NuWave OXYPURE 47001 User manual

Button Name Function Use
POWER Turns the OxyPure®on and off. Press POWER to turn the OxyPure®on and off.
Wi-Fi
MODE
Allows you to connect the OxyPure to your Wi-Fi
network Press and hold POWER to initiate Wi-Fi pairing.
AUTO Allows you to run the OxyPure at the lowest fan
speed, raising it based on PM level.
Press AUTO and the Auto back light will turn on. There is no time limit on the Auto Mode. Press
AUTO again to deactivate Auto Mode.
ECO
MODE
Allows you to save energy by keeping the OxyPure
fan off until it’s needed.
Press and hold POWER and ULTIMATE CLEAN to activate Eco Mode. The Power icon backlight
will be yellow while in Eco Mode.
ULTIMATE
CLEAN
Automatically switches to the highest fan speed
when the PM level rises. Press ULTIMATE CLEAN to activate the Ultimate Clean Mode.
FAN
SPEED Adjusts the OxyPure’s fan speed. There are 6 fan speed levels. Press FAN SPEED to adjust from Speed 1 (lowest) to Speed 6
(highest).
SLEEP
MODE
Turns off the control panel LED lights but keeps the
fan active.
Adjust the Fan Speed prior to activating Sleep Mode. Press and hold FAN SPEED for 2 seconds to
activate Sleep Mode.
TIMER Sets a countdown timer to shut off the OxyPure or
end the current function. Press TIMER to select from the 6 timer settings of 1/2, 1, 2, 4, 8 or 12 hours.
TURBO Operates at fan speed 6 for a set time. Press TURBO to set the OxyPure to run at the highest speed for 1/2, 1 or 2 hours.
AIR Air Quality Indicator The color coded display shows the current particulate matter level in the air.
ODOR Odor Indicator The color coded display shows the current odor level in the air.
See the Owner’s Manual for details.
Air/Odor Quality - Detects particles as small as 2.5/1000mm
Particulate Matter (PM) with a diameter of 2.5 microns or less
0~5 5~10 10~20 20~30 30~50 Over 50
Fan Speeds
1 2 3 4 5 6
High PM LevelLow PM Level
Quick Start Guide
Refer to the Owner’s Manual for more details
Model No: 47001 - 47009
ODOR
NO
ODOR
STRONG
ODOR
REPLACE
FILTER 4
CLEAN
FILTER 2
WIFI
SLEEP MODE
AUTO
ULTIMATE
CLEAN
FAN
SPEED TIMER TURBO
HR CLEAN DIRTY
POWER
HRHIGHLOW
ECO-FRIENDLY MODE
RESET FILTER 2
HOLD FOR 2 SECONDS
RESET FILTER 4
HOLD FOR 2 SECONDS
AIR
ODOR
NO
ODOR
STRONG
ODOR
OXYPURE® SMART AIR PURIFIER
AUTO
ULTIMATE
CLEAN
FAN
SPEED
HIGHLOW
SLEEP MODE
TIMER
HR
TURBO
HR
CLEAN DIRT
AIR
ULTIMATE
CLEAN
+

Wi-Fi LED Status
Pairing Mode & AP Mode
Solid Light The OxyPure®is paired with the Wi-Fi and
ready to be used.
Rapid Blinking Light
The OxyPure is in Pairing Mode. The OxyPure
will remain in Pairing Mode for up to 3 minutes,
or until your device is paired.
Slow Blinking Light The OxyPure is in AP Mode.
No Light The OxyPure’s Wi-Fi is off.
Before Use
1. Make sure the OxyPure® is unplugged. Open the panel on the back to
expose the lters.
2. Pull the lters from their slots.
3. Remove the plastic wrapping from the lters.
4. Fully reinsert the lters into the Oxypure and close the panel.
5. Remove the sticker from the control panel.
Filters
Stainless-Steel Prefilter (Lifespan up to 20 years)
• Made from rust-free 18/8 stainless-steel.
• The durable, washable and reusable Prefilter captures and collects large
particles
Bio-Guard®Filter (Lifespan up to 20 years)
• The 8,000-volt electrostatic filter captures airborne particles as small as 0.1
microns..
Ozone (O3) Emission Removal Filter (Lifespan up to 20 years)
• Eliminates harmful ozone gas from the home, reducing ozone levels to
less than 1 ppb – 70 times lower than the EPA’s household standard of
70 ppb.
2-in-1 HEPA/Carbon Filter (Lasts up to 1 year)
• The double-sided filter traps airborne particles like pollen and pet dander
while also trapping smoke, unwanted odors and VOCs.
Customer Service: [e-mail]
4
4
3
3
2
2
1
1
Connection (Optional)
Connect the OxyPure to your home Wi-Fi network and pair it with
your smart device:
1. Download the NuWave® Connect app via the Apple Store or
Google™ Play Store on your smartphone or device and open
the app.
2. Once you download the NuWave® Connect app, ensure your
phone is connected to your home Wi-Fi network on the 2.4GHz
frequency and that your phone’s Bluetooth is on.
3. Turn on the OxyPure and activate Wi-Fi Pairing Mode by
pressing and holding POWER until the light next to the Wi-Fi
symbol begins to blink rapidly.
4. In the NuWave® Connect app, tap the +symbol, then tap Auto
Scan and select your device.
5. Enter your Wi-Fi network’s password and tap Confirm. If
the connection is successful, the app will display “Added
Successfully” on the screen.
If you’re unable to pair your OxyPure using Auto Scan, follow
the instructions for AP Mode or EZ Mode on page 9 of the
owner’s manual.
Wi-Fi

