Plura PBM-4K-H Series User manual

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H
"COMPREHENSIVE AND AFFORDABLE 4K/UHD" Series
PBM-209-4K-H
PBM-210-4K-H
PBM-217-4K-H
PBM-221-4K-H
PBM-224-4K-H
PBM-232-4K-H
PBM-247-4K-H
PBM-255-4K-H
PBM-221-4K-H PBM-224-4K-H
PBM-217-4K-H
PBM-210-4K-H

Re-imagine Beyond Technology [e-mail]
Table of Contents
PRECAUTION ------------------------------------------------------------------------------------------------------------- 5
1. OVERVIEW----------------------------------------------------------------------------------------------------------- 8
2. ADVANCED FEATURES --------------------------------------------------------------------------------------------- 8
3. FUNCTIONAL EXPLANATION OF EACH PART-------------------------------------------------------------------- 9
1. FRONT PANEL -------------------------------------------------------------------------------------------------------- 9

PBM-224-4K-H -------------------------------------------------------------------------------------------------- 9
 Front Keys Arrangements -------------------------------------------------------------------------------------- 9
 Front Keys Operations ----------------------------------------------------------------------------------------- 10
 USB Port-------------------------------------------------------------------------------------------------------- 10
 Speaker Out---------------------------------------------------------------------------------------------------- 10
2. REAR PANEL -------------------------------------------------------------------------------------------------------- 11

Connection Details--------------------------------------------------------------------------------------------- 11
 DC Battery IN -------------------------------------------------------------------------------------------------- 11
 RJ-45 – GPI, Control LAN 1 & Control LAN 2 (Ember+) ---------------------------------------------------- 11
 Interface description------------------------------------------------------------------------------------------- 12
4. MENU OVERVIEW -------------------------------------------------------------------------------------------------12
1. TO SHOW AND REMOVE THE MENU ---------------------------------------------------------------------------------- 12
2. TO GO TO THE NEXT LEVEL ------------------------------------------------------------------------------------------- 12
3. TO GO BACK TO THE PREVIOUS LEVEL --------------------------------------------------------------------------------- 13
4. TYPICAL MENU OPERATION ------------------------------------------------------------------------------------------ 13
5. BASIC OPERATION-------------------------------------------------------------------------------------------------13
1. TURNING ON THE MONITOR ----------------------------------------------------------------------------------------- 13
2. VOLUME ADJUSTMENT----------------------------------------------------------------------------------------------- 13
6. ON SCREEN MENUS SELECTION AND ADJUSTMENT----------------------------------------------------------14
1. HOW TO ADJUST THE OSD SCREEN ---------------------------------------------------------------------------------- 14
7. SELECT VIDEO INPUT --------------------------------------------------------------------------------------------- 15
1. HOW TO SELECT VIDEO SOURCE BY OSD----------------------------------------------------------------------------- 15
8. PICTURE MENU OPTIONS ----------------------------------------------------------------------------------------15
1. ADJUST ------------------------------------------------------------------------------------------------------------- 16
Operating Instructions
PBM-4K-H SERIES
2

