OWNER’S MANUAL
Smart Air Purier

2
2
Using your smartphone or
smart device, scan the QR code
located on the unit label on the
back of the unit.
You will be directed to NuWave’s
product registration page with
your unit’s unique serial number
automatically entered in the
appropriate eld.
NOTE: If you do not have a
web-enabled smart device,
simply visit nuwavenow.com/QR
and manually enter in your unit’s
serial number.
Fill out the remaining information
and complete the optional survey.
Once you submit your
information, you will receive
a conrmation email containing
your extended warranty details.
1
2
3
4
REGISTER
NOW!
*Register your product within 1 year of date of purchase for a free
6-month extension of your limited warranty.
As a special thank-you for registering your NuWave
unit, you’ll automatically receive an additional 6 months
added to your limited manufacturer’s warranty!*
All you have to do is follow these simple steps.

nuwavenow.com 3 nuwavenow.com 3
1
2
3
QR code readers
6
for an additional
months
warranty!
Open your mobile app store
(App Store, Google Play).
Search for "QR code readers."
Simply download the QR code reader to your phone,
open it, scan the code and you are ready to go.
NOTE: You may need to open your downloaded QR
code reader each time you want to scan a QR code.
DOWNLOAD THE QR CODE
APP TO YOUR MOBILE DEVICE

nuwavenow.com 5
ENGLISH
nuwavenow.com 5
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
READ ALL INSTRUCTIONS
WARNING: When using the OxyPure, basic safety
precautions should always be followed:
1. To protect against risk of electrical shock, DO NOT
immerse cord, plug, or any part of the OxyPure unit in
water or any other liquids.
2. Close supervision is necessary when the OxyPure is
used by or near children. The unit is not intended for
use by children, persons with reduced physical, sensory,
or mental capabilities, or those with lack of expertise or
knowledge of this unit.
3. Do not operate OxyPure with a damaged cord, plug,
after unit malfunctions, is dropped, or damaged in any
manner. Contact Customer Service at 1-877-689-2838
or email [e-mail] for information.
4. Discard the protective plastic covering the power plug
before use.
5. Do not run cord under carpeting. DO NOT cover cord
with throw rugs, runners, or other coverings.
6. Do not route cord under furniture or appliances. Arrange
cord away from high-traffic areas where it will not be
tripped over.
7. Do not plug OxyPure in outlet or power strip that is
being used by other appliances.
8. Remove any dust or water from the plug, if needed.
9. Set up the OxyPure on flat, stable ground.
10. Do not set up where the OxyPure could be pushed,
kicked, or tripped over.
11. Leave at least 2-3 feet of space between the unit’s vents
and any walls.
12. Do not install the unit near a heating device.
13. Do not use in locations exposed to moisture or water.
14. Do not use unit near flammable or combustible gases
or vapors.
15. Do not operate the OxyPure on its side.
16. NOT INTENDED FOR OUTDOOR USE.

IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
important safeguards
66
17. Do not place objects on top of the OxyPure.
18. Do not sit or stand on or lean against the OxyPure.
19. Alteration or modification of any part of the OxyPure or the
use of attachments not recommended by the manufacturer
may cause fire, injury, or damage to property.
20. As with most electrical units, electrical parts are live even
when the OxyPure is off. Be sure the unit is unplugged
when assembling.
21. Do not use the OxyPure in a factory or industrial setting
where machine oil may be present in the air.
22. Turn the power OFF on the OxyPure before unplugging
the unit. Unplug the OxyPure from outlet when not in
use, before putting on or taking off parts, when removing
or replacing the filters, and before cleaning.
23. Turn the power OFF and unplug when the unit is
unattended for extended periods.
24. FOR HOUSEHOLD USE ONLY.
25. Keep manual handy for future reference.
WARNING! RISK OF ELECTRIC SHOCK:
These servicing instructions are for use by qualified
personnel only. To reduce the risk of electric shock, do
not perform any servicing other than that is contained in
Instructions unless you are qualified to do so.

