Parker DINCon II Assembly instructions

Parker DINCon II, DINPres II,
& DINTemp II Modules
Installation, Operating & Maintenance Instructions

2
Parker Hannifin Corporation has a continuous policy of product development and although the Company reserves the right to
change specification, it attempts to keep customers informed of any alterations. This publication is for general information only and
customers are requested to contact your local Parker Sales Representative for detailed information and advice on a product’s
suitability for specific applications. All products are sold subject to the company’s Standard conditions of sale.
DINCon II™ DINPres II™ and DINTemp II™ are registered trademarks of Parker Hannifin Corporation.

3
Contents
Introduction ................................................................................................................................. 6
Calibration .................................................................................................................................. 6
Warranty ..................................................................................................................................... 7
Standards ................................................................................................................................... 7
Installation & Start-Up ................................................................................................................. 7
Maintenance & Cleaning ............................................................................................................. 7
DIN II Module Specifications ....................................................................................................... 8
Installation ................................................................................................................................ 11
Operating Instructions............................................................................................................... 14
Modbus Register List ................................................................................................................ 16
DINCon II Registers .................................................................................................................. 16
DINPres II Registers ................................................................................................................. 20
DINTemp II Registers ............................................................................................................... 25
Revision History:
Rev. # Date Author Description
A 4/25/2019 A. Dawson Initial release, based on original SciLog DIN Module
Manual

4
Precautions
READ this manual BEFORE operating or servicing this equipment.
FOLLOW these instructions carefully.
SAVE this manual for future reference.
DO NOT allow untrained personnel to operate, clean, inspect, service or tamper with
this equipment.
ALWAYS DISCONNECT this equipment from the power source before cleaning or
performing maintenance.
Contact your local Parker Division for parts, information and service.
WARNING
DISCONNECT ALL POWER TO THIS UNIT BEFORE INSTALLING,
SERVICING, CLEANING OR REMOVING THE FUSE. FAILURE TO DO
SO COULD RESULT IN BODILY HARM AND/OR PROPERTY DAMAGE.
CAUTION
OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC
SENSITIVE DEVICES.
WARNING
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS
EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND
ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO
OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.
WARNING
FOR CONTINUED PROTECTION AGAINST SHOCK HAZARD, CONNECT
TO PROPERLY GROUNDED OUTLET ONLY. DO NOT REMOVE THE
GROUND PRONG.
CAUTION
USE ONLY CLASS 2 LISTED EXTERNAL 24 VDC POWER SUPPLY WITH
THESE DEVICES.

5
Précautions
LISEZ ce manual AVANT de faire fonctionner ou d’entretenir cet équipment.
SUIVEZ attentivement ces instructions.
CONSERVEZ ce manuel pour future référence.
NE LAISSEZ PAS du personnel non qualifié utiliser, nettoyer, inspecter, entretenir, réparer ou
manipuler cet équipement.
DÉBRANCHEZ TOUJOURS cet équipement de la source de courant avant de nettoyer ou
d’exécuter l’entretien.
APPELEZ PARKER pour pièces détachées, renseignements et entretien.
ATTENTION
DÉBRANCHEZ TOUT COURANT DE CETTE UNITÉ AVANT DE FAIRE
L’INSTALLATION, D’EFFECTUER L’ENTRETIEN, LE NETTOYAGE OU
AVANT DE RETIRER LE FUSIBLE. NE PAS OBSERVER CES
PRÉCAUTIONS RISQUERAIT DE CAUSER DES BLESSURES
CORPORELLES OU/ET D’ENDOMMAGER L’
É
QUIPEMENT.
PRUDENCE
SOYEZ PRUDENT LORSQUE VOUS MANIPULEZ DES APPAREILS
SENSIBLES À L’ÉLECTROSTATIQUE.
ATTENTION
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS
EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND
ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO
OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.
ATTENTION
POUR ASSURER UNE PROTECTION CONTINUE CONTRE UNE
DÉCHARGE ÉLECTRIQUE, BRANCHEZ UNIQUEMENT SUR UNE PRISE
CORRECTEMENT RELIÉE Á LA TERRE. NE RETIREZ PAS LA FICHE DE
TERRE.
PRUDENCE
N'UTILISER QUE DE L'ALIMENTATION ÉLECTRIQUE 24 VDC
EXCLUSIVE DE CLASSE 2 AVEC CES DISPOSITIFS.

