NSK Ti-Max X500L User manual

Use Environment
Temperature : 0 - 40°C , Humidity: 30 - 75 % , Atomospheric Pressure: 700 - 1,060 hPa
Store and Transportation Environment
Temperature : -10 - 50°C , Humidity: 10 - 85% , Atomospheric Pressure: 500 - 1,060 hPa
Benutzungsumgebung
Temperatur : 0 - 40°C , Luftfeuchtigkeit: 30 - 75 % , Atmosphärischer Luftdruck: 700 - 1.060 hPa
Transport und Lagerung
Temperatur : -10 - 50°C , Luftfeuchtigkeit: 10 - 85 % , Atmosphärischer Luftdruck: 500 - 1.060 hPa
Environnement d’utilisation
Température : 0 - 40°C , Humidité: 30 - 75 % , Pression atmosphérique: 700 - 1.060 hPa
Transport et environnement de stockage
Température : -10 - 50°C , Humidité: 10 - 85 % , Pression atmosphérique: 500 - 1.060 hPa
Entorno de uso Temperatura: 0 - 40˚C, Humedad: 30 - 75%RH, Presión atmosférica: 700 - 1.060hPa
Transporte y entorno de almacenamiento Temperatura: -10 - 50˚C, Humedad: 10 - 85%RH, Presión atmosférica: 500 - 1.060hPa
Ambiente di utilizzo Temperatura: 0 - 40˚C, Umidità: 30 - 75%UR, Pressione atmosferica: 700 - 1.060hPa
Trasporto e ambiente di stoccaggio Temperatura: -10 - 50˚C, Umidità: 10 - 85%UR, Pressione atmosferica: 500 - 1.060hPa
KaVo®and MULTIflex®are registered trademarks of Kaltenbach & Voigt GmbH & Co., Germany. Sirona®is a registered trademark of Sirona Dental Systems GmbH, Germany.
W&H®and Roto Quick®are registered trademarks of W&H Dentalwerk Bürmoos GmbH, Austria. Bien-Air®and Unifix®are registered trademarks of Bien-Air Dental S.A.,Switzerland.
KaVo®und MULTIflex®sind eingetragene Marken von Kaltenbach & Voigt GmbH & Co., Deutschland. Sirona®ist eine eingetragene Marke von Sirona Dental Systems GmbH, Deutschland.
W&H®und Roto Quick®sind eingetragene Marken von W&H Dentalwerk Bürmoos GmbH, Österreich. Bien-Air®und Unifix®sind eingetragene Marken von Bien-Air Dental S.A., Schweiz.
KaVo®et MULTIflex®sont des maques déposées de la société Kaltenbach & Voigt GmbH & Co, Allemagne. Sirona®est une maque déposée par la société Sirona Dental Systems GmbH, Allemange.
W&H®et Roto Quick®sont des marques déposées de la société W&H Dentalwerk Bürmoos GmbH, Autriche. Bien-Air®et Unifix®sont des marques déposées de la société Bien-Air Dental S.A. Suisse.
KaVo®y MULTIflex®son marcas registradas de Kaltenbach & Voigt GmbH & Co., Alemania. Sirona®es una marca registrada de Sirona Dental Systems GmbH, Alemania.
W&H®y Roto Quick®son marcas registradas de W&H Dentalewerk Bürmoos GmbH, Austria. Bien-Air®y Unifix®son marcas registradas de Bien-Air Dental S.A., Suiza.
KaVo®e MULTIflex®sono marchi registrati di Kaltenbach & Voigt GmbH & Co., Germania. Sirona®è un marchio registrato di Sirona Dental Systems GmbH, Germania.
W&H®e Roto Quick®sono marchi registrati di W&H Dentalwerk Bürmoos GmbH, Austria. Bien-Air®e Unifix®sono marchi registrati di Bien-Air Dental S.A., Svizzera.
ENIT
ENES
ENFR
DE
ENEN
ENIT
ENES
ENFR
DE
ENEN

