Nec N401i User manual

Emergency Services and Safety

Precautions

Emergency Services

To make an emergency call in any country

☛Press 1 1 2 .

Ask the operator for the service which you require: Police,

Ambulance, Fire Brigade, Coastguard or Mountain Rescue

Services. Give your position and, if possible, remain

stationary to maintain phone contact.

The 112 emergency number service is available on every

digital network service. The number 999 is an alternative

emergency number for the UK only, and can only be used

with a valid SIM card.

2Due to the nature of the cellular system, the

success of emergency calls cannot be

guaranteed.

General Care

A cellphone contains delicate electronic circuitry, magnets,

and battery systems. You should treat it with care and give

particular attention to the following points.

•Do not allow the phone or its accessories to come into

contact with liquid or moisture at any time.

•Do not place anything in the folded phone.

•Do not expose your phone to extreme high or low

temperatures.

•Do not expose your phone to naked flame, cigars or

cigarettes.

•Do not paint your phone.

•Do not drop or subject your phone to rough treatment.

•Do not place the phone alongside computer disks, credit

cards, travel cards and other magnetic media. The

information contained on disks or cards may be affected

by the phone.

•Do not leave the phone or the battery in places where the

temperature could exceed 60°C; e.g. on a car dashboard

or on a window sill, behind glass in direct sunlight, etc.

•Do not remove the phone’s battery while the phone is

switched on.

•Take care not to allow metal objects, such as coins or key

rings, to contact or short-circuit the battery terminals.

•Do not dispose of battery packs in a fire. Your phone's Li-

ion batteries may be safely disposed of at Li-ion recycling

points. For more specific battery and power supply

information, see page 3.

•Do not put your phone's battery in your mouth as battery

electrolytes may be toxic if swallowed.

•Do not attempt to dismantle the phone or any of its

accessories.

•This equipment is fitted with an internal battery that can

only be replaced by a qualified service engineer. There is

a risk of explosion if the battery is replaced by an

incorrect type. Dispose of the used battery in accordance

with the manufacturer's instructions.

•Using any battery pack, AC adapter or Vehicle power

adapter (option) not specified by the manufacturer for

use with this phone creates a potential safety hazard.

•The earpiece may become warm during normal use and

the unit itself may become warm during charging.

•Use a damp or anti-static cloth to clean the phone. Do

NOT use a dry cloth or electrostatically charged cloth. Do

not use chemical or abrasive cleaners as these could

damage the case.

•Remember to recycle: the cardboard packaging supplied

with this phone is ideal for recycling.

•Do not leave the battery pack empty or disconnected for

a long time, otherwise some data may be initialized.

•Your phone contains metal which may cause you an itch,

a rash or eczema depending on your constitution or

physical condition.

•Take care not to put your phone in the back pocket of

your trousers or skirt and then sit on it. Also, do not put

your phone at the bottom of bag where it may subject to

excessive weight or pressure.

Doing so may damage the LCD and camera lens and

cause them malfunction.

•Take care not to hold the Light too close to your or other

people’s eyes when the Light is lit.

•Do not aim or direct the InfraRed (IR) data port towards

your or other people’s eyes when using the IR data

exchange.

•The foam covers the earpiece of the headset (option). Do

not put any other part of the headset in your ears.

Aircraft Safety

•Switch off your phone and remove its battery when inside

or near aircraft. The use of cellphones in aircraft is illegal.

It may be dangerous to the operation of the aircraft and it

may disrupt the cellular network. Failure to observe this

instruction may lead to suspension or denial of cellphone

service to the offender, or legal action, or both.

•Do not use your phone on the ground without the

permission of the ground crew.

Hospital Safety

•Switch off your phone in areas where the use of

cellphones is prohibited. Follow the instructions given by

the respective medical facility regarding the use of

cellphones on their premises.

General Safety

•Observe ‘Turn off 2-way radio’ signs, such as those near

stores of fuel, chemicals or explosives.

•Do not allow children to play with the phone, charger or

batteries.

•Small parts are included in your phone. Keep them out of

reach of small children, for whom it could be a choking

hazard.

•The operation of some medical electronic devices, such

as hearing aids and pacemakers, may be affected if a

cellphone is used next to them. Observe any warning

signs and manufacturer's recommendations.

•If you have a weak heart, you should take extra

precautions when setting functions such as the Vibrator

and Ringer volume functions for incoming calls.

•If you set the Vibrator setting to anything other than OFF,

be careful that the phone is not near a source of heat

(e.g. a heater) and that it does not fall from a desk due to

the vibration.

Road Safety

•You MUST exercise proper control of your vehicle at all

times. Give full attention to driving.

•Observe all the recommendations contained in your local

traffic safety documentation.

•Pull off the road and park before making or answering a

call if driving conditions so require.

