Oki 24DX Series User manual

DIGITAL LED PRINTERS
The success of any business ultimately
comes down to controlling costs.That
includes providing each workgroup
with the tools they need to streamline
workflow and increase productivity.
Which is precisely why we’ve developed
the OKIPAGE®24DX Series of network
printers,equipped with
standard features
designed to enhance
the production
of the entire
workgroup.Their
high-speed engine
(boosted by the
powerful R4700,
120 MHz micro-
processor) and Digital
LED PrintingTechnology
deliver legendary OKI®reliability and true
600-dpi quality at a super-fast 24 pages
per minute.
The OKIPAGE 24DX Series also includes
trueAdobe® PostScript®technology—
the worldwide standard for high-quality
imaging—so users can reliably print any-
thing and everything,from simple office
memos to visually-rich presentations,
Web pages or product brochures.
Double your productivity with
duplex printing
Standard with every OKIPAGE 24DX is
its duplex (2-sided)
printing capability.
Digital LED tech-
nology allows the
OKIPAGE 24DX
Series duplexer to
print on both sides
of a sheet at full-
engine speed
(12 pages per
minute,2-sided,so
you still get 24 impressions per
minute)!The bottom line is a better
bottom line:you save time and money
on natural resources,ultimately lowering
your cost per page and total cost of own-
ership of printed communication.
A workgroup workhorse
Load it up and let it run!The OKIPAGE 24DXn
features an enormous 1160-sheet paper
capacity by including as a standard feature
a 530-sheet second paper tray for even
greater paper options.The OKIPAGE 24DX
comes standard with 630 sheets of paper
capacity.Both expand to a maximum of
1790 sheets to keep cranking out your
documents unattended.Fewer reloads
means less time attending to the printer,
and more time attending to business.And
other input options,such as the multi-
purpose feeder,provide even greater
hands-off functionality that further
enhance office productivity.
The OKIPAGE 24DX features
16 MB of memory standard,while the
OKIPAGE 24DXn includes 32 MB standard,
so they can handle even complex and
graphics-intensive documents.You can
also plug in additional memory,up to
80 MB worth.
Con igured or your business
No matter what kind of network you
have,the OKIPAGE 24DX Series is ready
to go right out of the box.It features full
cross-platform compatibility with
Windows® , MS-DOS®and Macintosh®
operating systems.
The OKIPAGE 24DX Series—advanced
features,superior performance,exceptional
reliability and the best value in its class.It’s
the ultimate network printer,and the smart
choice for any fast-paced office.
The best printer
for reliable
2-sided network
printing.
DIGITAL LED PRINTERS
Digital LED technology
allows or duplex (2-sided)
printing at ull engine speed.
Fast 24 ppm Printing
or High-Volume
Networks.
Fast 24 ppm Printing
or High-Volume
Networks.

The OKIPAGE®24DX Series: Plugged in to
the way your network works
NT SYSTEM
Networking with an NT System
Integrating the OKIPAGE 24DX Series
into your network is a snap with an
OkiLAN®internal print server.
Considering the wide range of advanced
features and time- and money-saving
benefits the OKIPAGE 24DX Series
provides,it would be a shame not to
share it over the network.
OKI®has a broad range of experience
in supporting the networking capabilities
of its printers.OkiLAN print servers
enable the high-volume performance and
reliability of the OKIPAGE 24DX Series in
a wide variety of network environments.
OKI offers a choice of internal and
external network print servers to meet
the needs of the most popular
configurations of Ethernet networks.
They also enable the high performance
and reliability of the OKIPAGE 24DX
Series to be shared in a wide variety of
network environments.
The OKIPAGE 24DXn printer
ships factory-configured with the
OkiLAN 6100e internal print server.
The OKIPAGE 24DX printer can also
be equipped with the OkiLAN 6100e,
or a variety of other OkiLAN print server
options,such as the OkiLAN 510e internal
print server or the OkiLAN 6010e
external print server.
High per ormance, lower
“cost per seat”
The OkiLAN 6100e 10/100BASE-T
Ethernet print server connects your
printer to 10BASE-T or 100BASE-T
Ethernet networks,and supports multiple
protocols so you can be assured it will
work in your network environment.
It’s built to handle the rigorous
demands of practically any
multiple-user environment—even
groups of up to 30—without
hindering printing performance.
OKIPAGE 24DXn
Which OKIPAGE 24DX Series Digital
LED Printer is right or you?
