Panasonic HMe Series User manual

TOUCH TERMINALS
HMe Series
Instruction Manual
ACGM0195V3EN
Version 1.01

2
Table of contents
1. Introduction ...................................................................................................................................3
2. Important symbols ........................................................................................................................4
3. Product overview ..........................................................................................................................5
4. Standards and approvals .............................................................................................................6
5. Productidentication ...................................................................................................................7
6. Technical data common to all models.........................................................................................8
6.1 Hardwarespecications ........................................................................................................8
6.2 Environmentalconditions ......................................................................................................8
6.3 Electromagneticcompatibility(EMC) ....................................................................................9
6.4 Durabilityinformation ............................................................................................................9
7. Technical data by model.............................................................................................................10
8. Product dimensions.................................................................................................................... 11
8.1 HMe04................................................................................................................................. 11
8.2 HMe07.................................................................................................................................12
8.3 HMe10.................................................................................................................................13
9. Installation ..................................................................................................................................14
9.1 Installationenvironment ......................................................................................................14
9.2 Installationprocedure..........................................................................................................15
10. Connections.................................................................................................................................16
10.1 HMe04.................................................................................................................................16
10.2 HMe07.................................................................................................................................17
10.3 HMe10.................................................................................................................................18
10.4 Serialport............................................................................................................................19
10.5 Ethernetport .......................................................................................................................19
10.6 Powersupply,grounding,andshielding..............................................................................20
11. Cleaning faceplates.....................................................................................................................21
12. Getting started.............................................................................................................................21
13. System settings tool ...................................................................................................................22
13.1 Introduction .........................................................................................................................22
13.2 Activationofsystemsettingsinusermode.........................................................................22
13.3 Activationofsystemsettingsinsystemmode.....................................................................23
13.4 Optionsavailableinsystemsettings..................................................................................23
14. Touch screen calibration ............................................................................................................24
15. Unpacking and packing instructions ........................................................................................24
16. Record of changes ......................................................................................................................25

3
Introduction
1. Introduction
Thisinstructionmanualcontainsinformationabouttheinstallation,transportation,storage,assembly,
useandmaintenanceofprogrammabledisplaysoftheHMeseries.
Thefollowingmodelsareavailable:
• HMe04:ProgrammabledisplaywithTFTcolor4.3”widescreendisplaytouchscreen
• HMe07:ProgrammabledisplaywithTFTcolor7”widescreendisplaytouchscreen
• HMe10:ProgrammabledisplaywithTFTcolor10.1”widescreendisplaytouchscreen

4
Importantsymbols
2. Important symbols
Oneormoreofthefollowingsymbolsmaybeusedinthisdocumentationtoindicatethetypeofhaz-
ard.
DANGER
Indicatesahazardoussituationwhich,ifnotavoided,willresultindeathorseriousinjury.
WARNING
Indicatesahazardoussituationwhich,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION
Indicatesahazardoussituationwhich,ifnotavoided,couldresultinseriousormoderateinjury.
Notice
Indicatesapropertydamagemessage.

5
Productoverview
3. Product overview
TheHMeseriesprogrammabledisplayscombinestate-of-the-artfeaturesandtopperformancewith
anoutstandingdesign.TheyaretheidealchoiceforalldemandingHMIapplicationsincludingfactory
andbuildingautomation.
TheHMeseriesprogrammabledisplayshavebeendesignedtoruntheHMWINsoftware.
• CompatiblewithHMWINStudio.
• Fullvectorgraphicsupport.NativesupportofSVGgraphicobjects,transparencyandalphablend-
ing.
• Screenobjectdynamics:controlvisibilityandtransparency,move,resize,rotateanyobjecton
screen.Changepropertiesofbasicandcomplexobjects.
• MultilanguageapplicationswithTrueTypefonts.Easilycreate,installandmaintainapplicationsin
multiplelanguagestomeetglobalrequirements.
• Datadisplayinnumerical,text,bargraph,analoggaugesandgraphicimageformats.
• Richsetofstate-of-the-artHMIfeatures:dataacquisitionandlogging,trendpresentation,alarmhan-
dling,schedulerandtimedactions(dailyandweeklyschedulers,exceptiondates),recipes,security
andusermanagement,emailandRSSfeeds.
• Wideselectionofcommunicationdriversavailablewithmultiple-drivercommunicationcapability.
• Remotemonitoringandcontrolwithclient/serverfunctionality.
• On-lineandO󰀨-linesimulationwithHMWINStudio.
• PowerfulscriptinglanguageforautomatedHMIapplications.E󰀩cientscriptdebuggerimprovespro-
ductivityinapplicationdevelopment.
• Richgalleryofvectorsymbolsandobjects.

6
Standardsandapprovals
4. Standards and approvals
Theproductshavebeendesignedforuseinanindustrialenvironmentincompliancewiththe2014/30/
EUEMCDirective.
Theproductshavebeendesignedincompliancewith:
EN61000-6-4 EN55011ClassA
EN61000-6-2 EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Theinstallationoftheseproductsintotheresidential,commercialandlight-industrialenvironments
isallowedonlyinthecasethatspecialinmeasuresaretakeninordertoensureconformityto
EN61000-6-3.
IncompliancewiththeaboveregulationstheproductsareCEmarked.