nuwavenow.com 7
ENGLISH
nuwavenow.com 7
Electrical Information
A short power-supply cord (or detachable power-
supply cord) is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer
cord. Longer detachable power-supply cords or
extension cords are available and may be used if
care is exercised in their use. If a longer detachable
power-supply cord or extension cord is used:
1. The marked electrical rating of the extension cord
should be at least as great as the electrical rating of
the appliance.
2. The longer cord should be arranged so that it will
not drape over the countertop or tabletop where it
could be pulled on or tripped over unintentionally. The
OxyPure should be operated on a separate electrical
outlet from other operating appliances due to wattage
limitations. The appliance has a polarized plug (one
blade is wider than the other). To reduce the risk
of electric shock, this plug is intended to fit into a
polarized outlet only one way. If the plug does not fit
fully into the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. Do not attempt to
modify the plug in any way.
3. If the appliance is of the grounded type, the cord
set or extension cord should be a grounding-type
3-wire cord.
SEE INSTRUCTIONS BEFORE USE
ADDITIONAL SAFEGUARDS

important safeguards
8
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
88
SAVE THESE INSTRUCTIONS
Read and understand the entire manual before using
the OxyPure.
1. Do not operate the unit if abnormal sounds or motion
is detected.
2. If a hard or foreign object comes into contact with fan, do
not operate. Turn off and unplug unit.
3. Inspect for any loose or missing parts before and after
each use. If parts are loose, damaged, or missing,
contact Customer Service at 1-877-689-2838 or email
[e-mail].
4. Always use extreme caution when operating the
OxyPure or any machinery.
5. Children should be supervised to ensure that they do not
play with the appliance.
6. Do not pull, lift, drag, pick up, or carry the unit by its cord.
7. Do not block air inlet or outlet vents.
8. Do not operate the OxyPure without a filter.
DO NOT USE THE UNIT FOR OTHER THAN ITS
INTENDED USE.
Note: Put the OxyPure on a surface that is horizontal,
even, and stable. This appliance is intended for normal
household use.
NOTICE: THE FAILURE TO FOLLOW ANY OF
THE IMPORTANT SAFEGUARDS, ADDITIONAL
SAFEGUARDS, OR THE INSTRUCTIONS FOR SAFE
USE IS A MISUSE OF THE OXYPURE THAT CAN
VOID YOUR WARRANTY AND CREATE THE RISK OF
SERIOUS INJURY.

nuwavenow.com 9
ENGLISH
nuwavenow.com 9
PARTS & ACCESSORIES
To order parts head over to the Replaceable Parts section of this
manual or NuWaveNow.com.
Sensor Cover
Part #: 47106
Filter Sensor
Part #: 47107
HEPA/Activated
Carbon Combo Filter
Part #: 47108
Ozone Emission
Removal Filter
Part #: 47109
Bio-Guard™ Filter
Part #: 47110
Stainless Steel Pre-Filter
Part #: 47111
9a
9b
10
11
12
13
Air Vent
Part #: 47101
Front Display
Touchpad Panel
Part #: 47102
Handles
Odor Sensor
Base
Part #: 47104
In Flow Vent
Filter Slot Cover
Part#: 47105
Wheels
1
2
3
4
5
6
7
8
1
2
Front Back
5
9a
9b
7
68
10
11
12
13
3
4

instructions
10
INSTRUCTIONS
10
Air Filter Assembly
The OxyPure comes with four different
preassembled filters inside the unit.
When filters require replacement or
cleaning, follow all directions when
assembling.
See Cleaning & Maintenance.
Filter Functions
Air purifiers are more effective in operation when all
windows and doors are closed. Purifies extra-large rooms
up to 1,200 sq. ft.
Stainless Steel Pre-Filter
Washable and reusable for up to 20 years.
Captures and collects large particles, pollutants, and
allergens including pet hair, dander, and pollen.
Bio-Guard™ Filter
Washable and reusable for up to 20 years.
8,000V, positive and negative charges capture and trap
pollutants as small as 0.09 microns, including bacteria, mold,
viruses, smoke, pollen, and allergens.
Ozone Emission Removal Filter
Reusable for up to 20 years. Not washable.
Eliminates ozone emissions and other harmful airborne
chemicals.
HEPA/Activated Carbon Combo Filter
Lifespan, 6 months to 1 year. Not Washable.
Captures and traps pollen, allergens, industrial emissions,
VOCs including formaldehydes, household fumes, odors and
nitrogen dioxides from gas stoves and car exhausts.
The order of the filters inside the
OxyPure is as follows:
1. Stainless Steel Pre-Filter
2. Bio-Guard™Filter
3. Ozone Emission Removal Filter
4. HEPA/Activated Carbon Combo Filter
4
3
2
1
WARNING
Do not plug OxyPure in outlet or power strip
that is being used by other appliances.

