Oneida Air Systems Supercell Mobile User manual

Supercell®Mobile
Supercell® Turbo Mobile
High-Pressure
Dust Collector
14 Gallon
# XSK000014-P
# XSK040014-P
Doc. #ZBM000040 Appearance may vary slightly
OWNER’S MANUAL
U.S. Patent: #8393050,
#8377160, #9125535,
#D917806
Rev: B 20221128LL
READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNING LABELS BEFORE
USING THE DUST COLLECTOR.

oneida-air.com 1
Table of Contents
System Start-Up Information 2
Supercell/Supercell Turbo System Specications 6
System Dimensions 7
System Contents 8
Cart Contents 10
Assembly Instructions 12
Maintenance 24
Troubleshooting 26
F.A.Q. 28
Recommended Accessories 29
Warranty Information 31
Notes 32

Oneida Air Systems, Inc.2
System Start-Up Information
 WARNING 
1. READ and understand ALL instructions and warning labels BEFORE using the dust collector.
2. REPLACE warning labels if they become obscured or removed.
3. ALWAYS follow all applicable federal, state, local, OSHA, NFPA, or authorities having jurisdiction codes
and regulations when installing and operating this dust collector.
4. ENSURE that all users of this Dust Collector are informed of all warnings and precautions, safe use, and
maintenance procedures.
5. FULL mental alertness is required. NEVER operate under the inuence of drugs or alcohol, when tired, or
when distracted.
6. DO NOT allow use by or near children.
7. DO NOT allow to be used as a toy. Close attention is necessary when used by or near children.
8. NEVER leave the dust collector running while unattended.
9. TURN OFF and UNPLUG the dust collector BEFORE walking away, servicing, or cleaning. Allow the
fan blower motor to come to a COMPLETE STOP before walking away or performing any maintenance,
service, cleaning, or adjustments. is eliminates the risk of injury from unintended startup or contact with
live electrical components.
10. ENSURE that your dust collector is turned OFF and UNPLUGGED during installation. is eliminates the
risk of injury from unintended startup or contact with live electrical components.
11. COMPLETELY INSTALL ductwork/ex hose before operating collector.
a. Seal ductwork with silicone sealant or duct tape if leaks are found.
b. Have dust drum in place and sealed.
c. NEVER operate without lter and cowling in place. is machine has high speed rotating elements than
can cause severe injury.
12. ONLY use the dust collector for its intended purpose as described in this manual. DO NOT force it or
an attachment to do a job for which it was not designed. Consult this owner’s manual or reach out for
recommended accessories.
13. ENSURE enough air volume is at the suction point to capture all the particulate generated.
Before Purchasing or installing a dust collection system the process owners/operators
are cautioned to do so in accordance with prescribed Federal, State, Local, OSHA, NFPA,
and any other applicable codes or regulations relating to the type of dust(s) you are
collecting.
This manual contains specific precautionary statements relative to worker safety. Read
thoroughly and comply as directed. The most up to date safety information can be found
on our website: oneida-air.com/safety

