Motorola IMPRES Smart Energy System User manual

Accessories
IMPRES
TM
Adaptive
Single Unit Charger
ru
pt-PT
nl-NL
it-IT
fr-FR
es-ES
en
de-DE
6864121B18.book Page 1 Thursday, October 9, 2014 11:35 PM

6864121B18.book Page 2 Thursday, October 9, 2014 11:35 PM

1
English
TABLE OF CONTENTS
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operational Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operational Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPRES Feature / Benefit Description . . . . . . . . . . . . . . . . . . . . . . . . 3
Operational Characteristics / Differences: . . . . . . . . . . . . . . . . . . . . . 4
Power Sources and Motorola Authorized Power Adapters . . . . . . . . . 7
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Manually Reconditioning the Battery . . . . . . . . . . . . . . . . . . . . . . 11
Automatically Reconditioning the Battery . . . . . . . . . . . . . . . . . . . 11
Manually Terminating the Reconditioning Process . . . . . . . . . . . . 12
Removing a Radio or Battery from the Charger . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6864121B18.book Page 1 Thursday, October 9, 2014 11:35 PM

2
English
THE IMPRES ADAPTIVE CHARGER IS UNLIKE ANY CHARGING
DEVICE YOU HAVE EVER USED BEFORE.
PLEASE READ THROUGH THIS MANUAL COMPLETELY BEFORE
OPERATING THIS UNIT:
IMPORTANT SAFETY INSTRUCTIONS
This document contains important safety and operating instructions. Please read
these instructions carefully and save them for future reference.
OPERATIONAL WARNINGS
1. To reduce risk of injury, charge only the rechargeable Motorola authorized
batteries listed in Table 1 on page 5. Other batteries may explode, causing
personal injury and damage.
2. Use of accessories not recommended by Motorola may result in risk of fire,
electric shock, or injury.
3. To reduce risk of damage to the electric plug and cord, pull by the plug rather
than the cord when disconnecting the charger.
4. An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in risk of fire and electric shock. If an
extension cord must be used, make sure that the cord size is 18AWG for
lengths of up to 100 feet (30.48m), and 16AWG for lengths up to 150 feet
(45.72m).
5. To reduce risk of fire, electric shock, or injury, do not operate the charger if it
has been broken or damaged in any way.
6. Do not disassemble the charger – it is not repairable and replacement parts are
not available. Disassembly of the charger may result in risk of electric shock or
fire.
7. To reduce risk of electric shock, unplug the charger from the ac outlet before
attempting any maintenance or cleaning.
8. For fuse replacement, use only fuses of the same type and rating listed on the
charger label.
9. This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
!
6864121B18.book Page 2 Thursday, October 9, 2014 11:35 PM

3
English
OPERATIONAL SAFETY GUIDELINES
• Turn the radio off when charging the battery.
• This equipment is not suitable for outdoor use. Use only in dry locations/
conditions.
• Connect equipment only to an appropriately fused and wired supply of the correct
voltage (as specified on the product).
• Disconnect from line voltage by removing the mains plug from the outlet.
• The socket outlet to which this equipment is connected should be close and
easily accessible.
• For equipment using fuses, replacements must comply with the type and rating
specified in the equipment instructions.
• Maximum ambient temperature around the charger must not exceed 40°C
(104°F).
• Make sure the cord is located where it will not be stepped on, tripped over, or
subjected to water, damage, or stress.
IMPRES FEATURE / BENEFIT DESCRIPTION
The IMPRES energy solution is an advanced Tri Chemistry energy system
developed by Motorola which encompasses (a) IMPRES batteries, (b) the IMPRES
Adaptive Charger, and (c) radio hardware / software which provides the capability
for IMPRES compatible radios to communicate with IMPRES batteries.
The IMPRES Adaptive Charger, when used in conjunction with Motorola IMPRES
batteries will:
1. Maximize operation time between charge cycles by automatically eliminating
memory effect.
2. Maximize battery life by significantly reducing heat during the trickle and post
charge cycles.
3. Eliminate the need to purchase reconditioning equipment and train personnel to
“manage battery maintenance tasks.”
With this unique patented system approach, there is no need to track and record
battery use, conduct manual reconditioning cycles or remove batteries from
chargers following charging.
The IMPRES Adaptive Charger monitors the usage pattern of the IMPRES battery,
stores that information in the IMPRES battery, and performs a recondition cycle
only when needed.
6864121B18.book Page 3 Thursday, October 9, 2014 11:35 PM