Re-imagine Beyond Technology [e-mail]
2. COLOR TEMPERATURE CONTROL-------------------------------------------------------------------------------------- 16
3. SCAN--------------------------------------------------------------------------------------------------------------- 16
4. ASPECT RATIO ------------------------------------------------------------------------------------------------------ 16
5. MONO/BLUE ONLY ------------------------------------------------------------------------------------------------- 17
6. PEAKING FILTER ----------------------------------------------------------------------------------------------------- 17
7. FALSE COLOR ------------------------------------------------------------------------------------------------------- 17
8. HDR MODE -------------------------------------------------------------------------------------------------------- 18
9. CAMERA LOG ------------------------------------------------------------------------------------------------------- 18
9. AUDIO MENU OPTIONS ------------------------------------------------------------------------------------------ 18
1. SDI / SFP OUTPUT ------------------------------------------------------------------------------------------------- 18
2. LEVEL METER ------------------------------------------------------------------------------------------------------- 19
3. VOLUME ------------------------------------------------------------------------------------------------------------ 20
10. MARKER MENU OPTIONS ----------------------------------------------------------------------------------------20
1. MARKER & USER MARKER------------------------------------------------------------------------------------------- 21
2. SAFETY AREA ------------------------------------------------------------------------------------------------------- 21
3. CENTER MAKER ----------------------------------------------------------------------------------------------------- 21
4. MARKER WIDTH----------------------------------------------------------------------------------------------------- 21
5. MARKER COLOR----------------------------------------------------------------------------------------------------- 21
6. PRESET1 & PRESET2 ------------------------------------------------------------------------------------------------ 22
11. GPI MENU OPTIONS ----------------------------------------------------------------------------------------------22
1. GPI CONTROL & GPI#---------------------------------------------------------------------------------------------- 22
12. SETUP MENU OPTIONS -------------------------------------------------------------------------------------------23
1. FACTORY DEFAULT --------------------------------------------------------------------------------------------------- 23
2. FUNCTION 1 ~6 ---------------------------------------------------------------------------------------------------- 23
3. ONSCREEN DISPLAY ------------------------------------------------------------------------------------------------ 24

OSD Option ---------------------------------------------------------------------------------------------------- 24
 Time code ------------------------------------------------------------------------------------------------------ 24
 Under Monitor Display (color: Tally R/G mode action ) ----------------------------------------------------- 25
 SDI Signal State ------------------------------------------------------------------------------------------------ 25
4. ADVANCED --------------------------------------------------------------------------------------------------------- 25

Information----------------------------------------------------------------------------------------------------- 25
 Control --------------------------------------------------------------------------------------------------------- 25
 Screen Control ------------------------------------------------------------------------------------------------- 26
 Config LAN1 --------------------------------------------------------------------------------------------------- 26
Operating Instructions
PBM-4K-H SERIES
3

Re-imagine Beyond Technology [e-mail]
 Config LAN2/Ember+------------------------------------------------------------------------------------------ 26
 Protocol Setting------------------------------------------------------------------------------------------------ 26
 Set ID----------------------------------------------------------------------------------------------------------- 26
 Fan Control----------------------------------------------------------------------------------------------------- 27
5. CAPTION FOR NORTH AMERICAN MARKET---------------------------------------------------------------------------- 27
6. OUTPUT RANGE----------------------------------------------------------------------------------------------------- 27
7. VIDEO RANGE------------------------------------------------------------------------------------------------------- 28
8. WAVEFORM --------------------------------------------------------------------------------------------------------- 28
13. OSD TREE -----------------------------------------------------------------------------------------------------------29
1. VIDEO -------------------------------------------------------------------------------------------------------------- 30
2. AUDIO-------------------------------------------------------------------------------------------------------------- 31
3. MARKER ------------------------------------------------------------------------------------------------------------ 32
4. GPI ---------------------------------------------------------------------------------------------------------------- 33
5. SETUP -------------------------------------------------------------------------------------------------------------- 34
Operating Instructions
PBM-4K-H SERIES
4

Re-imagine Beyond Technology [e-mail]
•PRECAUTION
Before operating this unit, please read this manual carefully.
WARNING:
To reduce the risk of any electric shock, please do not remove the back cover. No user serviceable parts inside. Refer any service matters to
qualified service personnel. To prevent fire or shock hazard, do not expose the rear of the set to rain or moisture. Do not rub, clean or hit the
Active Matrix LCD with object that may scratch, mark, or damage the Active Matrix LCD permanently.
CAUTION:
Unauthorized tampering with the inside of the monitor invalidates the warranty.
The manufacturer shall not warrant for any damage caused by improper maintenance and/or repair or work by third parties.
Important safeguards for you and your new product:
Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or
fire hazards. Please read and observe the following safety points when installing and using your new product and save them for future
reference.
1. Read Instructions
2. Follow Instructions
All operating and use instructions should be followed.
3. Retain Instructions
The safety and operating instructions should be retained for future reference.
4. Notice Warnings
All warnings on the product and in the operating instructions should be adhered to.
5. Cleaning
Disconnect the unit from the mains before cleaning the unit. Do not use abrasive cleaners. Use a damp
cloth ONLY for cleaning.
6. Water and Moisture
Operating Instructions
PBM-4K-H SERIES
5