•You MUST NOT stop on the hard shoulder of a motorway

to answer or make a call, except in an emergency.

•Switch off your phone at a refuelling point, such as a

petrol station, even if you are not refuelling your own car.

•Do not store or carry flammable or explosive materials in

the same compartment where a radio transmitter, such

as a cellphone, is placed.

•Electronic vehicle systems, such as anti-lock brakes,

speed control and fuel injection systems are not normally

affected by radio transmissions. The manufacturer of

such equipment can advise if it is adequately shielded

from radio transmissions. If you suspect vehicle

problems caused by radio transmissions, consult your

dealer and do not switch on your phone until it has been

checked by qualified approved installers.

Vehicles Equipped with an Air Bag

An air bag inflates with great force. Do not place objects,

including either installed or portable

wireless equipment, in the area over the air bag or in the

air bag deployment area. If in-vehicle wireless equipment

is improperly installed and the air bag inflates, serious

injury could result.

Emergency Services and

Safety Precautions

Third Party Equipment

The use of third party equipment, cables or accessories,

not made or authorized by NEC, may invalidate the

warranty of your cellphone and also adversely affect the

phone’s operation. For example use only the NEC mains

cable supplied with the AC charger.

Service

The cellphone, batteries and charger contain no user-

serviceable parts. We recommend that your NEC

cellphone is serviced or repaired by an NEC authorized

service centre. Please contact your Service Provider or

NEC for advice.

Non-Ionizing Radiations

The radio equipment shall be connected to the antenna via

a non-radiating cable (e.g. coax).

The antenna shall be mounted in a position such that no

part of the human body will normally rest close to any part

of the antenna unless there is an intervening metallic

screen, for example, the metallic roof.

Use only an antenna that has been specifically designed

for your phone. Use of unauthorized antennas,

modifications or attachments could damage your phone

and may violate the appropriate regulations, causing loss

of performance and radio frequency (RF) energy above the

recommended limits.

Efficient Use

For optimum performance with minimum power

consumption, note the following:

•Your phone has the internal antenna. Do not cover part

of the internal antenna of the phone with your hands. This

affects call quality, may cause the phone to operate at a

higher power level than needed and may shorten talk and

standby times.

Radio Frequency Energy

Your phone is a low-power radio transmitter and receiver.

When it is turned on, it

intermittently receives and transmits radio frequency (RF)

energy (radio waves). The system that handles the call

controls the power level at which the phone transmits.

Exposure to Radio Frequency Energy

Your phone is designed not to exceed the limits for

exposure to RF energy set by national authorities and

international health agencies. * These limits are part of

comprehensive guidelines and establish permitted levels

of radio wave exposure for the general population. The

guidelines were developed by independent scientific

organizations such as ICNIRP (International Commission

on Non-Ionizing Radiation Protection) through periodic and

thorough evaluation of scientific studies. The limits include

a substantial safety margin designed to assure the safety

of all persons, regardless of age and health, and to account

for any variations in measurements.

*Examples of radio frequency exposure guidelines and

standards that your phone is designed to conform to:

•ICNIRP, “Guidelines for limiting exposure to time-varying

electric, magnetic, and electromagnetic fields (up to 300

G Hz)-International Commission on Non-Ionizing

Radiation Protection (ICNIRP)”.

Health Physics, vol. 74. pp, 494-522, April 1998.

•99/519/EC Council Recommendation on the limitation of

exposure to the general public toelectromagnetic fields

0 Hz-300 GHz, Official Journal of the European

Communities, July 12,1999.

•ANSI/IEEE C95.1-1992. “Safety levels with respect to

human exposure to radio frequencyelectromagnetic

fields, 3kHz to 300 GHz”. The Institute of Electrical and

Electronics Engineers Inc., New York, 1991.

•FCC Report and Order, ET Docket 93-62, FCC 96-326,

Federal Communications Commission (FCC), August

1996.

•Radio communications (Electromagnetic Radiation

Human Exposure) Standard 1999, Australian

Communications Authority (ACA), May 1999.

Declaration of Conformity

•This product complies with the requirements of the

R&TTE Directive 1999/5/EC. The ‘Declaration of

Conformity’ leaflet can be found within this box.

License

•T9®Text Input and the T9 logo are registered trademarks

of Tegic Communication.

“T9 Text Input is licensed under one or more of the

following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,

5,945,928, 6,011,554, and 6,307,548; Australian Pat.

No. 727539; Canadian Pat. No. 1,331,057; United

Kingdom Pat. No. 2238414B; Hong Kong Standard Pat.

No. HK0940329; Republic of Singapore Pat. No. 51383;

Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR,

IT, NL, PT. ES, SE, GB; Republic of Korea Pat. Nos.