oneida-air.com 3
System Start-Up Information (Continued)
14. NEVER make modications without prior approval from Oneida Air Systems. Modifying the dust collector
or using it dierently than intended will void the warranty and may result in malfunction or mechanical
failure that leads to serious personal injury or death!
15. DO NOT locate or operate the system in moist, wet, poorly lit, or cluttered environments. Operating in
these areas can create shock hazards, increase the risks of accidents and injury, and/or lower the operating
lifespan of the dust collector.
16. DO NOT install in classied hazardous atmospheres without an enclosure rated for the application. System
Location must account for wind, seismic zone, and other load conditions. Codes may regulate acceptable
locations for installing dust collectors. Consult with the appropriate authorities having jurisdiction to ensure
compliance with all national and local codes regarding dust collector installation. Equipment must be
anchored in a manner consistent with local code requirements. Anchors must be sucient to support dead,
live, seismic, and other anticipated loads. Consult a qualied engineer for nal selection of anchorage.
17. ENSURE exhaust air is properly vented. It should NOT be vented into a wall, a ceiling, or a concealed space
of a building. Personal injury, death, and/or property damage can result from material discharge during
venting. e risk of personal injury and/or property damage can be minimized or avoided by locating
vented equipment outside buildings and away from normally occupied areas. If exhaust air is vented outside,
you must provide make up / return air. Flue gases (carbon monoxide) can be drawn into the shop from
furnaces, water heaters, or other appliances
18. INSPECT and MAINTAIN REGULARLY. Keep the dust collector in proper working order. A machine that
isn’t properly maintained, not working as it should, has been dropped, damaged, le outdoors, or dropped
in water could malfunction leading to serious personal injury or death!
19. AVOID CORD DAMAGE. DO NOT pull or carry by cord. DO NOT use cord as handle. DO NOT unplug
by pulling on cord. To unplug, grab the plug, DO NOT close door on cord or pull cord around sharp edges
or corners. DO NOT run dust collector over cord. DO NOT handle cord/plug with wet hands. Keep cord
away from heated surfaces.
20. ALWAYS check for damaged parts. A part that is damaged should be carefully checked to determine that it
will operate properly and perform its intended function. Immediately repair or replace damaged or mis-
adjusted parts before operating machine.
21. DO NOT put any object in openings. DO NOT use with any opening blocked. (Except when pulsing - See
Maintenance Section for more information.)
22. ALWAYS wear a NIOSH approved respirator when emptying dust bins and during operation. Some dust
created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals
known to cause cancer, birth defects or other long-term respiratory damage
23. ALWAYS keep hair, loose clothing, ngers, and all parts of body AWAY from openings and moving parts.
24. ALWAYS wear ANSI-approved safety glasses or a face shield when operating or observing machinery and
when emptying dust bin.
25. ALWAYS wear hearing protection during extended periods of operation.

Oneida Air Systems, Inc.4
System Start-Up Information (Continued)
1. THIS UNIT IS NOT RATED FOR USE IN COMBUSTIBLE ENVIRONMENTS.
2. DO NOT operate the dust collector in areas where explosion risks are high. Areas of high risk include, but
are not limited to, areas near pilot lights, open ames, or other ignition sources.
3. ONLY operate dust collector in locations that include a re suppression system or have a re extinguisher
available nearby.
a. e ABC type (dry chemical) is generally a good choice for small wood shops.
b. Additional information on portable extinguishers can be found in NFPA 10 (Standard for Portable Fire
Extinguishers).
4. DO NOT allow accumulation of layers of ne dust on horizontal surfaces. Especially overhead lights,
electrical boxes and fuse panels which can ignite dust. Keep the oor around the system clean and free of
scrap material, oil, grease.
5. ENSURE all equipment and ductwork is electrically grounded.
6. DO NOT use PVC drain pipe.
7. ALWAYS consult an electrician or qualied service personnel about wiring practices and electrical codes
in your area. ONLY allow an electrician or qualied service personnel to do electrical installation or repair
work.
8. ALWAYS disconnect power before accessing or exposing electrical equipment. Improper wiring can cause
re, electrocution, injury, or death.
9. DO NOT use to pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
10. DO NOT use to pick up liquids, ammable liquids, or combustible liquids, such as gasoline, or use in areas
where they may be present.
11. DO NOT use excessively large wood waste bins. Wood dust mixtures are highly ammable and can be
explosive
 FIRE HAZARDS 
Process owners/operators retain all responsibility for the suitability of fire and explosion
hazard mitigation, suppression, and isolation strategies and to follow all applicable
federal, state, local, OSHA, NFPA, or authorities having jurisdiction codes and regulations
when installing and operating this dust collector.
Improper operation of a dust control system may contribute to conditions in the work
area or facility that could result in severe personal injury and product or property
damage.
Oneida Air Systems assumes no responsibility or liability for the suitability of any fire and/
or explosion mitigation strategy, or any items incorporated into a collector as part of an
owner/operators hazard mitigation strategy.

oneida-air.com 5
Customer Service Dept.
1-866-387-8822 • [e-mail]
System Start-Up Information (Continued)
12. ALWAYS check your dust bin for smoldering materials before leaving the shop.
13. NEVER introduce sparks or sources of ignition into the dust collector. Sparks can be generated in several
ways:
a. High speed sanders, abrasive planers, saws, and edgers may strike foreign material and create a red-hot
metal fragment.
b. Knots in hardwood can create frictional sparks.
c. Trapped metal, when drawn into the dust collection system, can spark against ductwork.
d. Check wood stock for old nails and screws which can create red-hot metal fragments.
14. DO NOT overload woodworking equipment, especially sanders, as excessive frictional heat can
spontaneously ignite dust. Sanders can produce concentrations of dust well into the combustible range.
15. ALWAYS check that all dust collection equipment is properly selected and sized for the intended use.
Authorities with jurisdiction should be consulted before installing to verify local codes and installation
procedures. In the absence of such codes, install collector according to the National Electric Code, NFPA
No. 70-latest edition and NFPA 91, NFPA664 Code (NFPA 654 if combustible dust is present).