nuwavenow.com 11
ENGLISH
nuwavenow.com 11
WIFI CONNECTION
The OxyPure is equipped with Wi-Fi to operate the unit
from any location. To set up and activate the Wi-Fi:
1. Download the NuWave Connect app via the Apple Store
or Google Play on your smartphone or device and open
the app.
2. Make sure your phone is connected to your network.
Open the app and follow the instructions for the
verification process. Once verification is complete,
begin adding devices. To add a device tap "+" then
select "OxyPure."
3. Next, plug the OxyPure into a compatible power outlet.
To activate Wi-Fi Pairing Mode, press and hold the power
button on the OxyPure for 2 seconds until the light next
WIFI begins to rapidly blink at a rate of about 2 blinks per
second. Once the Wi-Fi light is rapidly blinking, in the app,
tap the Finish Network Configuration button on the bottom
of the Add Device page.
4. Next, you will be prompted to either connect to your network
or confirm your existing network password.
Note: To either connect to or change networks, depending on
your phone, you may be removed from the app to complete the
network connection. Return back to the NuWave Connect app
and continue with the setup process.
5. When the OxyPure is connected to the Wi-Fi, the light
next to “WIFI” will stop flashing and stay continuously lit.
• If the OxyPure did not connect to your network, the
WIFI light will turn off. Follow steps 3-4. Make sure
to select the proper Wi-Fi network and type the
correct password.

instructions
12
INSTRUCTIONS
12
Wi-Fi LED Status
Pairing Mode & Standby Mode
Solid Light The OxyPure is paired with the
Wi-Fi and ready to be used.
Rapid Blinking Light
The OxyPure is in Pairing Mode.
The OxyPure will remain in Pairing
Mode for up to 3 minutes, or until
your device is paired.
Slow Blinking Light The OxyPure is in Standby Mode.
No Light The OxyPure’s Wi-Fi is off.
Note: If the light on your unit is blinking slower, the unit is in
WiFi Standby Mode. To exit Standby Mode and initiate the
Pairing Mode, press and hold power for 2 seconds until the
WiFi light begins blinking rapidly.
Note: The OxyPure, as with most IoT devices (computing
devices), will only connect to a 2.4GHz* network.
• To reset the OxyPure WIFI, press and hold down “Power”
for 3 seconds. Follow step 4 (from previous page). The
OxyPure can now be operated from any location.
*Most routers will broadcast in 2.4GHz. If you need help
activating 2.4GHz, contact your ISP (Internet Service Provider).
/WIFI CONNECTION

nuwavenow.com 13
ENGLISH
nuwavenow.com 13
/WIFI CONNECTION
Power ON/OFF
1. Plug in your OxyPure into an outlet. Power will be lit in
red and unit will be in standby mode.
2. Press Power. Unit will turn on and Power will be lit green.
• Press AUTO. AUTO will illuminate.
• Bars next to AIR and ODOR will illuminate, measuring
current air quality.
• The fan will start.
3. Press Power again to turn unit off.
• When you select a different mode other than the
default "AUTO" before turning off, the unit will run the
previously selected mode when it is powered back on.
AUTO
When AUTO function is used, your unit will adjust the fan
speed automatically (no time limit).
1. Press "AUTO". "AUTO" will be lit.
ULTIMATE CLEAN
When in ULTIMATE CLEAN mode, the unit will automatically
adjust to the highest or lowest fan speed based on your air
quality (no time limit).
1. Press “ULTIMATE CLEAN”. ULTIMATE CLEAN will be
lit green.
2. Press “ULTIMATE CLEAN” to turn off.
SLEEP MODE
When in Sleep Mode the LED lights will be off but the fan will
still be active. Adjust the fan speed to your preference prior
to going into Sleep Mode.
1. Manually adjust FAN SPEED.
2. Press and hold “FAN SPEED” for 2 seconds to
activate SLEEP MODE.
• Unit will run under the fan speed that was
previously selected.
3. To turn off Sleep Mode, press any button.
Note: ULTIMATE CLEAN and TURBO will work during
Sleep Mode.