7
Productidentication
5. Productidentication
Theproductmaybeidentiedthroughaplateattachedtotherearcover.Youwillhavetoknowthe
producttypeyouareusingforcorrectusageoftheinformationcontainedintheguide.
Thefollowinginformationisprovidedbytheplate:
• Productmodelname
• Productpartnumber
• Year/weekofproduction
• VersionIDoftheproduct
• Serialnumber

8
Technicaldatacommontoallmodels
6. Technical data common to all models
6.1 Hardwarespecications
Touch screen technology Resistive
Real-time clock back-up Supercapacitor
Fuse Automatic
Serial port RS232,RS485,RS422softwarecongurable
Recipe memory Flash
Real-time clock Clock/calendarwithsupercapacitorback-up
Accuracy real-time clock
(at 25°C)
<100ppm
6.2 Environmental conditions
Operating temperature
(surrounding air temperature)
0to+50°C EN60068-2-14
Storage temperature -20to+70°C EN60068-2-14
Operating and storage humidity 5–85%RHnot-condensing EN60068-2-30
Vibrations 5–9Hz,7mmp-p
9–150Hz,1g
EN60068-2-6
Shock ±50g,11ms,3pulsesperaxis EN60068-2-27
Degree of protection IP66frontpanel(seenote) EN60529
Pollution degree environment 2
* Thefrontfaceoftheunit,installedinasolidpanel,hasbeentestedusingconditionsequivalenttothestan-
dardsshowninthe“Environmentalconditions”.Eventhoughthelevelofresistanceunitisequivalenttothese
standards,oilsthatshouldhavenoe󰀨ectontheHMecanpossiblyharmtheunit.Thiscanoccurinareas
whereeithervaporizedoilsarepresent,orwherelowviscositycuttingoilareallowedtoadheretotheunitfor
longperiodsoftime.IfthefrontfaceprotectionsheetontheHMebecomespeeledo󰀨,theseconditionscan
leadtotheingressofoilintotheunitandseparateprotectionmeasuresaresuggested.
Iftheinstallationgasketisusedforalongperiodoftime,oriftheunitanditsgasketareremovedfromthe
panel,theoriginaldegreeoftheprotectioncannotbeguaranteed.

9
Technicaldatacommontoallmodels
6.3 Electromagnetic compatibility (EMC)
Radiated disturbance test ClassA EN55011
Electrostatic discharge immunity test 8kV(airelectrostaticdischarge)
4kV(contactelectrostaticdischarge)
EN61000-4-2
Radiated, radio frequency,
electromagneticeldimmunitytest
80MHz–1GHz,10V/m
1.4–2GHz,3V/m
2–2.7GHz,1V/m
EN61000-4-3
Burst immunity test ±2KVDCpowerport
±1KVsignalline
EN61000-4-4
Surge immunity test ±0.5KVDCpowerport(linetoearth)
±0.5KVDCpowerport(linetoline)
±1KVsignalline(linetoearth)
EN61000-4-5
Immunity to conducted disturbances
inductedbyradiofrequencyeld
0.15–80MHz,10V EN61000-4-6
6.4 Durability information
Backlight service life (LED type) 20000hoursormore(Timeofcontinuousoperationuntilthe
brightnessofthebacklightreaches50%oftheratedvalue
whenthesurroundingairtemperatureis25°C,seenote)
Front foil (without direct
exposure to sunlight or UV rays)
10yearsifthesurroundingairtemperatureis25°C
UV resistance Indoorapplications:After300hourscycledhumidityinQUV
acceleratedweathering,someyellowingandbrittlenessmay
bepresent.
Solvent resistance Contactfor1/2hourat21°C,novisiblee󰀨ect:acetone,butyl
cellosolve,cyclohexanone,ethylacetate,hexane,isopropyl
alcohol,mek,methylenechloride,toluene,xylene
Contactfor24hoursat49°C,novisiblee󰀨ect:co󰀨ee,ketchup,
lemonjuice,mustard(slightyellowstain),tea,tomatojuice.
Touch screen reliability >1millionoperations
* Extendeduseinenvironmentswherethesurroundingairtemperatureis40°Corhighermaydegradebacklight
quality/reliability/durability.