•When operating the handpiece always consider the safety of the patient.
•The handpiece is designed only for dental clinical use.
•Do not attempt to disassemble the handpiece nor tamper with the mechanism.
•Check for vibration, noise and overheating outside the patient's mouth. If any abnormalities are found do not operate.
Contact your authorized NSK Dealer for service.
•
Should the handpiece not function normally, cease operation immediately and return the handpiece to your authorised NSK Dealer for
service.
•Depressing the Push Button while the bur is rotating could result in OVERHEATING of the handpiece head. Caution must be
exercised during use to keep cheek tissue away from the push button. Contact with soft tissue may cause the Push Button
to depress and injury to the patient may occur.
•Avoid impact on the handpiece. Do not drop the handpiece.
Caution
Thank you for purchasing this powerful NSK handpiece. Please read this operation manual carefully before use.
1
ENGLISH

Caution
X500L X500 X600L X650L X600 X700L X700
Model
Head Type Miniature Head Standard Head Torque Head
Rotation Speed 390,000 ~ 450,000min-1 380,000 ~ 440,000min-1 300,000 ~ 360,000min-1
Drive Air Pressure
0.25MPa (2.5kgf/cm2) ~0.3MPa (3.0kgf/cm2)
Chuck Type Push Button Chuck
Optics
ø10.3 x 11.7 mm ø11.2 x 13.6 mm ø13.2 x 13.6 mm
Head Size Diameter x Height
Burs Size: ISO1797-1 Type3 ø1.59~1.60
Friction Grip Standard ShankFriction Grip Short Shank
—
Cellular Glass Rod
—
Cellular Glass Rod
—
Cellular Glass Rod
Performance specifications
•Do not operate the handpiece without first inserting a bur or test-bur into the chuck.
•Remove the bur only after the handpiece has completely stopped rotating.
•Do not look into LED light directly.
•When abnormalities are in LED (dark, do not light on or flashing or so), contact dealer to repair.
(X500WLED/X500BLED/M600WLED/M600BLED/X700WLED/X700BLED)
•This product is classified as Class 1 LED Product. (X500WLED/X500BLED/X600WLED/X600BLED/X700WLED/X700BLED)
•Use a power source which meets the following requirements.
(X500WLED/X500BLED/X600WLED/X600BLED/X700WLED/X700BLED)
1.The electricity supply of the power source is below 15W both under normal and single failure conditions.
2.The power source uses a SELV circuit for electricity supply.
3.The output voltage of the power source is within the range recommended by the manufacturer of this product.
3
ENGLISH FRENCH GERMAN SPANISH ITALIAN
2

Performance specifications
CONNECTION (Fig.1)
To connect the handpiece to the coupling align the handpiece to the
coupling and push together (per the coupling manufacturers instructions).
DISCONNECTION (Fig.1)
Release the handpiece from the coupling (per the coupling manufacturers
instructions) and remove the handpiece.
NSK COUPLING : Pull back Connector Ring to release the handpiece.
First make sure the manufacturer’s coupling is firmly attached to the
handpiece tubing and the drive air pressure is correct.
Fig. 1
Handpiece
NSK Coupling
Connector Ring
Connection / Disconnection to the Coupling
—
—
—
AC/DC 3.3V ± 0.05V
3.0~4.0V
0.38A Typical (3.3V)
—
—
—
AC/DC 3.3V ± 0.05V
3.0~4.0V
0.38A Typical (3.3V)
—
—
—
—
—
—
White LED
Model
Head Type Torque HeadMiniature Head Standard Head
380,000 ~ 440,000min-1
0.25MPa (2.5kgf/cm2) ~0.3MPa (3.0kgf/cm2)
Push Button Chuck
Size: ISO1797-1 Type3 ø1.59~1.60
ø11.2 x 13.6 mm
Friction Grip Short Shank
ø10.3 x 11.7 mm
300,000 ~ 360,000min-1
Cellular Glass Rod
—
White LED
Friction Grip Standard Shank
Cellular Glass Rod
——
White LED
Cellular Glass Rod
AC/DC 3.3V ± 0.05V
3.0~4.0V
0.38A Typical (3.3V)
ø13.2 x 13.6 mm
X500KL/X500SL
X500WL/X500BL
X500K
X500WLED
X500BLED X600KL/X650KL/X600SL
X600WL/X600BL X600WLED
X600BLED
X600K
X700WLED
X700BLED
X700KL/X700SL
X700WL/X700BL
X700K
390,000 ~ 450,000min-1
Rotation Speed
Drive Air Pressure
Chuck Type
Burs
Optics
Voltage
Activate Voltage
Consumption current
Head Size Diameter x Height
—
—
—
—
—
—
5
ENGLISH FRENCH GERMAN SPANISH ITALIAN
4

