parktool PCS-EXT User manual

5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
PARK TOOL CO.
PCS-EXT Repair Stand Extension for PCS-1 and PCS-4
The PCS-EXT adds up to 21 inches (53 cm) of adjustable working height to
PCS-1 and PCS-4 Home Mechanic Repair Stands manufactured from 1996
to 2002. PCS-1 and PCS-4 stands of this generation were not adjustable in
height and used a removable composite top tube assembly. The PCS-EXT
will not work on pre-1996 PCS-1 or PCS-4 repair stands that used a non-
removable steel top tube.
Installation Instructions
1. Loosen two socket head cap screws on back of composite top tube.
Remove top tube from upright tube.
2. Swing sleeve assembly’s (#928A) quick release lever to open position
and fully loosen socket head cap screw.
3. Press sleeve assembly onto upright tube. The fit will be tight. When fully
seated, half of sleeve will fit over upright tube and half of sleeve will
extend above upright tube. Tighten socket head cap screw to secure
sleeve to upright tube (do not overtighten).
4. Press composite top tube assembly and shim (#926) onto end of extension
tube (#927). Tighten socket head cap screws (do not overtighten).
5. Swing sleeve assembly’s quick release lever to the open position. Insert
extension tube into sleeve, set desired working height, and swing lever
to closed position. At least 8” (20 cm) of extension tube must be inserted
into sleeve and upright tube. If tension of quick release is not adequate
to securely hold extension tube, swing lever open, tighten nut of quick
release, and swing the lever to closed position.
Note:To avoid personal injury and/or damage to repair stand or bike, always
remove bike from repair stand before making any height adjustments.
PCS-EXT Instructions/Instructions/Anleitung/Instrucciones

5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
PARK TOOL CO.
PCS-EXT Parts/Pièces/Teile/Partes
© 2018 ParkTool Co.
PARKTOOL® and the color BLUE are registered trademarks of ParkTool Co.
08/18
#927
Extension
Tube
#928A
Sleeve Assembly
Upright
Tube
Composite
Top Tube
#926
Shim
