Omron F3E User manual

1F3E Multibeam sensor
Ultra-flat multi-beam sensor for elevators
F3E
• Ultra-flat 9 mm shape for easy design-in in
elevator constructions
• Highest ambient light immunity
(200,000 lux) for installations with direct
sunlight exposition
• Triple crossing resolution maintained
close to zero distance
• Robust aluminum housing
• Ray failure toleration
• Test input
• Built-in amplifier
(operation with 10-30 VDC)
• Fulfills requirements of EN81-70
STRAC
K
LIFT AUTOMATION
Designed & manufactured
by
Ordering Information
Features
High reliability and flexibility:
Test input: Function of multi-beam sensor can be tested by transmitter cut off on test signal. A subsequent receiver cut off can be
monitored by control unit.
Ray failure toleration: As soon as one channel is not switching for more than 60 seconds, the F3E identifies a defect and deac-
tivates this channel. The sensor then functions normally again showing the defect channel by a red error LED.
Easy parameterization: By test input of transmitter a parameterization of L-ON/D-ON operation and shading of LED areas is pos-
sible. No complicated programming or remote control needed
Potential free output: The F3E provides a wear-free electronic relay output for highest connection flexibility and life-time.
Pitch Detection area channels Number of
optical axis Connection Output Model number
120 mm 1800 mm 16 46 5 m pre-wired potential-
free output
F3E-16-T1 5M
M8 Connector (4-pin) F3E-16-T6
40 mm 1800 mm 46 136 5 m pre-wired F3E-46-T1 5M
M8 Connector (4-pin) F3E-46-T6

2F3E Multibeam sensor
Rating/Specifications
ItemType F3E-16-T[..] F3E-46-T[..]
Rated sensing distance 0-5 m
Number LEDs 16 46
Number of optical axis 46 136
Resolution 120 mm 40 mm
Vertical detection area1
1other sizes available on request
20-1820 mm
Response time max. 110ms (signal interruption)
Light source (wave length) Infrared LED (880 nm)
Power supply voltage 10-30 VDC
Current consumption max. 120 mA / pair max. 240 mA / pair
Control output Wearless potential free output, 35 V AC/DC max., 150mA max. at 20°C, 100mA max.
at 60°C, D-ON (parameterization by emitter test input), max. leakage at open contact
0,001mA, contact resistance 4/12 Ohm
Test input / light emission stop function 110 ms max. response time
Ambient light immunity 2
2Measured at angle of 20°
200.000 lux
Ambient temperature -20…+60°C (operation) 3, -40…+70 (storage)
3No icing and condensation
EMC conformity/standards 73/23/EWG; 89/336/EWG; 95/16/EG; EN81-1; EN81-2; EN12015; EN12016;
EN61000-6-x
Protective degree IP54
Connection methods Pre-wire type (5 m PVC cable), M8-4-PIN
Indicator LEDs Emitter: power indicator (yellow);
Receiver: output indicator (yellow), output indicator (red)
Error status indication Red LED blinking: unstable operation, contamination, max. exceeding sensing dis-
tance
Red LED ON + yellow LED ON: beam channel defect
Dimension12070x40,7x9 mm 2000x40,7x9 mm
Weight 880g (connector version), 1040g (cable version)
Material Case Aluminum
Cable PVC
A = current scanning radius
A/2
A/3A/3
protected area
B
C
C
D
High resolution is realized by triple crossing of light
beams.
Automatic sensitivity control ensures steady and op-
timum light power. Even when sensors are operated
in dirty environment or at highest distances, no ad-
justment is necessary. Sensitivity control ensures
that the high resolution is maintained at small dis-
tances close to "zero".
Min. size of recognized objects:
Pitch B D C
120 mm 125 mm 65 mm 45 mm
40 mm 45 mm 35 mm 18 mm