instructions
14
INSTRUCTIONS
14
FAN SPEED
You can adjust from 6 different speeds (LOW to HIGH).
1. Press “FAN SPEED” to adjust.
2. To go back to the lowest level of fan speed, continue to
press “FAN SPEED” until the first bar is lit.
TIMER
Use the TIMER function to choose the duration of operation.
1. Press “TIMER”. The bar next to ½ hour will be lit.
• There are 6 preset times to choose from.
2. Press “TIMER” to increase time.
• Choose from ½ hour, 1, 2, 4, 8, or 12 hours.
• After pressing “TIMER” six times, all bars will be lit.
Press “TIMER” once more to turn TIMER off.
TURBO
The TURBO function cleans your air using the highest fan
speed at selected times.
1. Press “TURBO” to adjust from ½ hour, 1, or 2 hours.
• When the selected time has finished, TURBO will shut
off automatically.
To go back to the lowest level, continue to press “TURBO”
until bar next to ½ is lit.
AIR QUALITY INDICATOR
The OxyPure will automatically measure and display your
current air quality in the room.
• The bars will illuminate around “AIR” and “ODOR”,
indicating the current air quality. Bars will increase and
decrease, and are color coded, according to air quality.
CLEAN AND REPLACE FILTER INDICATORS
• The lights next to CLEAN FILTER 2 and REPLACE
FILTER 4 will illuminate, indicating that your filters will
need to be cleaned or replaced.
• To reset Indicators, see “Resetting the Filter and Air
Quality Indicators” in Cleaning & Maintenance.

nuwavenow.com 15
ENGLISH
nuwavenow.com 15
ULTIMATE CLEAN with TURBO
Cleans at the highest fan speed for ½ hour and will switch
to "ULTIMATE CLEAN" mode.
1. Press "ULTIMATE CLEAN". ULTIMATE CLEAN will be
lit green.
2. Press “TURBO”. Default is ½ hour and can adjust from 1
to 2 hours.
3. Press “TURBO” a fourth time to turn off.
ECO-FRIENDLY MODE
OxyPure will turn on automatically once it detects poor air
quality. The fan speed will adjust based on the quality of air.
1. Press “POWER” and “ULTIMATE CLEAN” at the same
time. POWER will be backlit yellow.
2. Press “POWER” and “ULTIMATE CLEAN” again to
turn off the Eco-Friendly Mode. “POWER” will no
longer be yellow.
TURBO with TIMER
When using TURBO with TIMER the default time is set to
2 hours.
1. Press “TIMER” to increase or decrease the time.
• Choose from ½ hour, 1, 2, 4, 8, or 12 hours.
TURBO with AUTO
Use the TURBO function to select desired time limit.
Once time is up, the unit will switch to “AUTO.”
1. Press “TURBO” to adjust from ½ hour, 1, or 2 hours.
2. Press “AUTO”.
ADVANCED FEATURES

