usewiretiestoholdthewiringawayfromcriticallocations.

Page: 4 of 10 11/5/2012
d) Move the hook in the direction of arrows (1) and (2) using a Flat-
head screwdriver and detach it from the A-pillar inner panel. (Fig.
1-4)
e) Remove the grommet in the direction of the arrow (3). (Fig. 1-4)
f) Install new supplied A-pillar tether clip into A-pillar before proceed-
ing.
6. Remove OE Mirror.
a) Using a #T20 Torx, loosen the mirror mounting bracket screw. (Fig.
1-5)
b) Grasp mirror mount at the tube, and gently pull upwards parallel to
the windshield to carefully slide mirror off windshield button.
1. AttachECmirror.
a) Hold the mirror head and slide the mount downwards as far as pos-
sible over the windshield button, until fully seated. (Fig. 2-1)
b) Using a #T20 Torx, tighten the mirror mounting bracket screw to 15
lb-in.
1. PlugECharnessconnectorintobackofmirror.(Fig.3-1)
Fig. 1-5
DO NOT rotate mirror, turn mirror side to side, or pull mirror away from
the windshield. Rotation, side to side movement, or pulling of mirror on
windshield button could damage or break the windshield and button,
requiring windshield replacement.
CAUTION
!
FLATHEAD SCREWDRIVER
Fig. 1-4
A-pillar connector must be replaced with the supplied tether clip.
!
NOTE
Fig. 2-1
Fig. 3-1
TORQUE SPEC.
15 lb-in (18 kg-cm)
EC Mirror Installation
RouteECHarnesstoVehiclePower

Page: 5 of 10 11/5/2012
2. RouteECharnessfrommirrortoheadliner.
a) Route EC harness into groove of wire cover and attach wire cover
to mirror base. (Fig. 3-2)
(a) Slide upper portion of wire cover up to headliner so the “forks” are
held by the headliner. (Fig. 3-2)
3. RouteECharnesstodriver-sideA-pillar.
a) Route EC harness between vehicle headliner and roof to top of
driver-side A-pillar area. (Fig. 3-3)
4. RouteECharnessdowndriver-sideA-pillar.
a) Route EC harness down A-pillar and begin to secure to the top of
the OE harness with (2) wire ties, as shown. (Fig. 3-4)
1. ConnecttheECharnesstotheOEMconnector.
a) Locate the 12-pin connector in the driver-side A-pillar, as shown.
(Fig. 4-1)
Fig. 3-2
Fig. 3-4
Wire Ties
Fig. 3-3
ConnectECHarnesstoPowerandGround
Fig. 4-1
12-pin
Connector
See Wire Tie Procedure on Page 2 for detailed instructions and images
of proper wire tie installation techniques.
!
NOTE
Ensure EC harness does not interfere with airbag operation. Do not
secure wire ties to air bag or sunroof drain tube.
CAUTION
!

Page: 6 of 10 11/5/2012
b) Disconnect the 12-pin connector. (Fig. 4-2)
c) Plug the male connector side of the EC harness into the lower OE
connector and plug the female connector side of the EC harness
into the upper portion of the OE harness. (Fig. 4-3)
1. SecureremainingECharnessindriver-sideA-pillar.
a) Place (1) piece of foam tape on top of the small OE connector and
the lower connector to prevent the EC harness from rattling. (Fig.
5-1)
b) Fold the Wires of the jumper harness down so that the upper
connector rests on the foam tape. Bundle any remaining slack in
EC harness near the OE connectors in the bottom of the A-pillar.
Secure bundle and jumper harness to OE harness of smaller OE
connector with (1) wire tie, as shown. (Fig. 5-2)
Secure EC Harness.
Fig. 4-2
Fig. 4-3
Lower
Connector
Fig. 5-1
Upper
Connector
Fig. 5-2
Wire Tie
Foam
Tape
See Locking Connectors Procedure on Page 2 for detailed instructions
and images of proper connector installation techniques.
!
NOTE
See Disconnecting Connectors Procedure on Page 2 for detailed in-
structions and images of proper connector removal techniques.
!
NOTE
See Wire Tie Procedure on Page 2 for detailed instructions and images
of proper wire tie installation techniques.
!
NOTE
Ensure EC harness does not interfere with airbag operation. Do not
secure wire ties to air bag or sunroof drain tube.
CAUTION
!
12-pin
Connector

Page: 7 of 10 11/5/2012
1. Reconnect negative battery cable.
2. TurntheignitionswitchtoON.
3. Withthevehicleinafairlywell-litarea,performthefollowing:
a) Verify the shift light on the bottom of the mirror is on and orange.
b) Verify button images are lit with orange back-lighting.
c) To make sure the auto-dimming feature is on, verify that the green
LED to the left of the center button is on. If it is not on, push the “ ”
button to turn the green LED on.
d) Cover the forward looking photocell on the back of the mirror with a
dark cloth or towel. (Fig. 6-1)
e) In a few seconds, the mirror will begin to darken.
f) Remove the cover from the forward looking photocell and the mirror
will begin to clear.
g) Verify that either a direction, such as NE, of “C” is displayed in the
display window. If not, ensure the feature is turned ON by pressing
the “ ” button.
4. TurntheignitionkeytotheOFFposition.
5. PusheachHomeLink®button,oneatatime,andverifythattheLED
indicatortotheleftofthecenterbuttonilluminatesred.(Fig.6-2)
6. Testingisnowcomplete.
1. Trimexcessoffalltiewraps.
2. Reinstall in reverse order, all trim pieces removed during installa-
tion.
3. PlaceUserGuideinvehicleglove-box.(Fig.7-1)
4. Remove fingerprints, smudges, etc. from mirror.
5. Verifyeachreinstalledcomponentforproperfitandfunction.
Fig. 6-1
Fig. 6-2
Fig.7-1
Testing
Time to darken will vary with ambient light level.
!
NOTE
If compass remains on, refer to troubleshooting section and recheck
proper wiring installation.
!
NOTE
Installation of Removed Components
Compass
Display
Green
LED
Dark
Cloth
Photocell
HomeLink®Buttons
Red LED
User Guide