4
English
The IMPRES Adaptive Charger will not overheat the battery regardless of how long
it is left in the pocket. The charger monitors the battery and automatically “tops off”
the battery, as required.
The IMPRES Adaptive Charger simplifies the charging and battery care process: All
a user needs to do is follow these simple steps:
1. Place the radio / battery in the charger
2. Remove the radio / battery when it's fully charged!
Motorola is the only manufacturer that offers a conditioning or reconditioning
charger that provides users with the choice of charging the radio with the battery
attached or the battery separately.
OPERATIONAL CHARACTERISTICS / DIFFERENCES:
1. IMPRES batteries may be charged in conventional chargers. However, in order
for the Smart Energy features to be enabled, each IMPRES battery must be
charged in an IMPRES Adaptive Charger. The first time an IMPRES battery is
charged in an IMPRES Adaptive Charger, the charger initially indicates a
STEADY YELLOW on the charger indicator. This first charge must be allowed
to complete to a STEADY GREEN indication on the charger indicator. This
properly calibrates the IMPRES battery and enables the Smart Energy
features. If this process is interrupted, the charger will calibrate the battery upon
the next insertion.
2. Since the IMPRES Adaptive Charger automatically determines the conditions
necessary to recondition the IMPRES battery, the charger may go into
recondition mode when a radio or battery is inserted. This is indicated by a
STEADY YELLOW on the charger indicator. The recondition mode can be
overridden, if required, by removing and reinserting the radio or battery. (Please
see instructions later in this guide.)
3. The IMPRES Adaptive Charger is designed to charge any battery listed in
Table 1 on page 5. However, only genuine IMPRES batteries will provide Smart
Energy features. (As new radio or battery models are introduced, this list will be
amended and distributed to customers via the various Global OEM and
Aftermarket organizations)
4. The IMPRES Adaptive Charger must be used to calibrate IMPRES Smart
batteries to ensure they accurately record, store and display IMPRES battery
usage data.
6864121B18.book Page 4 Thursday, October 9, 2014 11:35 PM

5
English
Table 1. Motorola Authorized Batteries
Kit (PN) Chemistry HazLoc Smart
HNN9028 NiCD No Yes
HNN9029 NiCD FM Yes
NTN7143 NiCD No No
NTN7144 NiCD No No
NTN7146 NiCD FM No
NTN7147 NiCD FM No
NTN7149 NiCD No No
NTN7150 NiCD No No
NTN7341 NiCD FM No
NTN7372 NiCD FM No
WPPN4013 NiMH No No
WPPN4037 NiMH FM No
HNN9031 NiCD No Yes
HNN9032 NiCD FM Yes
NTN8294 NiCD No No
NTN8295 NiCD FM No
NTN8297 NiCD FM No
NTN8299 NiMH FM No
NTN8610 LiIon No No
NTN8923 NiMH No No
HNN9033 NiCD No Yes
HNN9034 NiCD FM Yes
NTN4537*NiCD FM No
NTN4538 NiCD FM No
NTN4592*NiCD No No
NTN4593 NiCD No No
NTN4595 NiCD No No
NTN4596 NiCD FM No
NTN4657 NiCD No No
NTN4992 NiCD FM No
6864121B18.book Page 5 Thursday, October 9, 2014 11:35 PM