6
Introduction
You will find the DINCon II, DINPres II and DINTemp II Modules and sensors easy to use. The state-of-
the-art hardware and software design of the DIN Module and sensor combination allows you to
measure and document the conductivity, pressure or temperature of many filtration / separation
processes. With proper maintenance, the DIN II Modules will provide many years of excellent service
and performance.
Please read the following instructions carefully!
Inspections: Remove the products carefully from the shipping container. Check the contents against
the purchase order to verify that all parts are included and undamaged.
Please do the inspection now, even if the products are not used immediately. Many carriers must
receive damage claims within seven days of delivery. Please retain all packing material so unit may be
shipped safely, if necessary.
Customer Service:
Parker Hannifin Corporation
Bioscience Filtration Division
2340 Eastman Avenue
Oxnard, California, USA 93030
toll free: 877 784 2234
phone: [phone]
fax: [phone]
email: [email protected]
www.parker.com/bioscience
Parker Hannifin Manufacturing Ltd
Bioscience Filtration Division
Durham Road
Birtley, Co. Durham
DH3 2SF, England
phone [phone]
fax [phone]
email: [email protected]
www.parker.com/bioscience
Parker customer service personnel will be able to serve you more efficiently if you have the following
information:
 Serial number and model name of the equipment
 Installation procedure being used
 Concise list of symptoms
 List of operating procedures and conditions in use when problem arose
Calibration
The DIN II Modules are calibrated devices and are calibrated with test equipment that is traceable to SI
through NIST.
A Calibration Certificate is included with each unit and has a one year expiration date.
It is highly recommended that the Module be calibrated on an annual basis or more often if your
Metrology Department deems it necessary.
Parker Bioscience Filtration provides this Calibration Service, complete with a new certificate, showing
the “as found” and “as left” data.
Contact your local Parker Bioscience Filtration Territory Manager if a quote is needed for this service.
Onsite calibration can be arranged.

7
Warranty
Country specific information can be found at: www.parker.com/termsandconditions
Standards
EN 61326-1:2006, Class B
EN 61010-1:2010 Ed.3+ C1; C2
Conforms to UL STD 61010-1:2012 Ed.3+ R: 29Apr2016
Certified to CSA STD C22.2 No 61010-1-12:2012 Ed.3+U1;U2
Caution: The maximum recommended pressure for the sensors is 60 psi.
If this is exceeded, problems with leakage and functionality can occur.
Installation & Start Up
Installation of the DINCon II, DINPres II, and DINTemp II Modules must be carried out only by trained
personnel in accordance with the relevant regulations and this operation manual.
Make sure that the technical specifications and input ratings of the single-use sensors are observed.
See the appropriate Sensor Specifications page.
The protection provided by this equipment may be impaired if the single-use sensors are used in a
manner inconsistent with this manual or for purposes not specified by the manufacturer.
Maintenance & Cleaning
The Parker DIN II Modules are maintenance free. The single-use Parker sensors come pre-calibrated
from the factory and require no maintenance.
To remove dust, dirt and stains, the outer surfaces of the DIN II Modules may be wiped using a soft,
non-fluffing cloth moistened with water. If required, you may also use a mild detergent or 2-propanol.
The single-use sensors may be sanitized with 0.1 Molar NaOH, or 2-propanol. They may be autoclaved
up to 2 times, or gamma-irradiated with exposure up to 45 kGy.

8
Hardware
Specifications – All Modules
Dimensions W: 0.875¨ (2.2 cm); Height 4.0¨ (10.2 cm); D: 4.75¨ (12.1 cm)
Weight 0.3 lb. (0.14 Kg)
Enclosure Molded Plastic
Electrical
Power 24 VDC, 250 mA. Use only Class 2 External Power Supply
Battery CR1216, used for internal clock, not user serviceable
I/O Port Top 8 pin Terminal Block, numbered from rear:
1: +24 VDC 2: 24 VDC Return 3: N/C 4: Signal GND (COM)
5: RS-232 RX 6: RS-232 TX 7: RS-485 A 8: RS-485 B
I/O Port – 2 RJ45, Ethernet Connection
I/O Port - 3 USB Connection
Software
I/O Port
Bottom
14 Pin Sensor Connection, DINCon has 1, DINPres and
DINTemp have 3.
DISPLAY Power Status LED, Sensor Status LED’s
Modbus Modbus RTU via RS-232
Modbus RTU via RS-485
Modbus RTU via USB
Modbus TCP via Ethernet
Environmental
Temperature 4 – 60° C
Altitude Up to 2000 Meters
IP Rating IP20, Indoor dry environments, unit is wipe-down only
Rel. Humidity 0 – 95%
Voltage Fluctuation allowed: +/- 10%
Pollution Degree: 2