Re-imagine Beyond Technology [e-mail]
Do not use this product near water surface.
7. Transporting Product
This product should be moved with care. Quick stops, excessive force and uneven surfaces may cause the
product damages.
8. Accessories
Do not use accessories not recommended by PLURA Inc. as they may cause hazards.
9. Ventilation
Do not block any of the ventilation openings.
Install in accordance with the manufacturer’s instructions.
10. Power Sources
This product should be operated only from the type of power source indicated on the marking label. If you
are not sure of the type of power supply, consult your power supply company.
11. Power Lead Polarization
This product is equipped with a three-wire grounding-type cord. This is a safety feature. Do not use any
other type power cord.
12. Power Cord Protection
Power-supply cords should be dressed so that they are not likely to be pulled or pinched by items placed
upon or against them.
13. Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet. This will prevent possible damage to the product
due to lightning and power-line surges.
14. Grounding the product
This product must be grounded properly to comply with the safety regulations in the country of use. If you
are unsure of these regulations, please consult a qualified electrician.
15. Servicing
Do not attempt to service this product by yourself as opening or removing covers may expose you to
dangerous voltages or other hazards. Refer all servicing to qualified service personnel.
16. Damage Service Required
Isolate this product from the mains and refer to qualified service personnel under the following conditions:
A. If the power-supply cord or plug is damaged.
B. If the front LCD front has been damaged.
C. If the product does not operate correctly by following the operating instructions. Use only the user
control buttons any improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal operation.
D. If the product has been dropped.
Operating Instructions
PBM-4K-H SERIES
6

Re-imagine Beyond Technology [e-mail]
E. If the product exhibits a distinct change in performance.
17. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition and the warranty seal is provided.
18. Mounting
The product should be mounted on a wall as recommended in the instructions.
19. Power
This set operates on an AC supply; the voltage is as indicated on the label on the Manual. This appliance
must be earthed at all times through the chassis as well as through the power lead.
Operating Instructions
PBM-4K-H SERIES
7

Re-imagine Beyond Technology [e-mail]
1.OVERVIEW
THE NEW PBM-4K-H AFFORDABLE AND COMPREHENSIVE SERIES.
The PBM-4K-H series is our latest portfolio of 4K monitors that is capable to decode and preview a wide
range of signal standards in 4K, UHD, FHD and HD standards. The PBM-4K-H was introduced in alignment
with increased industry demand for an affordable yet comprehensive 4K monitor series. The PBM-4K-H
series is available in multiple sizes from 10 up to 55 inches, the Plura PBM-4K-H series bring the
exceptional built-in feature set Plura monitors are known for, maintaining quality and performance to give
production facilities an edge in Ultra HD monitoring.
2.Advanced FEATURES
The new PBM-4K-H has the following advanced features: -
1 x HDMI 1.4
1 x 12G, 6G, 3G, 1.5G
1 x 3G, 1.5G
1 x SFP Slot supporting 3G / 1.5 Standards
Supports up to 4096 x 2160 resolutions
HDR (High Dynamic Range) capabilities
PQ ( SMPTE ST 2084 ) & HLG ( Hybrid Log Gamma )
Ember+ Compliant, Ethernet & RS 232 Remote Control
RGB 12 Bit Digital Signal Processing
178° Viewing Angle Display
Gamma Selectable (0.8 – 3.0)
Color Temperature – User, VAR, Adjustable (11000K TO 3200K)
(ICAC) - Plura Intelligent Connection for Alignment & Calibration
3D LUT ( ITU-R BT 2020, Native, BT.709, SMPTE-C, EBU, NTSC, D-Cinema, 709)
Display Advanced Waveform & Vector Scope simultaneously with line select.
Operating Instructions
PBM-4K-H SERIES
8

