Neousys Technology POC-40 Series User manual

Neousys Technology Inc.
POC-40 Series
User Manual
Revision 1.0

Table of Contents
Table of Contents
Table of Contents...................................................................................................................2
Legal Information...................................................................................................................4
Contact Information...............................................................................................................5
Declaration of Conformity.....................................................................................................5
Copyright Notice....................................................................................................................6
Safety Precautions.................................................................................................................7
Service and Maintenance ......................................................................................................8
ESD Precautions....................................................................................................................8
About This Manual.................................................................................................................9
1Introduction
1.1 Specification of POC-40...........................................................................................11
1.2 Dimension.................................................................................................................13
1.2.1 Superior View....................................................................................................13
1.2.2 Front Panel View...............................................................................................14
1.2.3 Bottom View......................................................................................................15
1.2.4 Top Panel View.................................................................................................16
1.2.5 DIO Panel View (POC-40-DIO Only) ................................................................16
2System Overview
2.1 Unpacking the System.............................................................................................17
2.2 POC-40 Series Front Panel......................................................................................18
2.2.1 USB 2.0 Port.....................................................................................................19
2.2.2 System Status LED...........................................................................................20
2.2.3 GbE Port...........................................................................................................21
2.2.4 USB 3.1 Gen1 Port...........................................................................................22
2.2.5 DisplayPort........................................................................................................23
2.2.6 Reset Button.....................................................................................................24
2.2.7 4-Pin Terminal Block.........................................................................................25
2.3 POC-40 Series Top Panel.........................................................................................26
2.3.1 Power Button ....................................................................................................27
2.3.2 COM2 Port........................................................................................................28
2.3.3 COM1 Port........................................................................................................29
2.3.4 Isolated Digital Input/ Output (POC-40-DIO Only).............................................30
2.4 POC-40 Series Internal I/O.......................................................................................31
2.4.1 SO-DIMM Memory Socket................................................................................31
2.4.2 M.2 M Key Slot for SSD (SATA Signal Only).....................................................32
2.4.3 M.2 3042/ 3052 Bey Socket..............................................................................34
2.4.4 M.2 E Key Socket .............................................................................................36
2.4.5 Ignition Rotary Switch (POC-40-IGN Only).......................................................38
3System Installation
3.1 Disassembling the System Enclosure....................................................................40
3.2 Installing Internal Components...............................................................................42
3.2.1 DDR4 SO-DIMM Installation.............................................................................42
3.2.2 M.2 3042/ 3052 B Key Module, Micro SIM Card and Antenna Installation........43
3.2.3M Key M.2 2280 SATA SSD Module Installation...............................................46
3.2.4 M.2 2230 E Key Module Installation..................................................................47
3.3 Installing the System Enclosure .............................................................................48
3.4 DIN Rail Installation..................................................................................................50
3.5 Powering On the System .........................................................................................52
3.5.1 Powering On Using the Power Button...............................................................52
3.5.2 Powering On Using An External Non-Latched Switch.......................................53
3.5.3 Powering On Using Wake-on-LAN....................................................................54
3.6 Ignition Power Control (POC-40-IGN Only) ............................................................57

Table of Contents
3
3.6.1 Principles of Ignition Power Control..................................................................57
3.6.2 Additional Features of Ignition Power Control...................................................58
3.6.3 Wiring Ignition Signal........................................................................................59
3.6.4 Configure your Windows system.......................................................................60
3.6.5 Operation Modes of Ignition Power Control......................................................61
4BIOS Settings
4.1 COM1 Port Configuration ........................................................................................64
4.2 C-States.....................................................................................................................65
4.3 Wake-on-LAN............................................................................................................66
4.4 Power On after Power Failure..................................................................................67
4.5 Position New Boot Device.......................................................................................68
4.6 Watchdog Timer........................................................................................................69
5OS Support and Driver Installation
5.1 Operating System Compatibility.............................................................................70
5.2 Driver Installation.....................................................................................................71
5.2.1 Install Drivers Automatically..............................................................................71
5.2.2 Install Drivers Manually.....................................................................................72
5.3 Driver for Watchdog Timer and DIO........................................................................73
Appendix A Using WDT & DIO
WDT and DIO Library Installation.......................................................................................75
WDT Function Reference ....................................................................................................77
InitWDT..................................................................................................................................77
SetWDT .................................................................................................................................77
StartWDT ...............................................................................................................................78
ResetWDT .............................................................................................................................78
StopWDT................................................................................................................................78

Legal Information
Legal Information
All Neousys Technology Inc. products shall be subject to the latest Standard
Warranty Policy
Neousys Technology Inc. may modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Neousys
Technology Inc. will provide access to these new software, firmware or
documentation releases from download sections of our website or through our
service partners.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Neousys
Technology Inc. product by checking in advance with Neousys Technology Inc.
Customer is solely responsible for ensuring the compatibility and interoperability of
the third party’s products. Customer is further solely responsible for ensuring its
systems, software, and data are adequately backed up as a precaution against
possible failures, alternation, or loss.
For questions in regards to hardware/ software compatibility, customers should
contact Neousys Technology Inc. sales representative or technical support.
To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be
responsible for any interoperability or compatibility issues that may arise when (1)
products, software, or options not certified and supported; (2) configurations not
certified and supported are used; (3) parts intended for one system is installed in
another system of different make or model.