KR201211B1 and KR226206B1; and additional patents

are pending worldwide”

•USE OF THIS PRODUCT IN ANY MANNER THAT

COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS

PROHIBITED, EXCEPT FOR USE DIRECTLY

RELATED TO (A) DATA OR INFORMATION ENCODED

BY A CONSUMER FOR PERSONAL AND NON-

COMMERCIAL USE WITHOUT REMUNERATION; (B)

DATA OR INFORMATION (i) GENERATED BY AND

OBTAINED WITHOUT CHARGE FROM A CONSUMER

NOT THEREBY ENGAGED IN A BUSINESS

ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY;

AND (C) OTHER USES SPECIFICALLY AND

SEPARATELY LICENSED BY MPEG LA, L.L.C.

•Helvetica is a registered Trademark of Heidelberger

Druckmaschinen AG which may be registered in certain

jurisdictions.

•Java and all Java-based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc in the U.S. and other countries.

•This product contains ACCESS Co., LTD’s Compact

NetFront™ Plus internet browser software.

Compact NetFront™ is a registered trademark or

trademark of ACCESS CO., LTD in Japan and selected

countries worldwide.

•This product contains ACCESS CO., LTD’s JV-Lite2™

Java virtual machine software.

JV-Lite2™ is a registered trade mark or trademark of

ACCESS COl, LTD, in Japan and selected countries

world wide.

•This product contains ACCESS CO., LTD's IrFront®

Infrared communication software.

•i-mode and i-mode logos are trademarks or registered

trademarks of NTT DoCoMo.

For the purpose of improvement, the specifications for

this product and its accessories are subject to complete

or partial change without prior notice.

iii

Before You Start

User’s manual conventions

The instructions in this user’s manual make use of the shortcuts selection except special cases.

The following markers are used throughout the user’s manual to attract your attention:

/This type of paragraph will contain details of where to find information related to the topic in question.

2This type of paragraph will contain information worth noting.

,This type of paragraph will contain important information.

☛This type of description will contain procedures to operate your phone.

Menu shortcuts selection

The alternative shortcuts method of selection lets you jump straight to a menu or function without highlighting an icon and scrolling through the

intermediate menu options. The selection are made by pressing numbers on the keypad which relate to the displayed menu options.

2The instructions in this user’s manual make use of the shortcuts selection, except in special cases.

Reading the titles

Some titles in this manual contain information on how to access the functions. In these titles, Mstands for , the numbers indicate the menu shortcut

numbers (see “Overview of menu function” on page ix for details) and ... (three periods) indicate that there are more operations described in the

paragraph.

Reading the procedures

“Highlight” means to use the four way navigation keys (▲▼ )to move the area emphasized with different colouring.

“Select” means to highlight an item and then press .

Procedures are written omitting the verb “press”, except in some special cases.

For example, 12 means to:

☛Start from the standby screen ➔ Press to display the Main menu screen

☛Press 1 to display the Settings screen ➔ Press 2 to display the Phone modes screen

Simple procedures are connected by arrows (➔).

Check box/Radio button

A check box enables/disables an option out of a set of options, and multiple check boxes can be selected at the same time. On the other hand, selecting

a radio button automatically cancels the previous selection, so only one radio button can be selected at one time.

A check box/radio button option can be selected/cancelled by highlighting it and pressing .

▼

Display information

,The Liquid Crystal Displays (LCD) on your phone are manufactured using high-precision technology. Even so, the LCD may contain pixels

(dots) that fail to light or that remain permanently lit. Note that this is normal and does not indicate a problem with your display.

Status bar area

This area contains icons which

indicate the battery strength, new

SMS/MMS message(s), signal

strength, etc. (see page vii).

On screens other than the

standby screen, the clock display

is placed in this area.

Softkey area

This area contains context sensitive descriptions of the

Softkeys’ functions appropriate for the current screen.

Shortcut number

Press the appropriate number to

jump straight to a next menu. The

row colour is changed when

selected (e.g. to activate/deactivate

a facility).

Help icons

Displayed when you can use the key

represented by these icons (see page vii).

Next menu icon

Displayed when you can press or the

shortcut number to show the next menu.

▼

Page scroll bar

Displayed when

you can press ▼

to scroll to the next

page.

Shortcut menu

number

The current menu

number is displayed.

enu t

Desktop icon area

This area contains the

automatically displayed

and the manually created

desktop icons. They

provide shortcuts to

certain items/functions.

Help area

This area contains help

information appropriate

for the current screen

(e.g. key presses

remaining when

composing a message).

Parts and functions

Main-LCD

Send ( ) key

Softkey2(SK2)

Phonebook ( )key

End/on-off ( ) key

Alphanumeric keys

Mouthpiece

IR port

2nd-LCD

LED & light

Camera

Rear cover

Speaker

Clear (CLR)/Back key

Softkey1(SK1)

Menu ( ) key

Earphone

4 way navigation key

Select key

( )

Charger connector cover

Internal antenna

Side down key

Side up key

Through-hole

for straps

Earpiece

jack cover

for battery

(

)

Keypad shortcuts

The following operations are available from the standby screen.

