Neousys Technology Nuvo-9160GC Series User manual

Neousys Technology Inc.
Nuvo-9160GC Series
User Manual
Revision 1.2
coastipc.com | 866-412-6278 | [email protected]
Rev101823

Table of Contents
Table of Contents
Table of Contents...................................................................................................................2
Legal Information...................................................................................................................5
Contact Information...............................................................................................................6
Declaration of Conformity.....................................................................................................6
Copyright Notice....................................................................................................................7
Safety Precautions.................................................................................................................8
Service and Maintenance ....................................................................................................10
Avertissement concernant les piles...................................................................................10
Hot Surface Warning............................................................................................................11
Surface chaude ....................................................................................................................11
Battery Warning....................................................................................................................12
Entretien et ecessarie..........................................................................................................12
ESD Precautions..................................................................................................................13
Précautions ecessaries de décharge électrostatique (ESD)............................................13
Restricted Access Location ................................................................................................14
Lieu d’accès restreint ..........................................................................................................14
About This Manual...............................................................................................................15
1Introduction
1.1 Product Specifications.............................................................................................17
1.1.1 Nuvo-9160GC Specifications............................................................................17
1.1.2 Nuvo-9166GC Specification..............................................................................20
1.2 Nuvo-9160GC Dimension.........................................................................................22
1.2.1 Nuvo-9160GC Front Panel View.......................................................................22
1.2.2 Nuvo-9160GC Rear Panel View .......................................................................22
1.2.3 Nuvo-9160GC Side View..................................................................................23
1.2.4 Nuvo-9160GC Top View....................................................................................23
1.2.5 Nuvo-9160GC Bottom View..............................................................................24
1.3 Nuvo-9166GC Dimension.........................................................................................25
1.3.1 Nuvo-9166GC Front Panel View.......................................................................25
1.3.2 Nuvo-9166GC Rear Panel View .......................................................................25
1.3.3 Nuvo-9166GC Side View..................................................................................26
1.3.4 Nuvo-9166GC Top View....................................................................................26
1.3.5 Nuvo-9166GC Bottom View..............................................................................27
2System Overview
2.1 Packing List ..............................................................................................................28
2.1.1 Nuvo-9160GC Series Packing List....................................................................28
2.1.2 Nuvo-9166GC Series Packing List....................................................................29
2.2 Front Panel I/O..........................................................................................................30
2.2.1 USB3.2 Gen2x1 Port ........................................................................................32
2.2.2 USB2.0 Port......................................................................................................32
2.2.3 CMOS Reset Button .........................................................................................33
2.2.4 DVI Port............................................................................................................34
2.2.5 VGA Port...........................................................................................................35
2.2.6 USB3.2 Gen 1x1 Port .......................................................................................36
2.2.7 DisplayPort .......................................................................................................37
2.2.8 USB3.2 Gen2x2 Type-C Port............................................................................38
2.2.9 2.5 Ethernet Port/ Optional PoE+......................................................................39
2.2.10 Reset Button.....................................................................................................40
2.2.11 LED Indicators ..................................................................................................40
2.2.12 Power Button ....................................................................................................41
2.2.13 Cassette Module...............................................................................................42
2.3 Rear Panel I/O...........................................................................................................43
2.3.1 4-Pole 3.5mm Headphone/ Microphone Jack...................................................45
2.3.2 COM Ports........................................................................................................46
2.3.3 3-Pin Terminal Block for DC and Ignition Input..................................................47