Contact Information/ Declaration of Conformity
Contact Information
Headquarters
(Taipei, Taiwan)
Neousys Technology Inc.
15F, No.868-3, Zhongzheng Rd., Zhonghe Dist., New Taipei City, 23586, Taiwan
Tel: [phone] Fax: [phone] Email, Website
Americas
(Illinois, USA)
Neousys Technology America Inc.
3384 Commercial Avenue, Northbrook, IL 60062, USA
Tel: [phone] Email, Website
China Neousys Technology (China) Ltd.
Room 612, Building 32, Guiping Road 680, Shanghai
Tel: [phone] Email, Website
Declaration of Conformity
FCC This equipment has been tested and found to comply with the limits for a Class
Adigital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at own expense.
CE The product(s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to remain
CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.

Copyright Notice
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Neousys Technology, Inc.
Disclaimer This manual is intended to be used as an informative guide only and is subject
to change without prior notice. It does not represent commitment from Neousys
Technology Inc. Neousys Technology Inc. shall not be liable for any direct,
indirect, special, incidental, or consequential damages arising from the use of
the product or documentation, nor for any infringement on third party rights.
Patents and
Trademarks
Neousys, the Neousys logo, Expansion Cassette, MezIOTM are registered
patents and trademarks of Neousys Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Intel®, Core™ are registered trademarks of Intel Corporation
NVIDIA®, GeForce®are registered trademarks of NVIDIA Corporation
All other names, brands, products or services are trademarks or registered
trademarks of their respective owners.

Safety Precautions
Safety Precautions
Read these instructions carefully before you install, operate, or transport the
system.
Install the system or DIN rail associated with, at a sturdy location
Install the power socket outlet near the system where it is easily accessible
Secure each system module(s) using its retaining screws
Place power cords and other connection cables away from foot traffic. Do not
place items over power cords and make sure they do not rest against data
cables
Shutdown, disconnect all cables from the system and ground yourself before
touching internal modules
Ensure that the correct power range is being used before powering the device
Should a module fail, arrange for a replacement as soon as possible to minimize
down-time
If the system is not going to be used for a long time, disconnect it from mains
(power socket) to avoid transient over-voltage

Service and Maintenance/ ESD Precautions
Service and Maintenance
ONLY qualified personnel should service the system
Shutdown the system, disconnect the power cord and all other connections
before servicing the system
When replacing/ installing additional components (expansion card, memory
module, etc.), insert them as gently as possible while assuring proper
connector engagement
ESD Precautions
Handle add-on module, motherboard by their retention screws or the module’s
frame/ heat sink. Avoid touching the PCB circuit board or add-on module
connector pins
Use a grounded wrist strap and an anti-static work pad to discharge static
electricity when installing or maintaining the system
Avoid dust, debris, carpets, plastic, vinyl and styrofoam in your work area.
Do not remove any module or component from its anti-static bag before
installation

About This Manual
About This Manual
This manual introduces and demonstrates installation procedures of Neousys
POC-40 seriessystems. An extremely compact fanless computer featuring Intel®
Elkhart Lake Atom®, it is designed for space-restricted deployments such as factory
data collection, eugged edge computing, and mobile gateway applications.
Revision History
Version Date Description
1.0 Dec. 2022 Initial release

POC-40 Series
10
1 Introduction
POC-40 is an extremely compact fanless controller with dimensions measuring just
52 x 89 x 112 mm.It features Elkhart Lake Atom®processor that is designed for
space-restricted industrial applications such as edge computing or data collection.
The new Intel® Elkhart lakeAtom® x6211E
dual-core processor utilizes 10 nm process
technology, which delivers 1.7x the
performance of its previous generation. In
comparison to POC-200, POC-40 provides
similar computing performance at only 1/2 the
size. Built for industrial applications, it features
rich I/O ports such as two Gigabit Ethernet
LAN ports, four USB 3.1 Gen1/ 2.0 ports and
integrated 4-ch isolated digital inputs/ outputs
so you can connect general sensors or
cameras for machine vision purposes.
POC-40 also has up to four COM ports for
generic device communication. Wireless
connectivity is essential for the modern mobile
gateway, and POC-40 provides M.2 E key for full bandwidth WiFi 5/ WiFi 6 and B key
for 4G/ 5G module facilitating long-distance data transmission and allowing real-time
communication.
With a similar form factor as a traditional PICO-ITX, Neousys’ POC-40 is perfect for
projects that require above par performance in an extremely compact package.
POC-40 is a low power consumption, lightweight fanless design system that offers
wide temperature operation capability to suit harsh outdoor environments. It is the
ideal platform for outdoors as a mobile or industrial gateway.