Key Operation that involves pressing a key See page Operation that involves pressing and holding a key See page

Accessing the Main menu screen ix Setting/Cancelling the Side key lock 21

SK1 Accessing the Mail screen 42 Accessing the Inbox screen 42

SK2 Accessing the i-mode menu screen 38 Accessing the Java™ applications screen 66

Accessing the Phonebook list screen 47 Accessing the Message screen 27

▲Accessing the Phone modes screen 22 Setting the phone to Meeting mode/Returning to the previous

mode 22

▼Accessing the My data screen 61 Accessing the voice recall 7

Accessing the received calls list 10 Accessing the received calls list 10

Accessing the missed calls list 10 Accessing the missed calls list 10

Accessing the dialled calls list 10 Accessing the dialled calls list 10

Highlighting a desktop icon 19 Accessing the homepage (when Set homepage is set) 41

Ending a call or returning to the standby screen – Powering off 4

CLR Deleting character or returning to the previous screen – Deletes all the automatically displayed desktop icons 19

Deleting all characters when you enter text –

1Entering phone numbers 5 Calling the Voice mail centre 55

2to 9Entering phone numbers 5 One-touch dial to the corresponding number in the phonebook

(SIM) 7

0Entering phone numbers 5 Entering + when you make an international call 13

#Entering #6 Entering a pause –

Entering 6 Switching the ALS line 1/2 (if the SIM card supports ALS) 21

Side up

Accessing the volume control screen when your phone is open

(Use ▲▼, Side keys or 0to 9 keys to adjust the volume.) 21 Accessing the camera view finder screen 56

Activating the ring silencer function when you receive a call 21

Side down

Accessing the volume control screen when your phone is open

(Use ▲▼, Side keys or 0to 9 keys to adjust the volume.) 21 Turning on the light

(To turn it off, press any key or open/close your phone.) –

Activating the ring silencer function when you receive a call 21

▼

vii

LCD and displayed icons

Main-LCD

Indicates the battery level.

(red, green, blue)

Indicates the battery charging status (fast, slow,

pause).

Indicates that there is a new SMS in your phone.

Indicates that there is a new SMS on the network.

Indicates that the SIM memory is full.

Indicates that the Inbox in your phone is full.

(green)

Indicates that there is a mail on the server.

(blue)

Indicates that there is an MMS on the server.

(pink)

Indicates that there are mail and MMS on the server.

(orange)

Indicates that there is a new mail/MMS in your

phone.

2This orange icon blinks while a mail/MMS

is being downloaded

Indicates that the memory for mail/MMS is full.

(red, green/red, green)

Indicates that new voice mail messages are on the

network (No ALS/ALS Line 1/2).

Indicates secured communication on SSL.

Indicates that GPRS is active for purposes other

than i-mode connections.

(gray)

Indicates that the phone is in the GSM (Global

System for Mobile communication) network service

area and GPRS is active.

(yellow)

Indicates that the GPRS is available and i-mode is

active.

Indicates that the i-mode connection is carried out.

Indicates that the i-mode lock is on.

2No icon appears when the phone is outside

the GSM network service area, or when

the phone is in the GSM network service

area and GPRS is not attached.

Indicates the line status (ALS line 1/2 no ALS).The

icon with displayed in red indicates that the

ALS line 1 or 2 is unencrypted/no ALS.

Indicates the signal strength level.

Appears when you are outside the service area.

Network name (indicated in orange when using

roaming service)

Desktop icons

See “Desktop icons” on page 19 for details.

Indicates the call diversion is set.

Indicates the Meeting mode, Pocket mode, Car

mode.

2No icon appears for the Normal mode.

Indicates alarm-on, sound-off, vibrator-on, sound-

off/vibrator-on.

Indicates the IR modem is set to on, the auto start of

a Java™ application has failed.

Date

Day of week

Remote time

Local time

Indicates that you can use the options menu by

pressing

Indicates that you can use the phonebook list by

pressing .

Indicates the usable keys in black, while a Java™

application is in operation.

Indicates that the help display is available when

using SIM toolkit

136

789

viii

Indicates that a Java™ application is in operation.

<When the camera/video view finder is in

operation>

Indicates single/burst mode (camera).

Indicates the video mode is on or the video is

recording.

Indicates that the self timer is on.

Indicates the quality of the picture (super fine, fine,

normal, economy or super economy).

Indicates the quality of the video.

Indicates the photo/video screen size.

Indicates the shooting environment.

Indicates the brightness setting. The “+2” setting is

the brightest.

Indicates the zoom level.

Indicates the video mode is on, the video is playing,

on pause, fast forwarding, or rewinding.