OKIPAGE 24DX: 24 ppm, duplex
printing standard
OKIPAGE 24DXn:same as 24DX, but with
OkiLAN 6100e 10/100BASE-T Ethernet
internal print server, 530-sheet 2nd paper
tray, and 32 MB o RAM standard

Not only does that automatically increase
productivity within the entire team,it also
significantly lowers your“cost per seat”.
It’s the completely sharable,affordable
network printing solution.
Place it where you need it
Another valuable asset of OkiLAN®
print servers is that they enable you to
place the OKIPAGE®24DX Series Digital
LED Printer anywhere on the network,
wherever is most convenient for those
who use it most.This means you can
centralize each printer within each
workgroup,saving valuable time and shoe
leather by minimizing the distance users
need to go to retrieve their printouts.
Easy to manage with OkiVIEW®32
OkiVIEW 32 print server configuration
software,included with OkiLAN print
servers,is a powerful and efficient config-
uration and management tool that lets
network managers take full advantage of
networked printers.
This intuitive software utility lets you
easily control,configure and monitor any
network-connected OKI®print server,
minimizing the time and hassle of
manually managing every printer on
the network.
It’s all point-and-click simple.
OkiLAN 6100e+
Internal Print Server
A high-performance internal print server for 10/100BASE-T
Ethernet networks.
• Novell®IPX/SPX with NDS®technology
• TCP/IP protocol suite with additional
software utilities for UNIX®
• Hard to find Banyan®VINES®protocol standard
• Extremely user-friendly installation and
configuration software—automatic installation
script for Windows NT®support
• Built-in Web page for easy configuration and
status through any Web browser
• Also supports DLC and Apple®
EtherTalk®protocols
OkiLAN 6010e
Pocket Print Server
Economical, external 10BASE-T print server solution for
Novell NetWare® , Windows NT®and UNIX environments.
• Full Novell IPX/SPX with NDS technology
• TCP/IP protocol support with additional software
utilities for UNIX
• Miniature external design provides flexibility and
versatility—works with virtually any printer
that has an IEEE-1284 parallel port and
built-in hardware emulation
• Built-in Web page for easy configuration
and status through any Web browser
• Economical, attractive price
OkiLAN 510e
Internal Print Server
For 10BASE2and 10BASE-T Ethernet connectivity—fulfills
hardware requirements for the majority of network users.
• Novell IPX/SPX with NDS technology
• TCP/IP protocol suite
• Hard to find NetBEUI, DEC®LAT®and DLC
come standard
• Also supports Apple EtherTalk protocols

Driving the performance of the
OKIPAGE®24DX Series is OKI®
Digital LED PrintingTechnology.
Unlike lasers,which print
through a complicated
series of rotating mir-
rors and moving
parts,the OKI
printing process
uses flashing
pin-point
beams of light
that go straight
to the image
drum. All rock-
solid state.It’s
simply a more
sensible and
efficient technology:
Digital LED Printing.
Simply SmarterThan Laser.™
Reliability to count on
Because it’s so reliable,OKI backs
your OKIPAGE 24DX Series printer
with a 1-year on-site limited
warranty on parts and labor, and
the industry’s only 5-year
LED printhead warranty.
Should you need technical
assistance,count on
OKIcare™service and
support.Simply call
our customer
support hotline1:
1-800-OKI-DATA
(800-654-3282)
and speak to a
live service
representative,
7 days a week,
24 hours a day,
365 days a year.
For more information on the
OKIPAGE 24DX Series or other
OKI printers,visit ourWeb site at
www.okidata.com.Or,for the
OKI dealer nearest you,call
1-800-OKI-DATA.
Technology-driven reliability.
Industry-leading support.
OKIPAGE®24DX Series
DIGITAL LED PRINTERS
Technology
Print Speed: 24 pages per minute
Time to First Page: 6.7 seconds
Print Resolution: 600 dpi with 600 x1200 graphics
Standard RA emory: 16 MB (OKIPAGE 24DX)
32 MB (OKIPAGE 24DXn)
aximum RA emory: 80 MB
CPU: MIPS®R4700, 120 MHz, 32 bit
Compatibility: Windows®2000, 98, 95, 3.1x, Windows NT®4.0,
MS-DOS®and most other operating systems
Emulations: PCL®6 Adobe®PostScript®Level 2
IBM®ProPrinter®III XL and Epson®FX™(9-pin compatible)
Duty Cycle: Up to 65,000 pages per month maximum
Interfaces
Standard: IEEE-1284 compliant bi-directional parallel port
Internal Serial Interface RS232-C
Networking
Print Server: 10/100BASE-T Ethernet internal print server optional
on OKIPAGE 24DX, standard in OKIPAGE 24DXn OkiLAN®6010e
external print server and OkiLAN 510e internal print server,
both optional
Paper Handling
Standard Paper Input: 630 sheets (530-sheet letter/legal/universal
tray 100-sheet manual feed) standard in OKIPAGE 24DX
1160 standard in OKIPAGE 24DXn
aximum Paper Input: 1790 sheets
Paper Types: Single sheets, Envelopes, Mailing label stock,
Overhead transparencies
Paper Size: 3.4" x 5.5" minimum to 8.5" x 14" maximum
Standard Paper Output: 250 sheets, face down
Alternate Paper Output: 100 sheets, face up, straight paper path
Standard Paper Weight: 16–28 lb. main tray 16–36 lb. multifeeder
16–28 lb. 2nd/3rd tray duplex (2-sided) 16–28 lb.
