MJ LED LIGHTNING MJ-1057 User manual

LED BEAM SPOT WASH 150
LEDMOVINGHEAD
MJ-1057
User Manual
== = == = = == = == = ==
Thank you for choosing our LED BSW moving head light. For the sake of
your safety, Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
PROFESSIONAL LED LIGHTING

CONTENTS
1. Safety Instrucons .............................................................................. 1
2. Technical Specificaons ...................................................................... 3
3. Descripon .......................................................................................... 4
3.1 Control Panel .............................................................................. 4
4. Gobo and Lamp .................................................................................. 5
4.1 Gobos ........................................................................................ 5
5. How To Set The Unit ........................................................................... 5
5 .1 Main Funcon ........................................................................... 5
5.2 Home Posion Adjustment ..................................................... 11
5.3 Error Informaon .................................................................... 13
6. Control By Universal DMX Controller ............................................... 14
6.1 Connecon ...............................................................................
14
6.2 Address Seng ........................................................................
15
6.3 DMX 512 Configuraon ............................................................ 15
7. Troubleshoong ...............................................................................
23
8. Cleaning .............................................................................................
24

1
1. Safety Instrucons
WARNING
Please keep this User Guide for future consultaon. If you sell the unit to another user, be sure that
they also receive this instrucon manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulng defects or problems.
 Unpack and check carefully that there is no transportaon damage before using the unit.
 The unit is for indoor use only. Use only in a dry locaon.
 DO install and operate by qualified operator.
 DO NOT allow children to operate the fixture.
 Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.
 The unit must be installed in a locaon with adequate venlaon, at least 50cm from adjacent
surfaces.
 Be sure that no venlaon slots are blocked, otherwise the unit will be overheated.
 Before operang, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
 It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
 Maximum ambient temperature TA: 40℃. DO NOT operate it when the temperature is higher.
 DO NOT connect the device to any dimmer pack.
 During inial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defecve, and it will decrease gradually within 15 minutes.
 Make sure there are no flammable materials close to the unit while operang to avoid fire hazard.
Examine the power wires carefully; replace them immediately if there is any damage.
Unit’s surface temperature may reach up to 85℃. DO NOT touch the housing bare-handed during
its operaon, and allow about 15 minutes for cooling the unit down before replacing bulb or
maintenance as it could be very hot.
Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut off
Please read the instrucon carefully which includes important informaon about
the installaon, usage and maintenance.
the mains power immediately.
24
8 . Cleaning
The cleaning of internal and external opcal lenses and/or mirrors must be carried out periodically
to opmize light output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or parcularly dirty surrounding can cause greater accumulaon of dirt on the
unit’s opcs.
Clean with so cloth and use normal glass to clean liquid.
Always dry the parts carefully.
Clean the external opcs at least every 20 days. Clean the internal opcs at least every 30/60 days.
☆Important noce:
• In this instrucon for use contains about the installment and the use aspect
important informaon of the LED BSW moving head. When installing and using, you
need to look this usage instrucon strictly.
• Before open the LED moving head and if you want to do the repair work, please
make sure the power source is at the separaon condion.
• Every unit is tested completely and packed properly by the manufacturer. Please
make sure the packing and the unit are in good condion before installaon and use.
Should there be any damage caused by transportaon, consult your dealer and do not
use the unit. Any damage caused by improper use will not be assumed by the
manufacturer or dealer.
Aenon: Unceasingly carries on the product improvement about our company the
policy, in this instrucon booklet carries the data will have the possibility to be able to
change in the future, when no longer separate noce change maers concerned. Our
company retains when the product improvement changes the related specificaon
the authority. This instrucon booklet publisher cannot be responsible regarding this
instrucon booklet in informaon accuracy, also cannot the related consequence
which causes regarding these informaon be responsible.

2
 DO NOT operate in dirty or dusty environment, do clean fixtures regularly.