6
English
NTN7014*NiMH No No
NTN7058 NiCD FM No
NTN7426 NiMH FM No
NTN8251 NiMH FM No
NTN8818*LiIon No No
PMNN4047 LiIon No Yes
PMNN4048 NiMH No Yes
PMNN4049 NiMH FM Yes
PMNN4050 LiIon No Yes
PMNN4083*** Lilon No No
NTN7394** NiMH No No
NTN7395** NiCD No No
NTN7396** NiMH No No
NTN7397** NiMH FM No
NTN7398** NiCD FM No
NNTN6944*** Lilon No No
NNTN8128**** LiIon No Yes
NNTN8129**** LiIon FM Yes
NNTN8560**** LiIon TIA4950 Yes
PMNN4424**** LiIon No Yes
PMNN4448**** LiIon No Yes
Table 1. Motorola Authorized Batteries (Cont.)
Kit (PN) Chemistry HazLoc Smart
6864121B18.book Page 6 Thursday, October 9, 2014 11:35 PM

7
English
POWER SOURCES AND MOTOROLA AUTHORIZED POWER
ADAPTERS
This charger is designed for use in 100 V ac to 240 V ac, 50/60 Hz applications and
uses the following Motorola power cords:
*= Charger requires battery adapter P/N: 5889254E01, which
can be purchased from the Radio sales or Aftermarket sales
team representative.
** = Charger requires battery adapter P/N: PMLN5122, which can
be purchased from the Radio sales or Aftermarket sales team
representative.
*** = Charger requires battery adapter P/N: PMLN5429, which can
be purchased from the Radio sales or Aftermarket sales team
representative. Applicable to NNTN6944 and PMNN4083
batteries with manufacturing date code 846 onward.
**** = Charger requires battery adapter P/N: NNTN8169, which can
be purchased from the Radio sales or Aftermarket sales team
representative.
Table 2. Motorola Power Cords
Plug Type Charger Kit Power Cord
No Power cord / plug WPLN4114_R None
U.S./NA (with U.S. User Guide) WPLN4111_R 3004209T03
Euro WPLN4112_R 3004209T01
U.S./NA (with Euro User Guide) WPLN4117_R 3004209T03
U.K. WPLN4113_R 3004209T02
Australia/NZ WPLN4115_R 3004209T07
Argentina WPLN4116_R 3004209T08
Table 1. Motorola Authorized Batteries (Cont.)
Kit (PN) Chemistry HazLoc Smart
6864121B18.book Page 7 Thursday, October 9, 2014 11:35 PM

8
English
OPERATING INSTRUCTIONS
The charger’s pocket accommodates either a radio with a battery attached or a
battery alone. Prior to charging a radio with a battery, turn the radio off.
Batteries charge best if they are at room temperature when charged.
1. Plug the charger end of the power cord into the ac receptacle located at the
back of the charger.
2. Plug the wall receptacle end of the power cord into the appropriate ac outlet. A
successful power-up sequence is indicated by a SINGLE FLASH GREEN on
the charger indicator.
3. Insert a battery, or a radio with a battery (radio turned off), into the charger’s
pocket by:
a. Aligning the groove on each side of the battery with the corresponding raised
rail on each side of the charger pocket.
b. Pressing the battery toward the rear of the pocket.
c. Sliding the battery into the charger pocket, ensuring complete contact
between the charger and battery contacts.
Once the battery is properly seated into the pocket, the charger indicator
illuminates, indicating the charger has recognized the presence of the battery. Refer
to the charging indicators in Table 3 on page 9.
NOTE
The adaptive charger charges only the Motorola authorized
batteries listed in Table 1 on page 5. Other batteries may not
charge.
The adaptive charger has automatic features and capabilities that
are different from other battery chargers. Pay close attention to
the charge indicator to ensure that the charger is in the desired/
expected mode of operation.
NOTE
If a battery requires one of the battery adapters (see Table 1),
push back the battery guide (inside rear of the pocket) and slide
the battery adapter in place. When applicable, reverse the
procedure to remove the adapter.
6864121B18.book Page 8 Thursday, October 9, 2014 11:35 PM