Table of Contents
3
2.3.4 3-Pin Remote On/ Off .......................................................................................48
2.4 Internal I/O Functions...............................................................................................49
2.4.1 Dual SODIMM DRAM Slot................................................................................49
2.4.2 mini-PCIe Socket & Pin Definition.....................................................................50
2.4.3 M.2 2242/ 3042/ 3052 (B Key), Mini-SIM Card Slot & Pin Definition.................52
2.4.4 SATA Ports........................................................................................................54
2.4.5 DIP Switch ........................................................................................................55
2.4.6 On/ Off Ctrl & Status Output..............................................................................56
2.4.7 Internal USB 2.0 Port........................................................................................57
2.4.8 M.2 2280 (M Key) Slot for NVMe SSD..............................................................58
2.4.9 MezIOTM Interface & Pin Definition ...................................................................60
3System Installation
3.1 Disassembling the System......................................................................................63
3.2 Installing Internal Components...............................................................................67
3.2.1 CPU Installation for Barebone System..............................................................67
3.2.2 Remove and Replace the Existing CPU ...........................................................73
3.2.3 DDR5 SO-DIMM Installation.............................................................................80
3.2.4 mPCIe Module, Mini-SIM (2FF) Card and Antenna Installation ........................82
3.2.5 M.2 2242/ 3042/ 3052 (B Key) Module and Micro-SIM (3FF) Card Installation.84
3.2.6 M.2 2280 NVMe SSD Installation......................................................................86
3.2.7 MezIOTM Module Installation.............................................................................88
3.2.8 HDD/ SSD Installation.......................................................................................90
3.2.9 Ethernet/ PoE+ Port Panel Screw Fix...............................................................94
3.3 Nuvo-9160GC Graphics Card Replacement/ Installation......................................95
3.4 Nuvo-9166GC Series Graphics Card Replacement/ Installation ........................103
3.5 Installing the System Enclosure ...........................................................................109
3.6 Wall Mount Bracket Installation ............................................................................ 112
3.6.1 Wall Mount Bracket Installation.......................................................................112
3.6.2 Damping Bracket Installation (Optional)..........................................................114
3.7 Powering On the System.......................................................................................115
3.7.1 Powering On Using the Power Button............................................................. 115
3.7.2 Powering On Using External Non-latched Switch...........................................116
3.7.3 Powering On Using Wake-on-LAN.................................................................. 117
4System Configuration
4.1 BIOS Settings .........................................................................................................119
4.1.1 COM Port Configuration..................................................................................120
4.1.2 COM Port High Speed Mode ..........................................................................121
4.1.3 Delay for PEG Initialization .............................................................................122
4.1.4 Volume Management Device (VMD)...............................................................123
4.1.5 TPM Availability...............................................................................................126
4.1.6 Power over Ethernet (PoE) Power Enable......................................................127
4.1.7 Auto Wake on S5............................................................................................129
4.1.8 Power On After Power Failure Option.............................................................130
4.1.9 Power & Performance (CPU SKU Power Configuration)................................131
4.1.10 Wake on LAN Option ......................................................................................132
4.1.11 Boot Menu ......................................................................................................133
4.1.12 Add Boot Options (Position New Boot Device) ...............................................135
4.1.13 Watchdog Timer for Booting............................................................................136
4.2 AMT Configuration.................................................................................................137
4.3 RAID Configuration................................................................................................139
4.3.1 Enabling Volume Management Device (VMD) for RAID Volume Setup..........139
4.3.2 RAID Volume Setup........................................................................................141
4.3.3 Loading RAID Driver for Windows Installation ................................................148
5OS Support and Driver Installation
5.1 Operating System Compatibility...........................................................................151
5.2 System Driver Installation .....................................................................................152
5.3 Driver Installation for Watchdog Timer Control...................................................152

Safety Precautions
4
Appendix A Using WDT & DIO
WDT and DIO Library Installation .....................................................................................154
WDT Functions...................................................................................................................156
InitWDT................................................................................................................................156
SetWDT ...............................................................................................................................156
StartWDT .............................................................................................................................157
ResetWDT............................................................................................................................157
StopWDT .............................................................................................................................157
Appendix B PoE On/ Off Control
GetStatusPoEPort..............................................................................................................158
EnablePoEPort...................................................................................................................159
DisablePoEPort..................................................................................................................160