Air Filter Assembly
When maintaining the lters, unplug the unit and open the Filter Access
Panel. You will see that the order of the lters, from the outside in, is as
follows:
Stainless-Steel Prefilter
Bio-Guard® Filter
Ozone Emission Removal Filter
HEPA/Carbon Filter
4
3
2
1
The OxyPure®is easily movable with wheels on the bottom. Before moving your OxyPure, turn it off and unplug it from the outlet. Your settings will be saved
and will automatically activate next time the unit is turned on.
Cleaning & Maintenance
Filter Maintenance Indicator
• The FILTER 2 light will turn green after about 3 months to alert you that the Bio-Guard lter SHOULD be cleaned to maintain optimal performance. The light
will turn red after about 6 months, indicating that the Bio-Guard lter MUST be cleaned. Once cleaned, press and hold TIMER to reset the indicator light.
• The FILTER 4 light will turn green after about 6 months to alert you that the HEPA/Carbon lter SHOULD be replaced to maintain optimal performance. The
light will turn red after about 12 months, indicating that the HEPA/Carbon lter MUST be replaced. Once replaced, press and hold TURBO for 2 seconds to
reset the indicator light.
Cleaning the Filters
The lters need to be cleaned on schedule to help the unit maintain optimum performance.
1. Remove the Filter Access Panel in the r ear of the OxyPure®using its built-in handle.
2. Slide out the lters that need cleaning and spray with a mild detergent, then wipe clean.
3. Always allow the washable lters to dry completely, out of direct sunlight, before you reinstall them. Never place a wet lter into the OxyPure.
4. Reattach and close the Filter Access Panel. If the panel is not properly closed, the POWER button will blink red and the unit will not power on.
CAUTION
Unplug the OxyPure®from the power source before inserting or removing any parts or attachments and before cleaning.
Open Removing &
Inserting Filters
Access to Filters
Customer Service: [e-mail]
4
3
2
1
NOTE: The HEPA/Carbon lter cannot be cleaned.

Cleaning the Dust Sensor
The Dust Sensor is located on the side of
the unit.
1. Open the Dust Sensor Cover.
2. Using a dry cotton swab, gently remove
any dirt or dust from the Dust Sensor.
3. For more buildup on the Dust Sensor,
wipe it with a slightly wet cotton swab.
4. Remove any moisture with a dry cotton
swab.
NOTE: Consult the OxyPure Owner’s Manual
for more detailed cleaning instructions.
Do not immerse the OxyPure in water.
Clean the outside of the unit with a damp
sponge or cloth and wipe it dry. Make
sure all parts and covers are securely
attached.
Do not dry the lters in direct sunlight or
with a hot blow dryer.
©2023 NuWave®LLC • All Rights Reserved. • Customer Service:[e-mail]
Item: BQ47001- 47009 • Rev.1-V5-CB • 07-21-23
General Filter Cleaning Tips
1. Always Wear a Mask and Use Rubber gloves.
Prevents accidental inhalation of any contaminants when cleaning
your lters.
2. Move the OxyPure, Not the Filters
Minimizes lter shaking.
3. Handle the Filters Carefully
Be careful not to agitate the lters to avoid releasing trapped
contaminants.
4. Dry the Filters Completely
Never install a wet or damp lter into your OxyPure.
To Clean the Ozone Emission Removal Filter
1. Remove the lter. If possible, take them outside to clean.
2. Gently, but thoroughly, clean the lter using a brush-tipped vacuum.
3. Repeat the process on the other side. DO NOT GET WET.
To Clean the Stainless-Steel Prelter
The Prelter needs to be cleaned at least once every two months,
depending on use.
1. Use a brush-tipped vacuum to remove any dust or lint.
Cleaning the Odor Sensor
1. The Odor Sensor is behind the three slots above the Dust Sensor
Cover and may ONLY be cleaned using a brush-tipped vacuum.
Open
Note: If you are unable to close the Filter Access Panel for any
reason, the OxyPure will not operate and you will need to contact
NuWave Customer Service. Exercise caution to ensure the
tabs are not damaged when securing the Filter Access Panel.
OXYPURE® SMART AIR PURIFIER
4
3
2
1
ODOR
NO
ODOR
STRONG
ODOR
REPLACE
FILTER4
CLEAN
FILTER2
WIFI
SLEEPMODE
AUTO
ULTIMATE
CLEAN
FAN
SPEED TIMER TURBO
HR CLEAN DIRTY
POWER
HRHIGHLOW
ECO-FRIENDLYMODE
RESETFILTER 2
HOLDFOR 2 SECONDS
RESETFILTER 4
HOLDFOR 2 SECONDS
AIR
ODOR
NO
ODOR
STRONG
ODOR
REPLACE
FILTER4
CLEAN
FILTER2
WIFI
SLEEPMODE
AUTO
ULTIMATE
CLEAN
FAN
SPEED TIMER TURBO
HR CLEAN DIRTY
POWER
HRHIGHLOW
ECO-FRIENDLYMODE
RESETFILTER2
HOLDFOR2 SECONDS
RESETFILTER4
HOLDFOR2 SECONDS
AIR
EPA Establishment Number: 101594-CHN-1