9
English
In order for the features of Motorola Smart batteries and the Adaptive Charging
System to be fully available, the data contained in Motorola Smart batteries must be
initialized by the charger the first time it is charged. This process is indicated by a
STEADY YELLOW on the charger indicator (the same as though the battery were
reconditioning). The process is automatic, includes an initial reconditioning of the
battery, and begins charging upon completion of this process. This process requires
time to initialize the battery, so the battery should be left in the charger overnight on
the initial insertion.
Table 3. IMPRES Battery Charging Indicatprs
Charge Indicator Description
Single Flash Green Charger has successfully powered up.
Steady Red Battery is in rapid charge mode.
Flashing Green Battery has completed rapid charge (>90% available
capacity). Battery is in Top-Off charge (Trickle charge).
Steady Green Battery has completed charging and is fully charged.
Flashing Yellow Battery is recognized by charger but is waiting to
charge. (Either the battery voltage is too low or the
battery temperature is too low or to high to allow
charging. When this condition is corrected, the battery
will begin charging.)
Flashing Red Battery is unchargeable or not making proper contact.
Steady Yellow (This feature is for Smart batteries only)
Battery is in recondition mode. The length of time the
charger remains in this mode is dependent upon the
state of charge remaining in the battery when inserted.
(Fully charged batteries require more time to
recondition – 8 hours or more - than fully discharged
batteries.)
Flashing Red/Green (This feature is for Smart batteries only)
Battery has completed charging and is fully charged.
Battery continues to be usable and receives all IMPRES
benefits including usage tracking and automatic
reconditioning, but may be nearing the end of its rated
service life.
NOTE
The IMPRES Adaptive Charger is unique in that it has the ability,
when used with Motorola IMPRES batteries, to automatically
determine the need of the battery to be reconditioned.
6864121B18.book Page 9 Thursday, October 9, 2014 11:35 PM

10
English
The IMPRES Adaptive Charger operates both as:
•aCharger with all Motorola authorized batteries, and
•aReconditioner with Motorola authorized IMPRES batteries.
Charging the Battery
To ensure optimum performance, Motorola recommends all new batteries be left in
the charger 14 to 16 hours prior to initial use.
1. Once a battery or a radio with a battery is properly inserted into the charger, the
charger begins to rapid charge the battery and is indicated by a STEADY RED on
the charger indicator. The length of time the charger indicates STEADY RED is
dependent upon the charge remaining in the battery.
2. Completion of rapid charge (>90% available capacity) is indicated by a
FLASHING GREEN on the charger indicator. This indicates the “top-off” charge
(trickle charge) and requires approximately 1 hour.
3. Completion of “top-off” charge is indicated by a STEADY GREEN on the
charger indicator. This indicates the battery is fully charged.
4. Other indications that may appear on the charger indicator while charging are:
•FLASHING YELLOW – indicates that either the battery temperature or
battery voltage is out of range for charging. Charging resumes when these
conditions have been corrected.
•FLASHING RED AND GREEN – indicates that the battery may be
approaching the end of its rated service life. While this battery is fully
charged, its charging capacity has been reduced by usage and may not
adequately support heavier applications. This feature is available only
when used with Motorola IMPRES batteries. This is not a fault indication,
merely a notification to the user that the battery may soon no longer be able
to yield expected service and may need to be replaced. When this
indication occurs, contact your Motorola Sales Representative for
replacement batteries.
IMPORTANT:
The charger pocket is designed to accept several different battery
shapes and sizes, so it is important to make certain that a radio
with a battery attached or battery alone is inserted correctly. If a
radio with a battery attached or battery alone is inserted
incorrectly, the indicator will not illuminate, indicating that the
battery is not being charged.
NOTE:
New batteries (never used before) prematurely indicate a full
charge in some cases (STEADY GREEN indication)
6864121B18.book Page 10 Thursday, October 9, 2014 11:35 PM