 DO NOT touch any wire during operaon as there might be a hazard of electric shock.
 Avoid power wires together twist other cables.
 The minimum distance between light output and the illuminated surface must be more than 12
meters.
 Disconnect mains power before fuse/lamp replacement or servicing.
 Replace fuse/lamp only with the same type.
 In the event of serious operang problem, stop u sing the unit immediately.
 Never turn on and off the unit me aer me.
 The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
 DO NOT open the unit as there are no user serviceable parts inside.
 Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage
or malfuncon. Please contact the nearest authorized technical assistance center if needed.
 Disconnect the mains power if the fixture is has not been used for a long me.
 DO use the original packing materials before transporting it again.
Cauons:
 To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
 Hot lamp explosion hazard. DO NOT open the unit within 15 minutes aer switching off.
 DO replace the bulb once it is damaged, deformed or life-expired.
 DO NOT look directly at the light while the bulb is on.
 Never touch bulb with bare fingers, as it is very hot aer using.
 DO NOT start on the unit without bulb enclosure or when housing is damaged.
Installaon:
The unit is fully operaonal in three different mounng posions, hanging upside-down from a ceiling
or set on a flat level surface. To avoid internal damage to the unit, never mount the unit on its side as
illustrated above. Be sure this fixture is kept at least 0.5m away from any flammable materials
(decoraon etc.). Always use and install the supplied safety cable as a safety measure to prevent
accidental damage and/or injury in the event the clamp fails.
23
200-209
210-219
220-229
230-255
All reset
Enable blackout while Pan/Tilt Color Gobo Moving
Disable blackout while Pan/Tilt Color Gobo Moving
No funcon
7 . Troubleshoong
Following are a few common problems that may occur during operaon. Here are some suggesons
for easy troubleshoong:
A. The unit does not work, no light and the fan does not work
1. Check the connect power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED to see if it can be light up or not.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if they are linked properly.
2. If the DMX LED is on and no response to the channel, check the address sengs and DMX
polarity.
3. If you have intermient DMX signal problems, check the pins on connectors or on PCB of the unit
or the previous one.
4. Try to use another DMX controller.
5. Check to see if the DMX cables run near or run alongside to high voltage cables that may cause
damage or interference to DMX interface circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condion.
D. The lamp is cung out intermiently
1. The lamp is not working well. Check the mains voltage either too high or too low.
2. Internal temperature may be too high. Check if replacement of fan is needed on the head.

22
13
000-007
008-128
129-255
ANGLE/FROST
Off
Angle
Frost
14
000-007
008-255
PRISM
No effect
Prism Effect
15
000-127
128-189
190-193
194-255
R-PRISM
Index
Counter-clockwise rotaon fast to slow
Stop
clockwise rotaon slow to fast
16
000-255
FOCUS
0% ～ 100%
17
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
SHUTTER
Off
On
slow to fast strobe
open
Slow open fast close
open
Slow close fast open
open
Random strobe
Open
18
000-255
DIMMER
0% ～ 100%
19
000-255
DIMMER FINE
20
000-069
070-079
080-089
090-099
100-109
110-119
120-129
130-139
140-149
150-159
160-199
SPECIAL FUNCTION
No funcon
Enable blackout while Pan/Tilt Moving
Disable blackout while Pan/Tilt Moving
Enable blackout while Color changing
Disable blackout while Color changing
Enable blackout while Gobo changing
Disable blackout while Gobo changing
No funcon
Pan/Tilt reset
Effect reset
No funcon
150
2 . Technical Specificaons
Power supply
- AC 100~240V 50/60Hz
Power Consumpon
- 189W
Light Source
- 1 X W LED
Angle
-Beam Angle: 11°(on full open)
2°/4°/6°/8°/10° (with beam reducer)
3°/6°/9°/
12°/15°
/20
°(with zoom lens)
-Spot Angle: Fix Gobo: 2°- 15°(with zoom lens)
Rotang Gobo: 10°- 17°(with zoom lens)
-Wash Angle: 15°- 28°
Movement
- Pan: 540°
- Tilt: 270°
- Pan/Tilt moving speed adjustable.
