Wireless Force-Acceleration Sensor (PS-3202)
Introduction
The Wireless Force-Acceleration Sensor is a combination
wireless and USB sensor that connects to a computer or tablet
device through Bluetooth, and can also connect to a computer
using the included USB cable. The sensor measures force up to
±50 newtons (N), acceleration up to ±16 g (where 1 g is equal to
9.8 m/s2), and angular rotation rate up to ±2000 degrees per
second (dps). The sensor measures force as a push or pull
along its x-axis and measures acceleration in three dimensions
(x, y, and z). PASCO Capstone or SPARKvue can show the
resultant acceleration. The sensor uses a micro-
electromechanical system (MEMS) device.
The sensor is designed to optimize the battery usage time.
Since each sensor has a unique device ID number, more than
one can be connected to a computer or tablet at the same time.
Features
Battery Status LED
Indicates the charging status of the battery.
Battery LED Status
Red blink Low power
Yellow ON Charging
Green ON Fully charged
Bluetooth Status LED
Indicates the status of the sensor’s Bluetooth connection.
Bluetooth LED Status
Red blink Ready to pair
Green blink Connected
Yellow blink Remotely logging data
For information on remote data logging, see the PASCO
Capstone or SPARKvue online help.
NOTE: The Bluetooth Status LED is disabled
when connecting the sensor to a computer
using a USB cable.
Device ID
Use this to identify the sensor when connecting via
Bluetooth.
Rod Clamp Thumbscrew
Use this to mount the sensor to a rod or rod stand.
ON/OFF button
Press to turn the sensor on. Press and briefly hold to turn
the sensor off. Note that the sensor automatically turns
itself on when connected to a computer via USB. To
preserve battery, the sensor puts itself to sleep after several
minutes of inactivity if not connected.
Micro USB port
Use with the included micro USB cable to connect the
sensor to a USB charger. The port and cable can also be
used to directly connect the sensor to a computer without
the use of Bluetooth. This connection method is not
supported by iOS.
Bumper attachment
Attach this to the threaded hole on the front of the sensor
when recording measurements from collisions or impacts.
Hook attachment
Attach this to the threaded hole on the front of the sensor
when recording measurements from forces pulling on the
sensor.
Cart/track thumbscrew
Use this to mount the sensor to a PASCO cart.
Micro USB cable (not pictured)
Initial step: Charge the battery
Charge the battery by connecting the micro USB port to any
standard USB charger. The Battery Status LED is solid yellow
while charging. When fully charged, the LED changes to solid
green.
Product Guide | 012-14710D
1

Get the software
You can use the sensor with SPARKvue or PASCO Capstone
software. If you’re not sure which to use, visit
pasco.com/products/guides/software-comparison.
SPARKvue is available as a free app for Chromebook, iOS, and
Android devices. We offer a free trial of SPARKvue and
Capstone for Windows and Mac. To get the software, go to
pasco.com/downloads or search for SPARKvue in your device’s
app store.
If you have installed the software previously, check that you have
the latest update:
SPARKvue
Go to Main Menu > Check for Updates
PASCO Capstone
Go to Help > Check for Updates.
Check for a firmware update
SPARKvue
1. Press the power button until the LEDs turn on.
2. Open SPARKvue.
3. Select Sensor Data on the Welcome Screen.
4. From the list of available devices, select the sensor that
matches your sensor’s device ID. A notification appears if a
firmware update is available. Click Yes to update the
firmware.
5. Close SPARKvue once the update is complete.
PASCO Capstone
1. Press and hold the power button until the LEDs turn on.
2. Open PASCO Capstone.
3. Click Hardware Setup.
4. From the list of available devices, select the sensor that
matches your sensor’s device ID. A notification appears if a
firmware update is available. Click Yes to update the
firmware.
5. Close Capstone once the update is complete.
Set up the software
SPARKvue
Connecting the sensor to a tablet or computer via
Bluetooth:
1. Turn on the Wireless Force-Acceleration Sensor. Check to
make sure the Bluetooth Status LED is blinking red.