11
English
•FLASHING RED – indicates that the battery is unchargeable. This could be
the result of a loss of contact between the battery and the charger.
Charging resumes when the condition causing this indication is corrected.
Motorola Smart batteries have an internal memory device that is read by the
Motorola IMPRES Adaptive Charger. If an IMPRES battery is charged for more
than 2-1/2 minutes, the IMPRES Adaptive Charger retains the serial number of the
IMPRES battery. The IMPRES battery may be removed from the charger for up to
30 minutes. Once the battery is reinserted back into the charger, it will resume the
charging process from that point from when the battery was first removed.
Manually Reconditioning the Battery
Within 2-1/2 minutes of the initial insertion of an IMPRES battery (STEADY RED
indication), remove and reinsert the battery within 5 seconds to manually force
reconditioning to occur. The charger indicator changes from a STEADY RED to a
STEADY YELLOW. This forces the charger to recondition and automatically
recharge the battery.
Automatically Reconditioning the Battery
The Motorola IMPRES Adaptive Charger, when used in conjunction with a Motorola
IMPRES battery, has the ability to determine when it is appropriate to recondition
the battery.
When an IMPRES battery is properly inserted into the charger, the charger
determines if it is appropriate to recondition the battery. If the battery needs
reconditioning, the charger automatically indicates a STEADY YELLOW. This
process may take up to 8 hours or more to complete, depending upon the state of
charge and capacity rating of the battery when it is inserted.
It is important to note, for this process to be effective, the battery must be
allowed to complete the recondition/recharge process. Leave the battery in
the charger until the charger indicates a STEADY GREEN.
At the completion of the recondition cycle, the charger automatically recharges the
battery.
NOTE:
Excessive use of this feature reduces the cycle life of the battery.
6864121B18.book Page 11 Thursday, October 9, 2014 11:35 PM

12
English
Manually Terminating the Reconditioning Process
At any time during the reconditioning process of a Motorola IMPRES battery
(STEADY YELLOW indication), reconditioning may be terminated by removing and
reinserting the battery within 5 seconds. This causes the charger to terminate the
reconditioning process and begin the charging process. The charger indicator
changes to a STEADY RED.
Removing a Radio or Battery from the Charger
Use two hands to remove a radio or battery from the charger pocket – one hand to
hold and support the charger, and the other hand to remove the radio or battery.
TROUBLESHOOTING
The IMPRES Adaptive Charger incorporates the features of:
• a universal input (100 V ac-240 V ac, 50/60 Hz) power supply
• a constant current rapid charger,
• an interrupted current (negative pulse) conditioning charger
• a reconditioning unit.
The combination of the features listed above are unique in a desktop charger.
Therefore, operation of the radio with a battery attached while in the charger is not
recommended.
While in the charger, radio operation may result in minimally reduced radio
performance and extended battery charge time.
Additionally, the conditioning charge feature of this system creates an audible
“ticking” sound in the receiving radio during the rapid and trickle charge modes of
operation. This sound is caused by periodic discharge pulses to the battery. Should
this sound be objectionable to the user, changing the switch position located on the
bottom of the charger from position “A” to position “B” reduces the frequency of the
discharge pulses. This has a minimal impact on the effectiveness of the charger.
Towards the end of the rapid charge cycle (STEADY RED indication), the battery
voltage exceeds the normal operating voltage of the radio. The voltage returns to a
normal level following the rapid charge mode or when the battery is removed from
the charger.
If the radio is turned on while the charger is in rapid charge mode, the radio
becomes temporarily inoperable. This condition can be cleared by removing the
radio from the charger and turning the radio off and on again.
6864121B18.book Page 12 Thursday, October 9, 2014 11:35 PM