Oneida Air Systems, Inc.6
Supercell/Supercell Turbo System Specications
OPERATION
Maximum Suction Rating 97.8" WC
MOTOR AND ELECTRICAL
Motor Type 3x 1300W Modular Motors/ 4x 1300W Modular Motors
Horsepower 5HP Total / 6.7 HP Total
Motor Speed 48,880 RPM
Phase 1-Phase
Voltage 208-230V
Cycle 60HZ
Listed FLA 18A / 22A
On/O Switch Magnetic Starter with On-O Switch and RF Remote
Power Cord Length 10 feet
Power Connector NEMA 6-20 / BareWiring
Recommended Circuit Size 20A / 30A
Recommended Circuit Type HACR
Sound Emission 80 dBA @ 10 ft / 85 dBA @ 10 ft
CARTRIDGE FILTER
Filter Media Type HEPA Grade ePTFE Media
Filter Eciency E12
Filter Surface Area 40 sq ft
SYSTEM DIMENSIONS AND CONSTRUCTION
Primary Build Materials Cold Rolled Steel, Static Dissipative Polyethylene
Inlet 4" O.D.
Overall Height 61"
Overall Weight 105 lbs
e Supercell requires a 20 Amp
outlet receptacle to be installed by a
licensed electrician.
Bare Wiring
Two HotWires & Ground
Licensed Electrician
REQUIRED
Bare Wiring
Two Hot Wires & Ground
Licensed Electrician
REQUIRED
e Supercell Turbo requires that
it be installed to a 30 Amp breaker
(minimum) by a licensed electrician.

oneida-air.com 7
Nominal dimensions shown. Dimensions subject to slight variations in manufacturing.
Allow for an additional 24" of clearance above the Motor Assembly to allow for its removal during lter replacement and
other maintenance.
System Dimensions
36-13/16"
935 mm
Floor
21-9/16"
548 mm
28 -1/2"
724 mm
29-7/8"
760 mm
24-1/4"
616 mm
61"
1,549 mm

Oneida Air Systems, Inc.8
System Contents
Please unpack the parts carefully and conrm you have received each item listed here.
* Some components are pre-installed at the factory and are listed here for your convenience.
ID Part number Part description Qty
ABXI001501
BXI441501
Supercell Motor Assembly
SupercellTurbo Motor Assembly 1
B FPX040001 Filter Hold Down Plate 1
C FCS131040H 13" x 13" Conical HEPA-Grade Media Filter 1
D GCZ150000 15" Ring Clamp 1
E SCX040000 Cyclone 1
E1* DGA040000 4" Aluminum Blast Gate 1
E2* DAB040000 4" Male Duct Adapter 1
E3* AFR316066 Rivets 5
F SMS040001 Supercell Wall Bracket 1
G AHX000021 Supercell 14 Gal. Model Hardware Pack 1
G1 ZBT040001 Supercell Wall Bracket Template 1
G2 RGF000015 15" Barrel Gasket 1
G3 RGZ051820 Supercell Flange Gasket 1
G4 AFS015920 1/4"-20 x 3/4" Hex Head Bolt 6
G5 AFW025000 1/4" Flat Washer 6
G6 AFT900006 1/4"-20 Nylock Nut 6
G7 AFB155180 5/16-18 x 2-1/2" Hex Head Bolt 4
G8 AFW180000 5/16" Flat Washer 4
G9 AFW180516 5/16”Rubber Washer 4
G10 AFT155175 5/16 " Whiz-Lock Nut 4
G11 AFT900516 5/16" - 18 Nylock Nut 4
G12 AFW516075 5/16x 3/4" Nylon Spacer 1
G13 SMS040000 Rear Support Brace 1
G14 AFL990001 Latches 2
G15 AFS501032 10-32 1/2" Phillips Pan Head Screws 4
G16 AFT901032 10-32 Nylock Nut 4
ID Part number Part description Qty
G17 AFB155180 5/16-18 x 2-1/2" Hex Head Bolt 2
G18 AHX000033 Tubing Assembly 7
G18A VRV050500 1/2" ID Clear Vinyl Tubing 1/3'
G18B AWV000050 1/2" ID SwitchValve 1
G18C VRV050500 1/2" ID Clear Vinyl Tubing 7'
G19 ACH000058 Double Spring Clamp 1
G20 AHX000018 Quick Disconnect Kit 1
G20A RLH000006 1/4" NPT Nylon Elbow 1
G20B RLH000005 3/8”Socket 1
G20C RLH000004 3/8" Male Plug 1
G20D RLH000002 Nylon Washer 1
G20E RLH000003 Rubber O Ring 1
G20F RLH000007 Nylon Nut 1
G21 AXD600300 9-17 Gallon Drum Liner Bag 5
G22 RLH000023 23 mm Button Plug 1
G23 ACB640000 4-1/2" Turn-Key Band Clamp 2
G24 RGZ470114 Bin Gasket 4
G25 AMR000000 Remote Control Key Fob 1
H DHF042502 4" x 25' Vacuum Pressure Rated Flex-Hose 1
I AXB999110B Dust Sentry Automatic Bin Level Indicator 1
J SMD140400 Drum Assembly 1
J1 SDS140000 14 Gallon Molded Drum 1
J2* RHL000604 Drum Window 1
J3* AFS103258 10-32 5/8" Phillips Pan Head Screws 4
J4* AFT901032 10-32 Nylock Nuts 4
J5 RHC000012 3" Caster with 5/16"-18 x 3/4" Stems 5
If you cannot find an item on the list, examine the packaging materials very carefully for nested items.
Please note that certain components have been pre-installed. There may be hardware leftover.

