Mocka Milton 5 Shelf Plant Stand User manual

Milton 5 Shelf Plant Stand
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x4
washer
Z
Y
wall
anchor
x2
X
safety
strap x2
WV
screw
x2
wall
screw
x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
Allen Key
x1
A B C
D
Hardware Supplied
bolt
bolt
x22
x6
screw
x26
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips
E
adjuster
x2
Maximum weight limit per shelf is 10kg
Indoor Use Only

Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
Panel Layout
3
9
4
1
1
12
12
6
6
7
7
2
2
8
8
5
11
10
13
3
13
3
12
3
12

Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
12
Attach panels [6] to panel [1] and secure with 4x screws (B).
Attach 2x safety strap (V) and 2x washer (Z) to panel [6] and
secure with 2x screw (W). Tighten with a screwdriver.
Attach panels [7] to panel [1] and secure with 6x screws (B).
Tighten with a screwdriver.
.
11
6
7
6
7
B
B
B
B
W
B
B
B
B
B
B
V
Z
Z
W
V
Z
W
V

Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
3 4
Attach panel [10] to panel[2] and secure with 6x screws (B).
Tighten with a screwdriver.
Attach panel [11] to panel [2] and secure with 6x screws (B).
Tighten with a screwdriver.
22
10
11
B
B
B
B
B
B
B
B
B
B
B
B

Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
5 6
Attach panel [9] to panel [3] and secure with 4x screws (B).
Tighten with a screwdriver. Attach panels [12] to panel [6] and secure with 2x bolts (D) as shown.
1
B
B
B
B
D
D
3
9
12
12
D
short
long
6
6

Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
7 8
Attach panel [10] to panels [12] and secure with 2x bolts(A).
Tighten with an Allen Key (C).
Attach panels [8] to panel [10] and secure with 2x bolts(A).
Tighten with an Allen Key (C).
A
A
A
12
12
8
8
10
10
A
C

Milton 5 Shelf Plant Stand
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
910
Assembly Instructions
Attach panel [11] to panels [8] and secure with 2x bolts(A).
Tighten with an Allen Key (C).
Attach panel [9] to panels [8] and secure with 2x bolts(A).
Tighten with an Allen Key (C).
A
A
A
9
8
8
8
11

Attach panels [12] to panels [7] and [11] and secure with 4x bolts (D) as shown.
Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
1211
Attach panels [13] to panel [7] as shown. Attach 2x adjuster (E) to the
ends of panels [13].
D
D
D
D
12
12
11
7
7
13
13
E
E
short
long
D

5
6
6
Attach panels [4] to panels [6], [7] and [9] and secure with
6x bolts (A). Tighten with an Allen Key (C).
Attach panel [5] to panels [6], [7], [10] and [11] and secure with 8x bolts (A).
Tighten with an Allen Key (C).
Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
1413
A
A
A
A
A
A
A
A
A
A
A
A
A
A
C
C
10
11
77
9
4

You're done, enjoy!
Once assembled lift furniture into place, do not drag. Use a
drill to create a small hole lining up with the top of the safety
strap (V). Fasten to the wall using 2x washer (Z) , 2x wall
anchor (X) and 2x wall screw (Y). Ensure unit is balanced
and steady before use.
Milton 5 Shelf Plant Stand
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
1615
X
Y
Z
X
Y
Z
wall
anchor
screw
strap
washer