Page: 8 of 10 11/5/2012
1
2
3
4
5
6789
1 0
1 1
1 2
1 3
1 4
1 5
23
4567891 01 11 21 3
1 4
1. AdjustcompasszoneafterECmirrorinstallation.
a) The zone setting is factory preset to zone 8. Refer to Compass
Calibration Zone Map (Fig. 8-1) to find the correct compass zone
setting for your geographical location. Same map is in User Guide
as well.
b) To change the zone setting, push and hold the right, compass
display button until a number appears in the display. Press button
repeatedly until desired compass zone number is reached.
1. Calibrate compass.
a) Drive to an open, level area, away from large metallic objects or
structures.
b) Hold the right, compass display button for approximately 9 seconds,
until “C” test appears in the display. Release the right button to
enter the calibration mode.
c) Drive slowly in up to 3 circles until the “C” disappears and a direc-
tional heading is displayed. The compass is now calibrated.
Fig. 8-1
CompassZoneAdjustment(DealerInstallONLY)
CompassCalibration(DealerInstallONLY)

Page: 9 of 10 11/5/2012
Inspection
When the battery is disconnected, the DSC may stop operating.
 (TheDSCOFFindicatorwillashatthistime,andtheTCS/DSCoperationindicatorwillilluminate.)
1. Turn the ignition switch to “OFF” and then turn it back to “ON”.
2. Turn the steering wheel clockwise as far as it will go, and then turn it back counterclockwise as far as it
will go.
3. Check that the TCS/DSC operation indicator is turned off.
4. Turn the ignition switch to “OFF” and then turn it back to “ON”.
5. Check that the TCS/DSC operation indicator is turned off. If the TCS/DSC operation indicator is still
illuminated or the DSC indicator is not turned off when the ignition switch is turned back to “ON”, contact
your Mazda dealer.
CAUTION
!
If the battery is disconnected, the power windows may no longer fully open or fully close
automatically.
1. Turn the ignition key to the “ON” position.
2. Press the power window switch to fully open the power windows.
3. Lift up the power window switch to fully close the power windows, and keep it pulled up for approximately
2 seconds.
4. Position the engine switch at “OFF”, and then at “ON” again. When the function doesn’t work after these
procedures, please contact your Mazda dealer.
CAUTION
!
Inspection Parts
Inspection Items (O)
Clearance / Fit Scratches / Dirt /
Harness Interference
Installation /
Tightening /
Engagement
Operation Check
Negative battery terminal O
Driver-side Door Seal O O O
Driver-side A-pillar Trim O O O
EC mirror torx screw *1 O
EC harness connector O O O
EC mirror features:
- Auto-dimming *2 O
- Compass display *3 O
- HomeLink®*4 O
User guide *5 O
O : Applicable
*1:Tightenedto15lb-in(18kg-cm)
*2: Mirror dims (key must be in ON position).
*3:Displayseither“C”ordirectionalheading(keymustbeinONposition).
*4:RedLEDilluminateswheneachbuttonispushed(testwithkeyintheOFFposition).
*5:Invehicleglove-box.
If the battery is disconnected, the TPMS (Tire Pressure Monitoring System) initial setting is
reset and the system may not operate normally.
1. Adjust the tire pressure (verify tire pressure using label on body side with driver’s door open).
2. Turn the ignition switch to the “ON” position.
 3.PresstheTPMS(SET)switch(long-pressituntilTPMSwarninglightinmeterashestwotimesandabeep
sounds one time).
4. Turn the ignition switch to “OFF.”
 5.IftheTPMSwarninglightilluminatesorasheseventhoughtheaboveprocedurehasbeenperformed,contact
an Authorized Mazda Dealer.
CAUTION
!

Page: 10 of 10 11/5/2012
BASIC INSTALLATION TROUBLE-SHOOTING
Verifythefollowing:
1. B+harnesswire(pin10atthemirrorconnector)isreceiving+12V
withignitionOFFandON.
2. Switchedharnesswire(pin6atthemirrorconnector)isreceiving
+12VwithignitionONand0VwithignitionOFF.
3. Groundwire(pin3atthemirrorconnector)isproperlygrounded.
4. ECharnessisfullyinsertedintomirror.
5. Ensurejumperconnectorsareproperlyinstalled.
6. ECharnessisnotpinched,cutordamaged.
P1
NO. GAGE COLOR FUNCTION
1 20 AWG BLACK -
2
20 AWG BLACK -
3
20 AWG BLACK -
4
20 AWG BLACK -
5
20 AWG BLACK -
22 AWG RED IGNITION
6
20 AWG BLACK -
7
20 AWG BLACK -
820 AWG BLACK -
22 AWG BATTERY
920 AWG BLACK -
10 20 AWG BLACK -
11 20 AWG BLACK -
12
20 AWG BLACK -
22 AWG BLACK GROUND
P2
NO. GAGE COLOR FUNCTION
1 20 AWG BLACK -
220 AWG BLACK -
320 AWG BLACK -
420 AWG BLACK -
520 AWG BLACK -
620 AWG BLACK -
720 AWG BLACK -
820 AWG BLACK -
920 AWG BLACK -
10 20 AWG BLACK -
11 20 AWG BLACK -
12 20 AWG BLACK -
P3
NO. GAGE COLOR FUNCTION
1
2
3
22 AWG
4
5
6
IGNITION
7
12
22 AWG BLACK GROUND
RED