- Automac Pan/Tilt correcon.
- Easy calibraon and maintenance by magnec home posioning.
Dimmer/Shuer
- Blackout, 0~100% smooth dimming, independent shuer and various strobe effect.
- Integrated three features: beam, spot and wash
Color wheel
- 8 fixed colors plus white
- Rainbow effect in both direcons.
Gobo wheel
- 1 Stac gobo wheel with 7 gobos plus open
1 Rotang gobo wheel with 6 gobos plus open
Prism
- Prism : 3 facet prism rotang in both direcons
Frost
- Independent frost effect
3

4
Focus
- Motorized focus
Zoom
- Motorized linear zoom system
Protocols
- DMX 512
- Date input/output: 3/5 Pin XLR socket
Weight
- 12 Kg
Dimension
- 452× 290×256mm
3 . Descripon
3.1 Control Panel
Front view Rear view
1 2 34567
1. LED:
MASTER On Master mode
SLAVE On Slave mode
SOUND On Sound acvaon
DMX On DMX input present
2.Display: To show the various menus and the selected funcon.
3.Buon:
290
452
256
MENU To enter into move backward or leave the menu
UP To go
backward to move up in the menu
DOWN To go to move down in the menu
ENTER To perform the desired funcons
21
043-045
046-048
049-051
052-054
055-057
058-060
061-063
064-127
128-189
190-193
194-255
Color10
Color11
Color12
Color13
Color14
Color15
Color16
Color wheel indexing
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
10
000-007
008-016
017-025
026-034
035-043
044-052
053-061
062-067
068-127
128-189
190-193
194-255
GOBO WHEEL 1
Open
Gobo1-1
Gobo1-2
Gobo1-3
Gobo1-4
Gobo1-5
Gobo1-6
Gobo1-7
Gobo1 1-7 shaking
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
11
000-007
008-016
017-025
026-034
035-043
044-052
053-061
062-127
128-189
190-193
194-255
GOBO WHEEL 2
Open
Gobo2-1
Gobo2-2
Gobo2-3
Gobo2-4
Gobo2-5
Gobo2-6
Gobo2 1 -6 Shaking
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
12
000-127
128~189
190-193
194-255
R-GOBO 2
Index
clockwise rotaon fast to slow
Stop
Counter-clockwise rotaon slow to fast

5
4. DMX input/output: For DMX 512 operaon, use 3/5-pin XLR plug cable to link the units together
5. Power In: Used to connect to supply power.
6. Power out: Used to connect to next unit.
7. Fuse (T 5A): Protect the unit from damage of over current.
4. Gobo and Lamp
4.1 Gobos
CAUTION: Never unscrew the screws of the rotang gobo as the ball bearing will otherwise be
opened!
DANGER!
Install the gobos with the device switched off only.
Unplug from mains before changing gobos!
5. How To Set The Unit
5.1 Main Funcon
Turn on the unit, press the MENU buon into menu mode, and press the UP/DOWN buon unl the
required funcon is shown on the monitor. Select the funcon by the ENTER buon. Use the
UP/DOWN buon to choose the submenu, press the ENTER buon to store and automacally return
to the last menu. Press the MENU buon or let the unit idle one minute to exit menu mode.
In the event of disconnecng with mains power, press the UP buon for one minute to enter into
menu mode. Press MENU buon or let the unit idle one minute to exit.
