5&7.5HP
DirectDriveCyclonic
DustCollectors
OneidaAirSystems,Inc.1001 WestFayetteSt., Syracuse,N.Y.13204
Phone [phone] Fax[phone] www.oneida-air.com
Owner’sManual

ThankYou forChoosing anOneidaAirSystemsProduct!
OAS manufacturesand sellsdustcollection equipmentonly.Ourqualified techniciansand
salesstaff areavailable7:30am-6:00pmESTMon.-Thur.and 7:30am-5:00pmESTFri.to
answeranyquestionsconcerning OAS productsand dustcollection.Call forductworkdesign
and ductworkquotes,including systempricing and shipping cost.
TableofContents
Page
ReadtheentireOwner’sManualbeforeinstalling oroperating system!
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
IX.
X.
XI.
XII.
XIII.
XIV.
2
3
4
5
6
7-8
8
9
10
11
12
13
14
15
SystemStart-UpInformation
DirectDriveConfigurations
GeneralSpecifications&Fan PerformanceCurve
Dimensions
Stand Assembly
GeneralAssemblyInstructions
Fan /BlowerMaintenance
ExternalFilterBoxAssembly
FilterMaintenance
WireDiagram
Accessories
Troubleshooting
FireHazards-Read BeforeInstalling System
Termsand Conditions1
Proudly
Madein
theU.S.A.
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual

2
I.SystemStart-UpInformation
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
1.Read the installation andmaintenanceinstructionsaswell astherecommended
safetypracticesinthismanual.
2.Install Ductworkcompletely:
A.)Sealductworkwithsiliconesealantorducttape.
B.)HaveDustBininplaceandsealed beforerunningDustCollector.
3.WireFan /Bloweraccording towirediagramonpg.11inthisowner’smanual.
4.Havealicensedelectriciancheckcurrentdrawonmotorwithall gatesopen.Current
drawshouldnotexceedmaximummotoramperage.(OAS isnotresponsiblefor
destroyedmotors.)
Caution
The DirectDriveFan /Blowermakesthe systemtop heavy!
Useextremecarewhen setting the unitup!
Warning
Check amperage drawduring operation withall blastgates
open.Makecertainamperage isnotoutside operating limit
indicated on motorplate!
Warning
If amperage istoo high -shutdownimmediately!
(See troubleshooting section.)
Warning
DonotoperateFan /Blowerunless Cyclone and DustBin
areinplace.Motorwill overheat!

II.5&7.5hpDirectDriveConfigurations
1.NoFilter-VentOutside-
1.NoFilter
Caution:
If exhaustairisvented outside you mustprovide makeup /returnair.
Fluegases(carbon monoxide)can be drawnintotheshop fromfurnaces,
waterheatersorotherappliances.
2.External
Cartridge
Filters
3.External
Tube
Filter
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
PlenumAssembly
Tube
Filters
5Gal.Buckets-Collectsfine dust
PlenumAssembly
Removable
DustContainersRemovable
Chip/Dust
Bin
Pleated
Cartridge
Filters
3