Indicates the track information of the video (the video

file only, the video and audio file, or the audio file

only).

Indicates the video is played in normal/enlarged

screen size.

Displays the current volume level. The 0 is mute and

9 is the maximum.

2nd-LCD

Indicates the battery level.

(red, green, blue)

Indicates the battery charging status (fast, slow,

pause).

Indicates that there is a new SMS in your phone.

Indicates

that there is a new SMS on the network.

Indicates that the SIM memory is full.

Indicates that the Inbox in your phone is full.

(green)

Indicates that there is a mail on the server.

(blue)

Indicates that there is an MMS on the server.

(pink)

Indicates that there are mail and MMS on the server.

(orange)

Indicates that there is a new mail/MMS in your

phone.

Indicates that the memory for a mail/MMS is full.

(red, green/red, green)

Indicates that a new voice mail message is on the

network (No ALS/ALS Line 1/2).

Indicates that the alarm is set.

Indicates that the vibrator is set.

Indicates that the phone is in the Meeting mode,

Pocket mode, Car mode.

2No icon appears for the Normal mode.

Indicates the signal strength level.

Appears when you are outside the service area.

<When 2nd-LCD is used as the camera view finder

screen>

2The left image is when the phone is folded,

and the right image is when the phone is

open.

Indicates single or burst mode of the camera.

(blue)

Indicates that the video mode.

(red)

Indicates the video is recording.

Indicates that the self timer is on.

Indicates the photo/video screen size.

Indicates the battery level.

236

4578

Overview of menu function

Key Main menu Second level menu

3 i-mode i-mode

Settings

4 Phonebook Lists

Information #

Call options

5 Camera Camera

Video recorder

6 My data Videos

Sounds

Pictures

Music

Key Main menu Second level menu

1 Settings Phone

Phone modes

Main-LCD

2nd-LCD

Power saving

Calls

Security

Network

Reset settings

2 Message Inbox

Drafts

Outbox

Sent

Folder1

Folder2

Key Main menu Second level menu

7 Java Programs

Prog backlight

8 Accessory Music player

Calculator

Clock alarm

Scheduler

ToDo list

Notepad

Voice memo

Currency

Infrared

9 SIM toolkit

➡➡

➡

Standby screen Main menu screen

CLR

The Main menu has a set of icons for its top levels of options (examples of the top level are shown right)

which can be selected either using a combination of the 4-way navigation key (▲ ▼ ) and (menu

selection), or just the keypad (shortcuts selection).

2The title of the selected option will be displayed in the Help area.

2SIM toolkit icon is displayed only when your SIM card supports this function.

2With the Main menu screen displayed, press 0to display your own number.

▼

Getting Started 1

Basic Calls & Phone Use 5

Text Entry 14

IR Data Exchange 17

Desktop icons 19

Settings (M1) 21

Message (M2) 27

i-mode (M3) 33

Phonebook (M4) 47

Camera (M5) 56

My data (M6) 61

Java™ (M7) 66

Accessory (M8) 68

Index 77

Before You Start iii

User’s manual conventions............................................. iii

Display information ......................................................... iv

Parts and functions .......................................................... v

LCD and displayed icons ............................................... vii

Overview of menu function ............................................. ix

Getting Started 1

Preparing the phone ........................................................1

Standby and talk times.....................................................3

Checking the battery ........................................................3

Low battery alarm ............................................................3

Other battery alarms ........................................................3

Attaching and Removing the Emblem..............................4

Start-up ............................................................................4

Basic Calls & Phone Use 5

Making basic calls............................................................5

Ending a call ....................................................................5

Receiving an incoming call ..............................................5

Unsuccessful calls ...........................................................6

Emergency calls...............................................................6

Last number redial ...........................................................6

One-touch dial..................................................................7

Fast dialling......................................................................7

Displaying your own phone number (M0/M416) ..............7

Voice recall ......................................................................7

Options menu (during a call) ............................................7

Putting a call on hold........................................................8

Mute .................................................................................8

Transferring a call ............................................................8

Multi-party calls ................................................................ 8

Recording a call ...............................................................9

Call options (M43)............................................................ 9

Call settings (M16) ......................................................... 11

International dialling codes ............................................ 13

Roaming.........................................................................13

Text Entry 14

Mode change ................................................................. 14

T9®English text input ....................................................14

Normal text input............................................................ 15

Numeric input................................................................. 16

Key allocations............................................................... 16

IR Data Exchange 17

Positioning of the phones...............................................17

IR send...........................................................................17

IR receive (M891) .......................................................... 18

IR modem (M892) ..........................................................18

Desktop icons 19

Settings (M1) 21

Phone(M11) ...................................................................21

Phone modes (M12) ......................................................22

Main-LCD (M13) ............................................................ 23

2nd-LCD (M14) .............................................................. 23

Power saving (M15) ....................................................... 24

Calls (M16).....................................................................24