2. Open SPARKvue, then click Sensor Data.
3. From the list of available wireless devices on the left, select
the device which matches the device ID printed on your
Wireless Force-Acceleration Sensor.
Connecting the sensor to a computer via micro USB cable:
1. Open SPARKvue, then click Sensor Data.
2. Connect the provided micro USB cable from the micro USB
port on the sensor to a USB port or powered USB hub
connected to the computer. The sensor should
automatically connect to SPARKvue.
Collecting data using SPARKvue:
1. Select the measurements you intend to record from the
Select Measurements for Templates menu by clicking the
check box next to the relevant measurements' names.
2. Click Graph in the Templates section to open the
Experiment Screen. The graph’s axes will auto-populate
with the selected measurements.
3. Click Start to begin recording data.
PASCO Capstone
Connecting the sensor to a computer via Bluetooth:
1. Turn on the Wireless Force-Acceleration Sensor. Check to
make sure the Bluetooth Status LED is blinking red.
2. Open Capstone, then click Hardware Setup in the
Tools palette.
3. From the list of Available Wireless Devices, click the
device which matches the device ID printed on your
Wireless Force-Acceleration Sensor.
Connecting the sensor to a computer via micro USB cable:
1. Open Capstone. If desired, open Hardware Setup to
check the connection status of the sensor.
2. Connect the provided micro USB cable from the micro USB
port on the sensor to a USB port or powered USB hub
connected to the computer. The sensor should
automatically connect to Capstone.
Collecting data using Capstone:
1. Double-click the Graph icon in the Displays palette to
create a new blank graph display.
2. To assign measurements to the graph’s axes, click each
<Select Measurement> box and select an appropriate
measurement from the list.
3. Click Record to begin collecting data.
Wireless Force-Acceleration Sensor | PS-3202
2

Zero (tare) the sensor
At the beginning of an experiment, the measurement from the
sensor may not be zero when the force or acceleration is
actually zero. This is a normal behavior that is corrected when
you zero (or tare) the sensor using PASCO Capstone or
SPARKvue. For information on zeroing the sensor, check the
PASCO Capstone or SPARKvue online help and search for
"Zero sensor".
IMPORTANT: Zeroing of the acceleration
sensor should only be done if you are only
measuring the acceleration on a single axis, as
zeroing the acceleration sensor will cause the
other two acceleration measurements to no
longer be accurate.
Set up the hardware
Connecting bumper and hook attachments
Screw the bumper or hook attachment into the threaded hole on
the front end of the sensor, as shown below. This will connect
the attachment to the force sensor, allowing force values to be
properly recorded.
Direction of acceleration sensitivity
The acceleration sensing units inside the sensor are oriented so
that the lines of greatest sensitivity follow the x, y, and zarrows
indicating the direction of acceleration.
Figure 1. The axes of greatest acceleration sensitivity.
In the orientation shown in Figure 1, the x-axis direction is
'along' the axis of the sensor. The y-axis direction is
perpendicular to the axis of the sensor and parallel to the label
on top of the sensor. The z-axis direction is perpendicular to the
label on top of the sensor.
Calibration
The Wireless Force-Acceleration Sensor is calibrated at the
factory. Further calibration is not usually necessary, especially if
you are measuring a change in force, acceleration, or rotational
motion, rather than absolute values of any of these quantities.
However, it is possible to calibrate the sensor using PASCO
Capstone or SPARKvue. For information on this procedure, see
the Capstone or SPARKvue online help.
Mounting the sensor
Mounting the sensor on a rod
Slide the sensor onto a rod and secure it in place with the Rod
Clamp Thumbscrew, as shown below.
Mounting the sensor on a PASCO cart
1. Insert the included Cart/Track Thumbscrew through the
hole in the sensor labeled Cart.
2. Place the sensor onto the top surface of the PASCO cart.
Screw the thumbscrew into the threaded hole on the top of
the cart, securing the sensor in place.
Mounting the sensor on a Track Bracket
1. Mount the Force Sensor Track Bracket (ME-6622) into the
T-slot on a PASCO track.