The main funcons are shown below（the grayed boxes are preset sengs）:
20
032-039
040-047
048-055
056-063
064-071
072-079
080-087
088-095
096-103
104-111
112-119
120-127
128-135
136-143
144-151
152-159
160-167
168-175
176-183
184-191
192-199
200-207
208-215
216-223
224-231
232-239
240-247
248-255
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17
Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
Macro 23
Macro 24
Macro 25
Macro 26
Macro 27
Macro 28
Macro 29
Macro 30
Macro 31
8
000-255
MACRO SPEED
fast to slow
9
000-015
016-018
019-021
022-024
025-027
028-030
031-033
034-036
037-039
040-042
COLOR
White
Color1
Color2
Color3
Color4
Color5
Color6
Color7
Color8
Color9

6
Fixture Test
DMX Sengs
512
MasterSlave
No
Display Sengs
1
Hold
Yes
mode 1(17)
No/Yes
0~30
English/Chinese
Fixture Sengs
mode 2(20)
5m
10m
15m
***
Blackout
Linear
Square Low
Inv.SQ Law
S Curve
Show Seng
Show1
Show4
Master
Slave1
Slave2
0
100
Yes
Fixture Informaon
No
Reset Funcons Yes
No
Special Funcons
19
000-255
0% ～ 100%
17
000-069
070-079
080-089
090-099
100-109
110-119
120-129
130-139
140-149
150-159
160-199
200-209
210-219
220-229
230-255
SPECIAL FUNCTION
No funcon
Enable blackout while Pan/Tilt Moving
Disable blackout while Pan/Tilt Moving
Enable blackout while Color changing
Disable blackout while Color changing
Enable blackout while Gobo changing
Disable blackout while Gobo changing
No funcon
Pan/Tilt reset
Effect reset
No funcon
All reset
Enable blackout while Pan/Tilt Color Gobo Moving
Disable blackout while Pan/Tilt Color Gobo Moving
No funcon
20 Channels (Mode 2):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0 ° ～ 540°
2 000-255 PAN FINE
3
000-255
TILT
0 ° ～ 270°
4 000-255 TILT FINE
5 000-255
PAN/TILT SPEED
Fast to Slow
6
000-015
016-063
064-127
128-191
192-255
SHOW MODE
Null
Show 1
Show 2
Show 3
Show 4
7
000-007
008-015
016-023
024-031
PAN/TILT MACRO
Off
Macro 1
Macro 2
Macro 3

18
008-016
017-025
026-034
035-043
044-052
053-061
062-127
128-189
190-193
194-255
Gobo2-1
Gobo2-2
Gobo2-3
Gobo2-4
Gobo2-5
Gobo2-6
Gobo2 1 -6 Shaking
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
10
000-127
128~189
190-193
194-255
R-GOBO 2
Index
clockwise rotaon fast to slow
Stop
Counter-clockwise rotaon slow to fast
11
000-007
008-128
129-255
ANGLE/FROST
Off
Angle
Frost
12
000-007
008-255
PRISM
No effect
Prism Effect
13
000-127
128-189
190-193
194-255
R-PRISM
Index
Counter-clockwise rotaon fast to slow
Stop
clockwise rotaon slow to fast
14
000-255
FOCUS
0% ～ 100%
15
000-007
008-015
016-131
132-139
140-181
182-189
190-231
232-239
240-247
248-255
SHUTTER
Off
On
slow to fast strobe
open
Slow open fast close
open
Slow close fast open
open
Random strobe
Open
16 DIMMER
7
DMX Sengs
To select DMX Sengs press the ENTER buon to confirm, use the UP/DOWN buon to select DMX
Address, DMX Channel Mode or DMX State.
DMX Address —DMX512 address seng
To select DMX Address, press the ENTER buon to confirm. Use the UP/DOWN buon to adjust
the address from 001 to 512, press the ENTER buon to store. Press the MENU buon back to the
last menu or let the unit idle one minute to exit menu mode.
DMX Channel Mode — channel mode
To select DMX Channel Mode, press the ENTER buon to confirm. Use the UP/DOWN buon to
select Mode1 (17 ) or Mode2 (20) channels mode, press the ENTER buon to store. Press the
MENU buon back to the last menu or let the unit idle one minute to exit menu mode.