Security (M17)................................................................ 24

Network (M18) ...............................................................26

xii

Reset settings (M19)...................................................... 26

Message (M2) 27

Message overview ......................................................... 27

Reading a message (M21) ............................................ 28

Creating a message....................................................... 31

Cell broadcast (M27) ..................................................... 33

i-mode (M3) 33

i-mode operation guide .................................................. 33

i-mode screen ................................................................ 38

i-mode menu screen ...................................................... 38

iMenu screen ................................................................. 41

Mail screen .................................................................... 42

i-mode glossary ............................................................. 46

Phonebook (M4) 47

Phonebook types ........................................................... 47

Accessing your phonebook (M4) ................................... 48

Phonebook list Options menu........................................ 49

Personal data Options menu ......................................... 54

Scratchpad number ....................................................... 54

Voice mail (M417).......................................................... 55

Camera (M5) 56

Notes on using the camera............................................ 56

Taking a picture (M51)................................................... 57

Recording a video (M52) ............................................... 59

My data (M6) 61

Videos (M61) ................................................................. 61

Sounds (M62) ................................................................ 62

Pictures (M63) ............................................................... 62

Music (M64) ................................................................... 63

File selector Options menu ............................................ 64

Java™ (M7) 66

Programs (M71)............................................................. 66

Prog backlight (M72)...................................................... 67

Accessory (M8) 68

Music player (M81) ........................................................ 68

Calculator (M82) ............................................................ 69

Clock alarm (M83) ......................................................... 69

Scheduler (M84) ............................................................ 70

ToDo list (M85) .............................................................. 72

Notepad (M86)............................................................... 73

Voice memo (M87) ........................................................ 75

Currency (M88).............................................................. 75

Infrared (M89) ................................................................ 76

Index 77

Getting Started

Preparing the phone

Before trying to use your phone, make sure that a valid Subscriber Identity Module (SIM) card is inserted and the battery is charged.

SIM card

Before using your phone, you must sign-up with one of the digital network service providers. In addition to your subscription details you will receive a

personal SIM (Subscriber Identity Module) card which is inserted into your phone.

If the SIM card is removed, the phone becomes unusable until a valid SIM card is fitted. It is possible to transfer your SIM card to another compatible

phone and resume your network subscription. The screen on your phone will display appropriate messages if no SIM card is fitted.

,If the phone, or the SIM card, is lost or stolen then you should contact your service provider immediately in order to bar it from use.

2The phone supports a number of languages and the keyboard symbols have been chosen for world-wide operation.

2The digital technology of your phone helps to ensure that your conversations are kept secure.

2The SIM card contains personal data such as your electronic phonebook, messages (see “Message (M2)” on page 27) and also details of the network

services you have subscribed to. The phone will not work (except for emergency calls on some networks) unless a valid SIM card is fitted.

,Be sure to turn the phone off before inserting and removing a SIM card. Otherwise damage to the SIM card can occur.

Inserting a SIM card

,Be sure to turn the phone off before removing the battery pack.

☛While pressing down the areas marked with of the rear cover as indicated by arrows ➀, slide the rear cover about 3 mm in the direction of

arrows ➁with your finger tips. Then, lift the cover up in the direction of arrow ➂to remove it.

☛Lift the finger tab of the battery pack up in the direction of arrow ➃. Then lift the battery pack out in the direction of arrow ➄.

☛With the metal part facing down, insert the straight end of the SIM card under the holder in the direction of arrow ➅. Slide the SIM card all the way

until it reaches the end.

☛Align the marks on the battery pack with the marks on the phone. Insert it into the cavity in the phone body in the direction of arrow

➇, making sure that the tabs on the battery pack fit properly into the notches in the phone. Then, press the battery pack down in the direction of

arrow ➈to clip it into the phone.

☛Make sure that the battery pack is securely attached to the phone and align the rear cover with the grooves on the phone so that there is a gap

of about 3 mm at the end of the cover. After making sure that there is no gap between the rear cover and the phone body, slide the rear cover in

the direction of arrows ➉until you hear a click.

,If the SIM card is not fully inserted when the battery is replaced, damage to the SIM card can occur.

/If the SIM card is already fitted, see “Start-up” on page 4.

Removing a SIM card

☛With the battery removed, push the short and straight end of the SIM card with your thumb to

slide it gently in the direction of arrow ➆➔Lift the SIM card after it is completely removed from

the holder.

Charging the battery

Before trying to use your phone, insert the phone’s battery, connect the NEC battery charger (AC

adapter) supplied with your phone to a suitable mains power socket.

☛Pull open the charger connector cover gently.

,Be careful when handling the charger connector cover. Do not pull strongly.

