Montezuma M162403SL User manual

OWNER'S MANUAL
16" X 24"
SIDE LOCKER
M162403SL
www.montezumastorage.com

2
LIFE ORGANIZED
Montezuma is committed to helping you succeed in both your work
and personal life by being organized, prepared and equipped with
the right tools, gear and home supplies at your finger tips.
We are here to ensure that your life is organized.
Thank you for your purchase of this Montezuma Side Locker.
ATTENTION
TO REDUCE THE RISK OF INJURY, THE USER MUST READ AND
UNDERSTAND THIS INSTRUCTION MANUAL BEFORE USING THIS
PRODUCT FOR THE FIRST TIME. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Fill in the following information and retain
this owner's manual for future reference:
MODEL(S):
DATE OF PURCHASE:
PLACE OF PURCHASE:
RECEIPT NO:

3
SPECIFICATIONS
MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 450 lb (204 kg)
MAXIMUM DRAWER WEIGHT: 100 lb (45 kg)
MAXIMUM SHELF WEIGHT CAPACITY: 100 lb (45 kg)
16" x 24" 3-DRAWER SIDE LOCKER
M162403SL
OVERALL DIMENSIONS:
15-7/8" W x 24-5/8" D x 59-3/4" H
(40.3 cm W x 62.5 cm D x 151.9 cm H)
NET WEIGHT: 128 lb (58 kg)
INSIDE TILL/DRAWER DIMENSIONS:
REF DIMENSIONS QTY
A12-7/8" W x 17-3/4" D x 7-7/8" H
(32.7 cm W x 45 cm D x 20 cm H) 1
B16-3/4" W x 9-3/8" D x 2" H
(42.7 cm W x 23.8 cm D x 5 cm H) 3
WE RECOMMEND USING THIS SIDE LOCKER
WITH ANY MONTEZUMA 24" DEEP TOOL COMBO
THAT IS 46" OR WIDER
A
B

4
PARTS LIST
To order replacement parts, email [e-mail] or call 1-800-459-4409
(Monday–Friday, 8:00 am–4:30 pm, CST). Have the part number and quantity ready.
Replacement keys may be ordered using the code that appears on the face of the lock.
Not all parts are covered under warranty. Those parts not covered can be purchased.
REF DESCRIPTION PART NUMBER QTY
1M4 x 5 mm Phillips Head Bolt 320060 2
2Handle 301883 1
3Till Liner 552158 1
4Lock and Key (1201–1204) 304166 1
5Shelf 242013 2
6Shelf Support 203902 8
7Shelf Liner 552157 3
8Drawer Liner 552159 3
9Mat 314219 1
10 Slide Set 300027–300028 3
11 EVA Liner 600100 2
12 End Cover 314047 4
13 M6 x 20 Counter Sink Screw 320049 4
14 Hanger 241998 1
15 Connector 241999 1
16 M6 x 12 Hex Bolt 321051 4
17 Cantridge Magnet 312033 1
18 Gas Strut 303217 2
1
2
4
5
6
13
14
15
16
12
10
18
7
8
3
11
17
9
x x x
The keys
are taped
to the shelf.

M4 x 5 mm Phillips
Head Bolt
Pre-installed
For attached the handle
Handle
Pre-installed
For opening lid
2 1
Till Liner
For protecting your till
Shelf Liner
For protecting your shelves
Drawer Liner
For protecting
your drawers
1
3 3
x x x
Lock and Key
For securing
your valuables
1
Shelf
For placing at
desired height
Shelf Support
For installing the shelf
2 8
Mat
For the bottom pivot
of the door
Slide Set
Pre-installed
For installing drawers
1
3
End Cover
Pre-installed on side
panel – remove when
hanging on a tool cabinet
EVA Liner
For attaching to the
bottom of the side locker
2 4

4
1
1 2
Connector
For attaching the side
locker to a tool combo
M6 x 12 mm Hex Bolt
For attaching
the connector
Cantridge Magnet
Pre-installed
For keeping door closed
Gas Strut
Pre-installed
For lifting the hutch lid
Hanger
For hanging the side
cabinet on a tool cabinet
1
M6 x 20 Counter
Sink Screw
For installing the hanger
4

7
HANGER INSTALLATION
The hanger can be mounted on either side
of a tool cabinet. If necessary, remove the
side handles from the tool cabinet.
To install the hanger, position it over the
holes in the tool cabinet and attach using
four M6 x 20 counter sink screws. Tighten
securely.
EVA LINER INSTALLATION
Attach two EVA liners to the side locker in
the locations indicated.

8
SIDE LOCKER-CABINET
CONNECTION
Remove the end covers from the side panel of the side locker. Hang the side locker on
your tool cabinet.
Position the connector on the back of the side locker and tool cabinet. Attach to the side
locker using two M6 x 12 hex bolts and to the tool cabinet with two M6 x 12 hex bolts.
SHELF INSTALLATION
Insert shelf supports inside the side locker
at the desired heights.
Place the shelves on the shelf supports.

9
DOOR REVERSAL
To reverse the door, pull off the pivot and remove the door. Then install the door on the
other side by inserting the pivot. Be sure to move the mat on the bottom of the door and
the magnet to the other side.
DRAWER REMOVAL
Pull the drawer out so that it’s almost fully extended. Push up on the black release lever
on one side, while pushing down on the black release lever on the other side. While
holding the levers in these positions, pull the drawer outward until it is released from the
drawer slide.
ONE SIDE – PUSH UP OTHER SIDE – PUSH DOWN
DRAWER REPLACEMENT
Extend the drawer slides from the unit. Insert the brackets on each side of the drawer
into the slots in the slides, being careful that they are properly positioned. Once properly
inserted, completely close the drawer to set the slides in position.

10
MAINTENANCE
Periodically clean the drawer fronts, trim, and other surfaces with mild detergent and water.
Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This
is especially important in low temperatures, which can cause the bearing to become stiff.
Grease and oil can be removed with most standard cleaning fluids. For safety, use a
nonflammable cleaning fluid.
SAFETY
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Close the cover and lock the door before moving this product.
DO NOT stand or lean on this product.
WEAR SAFETY GLASSES when removing or repositioning the slides. The tool could
slip, which may cause personal injury.
BE CAREFUL when opening more than one drawer. The product could become unstable
and tip, which may cause personal injury or product damage.
DO NOT mount this product on a truck bed or any other moving object. This may cause
personal injury or product damage, and will void the warranty.
Secure this product properly before moving it with a forklift.
Keep the product on level surfaces. The product could become unstable and tip if stored
or moved on an uneven surface, which may cause personal injury or product damage.

11
This product is warranted to be free from defects in materials
and workmanship for a period of five (5) years from the date
of original purchase.
If this product is defective, email [e-mail]
or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the
product is defective, we will replace the defective part at no cost to you.
Please do not ship your product back to the store or to us
unless we send you written instructions for return.
In the event it becomes necessary for your product
to be returned, we will notify you how to proceed.
A copy of your original purchase receipt must accompany
the returned product.

M162403SL_02/19
Manufactured by:
QUALITY CRAFT
Surrey, BC, Canada V3S 5N4
[e-mail]
1-800-459-4409
(Monday to Friday, 8:00 am–4:30 pm, CST)
Made in China
www.montezumastorage.com