DMX State — fixture state while DMX single stops
To select DMX State, press the ENTER buon to confirm. Use the UP/DOWN buon to select
Master Slave(fixture enters to master slave mode),Blackout (fixture blacks out if DMX signal stops)
or Hold (fixture connues to obey the last command it received Via DMX if DMX signal stops),
press the ENTER buon to store. Press the MENU buon back to the last menu or let the unit idle
one minute to exit menu mode.
Fixture Sengs
To select Fixture Sengs, press the ENTER buon to confirm, use the UP/DOWN buon to select Pan
Inverse, Tile Inverse, P/T Feedback, Dimmer Curve or Show Focus.
Pan Inverse
To select Pan Inverse, press the ENTER buon to confirm. Use the UP/DOWN buon to select No
(normal) or Yes (pan inverse), press the ENTER buon to store. Press the MENU buon back to
the last menu or let the unit idle one minute to exit menu mode.
Tilt Inverse
To select Tilt Inverse, press the ENTER buon to confirm. Use the UP/DOWN buon to select No
(normal) or Yes (lt inverse), press the ENTER buon to store. Press the MENU buon back to the
last menu or let the unit idle one minute to exit menu mode.
P/T Feedback
To select P/T Feedback, press the ENTER buon to confirm. Use the UP/DOWN buon to select
No (Pan or lt’s posion will not feedback while out of step) or Yes (Feedback while pan/lt out of
step), press the ENTER buon to store. Press the MENU buon back to the last menu or let the
unit idle one minute to exit menu mode.

8
Dimmer Curve
To select Dimmer Curve, press the ENTER buon to show the DIMMER CURVE on the display. Use
the DOWN/UP buon to select the Mode 1 or Mode 2 or Mode 3 or Mode 4. Once the mode has
been selected, press the ENTER buon to setup, to go back to the funcons without any change
press the MENU buon again. Press and hold the MENU buon about one second or wait for one
minute to exit the menu mode.
Mode 1(Opcally Linear):
The increase in light intensity appears to be linear as DMX value is increased.
Mode 2(Square Law):
Light intensity control is finer at low levels and coarser at high levels.
Mode 3(Inverse Square Law):
Light intensity control is coarser at low levels and finger at high levels.
Mode 4(S-cure):
Light intensity control is finger at low levels and high levels and coarser at medium levels.
Show Focus
To select Show Focus, press the ENTER buon to confirm. U se the UP/DOWN buon to select
5m,10m or 15m, press the ENTER buon to store. Press the MENU buon back to the last menu
or let the unit idle one minute to exit menu mode.
Show Seng
To select Show Seng, press the ENTER buon to confirm, use the UP/DOWN buon to select Show
Mode, Slave Mode or Sound Sense.
Show Mode
To select Show Mode, press the ENTER buon to confirm. U se the UP/DOWN buon to select
show1, show 2, show 3 or show 4, press the ENTER buon to store. Press the MENU buon back
to the last menu or let the unit idle one minute to exit menu mode.