cleaning & maintenance
16
CLEANING & MAINTENANCE
16
Your OxyPure can easily be moved from one location to
another. Just hold the OxyPure by the handles on each
side and roll the unit to the chosen location. The wheels
underneath provide extra maneuverability and mobility
whenever it's needed.
Before First Use
Wipe Top Vent and In Flow Vent with a slightly damp cloth or
paper towel. Dry thoroughly before use.
After Use
Your OxyPure should be cleaned periodically and after
excessive use to ensure proper performance and function.
To clean the outsides of the OxyPure, use a cloth or paper
towel to remove dust and other particles. For tougher
buildup, use a damp cloth or paper towel and dry thoroughly.
Cleaning the Top Vent and In Flow Vent
1. Use a soft brush to remove dust and debris.
2. If needed, use a slightly wet paper towel or damp
cloth to remove larger buildup. Do not use any harsh
abrasives or cleaning pads on Top Vent or any part of
the unit.
Cleaning the Odor Sensor Opening
The Odor Sensor is located on the side
corner of the OxyPure toward the top,
under the small grill opening.
• Keep Odor Sensor clear of dust and
debris using a soft cloth to maintain
accurate odor readings.
• DO NOT tamper with Odor Sensor or
opening over Sensor. Do not spray inside or near small grill
opening over the Odor Sensor. Doing so may cause the
Sensor to malfunction and can void your warranty.
Odor Sensor

nuwavenow.com 17
ENGLISH
nuwavenow.com 17
CAUTION
DO NOT drop any dust or residue into
the OxyPure when cleaning.
The CLEAN FILTER 2 indicator will turn blue after 3 to
6 months, indicating the filter should be cleaned for
optimal results (Bio-Guard™ Filter). The CLEAN FILTER 2
indicator will turn red after 6 months of use, indicating
the filter needs to be cleaned.
The REPLACE FILTER 4 indicator will turn red when the
filter (HEPA/Activated Carbon Combo Filter) needs to be
replaced. The filter will last 6 months to 1 year depending
on how often the unit is running in its environment.
Changing the Filters
The filters inside the filter slot need to be changed or
cleaned on schedule to help your OxyPure maintain
optimum, efficient performance.
1. Remove Filter Slot Cover in back rear of the OxyPure
using its built-in handle.
2. Slide out filters that need cleaning or replacing.
3. Allow washable filters to dry completely before you
reinstall into the unit.
• Never place a wet filter into the OxyPure.
• Filter Slot Cover must be secure or unit will not work.
4
3
2
1
The order of the filters inside the
OxyPure is as follows (bottom to top):
1. Stainless Steel Pre-Filter
(washable)
2. Bio-Guard™Filter (washable)
3. Ozone Emission Removal Filter
(not washable)
4. HEPA/Activated Carbon Combo
Filter (not washable)
• The OxyPure should be placed
on the floor when assembling
the filters.

cleaning & maintenance
18
CLEANING & MAINTENANCE
18
DO NOT WASH Ozone Emission Removal Filter or
HEPA/Activated Carbon Combo Filter. Ozone Emission
Removal Filter should be replaced every 20 years.
The HEPA/Activated Carbon Combo Filter should be
replaced 6 months to 1 year, depending on how often
the unit is running in its environment.
CAUTION
Unplug the OxyPure from the power source
before inserting or removing any parts or
attachments and before cleaning.
HEPA/Activated
Carbon Combo Filter
Ozone Emission Removal Filter
Bio-Guard™Filter
Stainless Steel Pre-Filter
Cleaning the Filters
To clean the Bio-Guard™ Filter:
1. Remove filter.
2. Spray mild degreaser, let sit for 2-3 minutes.
3. Submerge in warm water, shake, remove.
4. Repeat process until clean.
5. Rinse with warm water.
6. Dry completely before use.
The Pre-Filter collects large particles and will need to
be cleaned at least once every two months depending
on use.
1. Use a vacuum or paper towel to remove any dust or lint.
2. Clean with warm soapy water.