13
English
During the reconditioning process, the battery becomes fully discharged. As a
result, the radio may not function during reconditioning mode.
In some cases, such as use near fluorescent lighting or electric motors, a slight
hum may be noticed in the receiving radio. If this occurs, moving the charger or
repositioning the power cord should eliminate the hum.
When troubleshooting, always observe the charge indicator – Refer to Table 3 on
page 9.
Table 4. Troubleshooting
Problem What it means... What to do...
No charger
indication
1a. Charger contact is not
being made.
1b. No power to the charger.
1a. Check that the radio with battery,
or the battery alone, is inserted
correctly.
1b. Make sure that the power cord is
securely plugged into the
charger and an appropriate ac
outlet, and that there is power to
the outlet.
Flashing Red
Indication
2a. Charger contact is not
being made.
2b. Battery is unchargeable.
2a. • Remove the battery from the
charger and replace it back
into the charger.
• Verify that the battery is a
Motorola authorized battery
listed in Table 1. Other
batteries may not charge.
• Remove power from the
battery charger and, using a
clean dry cloth, clean the gold
metal charging contacts of
both the battery and the
charger.
2b. Replace battery.
Flashing Yellow
Indication
3. Battery is waiting to
charge. The battery
temperature may be
below 5°C (41°F) or
above 40°C (104°F) or
the battery voltage may
be lower than the
predetermined threshold
level for rapid charging.
3. When this condition is corrected,
the battery will begin charging.
6864121B18.book Page 13 Thursday, October 9, 2014 11:35 PM

14
English
SERVICE
Adaptive Single-unit Chargers are not repairable. Order replacement chargers as
necessary from your local Motorola Sale Representative.
6864121B18.book Page 14 Thursday, October 9, 2014 11:35 PM

1
Deutsch
INHALTSVERZEICHNIS
Wichtige Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnhinweise für den Betrieb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Sicherheitsrichtlinien für den Betrieb . . . . . . . . . . . . . . . . . . . . . . . . . 3
Leistungsmerkmale des IMPRES-Ladegeräts . . . . . . . . . . . . . . . . . . 3
Betriebscharakteristik und funktionelle Unterschiede: . . . . . . . . . . . . 4
Netzteile und von Motorola zugelassene Netzadapter . . . . . . . . . . . . 7
Bedienungsanleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Laden des Akkus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Manuelle Rekonditionierung des Akkus . . . . . . . . . . . . . . . . . . . . 11
Automatische Rekonditionierung des Akkus . . . . . . . . . . . . . . . . 11
Manuelles Beenden des Rekonditionierungsprozesses . . . . . . . . 12
Entnehmen des Handsprechfunkgeräts bzw. des Akkus aus dem
Ladegerät . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Fehlersuche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wartung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6864121B18.book Page 1 Thursday, October 9, 2014 11:35 PM