Legal Information
Legal Information
All Neousys Technology Inc. products shall be subject to the latest Standard
Warranty Policy
Neousys Technology Inc. may modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Neousys
Technology Inc. will provide access to these new software, firmware or
documentation releases from download sections of our website or through our
service partners.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Neousys
Technology Inc. product by checking in advance with Neousys Technology Inc..
Customer is solely responsible for ensuring the compatibility and interoperability of
the third party’s products. Customer is further solely responsible for ensuring its
systems, software, and data are adequately backed up as a precaution against
possible failures, alternation, or loss.
For questions in regards to hardware/ software compatibility, customers should
contact Neousys Technology Inc. sales representative or technical support.
To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be
responsible for any interoperability or compatibility issues that may arise when (1)
products, software, or options not certified and supported; (2) configurations not
certified and supported are used; (3) parts intended for one system is installed in
another system of different make or model.

Contact Information/ Declaration of Conformity
Contact Information
Headquarters
(Taipei, Taiwan)
Neousys Technology Inc.
15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan
Tel: [phone] Fax: [phone] Email, Website
Americas
(Illinois, USA)
Neousys Technology America Inc.
3384 Commercial Avenue, Northbrook, IL 60062, USA
Tel: [phone]Email, Website
China
Neousys Technology (China) Ltd.
Room 612, Building 32, Guiping Road 680, Shanghai
Tel: [phone]Email, Website
Declaration of Conformity
FCC
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at own expense.
CE
The product(s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to remain
CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.

Copyright Notice
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Neousys Technology, Inc.
Disclaimer
This manual is intended to be used as an informative guide only and is subject
to change without prior notice. It does not represent commitment from Neousys
Technology Inc. Neousys Technology Inc. shall not be liable for any direct,
indirect, special, incidental, or consequential damages arising from the use of
the product or documentation, nor for any infringement on third party rights.
Patents and
Trademarks
Neousys, the Neousys logo, Expansion Cassette, MezIOTM are registered
patents and trademarks of Neousys Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Intel®, Core™are registered trademarks of Intel Corporation
NVIDIA®is a registered trademark of NVIDIA Corporation
All other names, brands, products or services are trademarks or registered
trademarks of their respective owners.

Safety Precautions
Safety Precautions
⚫Read these instructions carefully before you install, operate, or transport the
system.
⚫Install the system or DIN rail associated with, at a sturdy location
⚫Install the power socket outlet near the system where it is easily accessible
⚫Secure each system module(s) using its retaining screws
⚫Place power cords and other connection cables away from foot traffic. Do not
place items over power cords and make sure they do not rest against data
cables
⚫Shutdown, disconnect all cables from the system and ground yourself before
touching internal modules
⚫Ensure that the correct power range is being used before powering the device
⚫Should a module fail, arrange for a replacement as soon as possible to
minimize down-time
⚫By means of a power cord connected to a socket-outlet with earthing
connection
⚫This product is intended to be supplied by a Listed Power Adapter or DC
power source, rated 12-35Vdc, 16A, Tma 60 degree C and 5000m altitude
during operation. If further assistance is required, please contact Neousys
Technology
⚫If the system is not going to be used for a long time, disconnect it from mains
(power socket) to avoid transient over-voltage

Mesures de sécurité
Mesures de sécurité
Lire attentivement ces directives avant d’installer, d’utiliser ou de transporter le système.
Installer le système ou la barrette DIN qui lui est associée, à un endroit solide
Installer la prise de courant près du système et pour qu’elle soit facilement accessible
Fixer chaque module du système à l’aide de ses vis de fixation
Éloigner de la circulation piétonne les cordons d’alimentation et autres câbles de
connexion. Ne jamais placer d’objets sur les cordons d’alimentation et s’assurer qu’ils ne
reposent pas contre les câbles de données
Avant de toucher les modules internes, arrêter, débrancher tous les câbles du système et
raccordez-vous à la terre
S’assurer que la bonne plage de puissance est utilisée avant d’alimenter l’appareil
Prévoir un remplacement dès que possible en cas de défaillance d’un module, afin de
minimiser les temps d’arrêt
Au moyen d’un cordon d’alimentation branché à une prise de courant avec mise à la
terre (MALT)
Ce produit doit être alimenté par un adaptateur de courant homologué ou une source
d’alimentation CC, de 12-35 Vcc et 16 A, conçue pour fonctionner à 60 ºC Tma et à
5 000 m d’altitude. Communiquer avec Neousys Technology si de l’assistance
supplémentaire est requise
Si le système ne sera pas être utilisé pendant une période prolongée, le débrancher du
réseau (prise de courant) pour éviter une surtension transitoire