nuwavenow.com 19
ENGLISH
nuwavenow.com 19
3. Rinse thoroughly and remove any soap particles on
the filter.
4. Allow filter to dry completely BEFORE placing back into
OxyPure (up to 12-24 hours to dry).
Resetting the Filter and Air Quality Indicators
1. To reset the Air Quality Indicator for Filter 2, press and
hold down “TIMER” for 2 seconds until a beep is heard.
• After a filter is cleaned or replaced and indicator is
reset, the first green bar around AIR will be lit.
2. To reset the Air Quality Indicator for Filter 4, press and
hold down “TURBO” for 2 seconds until a beep is heard.
• After a filter is cleaned or replaced and indicator is
reset, the first green bar around ODOR will be lit.
Cleaning the Filter Sensor
The Filter Sensor is located on the back,
above the Filter Slot Cover.
1. Open the panel (Sensor Cover).
2. Using a dry cotton swab or small, soft
brush, gently remove any dirt or dust
from the Sensor.
3. For more buildup on Sensor, wipe
with a slightly wet cotton swab.
4. Remove any moisture with a dry
cotton swab.
• The Filter Sensor requires regular
cleaning (approx. every 3 months)
for the unit to operate efficiently.
• If your OxyPure is set up in an area with high dust
accumulation, more frequent cleaning of the Filter
Sensor is needed.
• Do not use the cotton swab on any part or area other
than the Filter Sensor.
Sensor Cover

cleaning & maintenance
20
CLEANING & MAINTENANCE
20
Cleaning Underneath Top Vent
The Top Vent of your OxyPure can be removed to clean
the surface underneath the Top Vent and the inner
vent screen.
To clean the surface underneath and inner vent screen:
1. Turn the OxyPure off and unplug the unit.
2. Lift the Top Vent using the built-in tab.
3. Using a dry or slightly wet paper towel, wipe up any dust or
accumulated particles off surface and inner vent screen.
To clean the inner wall opposite of the fan or to remove
an object that has fallen through
the inner vent:
1. After removing Top Vent, locate
the two screws closest to the end
on the inner vent near the grill
opening, underneath the main Top
Vent. DO NOT unscrew the four
outer screws.
2. Use a Phillips screwdriver to
loosen the two screws (only).
3. Lift up inner vent.
• Only a portion of the inner vent
will lift up.
4. After cleaning inner wall with
a soft cloth or paper towel,
reassemble inner vent, retightening the two screws, and
replace Top Vent.
• Make sure all parts are secure before plugging
OxyPure back in and turning on again.
Note: DO NOT unscrew the four outer screws located
toward the corners. Doing so will void your warranty.
XX
X X
Do not immerse the OxyPure in
water. Clean with a damp
sponge or cloth and wipe dry.
Make sure all parts and covers
are securely attached.

nuwavenow.com 21
ENGLISH
nuwavenow.com 21
TROUBLESHOOT GUIDE
Unit does not turn on.
1. The plug is not in the wall outlet. Plug into wall outlet.
2. “Power” on touchpad panel is not on. Press “Power”.
3. The Filter Slot Cover in the back rear is off or loose.
Make sure Filter Slot Cover is on securely.
TIMER does not work when pressed.
The unit is not reading the function selected.
Press “FAN SPEED” or “AUTO”, then press “TIMER”.
The fans are not blowing.
1. An appropriate outlet is not being used. Make sure outlet
has appropriate voltage for use.
2. The Filter Slot Cover in back rear is not properly in
place. Make sure Filter Slot Cover is on securely.
Speed of the airflow is not changing when “FAN
SPEED” is pressed.
Unit may be in manual AUTO mode. Set the OxyPure
to other operating mode on the touchpad then press
“FAN SPEED”.
Airflow out of Top Vent is weak.
Air filter(s) are dirty. Change or clean the air filters.
Unit is producing smoke or odor.
Air filter(s) are dirty. Change or clean the air filters. If
problem continues, contact Customer Service at 1-877-
689-2838 or email [e-mail].
CLEAN and REPLACE FILTER Indicators have not
reset after filter(s) has been cleaned or changed.
1. The Filter Sensor is not reading the new filter installed.
Turn unit off then turn on. Press and hold down
“TIMER” for 2 seconds until a beep is heard.
2. Turn unit off, unplug and adjust filter(s). Plug in and
turn the unit ON again.
3. The Filter Slot Cover in back rear is not securely in
place. Make sure Filter Slot Cover is on securely.
4. The Filter Sensor is dirty. Clean the Filter Sensor.