9
Installation
Overview:
The DINCon II, DINPres II, and DINTemp II Modules are designed to be installed as
part of a control system inside a control cabinet that has a 24 VDC source available and
has Modbus communication protocol capability.
The DIN II Modules are installed on standard DIN II rail. They are usually mounted with
the red locking tab located at the bottom of the unit. This places the Power and
Communication connections at the top of the Module and the Sensor connections at the
bottom. They may be mounted upside-down if that proves useful.
Wiring Power and Communication:
Connect 24 Volts DC, 250 mA power to Pins 1 (+) and 2 (-) of the 8 pin terminal block.
(Note - pin 1 is at the rear, nearest the DIN rail.)
All data acquisition is via Modbus registers in either RTU or ASCII. The available
physical layers are RS-232, RS-485, Ethernet and USB. The recommended physical
layer for installation of multiple units is Modbus/RTU over RS-485 with Modbus/TCP via
Ethernet a close second.
For RS-232, connect to the following: Pin 4 = Signal Ground, Pin 5 = RX, Pin 6 = TX.
For RS-485, connect to the following: Pin 7 = RS485-A, Pin 8 = RS485-B.
For Ethernet connect an Ethernet cable to the provided RJ45 jack.
For USB connect to the provided USB Type A jack.
Pin 1: +24VDC
Pin 2: Common
Pin 3: Not Connected
Pin 4: Si
g
nal Ground
Pin 5: RS-232 RX
Pin 6: RS-232 TX
Pin 7: RS-485
A
Pin 8: RS-485 B
USB
RJ45 Ethernet
DIN
II
Rail

10
Connecting Sensors:
All sensors, SciCon II for use with the DINCon II Module, SciPres II for use with the
DINPres II Module, and SciTemp II for use with the DINTemp II Module are disposable
flow through sensors that are purchased separately from Parker and come pre-
calibrated.
The sensors connect to a provided cable that has an Amphenol bulkhead watertight
connector on the sensor end and a 14 pin connector on the other end that plugs into a
matching port on the bottom of the Module. The DINCon II has only one port, and uses
only one SciCon II Sensor. The DINPres II and DINTemp II have 3 ports, can support
up to 3 SciPres II or SciTemp II Sensors, and they are referred to as P1 – P3 or T1 – T3
beginning with P1 and T1 at the rear, or the closest connector to the DIN rail. These
cables are 12” long providing flexibility in where the bulkhead fittings are installed on the
control cabinet.
These cables ship with a ferrite clamp included that should be attached and secured to
the cable as shown below: (anywhere along the cable is fine.)
Sensor 1
Sensor 2
Sensor 3
DIN II Rail locking clip

11
When powered up and connected the Sensor Status LEDs on the front of the Module are
colored as follows:
 Green = Connected
 Red = Disconnected
 Yellow = Connected but not calibrated.
If the LED shows Yellow, it’s time to replace the affected Sensor with a new one.
Connecting the wrong type of Sensor to the module also results in a Yellow indication.

12
Operating Instructions:
Modbus Overview:
The Parker DIN II modules communicate via the Modbus protocol. All data is transferred
using the Modbus holding registers. The default connection is RS-485 at 115,200 baud,
8 bits, even parity and one stop bit.
Note: If parity setting (register 109) is changed to “none” then two stop bits must be
used.
The default Modbus mode is RTU. The Default Modbus addresses (register 105) for the
various Modules are:
DINCon II: 10
DINPres II: 20
DINTemp II: 30
Four physical layer interfaces are available for DIN II Module communications:
RS232 – Modbus/RTU or Modbus/ASCII
RS485 – Modbus/RTU or Modbus/ASCII
Ethernet - Modbus/TCP
USB - Modbus/RTU or Modbus/ASCII
The active Modbus interface is selected by connecting to the modules built-in web
server. Connect using an Ethernet patch cable and a hub on your network, or directly to
the unit with an Ethernet crossover cable. The default IP addresses are 192.168.0.142
for the DINCon II, 192.168.0.143 for the DINPres II, and 192.168.0.144 for the
DINTemp II. It may be necessary to create a new connection or modify and existing
one. Make any changes required to configuration and click on “Submit” to save them to
the module.
Any changes made via this interface require a power cycle of the module to take effect.