Fig. 3
Caution
Fig. 2
Insertion & Removal of the bur
TO INSERT THE BUR (Fig. 2) TO REMOVE THE BUR (Fig. 3)
Depress the Push Button and insert
the bur into the chuck until it is
secure. Release the button.
Stop the handpiece. Depress the
Push Button firmly and remove the bur.
Test that the bur is secure by gently
pulling and pushing the bur without
depressing the Push Button. This action
can also increase the chuck retention
power. If removing the bur becomes
difficult, depress the Push Button,
grip the bur with fine pliers and gently
remove the bur.
Information about burs
•Do not use non-standard burs. The ISO standard shank diameter is ø1.59 - ø1.60 mm.
•Do not use bent, worn, damaged, or non-concentric burs. Such burs can cause damage to the handpiece.
•Do not exceed the bur speed recommended by the bur manufacturer.
•Always keep the bur shank clean. Entry of hard debris into the chuck via the bur shank could cause
rotation slip and also prevent the bur from being securely located in the chuck.
•Fully depress the Push Button and insert the bur into the chuck until it is secure.
•Do not use short shank burs in Standard Head or Torque Head handpieces.
•Use short shank burs only in Mini Head handpieces.
•Do not use long surgical burs. Do not use burs longer than 26mm.
7
ENGLISH FRENCH GERMAN SPANISH ITALIAN
6

Maintenance of the Clean Head System
Fig. 4
Fig. 5
Outlet Holes
Outlet Holes
To maintain effective performance of the NSK Clean Head System it
is important before steriliz ation to clean the specific outlet holes
located in the handpiece head. (Fig. 4)
Remove any debris in and around the outlet holes with the brush.
Notice
Use only clean water to maintain the Clean Head System.
Half fill a cup with clean water. Operate the handpiece and, while it is
running, immerse half of the handpiece head in the water, (Fig. 5)
Intermittently stop and start the handpiece in the water for about 5
seconds. While still running, remove the handpiece from the water.
Stop the handpiece and wipe it dry. If debris remains, repeat the
process until the area is clean.
ENGLISH FRENCH GERMAN SPANISH ITALIAN
98

Automatic lubrication Manual lubrication
NSK Care3 Plus Fig. 6 PANA SPRAY Plus
Nozzle Caution
This handpiece can be washed via Thermo Disinfector. After cleaning the handpiece apply NSK PANA SPRAY Plus BEFORE autoclaving (Fig. 6). Make sure the CORRECT
application nozzle is connected to the plastic valve at the top of the spray can. Firmly insert the Nozzle into the rear of
the handpiece and activate the spray for 2-3 seconds until the spray exhausts from the handpiece head.
Always hold the NSK PANA SPRAY Plus can upright.
The spray lubricant is delivered from the can, into the handpiece, under
pressure. To prevent the handpiece from slipping from the Nozzle, always
hold the handpiece securily to the Nozzle.
Mount the arrow-head spray nozzle tip into the spray port and lubricate
chuck directly thorough the hole for bur attachment once a week.
Lubricate the handpiece EACH TIME BEFORE AUTOCLAVING
Before lubrication, first clean the handpiece as previously described.
NSK Care3 Plus automatic handpiece lubrication system
After cleaning the handpiece simply connect the handpiece to the correct
adaptor and activate the Care3 System per the Care3 System
instructions.
Other brands of automatic handpiece lubrication systems
After cleaning the handpiece simply connect the handpiece to the correct
adaptor and activate the System per the manufacturer's instructions.
ENGLISH FRENCH GERMAN SPANISH ITALIAN
11
10