III.GeneralSpecifications&FanPerformanceCurves
4
7.5hp FanPerformance Curve
5hp FanPerformance Curve
O.A.S.2002
c
Physicaland ElectricalDatafor5and 7.5hp DirectDrive Systems.
5hp 1220 maxcfm-2250 cfmw/typicalductwork
7.5hp 2900 maxcfm-2500 cfmw/typicalductwork
SystemPerformance
Heightw/55 Gal.Drum:132”
Footprint: 8.5’x3’
Fan Wheeldiameter:16”AirFoil design
Cyclone Inlet: 10”
SystemDimensions
TEFC60 HzMotor-SinglePhase
Insulation Class:F4
Voltage:230
Amperage:19.8
Made inU.S.A.
IntegralFanBlower-5hp
TEFC60 HzMotor-Three Phase
Insulation Class:F4
Voltage:208 -230 /460
Amperage:19.6-18.4/9.2
Made inU.S.A.
IntegralFanBlower-7.5hp
Standard:8Tube Filters-5hp,10 Tube Filters-7.5hp
Needlefelted polyesterfiltermediaBIAZHI/487 test-
Rated G
Captures99%oftestmaterialover20 microns
Captures99.5%oftestmaterialbetween 0.2-2.0microns
@11 fpmfacevelocity
TubeFilterBags
2Pleated Cartridges-260 sq.ft.
Spun Bonded polyesterBIAZH1/487 test-Rated C
Captures99.99%oftestmaterialover20 microns
Captures99.9%oftestmaterialbetween0.2-2.0microns
@11fpm
ExternalCartridgeFilters(2)
55 Gal.SteelDrums
Large dustbinsavailable
DustBin
Angleiron stand forfree-standing unit
Silencersavailable
MagneticMotorStarters
Options
5-7.5HPDirectDriveOwner’sManual
0 2 4 6 8 10 12
StaticPressure(In-H2O)
CFM
-Fan Curve
14 16 18
3000
2500
2000
1500
1000
500
0
3500
4000
3350
2875
2400 2025
1725
1400 1100
760
5hp System-2000 CFM@8”StaticPressure
0 2 4 6 8 10 12
StaticPressure(In-H2O)
CFM
-Fan Curve
14 16 18
3000
2500
2000
1500
1000
500
0
3500
4000
3500
3100
2725
2440 2100
1875 1590
7.5hp System-2700 CFM@8”StaticPressure

IV.Dimensions
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual5
14 1/2”
122 1/8”
-with8’Bags
1.5”
73/4”
30”
39 1/4”
62”
73 1/8”
12”
12”
32 1/8”
O.D.of
Mounting
Ring
69.875”
241/4”
Bolt
Holes
30 3/8”
10.031”
I.D.
7.64”
I.D.
1.25”
Flange
TubeFilters-Heightfor8’bags.Otherheightsavailable.
131”
w/55 gal.
steeldrum
105”
Note:Overall heightdimensionsarew/55 gal.drum.
122.125”
w/55 gal.
steeldrum
1.5”
102”
36”
TopView
116 1/8”
43”

6O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
V.AngleIronStand
CrossBracefor
CycloneAngleRing
tositon
1.Choosethesystemorientation,plenumcanbe ontherightortheleft ofthecyclone.
Bolttogetherthe standusing thecrossbarsand3/8”x1”bolts.Note:thecross baron
the cyclone stand goesintheback sothatthedustbincanslide out.

VI.AssemblyInstructions
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
Cyclone
Barrel
Cyclone
Barrel
AirInlet
Fan /Blower
1.
1.Orientthe blowerhousing tomatchthe stand
configuration andthe desired angleforthecyclone inlet.
Boltthe fan /blowertothe cyclone barrelusing the
hardwaretaped on the motor.
Boltsarealreadywelded on Fan/Blowerunit. Putabead
ofsilicone around top holeincyclone barrel,then put
boltsthrough holesinbarrel.Putflatwasheron bolt.
then lock washer,then hexnut.
Cyclone
Cone
2.
3.
2.Boltthefan housing and cyclone barreltothe cyclone
cone using hardwaretaped tocyclone barrel.Note:the
fan /blowerand the cyclone barrelareveryheavy.The
systemwill betop heavy.Onemethodistolaythe stand
down,then boltthe cyclone withthe fan /blowertothe
stand.The iron ring will be on top ofthe cross barsof
the stand.Putbead ofsilicone around inside edge of
flange on the cyclone cone.Then putboltthrough flat
washer,then boltthrough holesinbothflanges,thenput
lock washeron bolt, then attachhexnut.
Cyclone Inletand Fan /Blowerareindependent.
Filterscan be tothe rightorleft ofthe unit.
3.Tipthe fan housing and cone upright. The systemis
verytop heavy.Placeplenumon top ofthe plenum
stand.
4.Bolttheplenumtothefan housing outlet(rectangular).
Clampthe cartridgestothe plenum.Clampthe dust
binstothe bottomofthe cartridge filters.
Plenum
Stand
Cartridge
Filters
DustBins
Outlet
Air
Outlet
Continued on nextpage.
7
Silicone
Bead
Silicone
Bead
Bolt
FlatWasher
Flange
LockWasher
HexNut
16 ea.3/8”FlatWashers,Lock Washersand HexNuts
16 ea.3/8”FlatWashers,
Lock Washers,HexNuts
and 3/8x1”Bolts
Fan/BlowerisshippedstrappedtoCycloneBarrel. ItisNOT
attachedtotheunit.You mustboltthemtogether.Followthe
instructionsbelow.