2. Position the Wireless Force-Acceleration Sensor
underneath the Force Sensor Track Bracket, with the label
facing up. Ensure that the thumbscrew on the bracket is
directly over the hole in the sensor labeled IDS Bracket, as
shown in the figure on the next page.
Product Guide | 012-14710D
3

3. Insert the thumbscrew into the hole labeled IDS Bracket.
Tighten the thumbscrew to secure the sensor in place.
About the battery
The Wireless Force-Acceleration Sensor’s battery is partially
charged at the factory. If the battery status LED blinks red, use
the micro USB cable to connect the sensor to a USB port or
USB charger.
Maximizing battery life
Two factors that affect battery life are the storage temperature
and the number of charge cycles. Therefore, to maximize battery
life, avoid storing the sensor in very cold or very hot
environments, and disconnect the sensor from its charger once
it has been fully charged.
Troubleshooting
•If the Wireless Force-Acceleration Sensor loses Bluetooth
connection and will not reconnect, try cycling the ON
button. Press and briefly hold the button until the LEDs
blink in sequence, then release the button. Start the sensor
in the usual way.
•If the sensor stops communicating with the computer
software or tablet application, try restarting the software or
application. If the problem persists, press and hold the ON
button for 10 seconds, then release the button and start the
sensor in the usual way.
•If the previous steps do not fix a connection problem, turn
Bluetooth off and then back on for your computer or tablet,
then retry.
Software help
The SPARKvue and PASCO Capstone Help provide additional
information on how to use this product with the software. You
can access the help within the software or online.
SPARKvue
Software: Main Menu > Help
Online: help.pasco.com/sparkvue
PASCO Capstone
Software: Help > PASCO Capstone Help
Online: help.pasco.com/capstone
Specifications and accessories
Visit the product page at pasco.com/product/PS-3202 to view
the specifications and explore accessories. You can also
download experiment files and support documents from the
product page.
Experiment files
Download one of several student-ready activities from the
PASCO Experiment Library. Experiments include editable
student handouts and teacher notes. Visit
pasco.com/freelabs/PS-3202.
Technical support
Need more help? Our knowledgeable and friendly Technical
Support staff is ready to answer your questions or walk you
through any issues.
Chat pasco.com
Phone [phone] x1004 (USA)
[phone] (outside USA)
Email [e-mail]
Regulatory information
Limited warranty
For a description of the product warranty, see the Warranty and Returns page at
www.pasco.com/legal.
Copyright
This document is copyrighted with all rights reserved. Permission is granted to non-
profit educational institutions for reproduction of any part of this manual, providing
the reproductions are used only in their laboratories and classrooms, and are not
sold for profit. Reproduction under any other circumstances, without the written
consent of PASCO scientific, is prohibited.
Trademarks
PASCO and PASCO scientific are trademarks or registered trademarks of PASCO
scientific, in the United States and in other countries. All other brands, products, or
service names are or may be trademarks or service marks of, and are used to
identify, products or services of, their respective owners. For more information visit
www.pasco.com/legal.
Product end-of-life disposal
This electronic product is subject to disposal and recycling regulations that
vary by country and region. It is your responsibility to recycle your
electronic equipment per your local environmental laws and regulations to
ensure that it will be recycled in a manner that protects human health and
the environment. To find out where you can drop off your waste equipment
for recycling, please contact your local waste recycle or disposal service, or the
place where you purchased the product. The European Union WEEE (Waste
Electronic and Electrical Equipment) symbol on the product or its packaging
indicates that this product must not be disposed of in a standard waste container.
CE statement
This device has been tested and found to comply with the essential requirements
and other relevant provisions of the applicable EU Directives.
FCC statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.
Battery disposal
Batteries contain chemicals that, if released, may affect the environment
and human health. Batteries should be collected separately for recycling
and recycled at a local hazardous material disposal location adhering to
your country and local government regulations. To find out where you can
drop off your waste battery for recycling, please contact your local waste disposal
service, or the product representative. The battery used in this product is marked
with the European Union symbol for waste batteries to indicate the need for the
separate collection and recycling of batteries.
Wireless Force-Acceleration Sensor | PS-3202
4