2
Deutsch
DAS IMPRES-LADEGERÄT WEIST EINZIGARTIGE
LEISTUNGSMERKMALE AUF, DIE SIE BEI KEINEM ANDEREN
LADEGERÄT FINDEN WERDEN.
LESEN SIE DIESES HANDBUCH SORGFÄLTIG UND
VOLLSTÄNDIG DURCH, BEVOR SIE DAS IMPRES-LADEGERÄT
BENUTZEN:
WICHTIGE SICHERHEITSHINWEISE
Dieses Dokument enthält wichtige Sicherheits- und Bedienungshinweise. Bitte
lesen Sie diese Hinweise sorgfältig durch und heben Sie das Handbuch auf, damit
Sie sie später jederzeit nachschlagen können.
WARNHINWEISE FÜR DEN BETRIEB
1. Um die Verletzungsgefahr zu verringern, dürfen nur die in Tabelle 1 auf Seite 5
aufgeführten, von der Firma Motorola zugelassenen Akkus aufgeladen werden.
Andere Akkus können beim Aufladen explodieren und Verletzungen bzw.
Sachschäden verursachen.
2. Bei Verwendung von Zubehörteilen, die nicht von der Firma Motorola
freigegeben sind, besteht Feuer-, Stromschlag- und Verletzungsgefahr.
3. Ziehen Sie den Stecker niemals am Kabel aus der Steckdose, wenn Sie die
Stromversorgung des Ladegeräts unterbrechen möchten, um Beschädigungen
des Netzkabels und des Steckers zu vermeiden.
4. Verwenden Sie nach Möglichkeit kein Verlängerungskabel. Bei Verwendung
eines ungeeigneten Verlängerungskabels besteht Brand- und
Stromschlaggefahr. Wenn der Einsatz eines Verlängerungskabels unbedingt
erforderlich ist, sollten Sie auf die richtigen Kabeldimensionen achten.
5. Bei Verwendung schadhafter Ladegeräte besteht Feuer-, Stromschlag- und
Verletzungsgefahr.
6. Das Ladegerät kann nicht repariert werden, es enthält keine auswechselbaren
Teile und darf nicht auseinandergebaut werden, da hierbei Stromschlag- und
Feuergefahr besteht.
7. Bevor Sie das Ladegerät warten oder reinigen, sollten Sie den Netzstecker
abziehen, um einem Stromschlag vorzubeugen.
8. Defekte Sicherungen dürfen nur durch Sicherungen ersetzt werden, die den
Angaben auf dem Etikett am Ladegerät entsprechen.
9. Dies ist ein als Klasse A eingestuftes Produkt. In häuslicher Umgebung kann
dieses Produkt Funkstörungen verursachen. In diesem Fall obliegt es dem
Benutzer, entsprechende Maßnahmen zu ergreifen.
!
6864121B18.book Page 2 Thursday, October 9, 2014 11:35 PM

3
Deutsch
SICHERHEITSRICHTLINIEN FÜR DEN BETRIEB
• Schalten Sie das Handsprechfunkgerät zum Laden des Akkus ab.
• Das Ladegerät ist nicht für den Einsatz im Freien ausgelegt und darf nur in
trockenen Räumen betrieben werden.
• Schließen Sie das Ladegerät nur an eine ordnungsgemäß gesicherte und
verkabelte Steckdose an, die die richtige Spannung aufweist (siehe Etikett am
Ladegerät).
• Ziehen Sie den Netzstecker ab, wenn das Ladegerät von der Netzspannung
isoliert werden soll.
• Die Steckdose für das Ladegerät muss in der Nähe befindlich und leicht
erreichbar sein.
• In Geräten mit Überspannungsschutz dürfen nur solche Sicherungen verwendet
werden, die dem in der Bedienungsanleitung angegebenen Typ entsprechen.
• Das Ladegerät darf bei Umgebungstemperaturen über 40°C nicht eingesetzt
werden.
• Achten Sie darauf, dass Sie das Kabel so verlegen, dass niemand darauf treten
oder darüber stolpern kann. Außerdem darf es nicht mit Wasser in Berührung
kommen, Zugkräften ausgesetzt werden oder beschädigt werden.
LEISTUNGSMERKMALE DES IMPRES-LADEGERÄTS
Das IMPRES Akkuladesystem von Motorola ist ein modernes Energiesystem für
drei verschiedene Akkutypen. Zum System gehören: (a) IMPRES-Akkus, (b) das
IMPRES-Ladegerät und (c) Funkgerät-Hardware/Software, über die der
Datenaustausch zwischen IMPRES-kompatiblen Handsprechfunkgeräten und
IMPRES-Akkus möglich ist.
Die Verwendung des IMPRES-Ladegeräts zusammen mit IMPRES-Akkus bietet
die folgenden Vorzüge:
1. Die Betriebszeit zwischen Ladezyklen wird maximiert, da der Memory-Effekt
automatisch eliminiert wird.
2. Die Akku-Lebensdauer wird maximiert, da wesentlich weniger Wärme während
der Erhaltungsladezyklen und der an das Laden anschließenden Zyklen
entsteht.
3. Der Kauf von zusätzlichen Rekonditionierungsgeräten wird überflüssig, ebenso
die Schulung von Personal in „Akkuwartungsaufgaben“.
Mit diesem einzigartigen, patentierten Akkuladesystem gehören das Kontrollieren
und Protokollieren der Akkunutzung, die Durchführung manueller
Rekonditionierungszyklen und die Notwendigkeit, Akkus nach dem Aufladen aus
dem Ladegerät nehmen zu müssen, der Vergangenheit an.
6864121B18.book Page 3 Thursday, October 9, 2014 11:35 PM