13
Modbus register definitions are listed below for each type – DINCon II, DINPres II, and
DINTemp II.
For floating point values, the DIN II modules use the standard IEEE-754 format. To read
these via a Modbus test application such as Modbus Poll, set the format to little endian
byte swapped.
Depending on the controller in use, the registers may need to be offset by one.
The Modbus address and communication parameters for a module can be changed by
writing to registers 104-109 as a block (at the same time).
The Modules contain a Real Time Clock that will be set to the current date and the end
users time zone prior to shipment from Parker. If re-setting the Real Time Clock is
needed, the data must also be written in one continuous Modbus multi-register write
operation to registers 130-137.
The DINPres II Module has a selectable Data Refresh Rate, with the default of 13
milliseconds being raw data. (Register 143) If the default setting is not used, a
conditioned signal is provided.
The Sensors have individual ID numbers and calibration information stored in, and
printed on them. Values relating to the ID numbers can be found in registers 201-206
for Sensor 1, 241-246 for Sensor 2 and 281-286 for Sensor 3. (Note: The first letter of
this ID number, a “C”, “S” or “A”, is not in any of the registers.)
Units and Alarm Limits:
The Modules provide the ability to set the desired Units for the outputs, as well as
appropriate High and Low Alarm Limits. The alarms are absolute and not dependent
upon signal direction (i.e. The signal does not have to be above the low alarm limit
value first to trip it). The register list in section C below lists the available units for each
Module. All Alarm Limits default to 0.0 and are thereby initially disabled.
DINCon II:
Conductivity Units: Default: µS Register 140
Temperature Units: Default: ⁰C Register 143
Conductivity Limits: Low: Registers 160-161
High: Registers 162-163
Temperature Limits: Low: Registers 164-165
High: Registers 166-167
DINPres II:
Pressure Units: Default: psi Register 140
P1 Pressure Limits: Low: Registers 160-161
High: Registers 162-163
P2 Pressure Limits: Low: Registers 164-165
High: Registers 166-167
P3 Pressure Limits: Low: Registers 168-169
High: Registers 170-171

14
DINTemp II:
Temperature Units: Default: ⁰C Register 140
T1 Temperature Limits: Low: Registers 160-161
High: Registers 162-163
T2 Temperature Limits: Low: Registers 164-165
High: Registers 166-167
T3 Temperature Limits: Low: Registers 168-169
High: Registers 170-171
Hardware Calibration:
The factory hardware calibration data is available as read only values and is only
performed on new modules with a special test fixture at the time of manufacture.
Note on use of SciPres II Sensors:
The DINPres II reads and utilizes calibration data from SciPres II Sensors that have been
calibrated to two points, 0 and 30 psi. It has also been equipped a Max Pressure
Watchdog feature.
The Max Pressure Watchdog feature records in the sensor’s memory the maximum
pressure seen by the sensor while it is connected to the DINPres II. The maximum
recommended pressure for the sensors is 60 psi. If this is exceeded, problems with
leakage and functionality can occur. This value is available in the appropriate register;
see the list in the next section.
Please Note: If the company Metrology Department tests the sensors using a regulated
air source, care must be taken to avoid high inrush pressure. Much like inrush current in
electronics, if the valve to the regulator is opened too fast, this can expose the sensor to
higher pressures than the regulator is set for. This will be reflected in the Max Pressure
value, and may risk damage to the sensor. This can be reset or cleared if desired.

