Parker HASV08R User manual

Patent applied
$LU5HGXFWLRQ %ORZ(IILFLHQF\83
3XOVH&RQWLQXRXV
%ORZ&KDQJHRYHU%XWWRQ
1R(OHFWULFLW\
Air Saver Module
Air Saving Unit for Air Blowgun
Easy Energy Saving Solution
3XOVH)UHTXHQF\
$GMXVWPHQW
●Approx. 35% Air Consumption Reduction
●Possible to attach visible air blowgun
●Built-in pulse/continuous blow changeover button
●Blow efficiency up because of pulsed air
●With pulse frequency adjustment screw
HASV08R
www.parker.com
Parker Hannifin Corporation
Contact Information:

Specifications and Features
How to Connect Air Saver Module to Air Blowgun
HASV08R
0.35 〜0.8MPa
5〜15 Hz
Aluminum
IN Rc1/4, OUT R1/4
155 ｇ
Pulse frequency adjustment screwPulse/Continuous air blow changeover button
【Specifications 】
Pulsefrequencysetup
ONtime
OFFtime
Airreductionperformance
Lowerfrequency
5Hz
170ms
20%reduction
【Features】
Higherfrequency
15Hz
35ms
40%reduction
30ms
Pulse blow Continuous blow
CAT.No.KPL1609E-a
Model No.
Operating pressure
Body material
Port size
Weight
Pulse frequency
adjustment range
Pulse/Continuous blow change over button is mounted. When push the changeover
button, pulse blow will change to continuous blow. Also, the button is locked when
the button is turned 90 degree clockwise.
Turn the button counterclockwise to the original point in order to change to pulse
blow.
Pulse frequency is adjustable depending on types of work.
Higher frequency of pulse is adjusted by pulse frequency
adjustment button turned clockwise by flat-head screw
driver. Lower frequency of pulse is adjusted the adjustment
button turned counterclockwise.
* Connect Air Saver Module directly to an air blowgun
* Adjust pulse frequency by pulse frequency adjustment button that is suitable the air blowgun and application.
* Air Saver Module is for air blowgun only. We recommend "Air Saver Unit, ASV Series"is applicable for other pulse blow applications.