oneida-air.com 9
System Contents (Continued)
SHEET 1 OF 1
NAME:
14Ga Galv
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
Oneida Air Systems Inc. AND SHALL
NOT BE USED OR DISCLOSED TO
OTHERS, IN WHOLE OR IN PART,
WITHOUT THE WRITTEN AUTHORIZATION
OF Oneida Air Systems Inc.
5 4
3
2
1
PART NO.
SIZE
A
DO NOT SCALE
DRAWN DATE: 7/18/2019
ONEIDA AIR SYSTEMS INC.
1001 WEST FAYETTE STREET
SYRACUSE, NEW YORK 13204
1-800-732-4065
MFG APP:
DRAWN BY:
ENG APP:
TOL:
.XX
.10
.XXX .015
PROPRIETARY AND CONFIDENTIAL
MATERIAL: FINISH:
DIMENSIONS
ARE IN
INCHES
REV:
FPX040001
3RD ANGLE
FPX040001 - Filter Hold Down 14ga rev 3
3
KWG
G14 G15
G16
Thewall bracket should be installed to a sturdy, reinforced surface e.g. concrete wall, brick
wall,drywall with wooden studs.The wall bracket is designed to work with standard 16” stud
spacing.This template indicates the proper drill holes and the full, assembled size of the wall
bracket.
Wall Bracket Template
.5"
13mm
.5"
13mm
16"
406mm
8"
203mm
8"
203mm
4"
102mm
4"
102mm
SupercellWall Bracket Template
#ZBT040001
DrillHere DrillHere
DrillHere DrillHere
LEVEL THIS LINE
TheCyclone can be rotated in 90-degree increments so that the inlet is facing parallel or
perpendicularto the wall. Decide how you want your system oriented during installation to
bestmeet your shop’s needs. Other positions will not work as they will hinder installation of
theRear Support Brace.
Cyclone Mounting Positions
RIGHTFORWARD LEFT
G7
G8
G9
G10
G11
G12
G13
G1 JG20
G18
G20A
G18A
G20E G20F
G20B
G18B
G20C
G18C
G20D
G21
D
J5
I
G2
B
G22
G24
G6
G5
G4
G3
G25
G23
G19
H
G17
Filter Attachment Hardware
Filter Attachment Hardware
Mounting Hardware & Remote
Owner's Manual Envelope
Drum Hardware
Vent Tube Quick Disconnect Pk
A
C
E
F