☛Connect the charger plug (AC adapter) into the charger connector at the bottom of the phone. If

your phone is turned on and charging starts, the battery charging icon will be displayed. LED will

turn on in red while charging. When charging is complete, the LED will turn off.

2You are recommended to switch off the phone while charging. If you need to receive calls, your phone can be switched on and left in standby

while being charged, although the total time taken to charge is then increased.

The colour on the display shows the charging status of battery.

(red) Fast battery charging (green) Slow battery charging while the phone is in use (blue) Battery charging is stopped due to overheat

,Using any battery pack, AC adapter, vehicle power adapter (option) not specified by NEC for use with this phone can be dangerous and

may invalidate any warranty and approval given to the cellphone. Do not leave the charger connected to the mains supply when it is not

in use.

,Do not try to charge the battery if the ambient temperature is below 5°C (41°F) or above 35°C (95°F).

Rear cover

About 3 mm

Battery

Finger tab

Holder

SIM card

Notches

Tabs

About 3 mm

Check that there is no gap

between the rear cover

and the phone body.

Charger connector

Charger plug

Charger connector

cover

,DO NOT connect a charger or any other external DC source until the phone’s battery is inserted.

2If the phone does not respond, please wait for a few minutes. The charging will then start.

2If you use the phone while charging, handle the phone carefully since the cable or adapter is connected.

2If you make/receive a call while charging, the charging may temporarily be interrupted.

2Charging takes approximately 3 hours with your phone turned off.

2Even if the phone remains connected to the charger, battery residual capacity may decrease when the phone is used for video recording, playing or

other battery consuming operation.

,IMPORTANT BATTERY CHARGING INFORMATION

Charging a very low battery

The battery’s charge continues to drop after the low battery warning is displayed. In extreme cases where the battery is left uncharged for some

considerable time after this warning, a trickle charge is used to slowly top-up the battery to the safe level at which the fast charging can begin. The

phone can be in trickle charge for a few minutes before the fast charging starts.

Standby and talk times

Your phone works closely with the network you are using to provide the services you need, and the standby and talk times achieved will depend on how

you use the phone and choices made by the network operator.

In particular, factors such as your location within the network, the frequency at which this location is updated, the type of SIM card you have, your

reception of area messages or cell broadcast messages and the use of full rate or enhanced full rate speech, will affect both standby and talk times.

Checking the battery

☛Check icon at the top of the standby screen.

The block on the display shows the charge of your battery pack.

Full battery power Partial battery power Low battery power Battery empty

Low battery alarm

When the battery voltage falls below the working level, a low battery warning is displayed on the screen accompanied by LED illumination and a short

tone along with an empty battery icon. The phone will automatically power down shortly afterwards.

2Please charge the battery as much as possible when the battery is very low.

Other battery alarms

Your phone may display warnings when the battery temperature is too high, or the voltage of the battery or the charger is over the appropriate level.

Follow the instruction given by these warnings immediately.

Attaching and Removing the Emblem

Start-up

Switching the phone on

☛Hold down for about a second to switch on. The screen will display the selected greeting (see page 23) and the phone is then in standby.

2You may need to charge the battery before using your phone.

2When your phone is turned on, the specified ringer may sound.

2If your phone is accidentally turned off while downloading or deleting Java™ application, it will take longer than usual to start up the phone the next

time you turn on the power.

Switching the phone off

☛Hold down until the display shows the switch off message.

PIN code

The SIM card issued by your service provider has a security feature called PIN code protection. The Personal Identification Number (PIN) is a number

put on to the card by your service provider, and is 4 to 8 digits long. Some service providers supply SIM cards which will cause your phone to prompt for

Depressions

ttac

ng t

e em

em Removing the emblem

Remove the emblem by hooking your finger tips near the

square depressions and lifting in the direction of the

arrows. You can also remove the emblem from the other

side of the phone.

Attach the emblem, aligning the holes to

fit the 2nd-LCD, LED and camera.

Make sure the emblem is fitted over

the square depressions on each side

of the phone.

a PIN code when it is turned on. If this is the case, enter your code with the phone’s keypad. If you insert a SIM card other than your own, information

such as call logs may be lost. (See “Security (M17)” on page 24 for details.)

Basic Calls & Phone Use

Making basic calls

You make a simple call in the same way as you would with a normal phone, except that you need to press after entering the area Subscriber Trunk

Dialling (STD) code and the phone number. To make international calls, you must first enter the international dialling code (see page 13).

2Use the full STD area code even if you are calling to a person in the same town. If the numbers are too long to be displayed within one line, after

pressing , excess part is deleted and ‘...’ is added at its end.

2The main-LCD display shows the strength of the radio signal that links your phone to the network. The maximum signal strength is shown by 4 shaded

blocks and the minimum signal strength by 1 block.