Resident Fonts
Scalable Fonts: 35 PCL scalable fonts 10 TrueType®scalable fonts
37 PostScript fonts
Bitmap Fonts/Typefaces: Line printer, USPS POSTNET bar codes
OCR-A OCR-B
Environmental (Printer only)
Size (WxDxH): OKIPAGE 24DX: 14.4" x 18.2" x 13.0"
(36.6 cm x 46.2 cm x 33.1 cm)
Weight: OKIPAGE 24DX: 47 lbs. (21.3 kg)
Power: 120 VAC 50/60 Hz, 230 VAC 50/60 Hz
Warranty
Printer: 1-year limited on-site warranty on parts and labor 5-year
limited LED printhead warranty
Ordering Information (Part Number)
Printer:
OKIPAGE 24DX, 120V (Multi-lingual) 62413603
OKIPAGE 24DX, 230V (Multi-lingual) 62413602
OKIPAGE 24DXn, 120V (Multi-lingual) 62413606
OKIPAGE 24DXn, 230V (Multi-lingual) 62413605
Supplies:
Toner Cartridge: Average Life—
6,000 pages at 5% density 40468801
Image Drum: Average life—
30,000 pages continuous printing 40468701
IEEE-1284 Bi-directional Parallel I/F Cable 70000803
Options:
OkiLAN 6100e+ Internal Print Server 70035501
Infrared Transceiver for OkiLAN 6100e+ 70036501
OkiLAN®6010e External Print Server 70034401
OkiLAN 510e Internal Print Server 70032801
2nd and 3rd Paper Tray Mechanism (530 Sheet) 40346401
Multi-Purpose Feeder 40352801
16 MB SIMM (Memory Expansion) 70035001
32 MB SIMM (Memory Expansion) 70035101
4MB Flash SIMM 70035701
8MB Flash SIMM 70035801
1Available in U.S.A. and Canada only.
All specifications subject to change without notice.
©1999 Oki Data Americas, Inc. OKI, OkiLAN, OkiVIEW Reg. T.M., M.D., M.R., OKIPAGE Reg. T.M., OKIcare, “People
to People Technology” and design T.M., Oki Electric Industry Co., Ltd. 7-Day/24-Hour logo, On-Site Warranty logo,
“Digital LED Printing. Simply Smarter Than Laser.” T.M., Oki Data Americas, Inc. Windows, Windows NT, MS-DOS
Reg. T.M., Microsoft Corp. Novell, NDS Reg. T.M., Novell Corp. Banyan, VINES Reg. T.M., Banyan Systems Inc.
Apple, Macintosh, EtherTalk, TrueType Reg. T.M., Apple Computer Inc. MIPS Reg. T.M., Silicon Graphics Inc. PCL
Reg. T.M., Hewlett-Packard Company Adobe, PostScript Reg. T.M., Adobe Systems Inc. IBM, ProPrinter Reg. T.M.,
International Business Machines Corp. Epson Reg. T.M., Seiko Epson Corp. FX T.M., Epson America, Inc. DEC, LAT
Reg. T.M., Digital Equipment Corp. UNIX Reg. T.M., Unixsystems Laboratories, Inc.
Printed in the U.S.
To Contact Oki Data Americas, Inc.:
In USA: 2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: [phone]
In Canada: 2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: [phone]
Fax: [phone]
In Latin America and exico:
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: [phone]
Fax: [phone]
Web Site: www.okidata.com
The rock-solid OKI Digital LED
printhead utilizes a stationary array
o pulsing light-emitting diodes (detail)
to create high-resolution
text and graphics.
DIGITAL LED PRINTERS
4-digit Y2K compliant
S 10618/0300