VI.AssemblyInstructions(Cont.)
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
8
5.Attachflexhosetobottomofcollectorand tolidof
dustbin.Securelyfasten hoseclamps.Theremustbe
an airtightsealbetween the collectorand dustbin.
6.Makesurethedustbinlidsitssecurelyand the rubber
gasketon the binlidisinplaceon the barrel.Maintain
anairtightsealbetween cycloneanddustbintoprevent
motorfromoverloading.
IMPORTANT:
Donotoperatethe collectoruntil the dustbinisinplaceand
the connectorisairtightormotordamage couldresult!
Stayclearoffan exhaustwhilecollectorisoperating.
Collector
HoseClamp
HoseClamp
FlexHose
DustBin
4.
7.Attachthe ductworkfromthe woodworking machinestothe inletofthe collector.
8.Onexternalfiltermodels,attachthe PlenumAssemblyorconnecttoyourownplenumbox.
9.AttachfeetofAngleIron Stand tofloor.
Note:AssemblywithTube Filters-NoteplenumheightrequirementsofTube Filters-6’tubes-8’plenum/8’tubes-
10’plenum/10’tubes-12’plenum.Adjustsystemheightaccordingly.
VII.Fan/BlowerMaintenance
Ahigh pressureblowerrequiresacertainamountofresistancewhichwill preventmotor
overamperage.
Makesurepowersourcematcheswirevoltage configurations.
Check setscrewand keyinfan wheel,makesurefan wheelissecure.Fan blowershould
notvibrate.
1.Electrical-Failuretofollowinstructionsand safeelectricalprocedurescouldresultinseriousinjuryordeath.
Disconnectall powerand discharge all capacitorsbeforeservicing.Install and ground perlocaland national
codes.Consultalicensed electrician withquestionsorifrepairsarerequired.
ElectricalConnections-
A.)All wiring,fusing,and grounding mustcomplywithNationalElectricalCodesand localcodes.
B.)Todetermine properrotation and voltage connections,refertothe WireDiagramofthismanual.
C.)Usethepropersizeofline currentprotection and motorcontrolsasrequired bythe NationalElectricalCode
and localcodes.Recommended useis125%offull load ampsasshownon the nameplateformotorswith
40 degreesCelsiusambientand aservicefactorover1.0.Recommended useis115%offull load ampsas
shownon the nameplateforall othermotors.Donotuseprotection withlargercapacitiesthan recommended.
Three phasemotorsmusthaveall three phasesprotected.
2.Cleanliness -Keep boththe interiorand exteriorofthe motorfree fromdirt, water,oil,and grease.
3.Safety-Motorsshouldbe installed,protected and fused inaccordancewithlatestissue ofNationalElectrical
Code,NEMAStandardPublication No.MG2and localcodes.Rotating partssuchaspulleys,coupling,external
fans,and unusualshaft extensionsshouldbe permanentlyguarded.Keep handsand clothing awayfrom
moving parts.Electricalrepairsshouldbe made bytrained,qualified personnelonly.
4.Service -Notice -If lubrication instructionsareshownon the motornameplate,theywill supercede this
generalinstruction.
Warning:Rotating Fan Blades.Keep ObjectsClearofInletand Outlet.

