Montezuma 5624BNC User manual

OWNER'S MANUAL
56" X 24"
WORKBENCH WITH
BAMBOO WORKTOP
5624BNC
www.montezumastorage.com

2
LIFE ORGANIZED
Montezuma is committed to helping you succeed in both your work
and personal life by being organized, prepared and equipped with
the right tools, gear and home supplies at your finger tips.
We are here to ensure that your life is organized.
Thank you for your purchase of this Montezuma Workbench
ATTENTION
TO REDUCE THE RISK OF INJURY, THE USER MUST READ AND
UNDERSTAND THIS INSTRUCTION MANUAL BEFORE USING THIS
PRODUCT FOR THE FIRST TIME. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Fill in the following information and retain
this owner's manual for future reference:
MODEL(S):
DATE OF PURCHASE:
PLACE OF PURCHASE:
RECEIPT NO:

3
SPECIFICATIONS
MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 500 kg (1102 lb)
56" x 24" WORKBENCH
WITH BAMBOO TOP
5624BNC
OVERALL DIMENSIONS:
55-5/8" W x 23-5/8" D x 36-1/4" H
(141.2 cm W x 60 cm D x 92 cm H)

4
PARTS LIST
To order replacement parts, email [e-mail] or call 1-800-459-4409
(Monday–Friday, 8:00 am–4:30 pm, CST). Have the part number and quantity ready.
Replacement keys may be ordered using the code that appears on the face of the lock.
Not all parts are covered under warranty. Those parts not covered can be purchased.
REF DESCRIPTION PART NUMBER QTY
1M6 x 16 mm Hex Socket Head Screw 320327 40
2Adjustable Leveling Feet 110 0 6 8 4
1
2

5
FRAME ASSEMBLY
Assemble one end of the workbench
by attaching (2) short cross braces
to (1) Post A and (1) Post B using
(4) M6 x 16 mm hex socket head screws
per cross brace. See Figure 1.
Screw (2) leveling feet into the bottom of the
legs. See Figure 1.
Repeat to create the other end of the
workbench.
Connect the (2) ends together using the (2)
long cross braces and (8) M6 x 16 mm hex
bolts per cross brace. See Figure 2.
Figure 1
Figure 2

6
WORKTOP INSTALLATION
Lay the bamboo worktop upside down on a
soft mat for protection. Place the assembled
frame upside down on the worktop. The
bamboo worktop should be flush with the
back of the frame.
Attach the frame to the worktop using
(8) M6 x 16 mm hex socket screws.

7
MAINTENANCE
Periodically clean the frame and wood top with mild detergent and water.
Grease and oil can be removed from the steel portions of the workbench using most
standard cleaning fluids. For safety, use a nonflammable cleaning fluid.
SAFETY
DO NOT stand or lean on the work top.
DO NOT mount this product on a truck bed or any other moving object. This may cause
personal injury or product damage.
DO NOT alter this product in any manner. For example, do not weld external lockbars or
attach electrical equipment. This may cause product damage or personal injury.
Adjust the levelling feet so that the product is level. The product may become unstable
and tip if uneven, which may cause personal injury or product damage.
This product is warranted to be free from defects in materials and workmanship
for a period of one (1) year from the date of original purchase.
If this product is defective, email [e-mail] or
call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is
defective, we will replace the defective part at no cost to you. Please do not ship your
product back to the store or to us unless we send you written instructions for return.
In the event it becomes necessary for your product to be returned,
we will notify you how to proceed. A copy of your original purchase receipt
must accompany the returned product.
1

5624BNC_09/19
Manufactured by:
QUALITY CRAFT
Surrey, BC, Canada V3S 5N4
[e-mail]
1-800-459-4409
(Monday to Friday, 8:00 am–4:30 pm, CST)
Made in China