Starting a call

☛Key in the phone number. Check the number on the display ➔ or SK1 to send the input number to start the call

☛Before the other party answers the call, you can end the call by pressing briefly, pressing SK2 or closing your phone. When you use the

headset, you can also end the call by pressing and holding the button on it.

When the call is sent, the screen displays the number called or the name stored in the phonebook and a connection graphic or a Calling Line Identification

(CLI) picture that has been allocated to the number called (see page 53).

Correcting mistakes

Use the and to move the cursor and then press CLR to clear individual digits, or hold down CLR to completely clear a phone number.

Ending a call

☛While talking, press briefly or close your phone. The phone returns to the standby screen.

2If is held down, your phone will turn off.

2When you use the headset, you can also end a call by pressing and holding the button on it.

2You cannot end a call by closing your phone when the headset is connected.

Receiving an incoming call

When someone calls your number, the ringer will play (if set - see page 22), the LED glows in the specified colour, and the phone number of the caller

may be displayed if the calling line identification facility is available and the caller has activated the feature. If the caller’s phone number has been related

▼

and stored in your phonebook with a name and a CLI picture (see page 53), that name and picture will be displayed. If the caller has withheld their identity,

the screen will give a message that the caller’s number is being withheld.

2You also have options for holding and forwarding calls. These options depend on your network and your subscription arrangements.

Accepting an incoming call

☛While receiving an incoming call, press or SK1.

2When you use the headset, you can also accept an incoming call by pressing the button on it.

Rejecting an incoming call

☛While receiving an incoming call, press or SK2 briefly or close your phone.

2When you use the headset, you can also reject an incoming call by pressing and holding the button on it.

2You cannot reject a call by closing your phone when the headset is connected.

If your phone receives a call and you do not answer it, the screen will display the phone number (or the name if stored) of the caller (if available). This

information is stored in the missed calls list. Up to 20 missed calls are stored in this list.

2You can set your phone to answer a call when any key is pressed (see “Any key answer” on page 21).

2If you are making a call, the phone gives priority to receiving a call unless you have already pressed .

/See also: “Call diversion (M161)” on page 11 and “Call waiting and holding (M162)” on page 12.

/See also: “Call options (M43)” on page 9.

Unsuccessful calls

If dialled call is not successfully connected, the display will give an appropriate message.

If your phone has the auto redial function activated, the number will be automatically called again after a short delay (see page 12).

Emergency calls

The standard emergency number of 112 can be used.

☛Key in 1 1 2 ➔ or SK1 to connect the call to the local emergency services.

2On some networks, emergency calls can be made using the 112 number without a SIM card inserted.

Last number redial

You can redial the last number you called.

☛Ensure that the standby screen is displayed and no phone number is shown ➔twice to dial the last number you called.

/See also: “Call options (M43)” on page 9.

One-touch dial

One-touch dial for the phonebook (SIM) is available by pressing and holding the number keys between 2 and 9.

2A number for the One-touch dial corresponds to the location number in the phonebook (SIM).

2One-touch dial is available only for the phone numbers with the location number 2 to 9 stored in the phonebook (SIM).

Fast dialling

Fast dialling is activated in Abbreviated Dialling Numbers (ADN) by entering a number 1 to 255 (depending on the SIM card), and .

Fast dialling is also activated by entering the location number 1 to 500 of your phonebook (Phone) and then and .

Displaying your own phone number (M0/M416)

☛0or 416

Voice recall

You can store up to 10 voice recall recordings which can be allocated to a personal data stored in the phonebook (Phone). To store the voice recall

sound, see page 53. To use the voice recall function, use the following procedure:

☛Press and hold

2When you use the headset, you can also activate the voice recall function by pressing and holding the button on it from the standby screen.

☛Within 4 seconds, say the word or words you have recorded to identify the record you wish to recall. If the word or words were recognized, the

first phone number of the personal data stored in the phonebook (Phone) will be called automatically.

Options menu (during a call)

☛During a call, to display the options menu

No. Options menu (during a call)

1 Main menu Displays the Main menu screen. See “Overview of menu function” on page ix for details.

2Hold/Retrieve Puts the call(s) on hold or retrieves the call(s).

3Mute/Unmute Mutes or unmutes all active calls.

▼

2Depending on the conditions, some options may be displayed in gray and not be available.

Putting a call on hold

☛To put the received or dialled call on hold, SK1 or 2. To retrieve the call, SK1 or 2again.

Mute

You can mute the sound from the mouthpiece during a call. When your call is muted, the other party cannot hear any sound from your phone, but you

can still hear the sound from the other party.

☛To mute the sound during a call, press 3.To retrieve the sound, press 3 again.

2The mute function is automatically released after the call ends.

Transferring a call

When you have an active call and a held call, you can transfer the call and connect the two parties, then you can drop from the line while leaving those

two calls active.

☛To transfer the call, press 4.