POC-40 Series
11
1.1 Specification of POC-40
System Core
Processor Intel® Elkhart Lake Atom® x6211E dual-core 1.2GHz/ 3.0GHz 6W
processor
Graphics Integrated Intel®UHD Graphics
Memory Up to 32 GB DDR4-3200 SDRAM by one SODIMM socket
Panel I/O Interface
Ethernet 2x Gigabit Ethernet ports by Intel® I210 GbE controllers
USB 2x USB 3.1 Gen1 (5 Gbps) ports
2x USB 2.0 ports
Video Port 1x DisplayPort connector, supporting 4096 x 2160 resolution @
60Hz
Serial Port 1x software-programmable RS-232/422/485 ports (COM1)
1x 3-wire RS-232 ports (COM2)
Isolated Digital
I/O
Optional 4-ch isolated digital input and 4-ch isolated digital output
Audio 1x 3.5 mm jack for mic-in and speaker-out
Storage Interface
M.2 M key 1x M.2 2280 M key SATA interface
Internal Expansion Bus
M.2 B key 1x M.2 3042/ 3052 B key socket with internal SIM card socket for
4G/ 5G module
M.2 E key 1x M.2 2230 E key socket for WiFi 5/ WiFi 6
Power Supply
DC Input 1x 4-pin pluggable terminal block for 12-20V DC input
Remote Ctrl 1x 4-pin pluggable terminal block for remote control
Mechanical
Dimension 52 mm (W) x 89 mm (D) x 112 mm (H)
Weight TBD
Mounting DIN-rail mount (standard) or Wall-mount (optional)
Environmental
Operating
Temperature -25°C ~ 70°C */**
Storage
Temperature -40°C ~85°C */**

POC-40 Series
12
Humidity 10%~90% , non-condensing
Vibration Operating, MIL-STD-810G, Method 514.6, Category 4
Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table
516.6-II
EMC CE/FCC Class A, according to EN 55032 & EN 55024
* The 100% CPU/GPU loading for high temperature test is applied using Passmark®
BurnInTest™ v8.0. For detail testing criteria, please contact Neousys Technology
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk
(SSD) is required.

POC-40 Series
13
1.2 Dimension
1.2.1 Superior View

POC-40 Series
14
1.2.2 Front Panel View

POC-40 Series
15
1.2.3 Bottom View

POC-40 Series
16
1.2.4 Top Panel View
1.2.5 DIO Panel View (POC-40-DIO Only)

POC-40 Series
17
2 System Overview
Upon receiving and unpacking your POC-40 series, please check immediately if the
package contains all the items listed in the following table. If any item(s) are missing
or damaged, please contact your local dealer or Neousys Technology.
2.1 Unpacking the System
Item Description Qty
1 POC-40 ultra-compact fanless controller
(Please verify additionally purchased accessories such as memory
module, mSATA SSD, etc.)
1
2 3-pin pluggable terminal block 1
3 Neousys drivers & utilities DVD 1
4 DIN-rail mount clip 1
5 Screw package 1
6 DIO 16-pin to DB15 cable (POC-40-DIO only) 1

POC-40 Series
18
2.2 POC-40 Series Front Panel
The front panel of POC-40 system
featuresrich I/O ports, it has two
USB2.0, two GbE, two USB3.0
ports, a DisplayPort for video output
and 4-pin terminal block for DC
input.
No. Item Description
1
USB 2.0 port The USB 2.0 ports offer up to 480Mbit/s bandwidth and are
backward compatible with USB 1.1/ 1.0.
2 System status LED Four system LEDs, Power (PWR), Ignition control (IGN),
Hard Disk Drive (HDD) and Watchdog Timer (WDT).
3 GbE port The Ethernet port offers up to 1Gb/s transfer bandwidth
4 USB 3.1 Gen1 port
The USB 3.1 Gen1 ports support up to 5Gbit/s data
transfer bandwidth and are backward compatible with USB
2.0/ 1.1/ 1.0.
5 DisplayPort The dual DisplayPort ports can support up to 4096 x 2160
@ 60Hz resolution each.
6 Reset button Use this button to manually reset the system.
7 4-pin terminal block
(DC/ ignition input)
Compatible with DC power input from 12 to 20V, the
terminal block can also be used for ignition signal input.

POC-40 Series
19
2.2.1 USB 2.0 Port
The USB2.0 ports are implemented via native xHCI (eXtensible Host Controller
Interface) and are backward compatible with USB 1.1 and USB 1.0 devices. Legacy
USB support is also provided so you can use USB keyboard/ mouse in DOS
environment.
xHCI driver is supported natively in Windows 10, therefore you do not need to install
xHCI driver to utilize USB functions.

POC-40 Series
20
2.2.2 System Status LED
There are four LED indicators on the front panel: PWR, HDD, WDT and IGN. The
descriptions of these four LEDs are listed in the following table.
Indicator Color Description
PWR Green Power indicator, lid when system is on
IGN Green This LED is used to indicate ignition signal status (lid when
IGN signal is applied).
HDD Red Hard drive indicator, flashing when SATA HDD is active
WDT Yellow Watchdog timer indicator, flashing when watchdog timer has
started