3F3E Multibeam sensor
Output circuits
Dimensions
Mounting strap fixation
Status Warning
(yellow)
1
2
3
4
10 to 30 V DC
max. 250 mA /
35 V AC/DC
Load
brown
white
black
blue
(red)
Main
circuit
potential
free
ILoad
alternatively
Receiver
1
2
3
4
Connector PIN Arrangement
Power indicator
(green)
1
2
3
4
10 to 30 V DC
0 V
brown
white
black (not used)
blue
Main
circuit
alternatively
test input and programming
Transmitter
1
2
3
4
Connector PIN Arrangement
a1a2a3 a4a5
h
LED red
light rays
LED yellow
9
8
7
6
5
4
3
2
1
5.5
ø 4.5
Dimension F3E-16… F3E-46…
a5 25 mm 25 mm
a4 690 mm 650 mm
a3 640 mm 650 mm
a2 690 mm 650 mm
a1 25 mm 25 mm
h 2070 mm 2000 mm
1.5
8
9
40.75

4F3E Multibeam sensor
Accessories
Cable connectors
Note: Complete portfolio of connector types see OMRON Accessory Datasheet
F3E-Accessories
Type Size Cable Material Poles Length (m) LED Nut Order reference
slim line straight M8 PVC 4 5 no brass XS3F-M421-405-A
slim line angled M8 PVC 4 5 no brass XS3F-M422-405-A
robotic cable straight M8 PVC 4 5 no brass XS3F-M421-405-R
robotic cable angled M8 PVC 4 5 no brass XS3F-M422-405-R
Item Description Order reference
F3E-Installation Kit S Installation kit for stationary mounting on lift doors F3E-IK-S
F3E-Installation Kit M Installation kit for mounting to mobile doors panels F3E-IK-M
F3E-Power supply Power supply NTR 18/03 for operation with 240VAC/24DC,
buzzer function
F3E-PS1

5F3E Multibeam sensor
Installation Kit S
Installation Kit M
cone
M5x16
M4x10
M4x12
M4x12
M6x16
upper
mounting
angle
vertical
mounting
angle
sensor unit with
mounting strap
fixation
vertical
mounting angle lower
mounting
angle
sensor unit with
mounting strap
fixation
The upper mounting angle isscrewed
to the top of the door operator.
The lower mounting angle isscrewed
to the underside of the door sill.
Then the vertical mounting angle
- with the sensor unit already screwed onto it -
isinserted with itsconical end into the slot
in the lower mounting angle.
sensor unit with
strap fixation
mounting clamps
door panel

6F3E Multibeam sensor
Precautions
Power Supply Voltage and
Output Load Power Supply Voltage
Do not connect an AC power supply to the Sensor. If AC pow-
er (100 VAC or more) is supplied to the Sensor, it may ex-
plode or burn. Make sure that the power supply to the Sensor
is within the rated voltage range. If a voltage exceeding the
rated voltage range is supplied to the Sensor, it may explode
or burn.
Operating Environment
Do not use the Sensor in locations with explosive or flamma-
ble gas. Make sure that the product is operated in accordance
with IP54 standards.
Do not subject the multi-beam sensor to excessive shock
when mounting.
When you use the multi-beam sensor in the vicinity of an in-
verter motor, be sure to connect the protective earth ground
wire of the motor to earth. Failure to ground the motor may re-
sult in malfunction of the sensor.
Mounting the Sensor
Do not strike the Photoelectric Sensor with a hammer or any
other tool during the installation of the Sensor.
Cleaning
Never use paint thinners or other organic solvents to clean the
surface of the product
M8 Connector
Always turn OFF the power supply to the Sensor before con-
necting or disconnecting the metal connector. Hold the con-
nector cover to connect or disconnect it.
Secure the connector cover by hand. Do not use pliers; other-
wise the connector may be damaged.
If the connector is not connected securely, it may be discon-
nected by vibration or the proper degree of protection of the
Sensor may not be maintained.
@WARNING
The F3E multi-beam photoelectric sensor is not a
safety component for ensuring the safety of people
which is defined in EC directive (2006/42/EC) or by
any other regulations or standards.
In the interest of product improvement, specifications are subject to change without notice.Cat. No. E48E-EN-01A