Service and Maintenance/ Avertissement concernant les piles
Service and Maintenance
⚫ONLY qualified personnel should service the system
⚫Shutdown the system, disconnect the power cord and all other connections
before servicing the system
⚫When replacing/ installing additional components (expansion card, memory
module, etc.), insert them as gently as possible while assuring proper
connector engagement
Avertissement concernant les
piles
⚫Les piles risquent d’exploser si
10
ece sont mal installées.
⚫Ne jamais essayer de recharger, d’ouvrir de force ou de chauffer les piles.
⚫Remplacer les piles uniquement avec le
10
ece type ou l’équivalent
recommandé par le fabricant.

Hot Surface Warning/ Surface chaude
11
Hot Surface Warning
HOT SURFACE. DO NOT
TOUCH. “ATTENTION: Surface chaude. Ne
pas toucher.”
WARNING!
Components/ parts inside the
equipment may be hot to touch!
Please wait one-half hour after
switching off before handling parts.
Surface chaude
AVERTISSEMENT : SURFACE CHAUDE. NE PAS TOUCHER.
Les composants et
11
ecess à l’intérieur de l’équipement peuvent être chauds au
toucher. Après l’arrêt, attendre au moins 30 minutes pour que le système refroidisse
avant d’effectuer l’entretien.
⚫Respecter les règles de sécurité et d’entretien mentionnées au début du guide
d’utilisation!

Battery Warning/ Entretien et réparation
Battery Warning
⚫Batteries are at risk of exploding if incorrectly
installed
⚫Do not attempt to recharge, force open, or heat the
battery
⚫Replace the battery only with the same or equivalent
type recommended by the manufacturer
Entretien et
12
ecessarie
⚫La réparation du système ne peut être effectuée que par du personnel qualifié
⚫Avant de réparer le système, arrêter le système, débrancher le cordon
d’alimentation et toutes les autres connexions
⚫Lors du remplacement ou de l’installation de composants supplémentaires
(carte d’extension, module de mémoire, etc.), les insérer le plus doucement
possible tout en s’assurant que les connecteurs sont bien engagés jusqu’au
bout

ESD Precautions/ Entretien et réparation
ESD Precautions
⚫Handle add-on module, motherboard by their retention screws or the module’s
frame/ heat sink. Avoid touching the PCB circuit board or add-on module
connector pins
⚫Use a grounded wrist strap and an anti-static work pad to discharge static
electricity when installing or maintaining the system
⚫Avoid dust, debris, carpets, plastic, vinyl and
13
ecessari in your work area.
⚫Do not remove any module or component from its anti-static bag before
installation
Précautions
13
ecessaries de
décharge électrostatique
(ESD)
Tenir le module complémentaire et la carte mère par leurs vis de rétention ou le
châssis/dissipateur de chaleur du module. Éviter de toucher la carte de circuit
imprimé ou les broches du connecteur du module complémentaire
Afin de décharger l’électricité statique, utiliser une dragonne mise à la terre et
un tapis de travail antistatique lors de l’installation ou de l’entretien du système
Éviter la poussière, les débris, les tapis, le plastique, le vinyle et la mousse de
polystyrène dans votre zone de travail.
Ne retirer aucun module ou composant de son sac antistatique avant
l’installation