Oneida Air Systems, Inc.10
Cart Contents
Please unpack the parts carefully and conrm you have received each item listed here.
† Additional parts are included
ID Part number Part description Qty
K STX000114 Cart Handle 1
L RBC000001 Support Brace 1
M RBC000003 Handle Brace - Right 1
N RBC000002 Handle Brace - Left 1
O RBC000005 Bracket - Right 1
P RBC000004 Bracket - Left 1
Q STX140000 Cart Body 1
R VRW010002 10" Extra-Soft Tread Rubber Wheel 2
S AHX000025 Supercell Cart Hardware Pack 1
S1 AFS103238 10-32 3/8" Phillips Pan Head Screws 4
S2 AFT901032 10-32 Nylock Nut 4
ID Part number Part description Qty
S3 AFS156075 5/16-18 X 3/4" Carriage Bolt 6
S4 AFW180000 5/16" Flat Washer 12
S5 AFT900516 5/16 - 18 Nylock Nuts 10
S6 AFB155190 5/16-18 x 1" Hex Head Bolt 2
S7 AFW516075 5/16 x 3/4" Nylon Spacer 2
S8 AFW180516 5/16”Rubber Washer 2
S9 RHS000000 Vacuum Hose Storage Strap 1
S10 AFP500001 Cotter Pin 2
S11 RHC000012 3" Caster (5/16-18 x 3/4" Stem) 2
S12 RCP000125 1-1/4" Plastic Plug 2
If you cannot find an item on the list, examine the packaging materials very carefully for nested items.
Please note that certain components have been pre-installed. There may be hardware leftover.
You will need the following tools:
CART AND CYCLONE BODY DRUM LATCHES
Channel Lock Pliers #2 Phillips-Head Screw Driver 3/8" Wrench
7/16" Wrench Rubber Mallet - Optional #2 Phillips-Head Screw Driver
7/16" Socket Wrench
1/2" Wrench
1/2" Socket Wrench

oneida-air.com 11
S10S10
Cart Contents (Continued)
S4
S4 S4
S4
S4 S4
S5
S5 S5
S5
S6
S9
S6
S7
S8
S3S3
Q
K
L
NM
R R
S1
S1
S2
S2
S11
S12
O P

Oneida Air Systems, Inc.12
Assembly Instructions
1 Installing the Bin Gasket (G23) onto the
Mounting Bracket (F).
a. Turn the Mounting Bracket (F) upside
down [FIG. 1a].
b. Lay out the four Bin Gasket segments
(G23). DO NOT REMOVE THE BACKER
TAPE [FIG. 1b].
c. Arrange the Bin Gasket segments (G23)
in a circle with the ends interlocking and
aligning to the rounded front edge of the
wall bracket [FIG. 1c].
d. Carefully mark a circle around the inside
of the arranged Bin Gasket segments
(G23) with a marker to create a reference
line [FIG. 1d].
e. Peel the backer tape o of the Bin Gasket
segments (G23) and adhere them to the
Wall Bracket (F), lining them up with your
reference line [FIG. 1e].
Note: Press each gasket piece rmly onto the
bracket to ensure a long-lasting, airtight seal.
2 Secure Stem Casters (S11) to the threaded
insert on the bottom of the Cart Body (Q).
Seal the two holes at the end of the tubes of the
Cart Body with the Plastic Plugs (S12). [FIG.
2]
Note: For ease of assembly, we recommend
channel lock pliers to tighten the casters.
FIG. 1a FIG. 1b
FIG. 1c
FIG. 1e
FIG. 1d
FIG. 2
G23
F
Q
S11
S12S12

oneida-air.com 13
Assembly Instructions (Continued)
3 Secure both Rubber Wheels (R) to either side
of the axel on the bottom of the Cart Body (Q)
using a Cotter Pin (S10). [FIG. 3]
4 Li the Mounting Bracket (F) up and over
the Cart Body's (Q) threaded studs and slide
the Mounting Bracket (F) down so that the
threaded stud is snugly inside the smaller
section of each keyhole [FIG. 4].
5 Secure the Mounting Bracket (F) in place
using two Flat Washers (S4) and two Nylock
Nuts (S5) [FIG. 5].
FIG. 3
FIG. 4
FIG. 5
Threaded
Stud
Threaded
Stud
Threaded
Stud
Threaded
Stud
S5 S4
S10
R