17
240-247
248-255
Macro 30
Macro 31
6
000-255
MACRO SPEED
fast to slow
7
000-015
016-018
019-021
022-024
025-027
028-030
031-033
034-036
037-039
040-042
043-045
046-048
049-051
052-054
055-057
058-060
061-063
064-127
128-189
190-193
194-255
COLOR
White
Color1
Color2
Color3
Color4
Color5
Color6
Color7
Color8
Color9
Color10
Color11
Color12
Color13
Color14
Color15
Color16
Color wheel indexing
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
8
000-007
008-016
017-025
026-034
035-043
044-052
053-061
062-067
068-127
128-189
190-193
194-255
GOBO WHEEL 1
Open
Gobo1-1
Gobo1-2
Gobo1-3
Gobo1-4
Gobo1-5
Gobo1-6
Gobo1-7
Gobo1 1-7 shaking
Counter-Clockwise rotaon, fast to slow
Stop
Clockwise rotaon, slow to fast
9 000-007
GOBO WHEEL 2
Open

16
2
000-255
TILT
0 °～ 270°
3 000-255
PAN/TILT SPEED
Fast to Slow
4
000-015
016-063
064-127
128-191
192-255
SHOW MODE
Null
Show 1
Show 2
Show 3
Show 4
5
000-007
008-015
016-023
024-031
032-039
040-047
048-055
056-063
064-071
072-079
080-087
088-095
096-103
104-111
112-119
120-127
128-135
136-143
144-151
152-159
160-167
168-175
176-183
184-191
192-199
200-207
208-215
216-223
224-231
232-239
PAN/TILT MACRO
Off
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17
Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
Macro 23
Macro 24
Macro 25
Macro 26
Macro 27
Macro 28
Macro 29
9
Slave Mode
To select Slave Mode, press the ENTER buon to confirm. U se the UP/DOWN buon to select
master, slave 1 or slave 2, press the ENTER buon to store. Press the MENU buon back to the
last menu or let the unit idle one minute to exit menu mode.
Sound Sense
To select Sound Sense, press the ENTER buon to confirm. Use the UP/DOWN buon to adjust
the value from 0 to 100, press the ENTER buon to store. Press the MENU buon back to the last
menu or let the unit idle one minute to exit menu mode.
Display Sengs
Enter menu mode, select Display Seng , press the ENTER buon to confirm, use the UP/DOWN
buon to select Display Inverse, Contrast Rao, Temperature Unit or Language.
Display Inverse
Select Display Inverse, press the ENTER buon to confirm, present mode will blink on the display,
use the UP/DOWN buon to select No (normal display) or Yes (inverse display), press the ENTER
buon to store. Press the MENU buon back to the last menu or let the unit idle one minute to
exit menu mode.
Contrast Rao
Select Contrast Rao, press the ENTER buon to confirm, present mode will blink on the display,
use the UP/DOWN buon to adjust value from 0 to 30, press the ENTER buon to store. Press the
MENU buon back to the last menu or let the unit idle one minute to exit menu mode.
Temperature Unit
Select Temperature Unit, press the ENTER buon to confirm, present mode will blink on the
display, use the UP/DOWN buon to select ℃or ℉, press the ENTER buon to store. Press the
MENU buon back to the last menu or let the unit idle one minute to exit menu mode.
Language
Select Language, press the ENTER buon to confirm, present mode will blink on the display, use
the UP/DOWN button to select English or Chinese. Press the MENU buon back to the last menu
or let the unit idle one minute to exit menu mode.
Fixture Test
Enter menu mode, select Fixture Test, press the ENTER buon to confirm, use the UP/DOWN
buon to select Auto Test or Manual Test

10
Auto Test
Select Auto Test, press the ENTER buon to confirm, the unit will run built-in programs to
automacally test pan, lt, shuer, color, CMY, gobo, gobo rotaon, prism, prism rotaon, iris,
frost, zoom, focus, dimmer and lamp on/off. Press the MENU buon back to the last menu or exit
menu mode aer auto test.
Manual Test
Select Manual Test, press the ENTER buon to confirm, the present channel will show on the
display, use the UP/DOWN buon to select channel, press the ENTER buon to confirm, then use
the UP and DOWN buon to adjust the value, press the ENTER buon to store, the fixture will run
as the channel value indicates. Press the MENU buon back to the last menu or exit menu mode
idling one minute.
(All channels value will become 0 aer exing Manual Test menu)
Fixture Informaon
Enter menu mode, select Fixture Informaon, press the ENTER buon to confirm, use the
UP/DOWN buon to select Fixture use me or Firmware Version.
Fixture use hour
Select Fixture use hour, press the ENTER buon to confirm, fixture use me will show on the
display, press the MENU buon to exit.