5gallon buckets12”high (Notsupplied with
system).Can be purchased,PartNo.
SDS050000orrecycledjointcompoundbuckets
orfood storage containerscan be used.
VIII.ExternalFilterBagAssemblyPlenumBox
22 gauge galv.
Tube Filters
16oz.NeedleFelted Polyester
1Micron Filtration
HoseClamps
Part#-ACB120000
HoseClamps
Part#-ACB120000
Ring Thimble
Part#-FAZ000000
6’long -Part#FTS060000
8’long -Part#FTS080000*
10’long -Part#FTS100000
*Note:Alsoavailablewithzipper
bottomsfor9’ceilings.
1.Connectthe plenumtothe fan/bloweroutletwith
the boltsprovided.Band clamptube filterstothe
Ring Thimbleson the bottomofthe plenumand to
the topsofthe 5gal.buckets.
(Checkmounting height-Matchtobag heights)
Buildyourownplenum
Plenumboxcan be constructed ofplywood ormetal.
OneidaAirSystemssells22 gauge galv.plenumboxes.
The filtermediumisa16 ouncepolyesterfeltwhichhas
been singed inside tohelpreleasecaked dust.
Forthe tube stylefilters,a12”dia.ring thimble(Part#
FAZ000000)isneeded foreachfilter.The plenumboxand
the ring thimblesaresuspended abovethe floorataheight
thatwill allowfora5gallon plasticbucketand tube filterto
fitproperlyunderneath.
Awell sealed plywood boxwill makeagood plenumfor
airdistribution through the tube filters.Useplywood forthe
plenums.Cut12”dia.holesinthebottomofthebox(spaced
2-3”apart),sothatthe ring thimblesfitsnugly.The rings
shouldnotbe abletoslide through the holes.Bend Ring
Thimbletabsthen applyductsealantorcaulkaround the
edgeofthe ring thimble.Usesheetmetalscrewstosecure.
Besuretoremoveanysharpedgesfromthe bucketor
ring thimblethatmayabrade the filter.Slide the filterover
the thimblepastthe raised bead.Securewithabandclamp.
Slide thebottomofthe filteroverafivegallon plasticbucket.
Securewithaband clamporstrong bungee (shockcord).
Besurefilterisnotlooseormovingaround whenthesystem
ison.Thiscouldlead towearon the filter.
Withthe useofacyclone pre-separator,the bucketswill
notneed emptying veryoften,butdo need tobe checked
occasionally.Simplylift the bucket, the weightwill indicate
howfull the buckethasbecome.
12”12”12”
2”
2”
Air
Inlet
Plenumboxheight-12”min.Use3/8”orthickerplywood.
Sealplenumboxwithsilicone.
OASGalvanizedPlenumBox
Note:Plenumholeconfigurationvaries.The numberof
holesmatchesthe numberoffilters.
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual9

10
IX.FilterMaintenance
5-7.5HPDirectDriveOwner’sManualO.A.S.2002
c
ExternalFilterCartridgeCleaning Intervals
Caution:Finedustcollectedinfilterishazardous
toyourhealth!Donotbreathe!
Whenunitisturnedoff,usecompressed airtoblowdustoff from
exterioroffilter.Holdnozzleatleast8”awayfromfilterpleats*.
Donotremovebottomdustpan beforeorduring the blow-off
process!Letdustsettleintodustpan.Unclipand dumpoutdust.
Filterremovalisnotrequired.You can alsorun yourfingers
around the filterpleatstoknock materialdown.
*WARNING:Aclose,directblastwiththe compressed airnozzle
too closetofilter,maydamage filtermedia.Always wearsafety
glasseswhileblowing off filter.
ExternalFilterBags
Tap orgentlyshakefilterperiodicallyand letdustsettleintothe
5gal.buckets.Lift bucketstodetermine howfull bucketsare.
Emptydustfrombuckets.
Donot
removefabric
strapsaround
pleated
cartridge.

IX.SingleandThree PhaseWireDiagram
Use wiring diagramon motorplateifdifferentfrombelow.
-Electricallyinsulateall connections.
-Forcounter-clockwise rotation,looking fromtop ofmotordown.
5hp SinglePhase
Leeson Motor/230v /19.8amps/TEFC/CFace /3500 rpm
7.5hp Three Phase
Leeson Motor/208 -230/460v /19.6-18.4/9.2amps/TEFC/CFace
/3480 rpm
L1
L2
L3
T4
T5
T6Tietogether
Wiring shouldalways bedonebyalicensedelectrician!
Ground:Connecthouseground
wiretogreen chassisscrewin
motorwirehousing box.
Motor
Wire
Box
Green
Chassis
Screw
11
Top View
Outlet
Inlet
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
T1
T8
T4
T5
Tietogetherand insulatewith
awirenut(do NOTconnectto
anyhousewiring)
PowerLine 2*
P1PowerLine 1*
*PowerLine 1and 2areinterchangeable
208 /230 Volts
T1&T7
T2&T8
T3&T9
L1
L2
L3
T7&T4
T8&T5
T9&T6
Tietogether
460 Volts
T1
T2
T3
Tietogether
Tietogether
ToLine toreverserotationinterchangeanytwolineleads
Check rotation afterwiring.
Wireforcounter-clockwiserotation.