Restricted Access Location/ Lieu d’accès restreint
Restricted Access Location
The controller is intended for installation only in certain environments where both of
the following conditions apply:
⚫Access can only be gained by QUALIFIED SERVICE PERSONNEL who have
been instructed on the reasons for restrictions applied to the location and any
precautions that shall be taken
⚫Access is through the use of a TOOL, lock and key, or other means of security,
and is controlled by the authority responsible for the location
Lieu d’accès restreint
Le contrôleur doit être installé uniquement dans les environnements où les deux
conditions suivantes sont présentes :
⚫Le lieu ne peut être accédé que par du PERSONNELTECHNIQUE QUALIFIÉ
informé des raisons des restrictions appliquées à l’emplacement et des
précautions à prendre
⚫L’accès est contrôlé par l’autorité responsable de l’emplacement et se fait au
moyen d’un OUTIL, d’une serrure et d’une clé ou d’autres moyens de sécurité

About This Manual
About This Manual
This manual introduces Neousys Nuvo-9160GC edgeAI computer series featuring
Intel®13th/ 12th Gen Alder Lake Core™hybrid performance/ efficient core processors,
and support for an NVIDIAGPU card.
Nuvo-9160GC supports an NVIDIAgraphics card up to 130W.
Nuvo-9166GC supports an NVIDIAL4 inference accelerator.
The guide also demonstrates the system’s installation procedures.
Revision History
Version
Date
Description
1.0
Mar. 2023
Initial release
1.1
May. 2023
Nuvo-9160GC specification update
Added support for Intel®13th Gen. CPU for Nuvo-9160GC series
Added Nuvo-9166GC
1.2
Sep. 2023
Remove support for Sparkle GeForce RTX 3050 8GB Graphics
Card

Nuvo-9160GC Series
16
1 Introduction
Nuvo-9160GC series is a rugged edge AI computer that delivers superior CPU and GPU
performance by leveraging Intel’s 13th/ 12th Gen platform and NVIDIA’s graphics card to fuel
real-time AI inference applications involving multiple cameras such as production line vision
inspection, intelligent video analytics for surveillance or ITS, or autonomous mobile robot
(AMR).
The Nuvo-9160GC supports an NVIDIA
RTX graphics card up to 130W to offer
approximately 9 TFLOPS of FP32
performance
Nuvo-9160GC
Nuvo-9166GC supports the data center
grade NVIDIA®L4. Based on the NVIDIA®
Ada Lovelace architecture for
energy-efficient AI acceleration to offer
30.3 TFLOPS in FP32.
Nuvo-9166GC
Benefiting from the cutting-edge Intel®7 photolithography, Intel’s 13th/ 12th Gen processors can
offer up to 24 cores/ 32 threads with 1.8x the performance improvement compared to previous
Intel 11th/ 10th Gen platforms. The platform is designed to accommodate the latest NVIDIA
130W RTX GPU or an NVIDIA L4 inference accelerator.
Nuvo-9160GC has a proven thermal design to guarantee reliable system operation from -25°C
to 60°C. It features a passive-cooling design for the motherboard and segregated patented
ventilation design* for the GPU accelerator card within Neousys' patented expansion Cassette*.
The support of six GigE cameras (or IP cameras) and six USB3 cameras makes Nvuo-9160GC
ideal for various vision-basedAI application deployments. It also provides flexible data storage
options, including one M.2 2280 Gen4x4 NVMe providing up to 7000 MB/s extreme read/write
speeds and two 2.5" SATAHDD/SSD to expand storage capacity.
With performance enhancements and comprehensive I/Os, Nuvo-9160GC series is the perfect
edge AI inference platform for industrial environments from factory automation, smart
agriculture, and autonomous machines.

