DT310/DT710
6‐ButtonwithLCD
QuickReferenceCard

forDT310/DT710phonescontrolledbythe

SV8300
CommunicationServer



Someofthefeaturesdescribedinthis
QuickReferenceGuidemightrequire
additionalprogramminginthe
CommunicationServer.Fordetailed
informationpleaseconsultthe
comprehensiveUserGuideavailableat:
www.nec‐unified.com.



©NECUnifiedSolutions2010
Allrightsarereserved.Reproductioninwholeorinpartisprohibited
withoutthewrittenconsentofthecopyrightowner.
Allbrandnamesandproductnamesinthisdocumentaretrademarks
orregisteredtrademarksoftheirrespectivecompanies.

1. CallIndicatorLamp‐ Thislampflasheswhena
callterminatestotheterminalandlightssteadily
whenamessageisavailable.
2. LCD‐Displayscallinformationandoptions,
Menuinformationandsoftkeys.
3. Exit‐ThiskeyallowsyoutoexitfromtheMenu
orHelpmodeandgobacktothemainscreen.
4. SoftKeysTheSoftKeysshowtheavailable
featuresforyourcurrentactivity.Anyfeature
shownatthebottomoftheLCDisavailable.
5. Help‐Pressthiskeytodisplayinformationabout
theSoftKeysthatareinthecurrentLCDdisplay.
6. ProgrammableKeys‐Thesecanbeadditional
LineKeysorFeatureKeys.Pressakeytogetdial
toneforthatline,ortoexecutetheprogrammed
featurecode.
7. Recall‐Presskeytofinishthecallandhearthe
dialtone.
8. Feature‐Usedtoactivateanyfeaturesandto
programOne‐TouchSpeedDialKeys.
9. Answer‐WhentheLEDisON,pressthekeyto
answerawaitingcall.
10. Mic‐Pressthiskeytomutethemicrophone:the
LEDisOFF.Pressthekeyagaintoun‐mutethe
microphone.Beawarethatthiskeyisonlyfor
thehands‐freemicrophoneanddoesnothave
anyeffectontheheadset.
11. Menu‐Pressthiskeytoaccessthefunctions
whichareusednowandthen(suchasterminal
settings).
12. CursorKey‐Usethiskeytoaccessvarious
featureswithsimpleoperation.

‐ScrollUPkey‐Enterkey
‐Volume(UP)key‐Shortcutkey

‐LEFTkey‐RIGHTkey
‐RedialKey‐Directorykey


‐ScrollDOWNkey
‐Volume(DOWN)key

13. EnterKey‐ShortcutMenuforfrequently‐used
featuresorconfirmationofaselectedmenu
item.
14. RedialKey‐Presskeytoactivateredialfeature.
15. Speaker‐Controlsthebuilt‐inspeakerwhichcan
beusedforHandsFreedialing/monitoring.
16. Transfer‐Allowsthestationusertotransfer
establishedcallstoanotherstation.
17. Hold‐Placescurrentcallonhold.Toresumethe
heldcall,presstheLineKey.Duringaheldcall,
youcandialanotherpartybyselectingaNew
FlexibleLineKeywhichprovidesdialtone.


Issue:1.0‐May2010DT310/DT7106‐ButtonwithLCDQuickReferenceCardforSV83001


Issue:1.0‐May2010DT310/DT7106‐ButtonwithLCDQuickReferenceCardforSV83002
BASICSETTINGS
Toadjusthandsetvolume
PresstheScrollUP/DOWNkeyintheoff‐hookstatus
orduringacall.

Toadjustspeakervolume
PresstheScrollUP/DOWNkeyduringspeakerphone
operation,orduringacallthatisbeingplayedonthe
speaker.

Toadjustringtonevolume
PresstheScrollUP/DOWNkeyduringringing.

ToadjustLCDcontrast
PresstheScrollUP/DOWNkeywheninidlemodeto
adjusttheLCDcontrast.



MAKINGCALLS
1. LiftthehandsetorpresstheSpeakerkeyto
receivedialtone.
2. Enterthetelephonenumberoftherequired
party.


CONFERENCECALLS
1. Whileonacall,selecttheTransferkey.
2. Dialdesirednumber.
3. Aftercallisanswered,prestheConfSoftkey
4. Three‐wayconferenceisestablished.





TRANSFERRINGCALLS
1. WhileonacallpresstheTransferkey.
2. Dialdestinationtelephone,hanguporwaitfor
answer.

CALLHISTORY
ToviewinformationaboutOutgoingCalls(OG)and
IncomingCalls(IC)onyourtelephone

1. PresstheHIST(History)softkey.
2. PresstheOGSoftKeytoviewOutgoingCallsor
theICSoftKeytoviewIncomingCalls
3. PresstheUP/DOWNkeystogothroughthelist.

SPEEDDIALKEYS
Askyoursystemadministratorformoredetailsifyou
cannotconfigureprogrammablekeys.

ToconfigureaProgrammableKeyasaSpeedDial
key
1. Whenthephoneisinidlestate,pressthe
FeatureKey.TheLEDisswitchedON.
2. PressthedesiredProgrammableKeywhichmust
actasaSpeedDialKey.
3. Usethekeypadtoenterthenumberinformation
fortheSpeedDial.Onlydigits,*and#are
acceptedasnumericalinputinaSpeedDialKey.
4. PresstheFeatureKey.TheLEDisswitchedOFF.

TooriginateacallfromaSpeedDialKey
1. PressthedesiredSpeedDialKey,or
2. LiftthehandsetandpressthedesiredSpeedDial
Key,or
3. PresstheSpeakerKeyandpressthedesired
SpeedDialKey.

FUNCTIONKEYS
OneormoreProgrammableKeyscanbepre‐
programmedwithadedicatedfunctionora
telephonenumber.
Askyoursystemadministratorformoredetails.

Function
Pressingthiskeyactivatesthefunction.Youhaveto
doitwhileoff‐hook.ThecorrespondingLEDis
switchedON.
Pressingthekeyoncemorede‐activatesthefunction.
Youhavetodoitwhileoff‐hook.Thecorresponding
LEDisswitchedOFF.


STANDARDFEATURECODES
Thefollowinglistoffeaturecodesmightrequire
additionalprogrammingintheCommunicationServer.
Pleasecontactyoursystemadministratorformoredetails.

0OutsideNumber
1BreakIn/Executiveoverride
5CallBackset
8StartCallWaiting
*21CallForwarding‐AllCallsset
#21CallForwarding‐AllCallscancel
*23CallForwardingLogoutset
#23CallForwardingLogoutcancel
*25CallForwarding‐Busyset
#25CallForwarding‐Busycancel
*26CallForwarding‐Don'tAnswerset
#26CallForwarding‐Don'tAnswercancel
*27CallForwarding(Noanswer&Busy)set
#27CallForwarding(Noanswer&Busy)cancel
#37CallBackcancel
*53DoNotDisturbset
#53DoNotDisturbcancel
*61MessageWaitingLampControlset
#61MessageWaitingLampControlcancel
