NSK MPA Series User manual

OM-C0236E
002
Rubber Cap
Connection Cord Clip
Clip of Apex LocatorConnection Cord
Fig. 3
Fig. 2
Fig. 1
Fig. 5Fig. 4
Fig. 7Fig. 6
Head
File Clip
File
Fig. 8
File Clip Holder
Figure shows MPA.
F-type Contra Angle Head
MPA/MPAS
Caution
• Be sure that the Endodontic File and the Connection Cord End have
conduction of electricity before probing the root canal treatment.
• Slide back the File Clip Holder to motor direction when replacing the
Endodontic file and/or when not using Apex locator function.
• Do not bend the File Clip.
Mount the Endodontic file to the Contra Head and slide the File Clip
Holder to the head direction to contact the Endodontic file and File Clip.
(Fig.8)
Insert the Endodontic file into the head. Lightly turn the file until it
engages with the latch mechanism. (Fig.4) Push it inward to click. (Fig.5)
Removal file
Push the push button with a thumb, and the file is removed. (Fig.6)
Connect the Contra Angle Head Connection Cord with the Clip of Apex
locator. (Fig.3)
This operation manual is for : MPA-F, MPA-F4R, MPA-F10R, MPA-F16R, MPA-F20R,
MPAS-F, MPAS-F4R, MPAS-F10R, MPAS-F16R, MPAS-F20R
Please use MPA, when you use regular shank file. MPAS is used when using short shank
file, such as K3*, EndoWave* etc.
Remove the Rubber Cap on the backside of motor handpiece body
with slotted bit screw driver and insert the Connection Cord Clip. (Fig.1)
Mount Contra Angle Head to motor handpiece. Pull out the head
straightly when removing/replacing the head.
Insert the Connection Cord into the slit of Connection Cord Clip. Adjust
the tension of the Connection Cord between the head and the
Connection Cord Clip not to be slack. (Fig.2)
1. Mounting procedure
Caution
After the file is locked in place, lightly pull out the file to make sure the
file is locked. (Fig.7)
1
2
3
4
5
6

Fig. 9
Cord Mounting Pin
Hole
F-type Spray Nozzle
Fig. 10
Figure shows MPA.
PANA SPRAY Plus / PANA SPRAY (Option)
Caution
• Cord Clip is not autoclavable.
• Do not wipe with, or clean or immerse in, high acid water or
sterilizing solutions.
Caution
• Before mounting the lubricated Contra Angle Head to the motor
handpiece, wipe off extra oil. Stand on its end or lean it in the proper
position for gravity draining. Mount it after excess oil has been
completely drained.
• Hold the Contra Angle Head securely to prevent it from flying off by
the pressure of the spray.
• Hold the spray can upright.
Caution
Do not force to pull the Connection Cord.
Steam autoclave is recommended.
Sterilization is required first time you use and after each patient.
Autoclave Procedure :
Scrub dirt and debris from the handpiece, and clean with alcohol-
immersed cotton swab or cloth. Do not use a wire brush.
Lubricate with PANA SPRAY Plus (Option). Refer to 2. Lubrication.
Insert into an autoclave pouch. Seal the pouch.
Autoclavable up to max. 135˚C.
ex.) Autoclave for 20 min. at 121˚C, or 15 min. at 132˚C.
Keep the handpiece in the autoclave pouch to keep it clean until you
use it.
Sterilization at 121˚C for more than 15 minutes is recommended by
EN13060 or EN554.
Care3 Plus
NSK Care3 Plus automatic handpiece cleaning and lubrication system.
After connecting the handpiece to the correct adaptor, activate the
Care3 System per the Care3 System instructions.
• Connect/Disconnect the cord.
(1) To connect
Insert the Cord Mounting Pin at the end
of the cord into the hole on the Motor
Handpiece body. The cord should be at
right angle to the body.
Rotate the cord 90˚ until the cord seats
correctly.
(2) To Disconnect
Move back the cord rotate the opposite
direction and remove.
3. Sterilization
Supply PANA SPRAY Plus / PANA SPRAY or/and Care3 Plus (option) after
each use and/or before each autoclaving.
PANA SPRAY Plus / PANA SPRAY
Screw the F-type spray nozzle onto the PANA SPRAY Plus / PANA
SPRAY nozzle by approx. 10 turns. Insert the F-type spray nozzle into
the rear part of the contra angle head and lubricate the head for 2-3
seconds. (Fig.10)
2. Lubrication
1
2
3
4
5
1
2
’09.11.01 M
The EU directive 93/42/EEC was applied in the design and production of this medical device.