X.Accessories
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
DustBinOptions-(MustOrderCustomMountingStand.)
2.Hoppers-
Largecapacityhoppersfrom.5cu.yd.to3cu.yd.
3/16”reinforcingangleforaddedsupport-3/16”platebodyis
100%continuouslyMIGwelded on inside -3/8”rearcross brace
angle(not3/16”) -three3”basechannel-All anglesarestructural
notformed.
3.AirLocks -
Rotaryairlocksprovidean alternativetoanairtightdustbin
forlargervolumecapacityandless maintenance.
Example-A10”airlockwill drop1.85cu.ft. /rev.ofmaterial.
1.MultipleDrums-
CustomordertheSystemMounting Standformultipledrums
orhoppers.Standwidthswillvarydependingondustcontainer.
MagneticMotorStarters-The 5and 7.5hp directdrivedust
collectorsdonotcomewiredorwithanon/offswitch.Because
ofthevoltageand amperagerequirementsofthesystem,an
industrialswitchmustbe used.
OAS offersSquare“D”Full VoltageNon-Reversingacross
theLine Starters,NemaType 1EnclosurewithStart/Stopin
cover,andclass10overload.Industrialswitchescanalsobe
purchasedthrough yourlocalelectrician.Due tovarying
electricalcodes,OAScannotspecifyexactwiringrequirements.
When wiring the collectoryou shouldalways hirealicensed
electrician.
Bindicator-Provideslevelsensing fordrybulksolids.The
Bindicatoroperatesbyusing a1rpmsynchronousmotorto
rotateapaddle.
Whenpaddlerotationisimpededbymaterialsurrounding it,
the motorisde-energized and triggersaSPDTsnapswitch.
Thesnap switchcanbeused inconjunctionwithamotor
startertoturnequipmentoff orprovidealarmfunctions.
12

XII.Troubleshooting
MotorOverheating
The motor’sinternalcircuitbreakerwill tripifthe motorisoverheating.
Airleaksbetween the collectorand dustbin
-The lidofthe dustbinand the cyclone mustbe inplaceand sealed when operating the dustcollector.
-Makesureflexhoseisnottornand the hoseclampsaretight.
-Check drumlid;covershouldhaveafoamsealand be well seated.
-Check forholesorleaks inthe dustbinbarrel.
Caused By:
Motornotproperlywired.Check wireconnections.
-Check motorrotation -See wirediagram
Checkbreakerbox.Makesurepowersupplyis110Vifwiring 110Vor220Vifwiring for220V.
PoorDustPick-UpatWoodworking Machines
Caused By:
Checklengthofductrunsand ductdiameterscompared toductworkdesign guideline.
Makesureall ductworkissealed.Large airlosseswill occureven through small cracks inthe
ductwork.Usesilicone,ducttape orductmasticcompound asasealant.
Checkforairleaksbetween collectorand dustbin.
Closeall unused blastgatesatyourwoodworking machines.
Examine hood design forweaknessesaccording tothe ductworkguide.
Checkforarestricted pipe,too small ahood portortoo small abranchline.See branchline
diameterchartinductworkguide.
Besurethatyourfiltersareclean.See filtercleaning directions.
FilterClogging
Caused By:
Large chipsclogging the filter
-Check foraleakinthe dustbin,flexcoupling orlid.Checkforsplitortornflexcoupling.(See
also:MotorOverheating Section above)
-Makesuredustbinhasnotoverfilled.Dustbinshouldbe emptied beforethe dustreaches
top ofthe container.
-Interruption ofairflow,suchasvacuuming chipswithaflexhoseconnection,will increase
filtermaintenance.
-Minimum4”diameterpickup attoollocation.Less than 4”will restrictairflowintocollectorand
will increasefiltermaintenance.
Note:Ifyou continuetoexperience difficultywithyourcollectorcall OneidaAirSystemsat
1-800-732-4065 forassistance.
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
13