Firmware Version
Select Firmware Version, press the ENTER buon to confirm, firmware version will show on the
display, press the MENU buon back to exit.
Reset Funcons
Enter menu mode, select Reset Funcon, press the ENTER buon to confirm, use the UP/DOWN
buon to select Pan/Tilt, Effect or All.
Pan﹠Tilt —Reset Pan/Tilt
Select Pan﹠Tilt, press the ENTER buon to confirm, use the UP/DOWN buon to select Yes (the
unit will run built-in program to reset pan and lt to their home posions) or No(normal), press
the ENTER buon to store. Press the MENU buon back to the last menu or let the unit idle one
minute to exit menu mode.
15
5. The end of the DMX 512 system should be terminated to reduce signal errors.
6. 3 pin XLR connectors are more popular than 5 pins XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negave signal (-), Pin 3: Posive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negave signal (-), Pin 3: Posive signal (+), Pin4, Pin5 not used.
6 .2 Address Seng
If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512
so that the units can receive DMX signal.
Press the MENU buon to enter menu mode, select DMX Funcons , press the ENTER buon to
confirm, use the UP/DOWN buon to select DMX Address, press the ENTER buon to confirm, the
present address will blinking the display, use the UP/DOWN buon to adjust the address from 001 to
512, press the ENTER buon to store. Press the MENU buon back to the last menu or idling let the
unit idle one minute to exit menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
17 channels 1 18 35 52
20 channels 1 21 41 61
6.3 DMX 512 Configuraon
Please refer to below configuraons to control the fixtures
Aenons:
1. The unit will maintain the last condion unl reset if you cut-off the DMX signal.
2. For the channel Funcon, keep the value for about 5 seconds, then the corresponding funcon
will take into effect.
17 Channels (Mode 1):
CHANNEL VALUE FUNCTION
1 000-255
PAN
0 ° ～540°

14
6 . Control By Universal DMX Controller
6 .1 Connecon
D M X 5 1 2 C O N T R O L L E R
DMX OUT
1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor
between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the
last unit.
2. Connect the unit together in a “daisy chain” by XLR plug cable from the output of the unit to the
input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very
high-speed signal. Inadequate or damaged cables, soldered joints or corroded connectors can easily
distort the signal and shut down the system.
3. The DMX output and input connectors are pass-through to maintain the DMX circuit, when one of
the units’ power is disconnected.
4. Each lighng unit needs to have a DMX address to receive the data by the controller. The address
ATTENTION
Terminaon reduces signal errors and to avoid signal transmission problems and
interference. It is always advisable to connect a DMX terminal (Resistance 120 ohm 1/4W
between pin2 (DMX-) and pin3 (DMX+) of the last fixture).
number is between 0-511 (usually 0 & 1 are equal to 1).
11
Effect —Reset Effect
Select Effect, press the ENTER buon to confirm, use the UP/DOWN buon to select Yes (the unit
will run built-in program to reset effect to their home posions) or No, press the ENTER buon to
store. Press the MENU buon back to the last menu or let the unit id le one minute to exit menu
mode
All — Reset All
Select All, press the ENTER buon to confirm, use the UP/DOWN buon to select Yes (the unit
will run built-in program to reset all motors to their home posions) or No, press ENTER buon to
store. Press the MENU buon to exit.
Special Funcons
Factory Sengs
Select Factory Sengs, press the ENTER buon to confirm, use the UP/DOWN buon to select
Yes (the fixture will reset to factory sengs) or No (normal), press ENTER buon to store. Press
the MENU buon to exit.
Home Posion Adjustment
Press the MENU buon into menu mode, then press the ENTER buon for about 3 seconds into offset
mode to adjust the home posion. Select the funcon by the ENTER buon. Use the UP/DOWN
buon to choose the submenu, press the ENTER buon to store and automacally return to the last
menu. Press MENU buon to exit.
