NordicTrack SpaceSaver Plus User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. eep this manual
for future reference.
Serial Number
Decal
Model No. NTEL00807.0
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are commit-
ted to providing complete customer
satisfaction. If you have questions,
or if parts are damaged or missing,
PLEASE DO NOT CONTACT THE
STORE; please contact Customer
Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
USERʼS MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
V

TABLE OF CONTENTS
WARNINGDECALPLACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMBLY ...............................................................................5
HOWTOUSETHEELLIPTICALEXERCISER ..................................................13
MAINTENANCEANDTROUBLESHOOTING ...................................................21
EXERCISEGUIDELINES ...................................................................22
PARTLIST ..............................................................................24
EXPLODEDDRAWING ....................................................................26
ORDERINGREPLACEMENTPARTS ..................................................BackCover
LIMITEDWARRANTY ..............................................................BackCover
2
NordicTrack is a registered trademark of ICON IP, Inc.
WARNING DECAL PLACEMENT
The warning decals shown here have been
applied in the locations shown. If a decal is
missing or illegible, call the telephone
number on the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal may not be shown at actual
size.

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or per-
sons with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. Your elliptical exerciser is intended for home
use only. Do not use your elliptical exerciser
in a commercial, rental, or institutional set-
ting.
4. eep your elliptical exerciser indoors, away
from moisture and dust. Place your elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around your elliptical exerciser to mount,
dismount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. eep children under age 12 and pets away
from your elliptical exerciser at all times.
7. Your elliptical exerciser should not be used
by persons weighing more than 275 lbs.
(124 kg).
8. Wear appropriate exercise clothes when
exercising; do not wear loose clothes that
could become caught on your elliptical exer-
ciser. Always wear athletic shoes for foot
protection.
9. Hold the handgrip pulse sensor or the upper
body arms when mounting, dismounting, or
using your elliptical exerciser.
10. eep your back straight while using your
elliptical exerciser; do not arch your back.
11. The pulse sensor is not a medical device.
Various factors, including the userʼs move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. When you stop exercising, allow the pedals
to slowly come to a stop.
13. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
14. Use your elliptical exerciser only as
described in this manual.
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
IMPORTANT PRECAUTIONS

4
BEFORE YOU BEGIN
Thank you for purchasing the revolutionary
NordicTrack®SPACESAVER PLUS elliptical exerciser.
The SPACESAVER PLUS elliptical exerciser provides
a wide array of features designed to make your work-
outs at home more effective and enjoyable—and when
youʼre not exercising, the unique elliptical exerciser
can be folded out of the way.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
tacting us. The model number and the location of the
serial number decal are shown on the front cover of
this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Pulse Sensor
Upper Body Arm
Pedal Disc
Wheel
Pedal
Water Bottle Holder*
Console
Handle
Latch Button
Fan
*No water bottle is included

5
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own Phillips screwdriver , adjustable
wrench , and rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parenthe-
ses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The
number following the parentheses is the quantity needed for assembly. Note: Some small parts may have
been preassembled. If a part is not in the hardware kit, check to see if it has been preassembled.
M8 x 23mm
Washer (31)–10
M8 Split
Washer (97)–16
M4 x 16mm
Round Head
Screw (92)–23
M8 Washer
(106)–2
Wave Washer
(80)–2
M10 Split
Washer (99)–4
M10 x 80mm Patch Screw (93)–4
Large Wave
Washer (89)–2
M8 x 23mm
Thin Washer
(96)–2
M4 x 16mm
Blunt Screw
(33)–5
M8 Nylon
Locknut (94)–2
M8 x 45mm Patch Screw (90)–6 M10 x 58mm Shoulder Bolt (104)–2
M8 x 14mm Patch
Screw (84)–6
M8 x 19mm Patch
Screw (86)–6
M8 x 23mm Shoulder
Patch Screw (105)–2
M6 x 32mm Patch
Screw (113)–4

6
2. Attach the Left and Right Frame Covers (36,
37) around the Frame (1) with four M4 x 16mm
Round Head Screws (92).
3. With the help of another person, carefully tip
the elliptical exerciser onto its side. Attach the
Center Foot (40) to the Frame (1) with two
M4 x 16mm Blunt Screws (33). Then, return the
elliptical exerciser to the upright position.
Orient the Rear Stabilizer (3) as shown. While
another person lifts the Folding Frame (2),
attach the Rear Stabilizer to the Folding Frame
with two M10 x 80mm Patch Screws (93) and
two M10 Split Washers (99).
3
92
37
99
99
40
33
2
93
3
1
36
92 1
2
1.
See HOW TO FOLD AND UNFOLD THE
ELLIPTICAL EXERCISER on page 13 and
unfold the elliptical exerciser.
While another person lifts the front of the
Frame (1), attach the Front Stabilizer (4) to the
Frame with two M10 x 80mm Patch Screws (93)
and two M10 Split Washers (99).
4
93
99
1
1
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.