XIII.FireHazards-ReadBeforeInstalling and Operating
Donotuse thisproducttocollectothertypes ofdustorflammablevapors.
Fireorexplosion may occur!
Nevercollectsparks fromabenchgrinderintoawood dustcollector.
Neverintroducesparks orsourcesofignition intothe dustcollector.
Personnelshouldkeep atleast20 feetawayfromunit.
Check dustbinfrequentlyand beforeleaving the shop forsmoldering material.
Keep portableFireExtinguishershandy.
The ABCtype (drychemical)isgenerallyagood choiceforsmall wood shops.
Additionalinformation on portableextinguisherscan be found inNFPA10 (StandardforPortableFireExtinguishers).
Beespeciallycarefulwithsanding units.Theycan produceconcentrationsofdustinthe combustiblerange.Make
certainenough airvolumeisatthe suction pointtocaptureall the particulategenerated.
Thishigh airvolumewill dilutethe mixturebelowthe lowerlimitofflammability.Becarefulnottogeneratesparks into
the sanding dust.
Emptydustbinand clean filteroften,especiallywhen sanding.
Don’toverload woodworking equipment, especiallysanders.Excessivefrictionalheatcan spontaneouslyignitedust.
Sparks can be generated inseveralways:
High-speed sandersand abrasiveplanersmaystrikeforeign material
Sawsand edgersmaystrikeforeign materialand createared hotmetalfragment.
Knotsinhardwood can createfrictionalsparks.
Trampmetalwhen drawnintothe collectorcan sparkagainstductwork.
Check wood stock foroldnailsand screwswhichcan createred hotmetalfragments.
Avoidusing excessivelylarge wood wastestorage bins.
Always check storage binsforsmoldering materialbeforeleaving forthe day.
Electricallyground all equipmentand ducting.Staticsparks can ignitewood dust. (Avoidusing PVCdrainpipe)
Don’tallowaccumulation oflayersoffine duston horizontalsurfaces.(Especiallyoverhead lights,electricalboxes,
and fusepanelswhichcan ignitedust)
OneidaCollectorsaredesignedforWOODDUSTonly!!
Wood shaping and cutting processesgeneratewood chips,shavings,and dust. Thesematerialsareconsidered
combustible.Airborne wood dustbelow420 micronsinsize(.017 ofan inch)incertainconcentration rangeswhen
ignited can deflagrate(burnquickly).
Anignition sourcesuchasaspark,orember,can igniteadustmixtureresulting inan expanding flamefront, which
can causean explosion iftightlycontained.Adisturbancethatraisesacloud ofaccumulated fine dustcan raiseadditional
dustclouds,whichcan causeaseriesofexplosionsthatcan levelan entirebuilding.Until thistype offirehasbeen
witnessed,itisdifficulttobelievethe devastation.Thistype offireisrarebutworthsafeguarding against.
The bestwaytoavoidawood shop fireistokeep the shop clean.Ashop ankledeep industwithlayersoffine dust
everywhereisan accidentwaiting tohappen.Agood dustcollection systemreducesoverall firehazardsbutalsoadds
newconcerns.Afirehazardisstill present. Combustiblematerialisnowinthe dustcollectorand storage container.
It isthe buyer’sresponsibilitytofollowall applicablefederal,state,local,OSHA,NFPA,orauthoritieshaving
jurisdiction codesand regulationswhen installing and operating thisdustcollector.
FireMarshallsmaywantthe unitlocated outside ofthe building.If the collectorislocated inside the facility,
controlssuchassparkdetection,suppression,orexplosion venting maybe required.
MostlocaljurisdictionsconsultoradoptNFPA (NationalFireProtection Agency)codes.However,othercodes
mayapply.Localcodesmayvaryfromjurisdiction tojurisdiction.
NFPA664 Code book,“Standardforthe Prevention ofFiresand ExplosionsinWood Processing and Woodworking
Facilities”,appliestowoodworking operationsthatoccupyareasofmorethan 5,000 sq.ft. ortoareaswhere
dustproducing equipmentrequiresan aggregatedustcollection flowrateofmorethan 1500 cfm(CubicFeet
perMinute).Thisexemptssomesmall operatorsfromthe NFPA code 664,butothercodesmayapplyinyour
jurisdiction.ConsultyourlocalFireMarshall forhelp.Additionalinformation can be found inNFPA Code Book
664.
The following pointsareworthheeding:
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
The customerassumesthe responsibilityforcontacting theirinsuranceunderwriterwithregardtospecific
application requirementsofexplosion venting orifadditionalfireprotection and safetyequipmentmaybe
required.
14