15
Modbus Register List:
DINCon II Register List:
ADDRESS ACCESS FORMAT VALUE Default
90-99 R
A
SCII String DINCon Serial Numbe
r
100 R 16 bit Model Numbe
r
0
0 = DINCon
101-102 R IEEE Float Software Version
103 R/W 16 bit Reset Control
bit 0 = System Reset
bit 1 = Reset to Defaults
bit 2 = Alarm Reset
104-105 R/W 16 bit Modbus Address
104 may need be set to 0xa55a (hex) 0xa55a
registers 104-109 must be written as a block
105 contains Modbus address 10
106 R/W 16 bit Modbus Mode 0
0 = RS485 RTU
1 = RS485 ASCII
2 = RS232 RTU
3 = RS232 ASCII
4 = USB RTU
5 = USB ASCII
6 = TCP
107 R/W 16 bit Modbus Baud Rate (38400 default) 6
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 28800
6 = 38400
7 = 57600
8 = 115200
108 R/W 16 bit Modbus Serial Word Length ( 7 or 8) 8
109 R/W 16 bit Modbus Serial Parity (Even, 1 Stop Bit default) 2
0 = none, 2 Stop Bits
1 = odd, 1 Stop Bit
2 = even, 1 Stop Bit
110 R/W 16 bit TCP Address P1 192
111 TCP Address P2 168

16
DINCon II Re
g
ister List, Continued
ADDRESS ACCESS FORMAT VALUE Default
112 TCP Address P3 0
113 TCP Address P4 142
114 R/W 16 bit TCP Mask P1 255
115 TCP Mask P2 255
116 TCP Mask P3 255
117 TCP Mask P4 0
118 R/W 16 bit TCP Gateway P1 192
119 TCP Gateway P2 168
120 TCP Gateway P3 0
121 TCP Gateway P4 1
130 R/W 16 bit RTCC Control
bit0: Set Clock Values
Registers 130-137 must be written as a block
131 R/W 16 bit Day of Week (1-7)
132 R/W 16 bit Month
133 R/W 16 bit Day
134 R/W 16 bit Yea
r
135 R/W 16 bit Hour (24)
136 R/W 16 bit Minute
137 R/W 16 bit Second
140 R/W 16 bit Conductivity Units 0
0 = uS
1 = mS
2 = ppm KCl
3 = ppm NaCl
4 = ppm 442
141-142 R/W IEEE Float Cal Concentration (default 12.88mS) 12.88
143 R/W 16 bit Temperature Units 0
0 = C
1 = F
144-145 R/W IEEE Float Cal Temperature (default 25.0C) 25.0
150 R 16 bit Conductivity Status
bit0 = Set means disconnected
bit1 = Set means uncalibrated
bit2 = Set means low alarm
bit3 = Set means high alarm
151-152 R IEEE Float Conductivity Value
153 R 16 bit Temperature Status
bit0 = Set means disconnected
bit1 = Set means uncalibrated

17
DINCon II Re
g
ister List, Continued
ADDRESS ACCESS FORMAT VALUE Default
bit2 = Set means low alarm
bit3 = Set means high alarm
154-155 R IEEE Float Temperature Value
160-161 R/W IEEE Float Conductivity Alarm Limit - Low 0.0
162-163 R/W IEEE Float Conductivity Alarm Limit - High 0.0
164-165 R/W IEEE Float Temperature Alarm Limit - Low 0.0
166-167 R/W IEEE Float Temperature Alarm Limit - High 0.0
180 R/W IEEE Float Temperature Reference 25.0
201 R/W 16 bit Sensor ID Type
0 = Lue
r
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
202 R/W 16 bit Sensor ID Material
0 = N/
A
1 = Polysulfone
203 R/W 16 bit Sensor ID Month
204 R/W 16 bit Sensor ID Yea
r
205 R/W 16 bit Sensor ID Lot
206 R/W 16 bit Sensor ID Unit Numbe
r
208 R/W IEEE Float Sensor Temperature Offset (TO)
210 R/W IEEE Float Sensor Cal Factor (CF)

18
DINPres II Register List:
ADDRESS ACCESS FORMAT VALUE DEFAULT
90-99 R
A
SCII String DINPres Serial Numbe
r
100 R 16 bit Model Numbe
r
1
1 = DINPres
101-102 R IEEE Float Software Version
103 R/W 16 bit Reset Control
bit 0 = System Reset
bit 1 = Reset to Defaults
bit 2 = Alarm Reset
104-105 R/W 16 bit Modbus Address
104 may need to be set to 0xa55a 0xa55a
registers 104-109 must be written as a block
105 contains Modbus address 20
106 R/W 16 bit Modbus Mode 0
0 = RS485 RTU
1 = RS485 ASCII
2 = RS232 RTU
3 = RS232 ASCII
4 = USB RTU
5 = USB ASCII
6 = TCP
107 R/W 16 bit Modbus Baud Rate (38400 Default) 6
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 28800
6 = 38400
7 = 57600
8 = 115200
108 R/W 16 bit Modbus Serial Word Length (7 or 8) 8
109 R/W 16 bit Modbus Serial Parity (Even, 1 Stop Bit default) 2
0 = none, 2 Stop Bits
1 = odd, 1 Stop Bit
2 = even, 1 Stop Bit
110 R/W 16 bit TCP Address P1 192
111 TCP Address P2 168
112 TCP Address P3 0
113 TCP Address P4 143