Oneida Air Systems, Inc.14
Assembly Instructions (Continued)
FIG. 6
G16
S5 T3
QF
Q
Q
G14 G15
P
P
6 Align the Latches (G14) onto the holes on
either side of the Mounting Bracket (F) and
the holes on either side of the Cart Body (Q).
Secure them in place using two Pan-Head
Screws (G15) and Nylock Nuts (G16) [FIG 6].
Note: Firmly tighten this hardware. You may
need to open the latch to access the screw holes
for mounting.
7 Align the three bottom holes of the Le
Bracket (P) with holes on the le side of the
Cart Body (Q) [FIG 7a]. Secure them in place
using three Carriage Bolts (S3), three Flat
Washers (S4) and three Nylock Nuts (S5) [FIG
7b].
Mirror these steps on the opposing side of the
cart using the Right Bracket (O).
FIG. 7a
FIG. 7b
S4

oneida-air.com 15
Assembly Instructions (Continued)
FIG. 9b
FIG. 9a
8 Align the Le Brace (N) with the hole on the
Le Bracket (P). Secure to the Cart Handle (K)
using a Hex Head Bolt (S6) and Flat Washer
(S4) as shown in [FIG. 8a].
Mirror these steps using the Right Brace (O)
and Right Bracket (M).
Note: Hardware should be nger tightened. For
ease of assembly when connecting the Support
Brace (L), we recommend tilting the Le and
Right Braces up. [FIG 8b].
9 Align the Support Brace (L) with the holes on
the Right Brace (N) and Le Brace (N) Secure
using two Phillips Pan Head Screws (S1) and
two Nylock Nuts (S2) as shown in [FIG. 9a].
Note: For ease of assembly when connecting
the Cyclone (E), we recommend tilting the
connected Braces down [FIG 9b].
K P N S4 S6
FIG. 8a FIG. 8b
S1
S2

Oneida Air Systems, Inc.16
Assembly Instructions (Continued)
FIG. 11
G10
G9
M
E
11 Secure the Support Brace (L) to the Cyclone
(E) using a 2-1/2" Hex Head Bolt (G7), Flat
Washer (G8), Nylon Spacer (G12), Rubber
Washer (G9), and Whiz-Lock Nut (G10) as
shown in [FIG. 11].
Note: Hardware should be nger tightened until
the Le and Right Brace (N, O) are installed.
Inlet
Facing
Forward
FIG. 10a
FIG. 10b
G4
G3
G5
G6
E
10 Align the Cyclone (E) so the inlet is facing
foward [FIG. 10a].
Place the Flange Gasket (G3) and the Cyclone
(E) onto the Mounting Bracket (F) and align
the hole patterns on all three items. Secure
together using six Hex Head Bolts (G4), six
Flat Washers (G5), and six Nylock Nuts (G6)
[FIG. 10b].
G12
G8
G7

oneida-air.com 17
Assembly Instructions (Continued)
FIG. 13
G10
G9
E
G8
G7
FIG. 12
h
G9
S7
N
E
G8
G7
12 Secure the Le Brace (N) to the Cyclone
(E) using a 2-1/2" Hex Head Bolt (G7), Flat
Washer (G8), Nylon Spacer (S7), Rubber
Washer (G9), and Whiz-Lock Nut (G10) as
shown in [FIG. 12].
Mirror these steps using the Right Brace (N).
Note: e Hose Storage Strap (S9) can be
attached to either the Le or Right side of the
cart for your convenience. S9
13 Install the remaining Hex Head Bolt (G7), Flat
Washer (G8), Rubber Washer (G9), and Whiz-
Lock Nut (G10) to the remaining hole in the
Cyclone’s (E) upper ange [FIG. 13].
Note: Ensure that the Whiz-Lock Nuts are
torqued down so that the rubber washers are
rmly compressed - this will prevent air leaks.

Oneida Air Systems, Inc.18
Assembly Instructions (Continued)
FIG. 15
FIG. 16
FIG. 14
G11
B
C
C
C
E
E
D
G7
14 Place the Filter (C) on top of the Cyclone (E)
with the open side facing down [FIG. 14].
Note: Position the Filter (C) on the Cyclone (E)
so that is centered between all four Hex Head
Bolts (G7).
15 Slide the Filter Hold-Down Ring (B) over the
Filter (C) and the previously installed bolts
(G7) and secure in place using four Nylock
Nuts (G11) [FIG. 15].
Note: Tighten hardware so that the Filter's pre-
installed foam gasket is rmly compressed (by
roughly 50%). DO NOT OVERTIGHTEN.
16 Open and slide the Ring Clamp (D) over the
assembly so that it rests outside the upper
ange of the Cyclone (E) [FIG. 16].