XIII.TermsandConditions
Pleaselookoverthe shipped orderverycarefullyinthe presenceofthe deliveryperson fordamage or
incompleteshipmentbeforesigning the deliveryreceipt. Pleasenoteanytearsorirregularitiesinshipping
packaging,howeverslight, on theshippingdeliveryreceipt. Thiscouldbe an indication ofextensiveconcealed
damage.The shipping companywill nottakeresponsibilityifthe damage isnotnoted on the deliveryreceipt.
Inthe eventofshipping damage,call O.A.S.immediatelysowecan expeditereplacements.Pleasecheck
inall partswithin3days fromreceiving order.NotifyO.A.S.immediatelyofanymissing orincorrectparts.
O.A.S.doesnotacceptanyclaimsfordamage orshortage after3daysfromdateofdelivery.
Checking inOrder
OneidaAirSystemswarrantsproductsitmanufacturesforaperiod of2yearstothe originalpurchaserfrom
the dateofpurchase.Itemsnotmanufactured byO.A.S.arelimited totheirownmanufacturer’swarranties.
Thiswarrantydoesnotapplytodefectsdue directlyorindirectlytomisuse,negligence,accidents,abuse,
repairs,oralterationsorlackofmaintenance.ThisisOneida AirSystemssolewritten warrantyand anyand
all warrantiesthatmaybe implied bylaw,including anymerchantabilityorfitness,foranyparticularpurpose,
areherebylimited tothe duration ofthiswritten warranty.O.A.S.doesnotwarrantorrepresentthatthe
merchandisecomplieswiththe provisionsofanylaworactsunless the manufacturersowarrants.Inno
eventshall O.A.S.’sliabilityunderthiswarrantyexceed the purchasepricepaidforthe productand anylegal
actionsbroughtagainstOneida AirSystemsshall be tried inthe StateofNewYork,CountyofOnondaga.
Oneida AirSystemsshall inno eventbe liablefordeath,injuriestopersonsorpropertyorforincidental,
contingent, special,orconsequentialdamagesarising fromthe useofourproduct.
Oneida AirSystemsdoesnotwarrantorauthorizeuseofwood dustcollectorsforotherpurposes.This
includeswood productsthataretreated,coated,orotherwisealtered fromtheirnaturalstate.
LimitedWarranty
Productswill be shipped toBuyer’ssingledestination.Titleand riskoflossshall pass tothe Buyerupon
deliverytosuchdestination.Buyerpaystransportation expenses.Datesofshipmentareadvisoryand O.A.S.
will makereasonableeffortstoshipon orbeforethe datestatesforshipment, however,O.A.S.shall notincur
anyliabilityforfailuretoshipon thatdate.
DeliveryRisk ofLoss
BuyermustinformO.A.S.ofanyshortage ordamage,bysonoting inwriting,on the freightdeliverybill prior
tosigning toindicatereceiptofshipment.All claims,including claimscovered underthe limited warranty,are
subjecttoinspection and investigation byO.A.S.. O.A.S.reservesthe righttoinspectand investigateall
returned productsbeforeBuyer’sclaimissettled.All productsreturned foracashrefund mustbe unused,
resaleableand purchased withinthe lastsixmonths.Thereareno refundson flexhoseorcustommade
components.Therewill be a25%restocking fee applied toanyreturned items.
ReturnedGoodsPolicy
O.A.S.2002
c
5-7.5HPDirectDriveOwner’sManual
15