19
DINPres II Re
g
ister List, Continued
ADDRESS ACCESS FORMAT VALUE DEFAULT
114 R/W 16 bit TCP Mask P1 255
115 TCP Mask P2 255
116 TCP Mask P3 255
117 TCP Mask P4 0
118 R/W 16 bit TCP Gateway P1 192
119 TCP Gateway P2 168
120 TCP Gateway P3 0
121 TCP Gateway P4 1
130 R/W 16 bit RTCC Control
bit0: Set Clock Values
Registers 130-137 must be written as a block
131 R/W 16 bit Day of Week (1-7)
132 R/W 16 bit Month
133 R/W 16 bit Day
134 R/W 16 bit Yea
r
135 R/W 16 bit Hour (24)
136 R/W 16 bit Minute
137 R/W 16 bit Second
140 R/W 16 bit Pressure Units 0
0 = psi
1 = kPa
2 = ba
r
3 = mmHg
141-142 R/W IEEE Float Cal Pressure (Default 30psi) 30.0
143 R/W 16 bit Data Refresh Rate 6
0 = 13 milliseconds
1 = 25 ms
2 = 50 ms
3 = 125 ms
4 = 250 ms
5 = 350 ms
6 = 500 ms
7 = 750 ms
8 = 1 second
9 = 1.5 seconds
10 = 2 seconds
11 = 4 seconds
150 R 16 bit P1 Status
bit 0 = Set means Disconnected
bit 1 = Set means Uncalibrated
bit 2 = Set means Low Alarm

20
DINPres II Re
g
ister List, Continued
ADDRESS ACCESS FORMAT VALUE DEFAULT
bit 3 = Set means High Alarm
151-152 R IEEE Float P1 Pressure Value
153 R 16 bit P2 Status
bit 0 = Set means Disconnected
bit 1 = Set means Uncalibrated
bit 2 = Set means Low Alarm
bit 3 = Set means High
A
larm
154-155 R IEEE Float P2 Pressure Value
156 R 16 bit P3 Status
bit 0 = Set means Disconnected
bit 1 = Set means Uncalibrated
bit 2 = Set means Low Alarm
bit 3 = Set means High Alarm
157-158 R IEEE Float P3 Pressure Value
160-161 R/W IEEE Float P1 Pressure Alarm Limit - Low 0.0
162-163 R/W IEEE Float P1 Pressure Alarm Limit - High 0.0
164-165 R/W IEEE Float P2 Pressure Alarm Limit - Low 0.0
166-167 R/W IEEE Float P2 Pressure Alarm Limit - High 0.0
168-169 R/W IEEE Float P3 Pressure Alarm Limit - Low 0.0
170-171 R/W IEEE Float P3 Pressure Alarm Limit - High 0.0
201 R/W 16 bit P1 Sensor ID Type
0 = Lue
r
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
202 R/W 16 bit P1 Sensor ID Material
0 = N/
A
1 = Polysulfone
203 R/W 16 bit P1 Sensor ID Month
204 R/W 16 bit P1 Sensor ID Yea
r
205 R/W 16 bit P1 Sensor ID Lot
206 R/W 16 bit P1 Sensor ID Unit Numbe
r
208 R/W IEEE Float P1 Sensor Pressure Offset (PZ)
210 R/W IEEE Float P1 Sensor Cal Factor (CF)
212 R/W IEEE Float P1 Sensor Cal Pressure (CP1)
214 R/W IEEE Float P1 Sensor Cal Factor 2 (CF2)
216 R/W IEEE Float P1 Sensor Cal Pressure 2 (CP2)
235 R/W IEEE Float P1 Sensor Max Pressure
237 R/W 16 bit P1 Sensor MaxP, Day