10
Technicaldatabymodel
7. Technical data by model
Model HMe04 HMe07 HMe10
Display / Backlight TFTColor/LED
Colors 64K
Resolution 480x272 800x480 1024x600
Display size (inch) 4.3widescreen 7”widescreen 10.1”widescreen
Dimming yes
Usermemoryash 60MB
RAM 256MBDDR 512MBDDR
Serial port RS232,RS485,RS422DB9femalesoftware
congurable
RS232,RS485,
RS422
softwarecongurable
Ethernet port 10/100Mbit
USB port HostinterfaceV2.0,max.500mA
Real-time clock yes
Voltage 24VDC 18–32VDC
Current rating (at 24V DC) 0.25A 0.30A 0.38A
Weight 0.4kg 0.6kg 1kg

11
Productdimensions
8. Product dimensions
8.1 HMe04
Model A B L H D T
HMe04 136mm 96mm 147mm 107mm 29mm 5mm

12
Productdimensions
8.2 HMe07
Model A B L H D T
HMe07 176mm 136mm 187mm 147mm 29mm 5mm

13
Productdimensions
8.3 HMe10
Model A B L H D T
HMe10 271mm 186mm 282mm 197mm 29mm 6mm

14
Installation
9. Installation
9.1 Installation environment
Inordertomeetthefrontpanelprotectionclassications,properinstallationproceduremustbe
followed:
• Thebordersofthecutoutmustbeat.
• Eachxingscrewmustbetighteneduntiltheplasticbezelcornergetincontactwiththepanel.
• Thecutoutforthepanelmustbeofthedimensionsindicatedinthismanual.
Theproductisnotintendedforcontinuousexposuretodirectsunlight.Thismightacceleratetheaging
processofthefrontpanellm.
Theproductisnotintendedforinstallationincontactwithcorrosivechemicalcompounds.Checkthe
resistanceofthefrontpanellmtoaspeciccompoundbeforeinstallation.
Donotusetoolsofanykind(screwdrivers,etc.)tooperatethetouchscreenoftheproduct.
TheIP66isguaranteedonlyif:
• Themax.deviationfromtheplanesurfacetothecutoutis≤0.5mm
• Thethicknessofthecasewheretheproductismountedisfrom1.5mmto6mm
• Themax.surfaceroughnesswherethegasketisappliedis≤120μm.
(1)
(1) Installationcutout

15
Installation
9.2 Installation procedure
Fordetailsoninstallation,pleaserefertotheInstallationGuideprovidedwiththeproduct.Placethe
xingbracketsasshowninthefollowinggure.
Notice
Makesuretoscreweachxingscrewuntilthebezelcornergetsincontactwiththepanel.
Tighteningtorque:75Ncm

16
Connections
10. Connections
10.1 HMe04
(4) (1) (3)
(2)
(1) Serialport
(2) Ethernetport
(3) USBport
(4) Powersupply

17
Connections
10.2 HMe07
(4) (1) (3)(2)
(1) Serialport
(2) Ethernetport
(3) USBport
(4) Powersupply

18
Connections
10.3 HMe10
(4) (1) (3)(2)
(1) Serialport
(2) Ethernetport
(3) USBport
(4) Powersupply

19
Connections
10.4 Serial port
TheserialportisusedtocommunicatewiththePLCorwithanothertypeofcontroller.
StandardsavailableforthesignalsinthePLCportconnectorare:RS232,RS422,RS485.Usethe
correspondingcommunicationcablefortheconnection.
Theserialportissoftwareprogrammable.Makesureyouselecttheappropriateinterfaceinthepro-
grammingsoftware.
RS232 RS422, RS485
Pin Description
Serial port
Pin Description
1GND 1GND
2 2
3 TX 3 CHA-
4 RX 4 CHB-
5 5
6+5Voutput 6+5Voutput
7 CTS 7 CHB+
8RTS 8CHA+
9 9
ForRS485,pins4-3and8-7
mustbeconnectedexternally.
10.5 Ethernet port
TheEthernetporthastwoLEDstatusindicators.Theyworkasshowninthefollowingtable.
(1) (2)
(1)GreenLED (2)YellowLED Description
ON OFF NoLANcableconnected
BLINKING(linkactive) ON LANcableconnectedwith100Mbit/slink
BLINKING(linkactive) OFF LANcableconnectedwith10Mbit/slink

20
Connections
10.6 Power supply, grounding, and shielding
Thepowersupplyterminalblockisshowninthefollowinggure.
DCpowerconnector-AWG24wiresize-R/Cterminalblocks(XCFR2),femalepitch5.08mm,torque
4.5lb-in
NOTE
Makesurethatthepowersupplyhassu󰀩cientpowercapacityfortheoperationoftheproduct.
Theproductmustalwaysbegroundedtoearth.Groundinghelpslimitthee󰀨ectsofnoiseduetoelec-
tromagneticinterferenceonthecontrolsystem.
Useterminal3onthepowersupplyterminalblockearthconnection.
Thepowersupplycircuitmaybeoatingorgrounded.Inthelattercase,thepowersourcecommonis
connectedasindicatedwithadashedlineinthefollowinggure.
Whenusingtheoatingpowerscheme,notethatinternallythepowercommonisconnectedtothe
groundwitha1MΩresistorinparallelwitha4,7nFcapacitor.
Thepowersupplymusthavedoubleorreinforcedinsulation.Thesuggestedwiringforthepowersup-
plyisshowninthefollowinggure.
Alltheelectronicdevicesinthecontrolsystemmustbeproperlygrounded.Groundingmustbeper-
formedaccordingtoapplicableregulations.