Pan
Tilt
Color
Gobo 1
Gobo 2
RGobo 2
Prism
Rprism
AngleCFrost
Focus
Offset Menu
5.2

12
Pan—pan home posion adjustment
Enter offset mode, Select Pan, press the ENTER buon to confirm, the present posion will blink on
the display, use the UP/DOWN buon to offset the value from - 128 to 127, press the ENTER buon to
store. Press the MENU buon to exit.
Tilt—Tilt home posion adjustment
Enter offset mode, Select Tilt , press the ENTER buon to confirm, the present posion will blink on
the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon to
store. Press the MENU buon to exit.
Color 1—Color 1 home posion adjustment
Enter offset mode, Select Color 1, press the ENTER buon to confirm, the present posion will blink
on the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon
to store. Press the MENU buon to exit.
Gobo 1—Gobo 1 home posion adjustment
Enter offset mode, Select Gobo 1, press the ENTER buon to confirm, the present posion will blink
on the display, use the UP/DOWN buon to offset the value from - 128 to 127, press the ENTER buon
to store. Press the MENU buon to exit.
Gobo 2—Gobo 2 home posion adjustment
Enter offset mode, Select Gobo 2, press the ENTER buon to confirm, the present posion will blink
on the display, use the UP/DOWN buon to offset the value from - 128 to 127, press the ENTER buon
to store. Press the MENU button to exit.
R-Gobo 2—Gobo 2 rotaon home posion adjustment
Enter offset mode, Select R-Gobo 2, press the ENTER buon to confirm, the present posion will blink
on the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon
to store. Press the MENU buon to exit.
Prism—Prism home posion adjustment
Enter offset mode, Select Prism , press the ENTER buon to confirm, the present posion will blink on
the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon to
store. Press the MENU buon to exit.
R-Prism—Prism rotaon home posion adjustment
Enter offset mode, Select R -Prism, press the ENTER buon to confirm, the present posion will blink
on the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon
to store. Press the MENU buon to exit.
13
Beam/Frost—Beam/Frost home posion adjustment
Enter offset mode, Select Beam/ Frost, press the ENTER buon to confirm, the present posion will
blink on the display, use the UP/DOWN buon to offset the value from - 128 to 127, press the ENTER
buon to store. Press the MENU buon to exit.
Focus—Focus home posion adjustment
Enter offset mode, Select Focus, press the ENTER buon to confirm, the present posion will blink on
the display, use the UP/DOWN buon to offset the value from -128 to 127, press the ENTER buon to
store. Press the MENU buon to exit.
5.3 Error Informaon
Lamp Startup Fail
It appears when there is no lamp or some wires are damaged.
Temperature Sense Error
It appears when temperature check board is damaged.
Lamp Too Hot Power Off
It appears when temperature is detected higher than 110℃. Check if the unit is properly venlated, or
fans or temperature check board may is damaged.
Lamp Too Hot Low Power
It appears when detected temperature is higher than 105℃. the unit will run on a low power level.
Lamp On Over 700 Hour
It appears when the lamp always has been on over 700 hours, please turn off the lamp.
Memory Inial Fail
It appears when the memory IC is damaged.
CPU-B Error, CPU-C Error, CPU-D Error
They appear when board P.C or some wires are damaged.
Pan Reset Error, Pan Encode Error, Tilt Reset Error, Tilt Encode Error, Shuer Reset Fail, Dimmer
Reset Fail, Color Reset Fail, Cyan Reset Fail, Magenta Reset Fail, Yellow Reset Fail, Gobo1 Reset Fail,
R-Gobo1 Reset Fail, Gobo2 Reset Fail, Iris Reset Fail, Effect Reset Fail, R-Effect Reset Fail, Frost Reset
Fail, Flat Reset Fail, Focus Reset Fail, Zoom Reset Fail
They may appear when turning on or resetng the unit, for some parts such as board P.C are damaged.
Please contact the qualified maintenance.