5. Orient the Left and Right Upright Covers (19,
20) as shown. Attach the Upright Covers
around the Upright (10) with five M4 x 16mm
Round Head Screws (92).
7
5
19
20
10
92
92
4. Tip: Be careful not to pinch the Wire
Harnesses (64, 65) during this step.
While another person holds the Upright (10)
near the Frame (1), connect the Upper Wire
Harness (65) to the Lower Wire Harness (64).
Then, insert the Upright (10) into the Frame (1).
Attach the Upright with four M8 x 19mm Patch
Screws (86) and four M8 Split Washers (97).
Do not tighten the Patch Screws yet.
10
1
97
97 97
97
86
86
64
65
4
Avoid pinching the
Wire Harnesses (64, 65)
during this step

8
7. Attach the Right Upper Body Arm (23) to the
Right Upper Body Leg (72) with three M8 x
14mm Patch Screws (84) and three M8 Split
Washers (97).
Attach the Left Upper Body Arm (22) in the
same way.
22
23
24
72
97
97
84
7
6
31
24
80
72
86
86
71
65
80
10
31
6. Tip: Be careful not to damage the Upper
Wire Harness (65).
Apply a generous amount of the included grease
to the Upper Body Axle (71). Insert the Upper
Body Axle into the Upright (10).
Apply a small amount of grease to a Wave
Washer (80). Slide the Wave Washer onto the
left end of the Upper Body Axle (71).
Identify the Left Upper Body Leg (24), which is
marked with an “L” sticker, and orient it as
shown. Slide the Left Upper Body Leg onto the
left side of the Upper Body Axle (71).
Attach the Left Upper Body Leg (24) to the Upper
Body Axle (71) with an M8 x 19mm Patch Screw
(86) and an M8 x 23mm Washer (31).
Repeat this step for the Right Upper Body
Leg (72).
Grease
Grease

9
8. Hold the Right Rear Upper Body Cover (28) and
the Right Front Upper Body Cover (29) around
the Right Upper Body Leg (72). Attach the
Upper Body Covers with five M4 x 16mm Round
Head Screws (92).
Attach the Left Rear Upper Body Cover (26)
and the Left Front Upper Body Cover (27) in
the same way.
72
92
92
92
27
26
28
8
9
29
9. The Console (11) can be operated with four
1.5V “D” batteries (not included); alkaline batter-
ies are recommended. IMPORTANT: If the
elliptical exerciser has been exposed to cold
temperatures, allow it to warm to room tem-
perature before inserting batteries into the
Console. If you do not do this, the console
displays or other electronic components
may become damaged. Press the tabs on the
battery covers and remove the battery covers.
Next, insert four batteries into the Console;
make sure that the batteries are oriented as
shown by the diagrams inside the Console.
Then, reattach the battery covers.
The Console (11) can also be operated with an
optional power supply (not included). To pur-
chase a power supply, see the front cover of
this manual. To avoid damaging the console,
use only a manufacturer-supplied power
supply. Plug one end of the power supply into
the jack on the Console; plug the other end into
an outlet installed in accordance with all local
codes and ordinances.
Battery
Covers
Batteries Batteries
11

10
10. Tip: Be careful not to pinch the wires during
this step.
Attach the Handlebar (77) to the Upright (10)
with four M6 x 32mm Patch Screws (113).
10
77
111
113
Avoid pinching
the wires during
this step
6510
11. Tip: Be careful not to pinch the wires during
this step.
While another person holds the Console (11)
near the Upright (10), connect the console wire
to the Upper Wire Harness (65). Next, connect
the console pulse wire to the Pulse Sensor Wire
(111). Then, connect the console ground wire to
the Ground Wire (112). Insert the excess wire
into the Upright.
Attach the Console (11) to the Upright (10) with
four M4 x 16mm Round Head Screws (92).
11
92
112
92
Console Wire
Console
Pulse Wire
Ground Wire
11 10
Avoid pinching the
wires during this step
65
12. Slide the Lower Handlebar Cover (109) into the
slots in the underside of the Console (11).
Attach the Lower Handlebar Cover to the
Handlebar (77) with two M4 x 16mm Blunt
Screws (33).
12
111
109
33
77
11
Slots