Caution
Sterilization
Autoclave procedure
Use a brush to scrub debris from the handpiece. DO NOT use a wire
brush. Wipe clean with an alcohol-immersed cotton swab or cloth.
Lubricate the handpiece as previously described.
(Refer to Lubrication)
Insert the handpiece into an autoclave pouch and seal the pouch.
Autoclavable up to a max. 135°C
*EN13060 4.6.3 recommends autoclaving for 3 minutes (minimum
holding time) at 134°C or 15 minutes (minimum holding time) at
121°C. NSK recommends Class B or S sterilization.
Sterilization by steam generation
autoclave is recommended.
Sterilization is required first time
you use and after each patient.
•Always place the handpiece in the center or upper shelf of the chamber, as the local temperature at the bottom
of the chamber could rise beyond the level indicated on the autoclave.
•Do not heat or cool the handpiece quickly. Rapid change in temperature could damage the glass rod or subject
other metals to abnormal stress.
•Do not wash, soak, or wipe off the handpiece with an oxidation potential solution (strong acid, superacid solution) or
cold sterilization solution.
•The color may be slightly faded by repeated sterilization. (X650L)
ENGLISH FRENCH GERMAN SPANISH ITALIAN
13
12

(X L, X Series)
<X BL Series>
Bulb Bulb Holder
Joint
Bulb Bulb Holder
Joint
Replacing the optic illumination bulb Replacing the O-rings
Fig. 9
Fig. 10
Taper Ring
O-rings
Fig. 7
Fig. 8
Figure shows X600WL
<X WL Series>
Taper Ring Remove the handpiece from the coupling. Loosen and remove the
taper ring. (Fig. 7). Pull out the joint then remove the bulb holder,
then the bulb. Align the pins of the new bulb with the points in the
bulb holder and insert the bulb. Place the bulb holder back into the
joint. (Fig. 8). Firmly tighten the taper ring.
Optional Bulb : TA Bulb (Pack of 3) Order No.Y900132
Caution
Do not touch the glass section of new bulb. Screw the taper ring
tightly. A loose fitting taper ring could result in water and air
leakage. It is easier to screw in the taper ring when the bulb holder
is lightly pressed in by hand.
Replace the O-rings if water is present in the exhaust air line. This is an
indication of possible water leakage within the coupling. ALWAYS
change the complete set of O-rings. Remove the handpiece from the
coupling. Loosen and remove the taper ring at the rear of the handpiece.
(Fig. 9) Gently remove each O-ring with your thumb. Insert the complete
set of new O-rings in the correct grooves. (Fig. 10) Replace and firmly
tighten the taper ring.
Optional O-ring : PTL O-ring Set (Pack of 5) Order No.Y900580
Caution
Make certain that the taper ring is firmly tightened.
If the taper ring is loose water and air leakage could occur.
(X WL, X BL Series)
ENGLISH FRENCH GERMAN SPANISH ITALIAN
15
14

Fig. 11
Fig. 12
Cleaning the cellular glass optic rod
Disposing product
Cotton Swab
Cellular glass optic rod exit point
Cotton Swab
Cellular glass optic rod entry point
(X L, X KL, X SL, X WL, X BL Series)
Wipe clean the Cellular glass optic rod entry point (Fig.11) and exit
point (Fig. 12) with an alcohol-immersed cotton swab. Remove all
debris and oil.
Consult with dealer from whom you purchased it about waste disposal.
Caution
Do not use a sharp tool to clean the Cellular glass optic rod. It could
damage the glass and reduce the light transmission. If illumination
becomes dim please contact your dealer.
16