4
Deutsch
Das IMPRES-Ladegerät überwacht die Nutzungsmuster der IMPRES-Akkus,
speichert diese Informationen im IMPRES-Akku und führt nur dann einen
Rekonditionierungszyklus durch, wenn es erforderlich ist.
Im IMPRES-Ladegerät wird der Akku nie zu heiß, ganz gleich, wie lange er in der
Ladeschale steckt. Das Ladegerät überwacht den Akku und lädt ihn bei Bedarf
automatisch nach.
Mit dem IMPRES-Ladegerät wird der Lade- und Akkuwartungsprozess vereinfacht:
Gehen Sie einfach wie folgt vor:
1. Setzen Sie das Handsprechfunkgerät/den Akku in das Ladegerät ein.
2. Nehmen Sie das Handsprechfunkgerät/den Akku aus dem Ladegerät,
wenn es/er vollständig geladen ist!
Motorola ist der einzige Hersteller, der ein Konditionierungs- oder
Rekonditionierungsladegerät anbietet, bei dem Benutzer die Wahl haben, das
Funkgerät mit eingesetztem Akku oder den Akku separat aufzuladen.
BETRIEBSCHARAKTERISTIK UND FUNKTIONELLE
UNTERSCHIEDE:
1. IMPRES-Akkus können in herkömmlichen Ladegeräten geladen werden. Die
Chip-Funktion dieser Akkus werden aber nur dann aktiviert, wenn der IMPRES-
Akku in einem IMPRES-Ladegerät geladen wird. Wenn ein IMPRES-Akku das
erste Mal in einem IMPRES-Ladegerät aufgeladen wird, leuchtet die
Ladeanzeige des Ladegeräts zunächst GELB. Die Erstladung darf nicht
unterbrochen werden, d.h. der Akku darf erst dann aus dem Ladegerät
genommen werden, wenn die Ladeanzeige GRÜN leuchtet. Der IMPRES-Akku
wird dadurch ordnungsgemäß kalibriert und die Chip-Funktion aktiviert. Wird
der Erstladungsprozess unterbrochen, kalibriert das Ladegerät den Akku, wenn
er das nächste Mal in die Ladeschale gesteckt wird.
2. Das IMPRES-Ladegerät bestimmt die zum Rekonditionieren des IMPRES-
Akkus erforderlichen Bedingungen jeweils automatisch und schaltet daher
eventuell auf Rekonditionierungsbetrieb, wenn ein Handsprechfunkgerät oder
ein Akku in die Ladeschale gesteckt wird. Die Ladeanzeige leuchtet in diesem
Fall GELB. Der Rekonditionierungsbetrieb kann erforderlichenfalls durch
Herausnehmen und erneutes Einsetzen des Handsprechfunkgeräts bzw. Akkus
umgangen werden (siehe Gebrauchsanleitung in diesem Handbuch).
3. Das IMPRES-Ladegerät eignet sich zum Laden aller in Tabelle 1 auf Seite 5
aufgelisteten Akkus. Die Chip-Funktion steht allerdings nur bei Original-
IMPRES-Akkus zur Verfügung. (Bei der Einführung neuer
Handsprechfunkgeräte- bzw. Akkumodelle wird diese Liste entsprechend
aktualisiert und über die diversen globalen OEM- und
Kundendienstorganisationen an die Kunden verteilt.)
6864121B18.book Page 4 Thursday, October 9, 2014 11:35 PM