Nuvo-9160GC Series
17
1.1 Product Specifications
1.1.1 Nuvo-9160GC Specifications
System Core
Processor
Supports Intel® 13th-Gen Core™CPU (LGA1700 socket, 65W/ 35W TDP)
- Intel® Core™i9-13900E/ i9-13900TE
- Intel® Core™i7-13700E/ i7-13700TE
- Intel® Core™i5-13500E/ i5-13400E/ i5-13500TE
- Intel® Core™i3-13100E/ i3-13100TE
Supports Intel® 12th-Gen Core™CPU (LGA1700 socket, 35W/ 65W TDP)
- Intel® Core™i9-12900E/ i9-12900TE
- Intel® Core™i7-12700E/ i7-12700TE
- Intel® Core™i5-12500E/ i5-12500TE
- Intel® Core™i3-12100E/ i3-12100TE
- Intel® Pentium® G7400E/ G7400TE
- Intel® Celeron® G6900E/ G6900TE
Chipset
Intel® Q670E Platform Controller Hub
Graphics
Integrated Intel® UHD Graphics 770 (32EU)
Memory
Up to 64GB DDR5 4800 (two SODIMM slots)
AMT
Supports Intel vPro/ AMT 16.0
TPM
Supports dTPM 2.0
I/O Interface
Ethernet port*
5x 2.5GbE by I225 and 1x GbE by I219 with screw-lock
PoE+
Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6 (100 W total power
budget)
USB
1x USB 3.2 Gen2x2 (20 Gbps) port in type-C connector with screw-lock
4x USB 3.2 Gen2x1 (10 Gbps) ports in type-A connectors
2x USB 3.2 Gen 1x1 (5 Gbps) ports in type-A connectors
2x USB 2.0 ports
Video Port
1x VGA connector, supporting 1920 x 1200 resolution
1x DVI-D connector, supporting 1920 x 1200 resolution
1x DisplayPort connector, supporting 4096 x 2304 resolution
Serial Port
2x software-programmable RS-232/ 422/ 485 ports (COM1/ COM2)
2x RS-232 ports (COM3/ COM4)
Audio
1x 3.5 mm jack for mic-in and speaker-out

Nuvo-9160GC Series
18
Storage Interface
SATA HDD
2x internal SATA ports for 2.5” HDD/ SSD (up to 15mm thickness),
supporting RAID 0/1
M.2 NVMe
1x M.2 2280 M key NVMe socket (PCIe Gen4 x4) for NVMe SSD
Internal Expansion Bus
PCI Express
Slot
1x PCIe x16 slot@Gen3, 16-lanes PCIe signals in Cassette for installing an
NVIDIA® graphics card up to 130W TDP (Max. graphics card dimension is
188 mm(L) x 131 mm(W), dual slot allocation)
Mini PCI-E
1x full-size mini PCI Express socket
M.2
1x M.2 2242/ 3052 B key socket with SIM slot for M.2 5G/ 4G module
Power Supply
DC Input
1x 3-pin pluggable terminal block for 8~48VDC DC input
Remote Ctrl.
&LED Output
1x 3-pin pluggable terminal block for remote control and PWR LED output
Maximum
Power
Consumption**
CPU+GPU (RTX3050) full load without PoE
oWith i9-12900E (35W mode / PL2) + 130W GPU: 243.8W @ 48V
With i9-12900E (35W mode / PL1) + 130W GPU: 196.3W @ 48V
With i9-12900E (35W mode / PL2) + 130W GPU: 241.2W @ 24V
With i9-12900E (35W mode / PL1) + 130W GPU: 191.0W @ 24V
oWith i9-12900E (65W mode / PL2) + 130W GPU: 291.8W @ 48V
With i9-12900E (65W mode / PL1) + 130W GPU: 230.4W @ 48V
With i9-12900E (65W mode / PL2) + 130W GPU: 280.8W @ 24V
With i9-12900E (65W mode / PL1) + 130W GPU: 225.1W @ 24V
oWith i9-12900E (MAX mode / PL2) + 130W GPU: 326.4W @ 48V
With i9-12900E (MAX mode / PL1) + 130W GPU: 228.9W @ 48V
With i9-12900E (MAX mode / PL2) + 130W GPU: 324.0W @ 24V
With i9-12900E (MAX mode / PL1) + 130W GPU: 224.8W @ 24V
Mechanical
Dimension
240 mm (W) x 225 mm (D) x 110.5 mm (H)
Weight
4.4Kg (approx. without graphics card)
Mounting
Wall mount kit (standard) or damping bracket (optional)
Environmental

Nuvo-9160GC Series
19
* Due to I225-IT specification limitation, for systems running 2.5G Ethernet link speeds, please
limit the operating temperature to 60°C.
** System load (PL1) under 100W, the required DC input range is 8V to 48V
System load (PL1) between 100W to 180W, the required DC input range is 12V to 48V
System load (PL1) between 180W to 360W (single GPU), the required DC input range is 24V to
48V
***For sub-zero operating temperature, a wide temperature HDD or Solid State Disk (SSD) is
required.
*** For CPU operating at 65W mode, the highest operating temperature shall be limited to 50°C
and thermal throttling may occur when sustained full-loading applied. Users can configure CPU
power in BIOS to allow higher operating temperature.
Operating
Temperature
With 35W CPU and 130W GPU
-25°C ~ 60°C ***
With 65W CPU
-25°C ~ 60°C ***/ **** (configured as 35W TDP)
-25°C ~ 50°C ***/ **** (configured as 65W TDP)
Storage
Temperature
-40°C to 85°C
Humidity
10%~90% , non-condensing
Vibration
MIL-STD-810G, Method 514.6, Category 4
Shock
MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II
EMC
CE/ FCC Class A, according to EN 55032 & EN 55035

Nuvo-9160GC Series
20
1.1.2 Nuvo-9166GC Specification
System Core
Processor
Supporting Intel® 13th-Gen Core™CPU (LGA1700 socket, 65W/ 35W
TDP)
- Intel® Core™i9-13900E/ i9-13900TE
- Intel® Core™i7-13700E/ i7-13700TE
- Intel® Core™i5-13500E/ i5-13400E/ i5-13500TE
- Intel® Core™i3-13100E/ i3-13100TE
Supporting Intel® 12th-Gen Alder Lake Core™CPU
(LGA1700 socket, 35W/ 65W TDP)
- Intel® Core™i9-12900E/ i9-12900TE
- Intel® Core™i7-12700E/ i7-12700TE
- Intel® Core™i5-12500E/ i5-12500TE
- Intel® Core™i3-12100E/ i3-12100TE
- Intel® Pentium® G7400E/ G7400TE
- Intel® Celeron® G6900E/ G6900TE
Chipset
Intel® Q670E Platform Controller Hub
Graphics
Integrated Intel® UHD Graphics 770 (32EU)
Memory
Up to 64 GB DDR5 4800 SDRAM (two SODIMM slots)
AMT
Supports Intel vPro/ AMT 16.0
TPM
Supports dTPM 2.0
I/O Interface
Ethernet*
5x 2.5G Ethernet by I225-IT and 1x Gigabit Ethernet by I219-LM with
screw-lock
PoE+
Optional IEEE 802.3at PoE+ PSE for Port 3 ~ Port 6. 100W total power
budget
USB 3.2
1x USB 3.2 Gen2x2 (20 Gbps) port in type-C connector with screw-lock
4x USB 3.2 Gen2x1 (10 Gbps) ports in type-Aconnectors
2x USB 3.2 Gen1x1 (5 Gbps) ports in type-A connectors
USB 2.0
2x USB 2.0 ports
Video Port
(Integrated
Graphics)
1x VGA connector, supporting 1920 x 1200 resolution
1x DVI-D connector, supporting 1920 x 1200 resolution
1x DisplayPort connector, supporting 4096 x 2304 resolution
Serial Port
2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2)
2x RS-232 ports (COM3/COM4)
Audio
1x 3.5 mm jack for mic-in and speaker-out
Storage Interface
SATA HDD
2x internal SATA port for 2.5" HDD/ SSD installation, supporting RAID 0/ 1
M.2
1x M.2 2280 M key socket (PCIe Gen4 x4) for NVMe SSD
Expansion Bus
PCI Express
2x PCIe x16 slot@Gen3, 8-lanes PCIe signal in Cassette for installing
NVIDIA® L4 GPU and one additional PCIe card