Re-imagine Beyond Technology [e-mail]
3.Functional explanation of each part
1. Front Panel
PBM-224-4K-H
Front Keys Arrangements
Speaker
Front Key
LED
Tally LED
Headphone
USB IR
Operating Instructions
PBM-4K-H SERIES
9

Re-imagine Beyond Technology [e-mail]
Front Keys Operations
Key Name Operation
STANDBY ►Power ON/OFF Button.
SDI 1 ►Select SDI 1.
SDI 2 ►Select SDI 2.
HDMI ►Select HDMI.
SFP ►Select SFP1, SFP2.
COMPONENT ►Select COMPONENT.
CVBS ►Select CVBS / Composite.
F DISPLAY ►Display Functions settings.
F1 ~ F6
►Executes functions of user selected i.e.
Undefined, Aspect, Audio LV Meter, Audio Group, Audio Channel, H/V Delay,
Mono/Blue only, Gamma select, Marker size, Safety Maker Size, Marker Preset1,
Marker Preset2
MENU
►Activates main OSD menu.
►Navigates higher menu in main OSD menu.
► ► Exits OSD menu.
UP
►Increases speaker volume.
►Increases values of certain menu in main OSD menu.
►Executes function (by OSD help commands) in main OSD menu.
DOWN
►Decreases speaker volume.
►Decreases values of user menu in main OSD menu.
►Executes function (by OSD help commands) in main OSD menu.
SEL/INPUT ►Activates and selects OSD and input source.
►Changes input source.
►Executes functions (by OSD help commands) in main OSD menu.
Adjust
►Adjust Menu parameters (Volume -> Brightness -> Contrast -> Color -> Sharpness-> &
Tint)
►Turn Right = ‘UP' button
►Turn Left = ‘DOWN' button
USB Port
- This port is used for Firmware Upgrade.
Speaker Out
Interface Description
Speaker R out 8 ohm±15%, Max 5W + 5W
Speaker L out
Operating Instructions
PBM-4K-H SERIES
10

Re-imagine Beyond Technology [e-mail]
2. Rear Panel
Connection Details
DC Battery IN
PIN NO Description
1 GND
2 , 3
4 12V
RJ-45 – GPI, Control LAN 1 & Control LAN 2 (Ember+)
Remote PIN Assignment
8 PIN COMMON(GND) 4 PIN GPI 4 PORT
7 PIN GPI 7 PORT
(STAND BY/POWER ON/OFF) 3 PIN GPI 3 PORT
6 PIN GPI 6 PORT 2 PIN GPI 2 PORT
5 PIN GPI 5 PORT 1 PIN GPI 1 PORT
1
23
4
DC IN 12V DC IN 12V for PBM-210-4K-H, PBM-217-
4K-H, PBM-221-4K-H & PBM-224-4K-H
GPI CONTROL LAN 1 CONTROL LAN 2 RJ 45 Jack Face
Ember+
Operating Instructions
PBM-4K-H SERIES
11

Re-imagine Beyond Technology [e-mail]
Interface description
Interface Description
SDI 1 IN 12G/3G/HD/SD SDI
SDI 1 OUT
SDI 2 IN 3G/HD/SD SDI
SDI 2 OUT
SPF SFP Module x 1(SFP1/SFP2 3G Input)
HDMI High Definition Multimedia Input
RS232C Auto color calibration
USB Firmware Upgrade
Y/Cb/Cr COMPONENT Input
Composite CVBS Input
Audio In Y/Cb/Cr, CVBS Audio Input
Audio Out AUDIO MONITOR OUT
GPI GPI 1 ~ 7 Control Port
CONTROL LAN1 Network System Control
CONTROL LAN2 Network System Control (EMBER+)
AC IN AC90V ~ 240V, 50Hz/60Hz
DC IN DC 12V PBM-210-4K-H, PBM-217-4K-H, PBM-221-4K-H & PBM-224-4K-H
4. MENU OVERVIEW
In this system menu, there are several ways to maneuver the menu settings.
Most menus consist of three levels to select the necessary option, but some settings require greater depth.
If you press the MENU button, the first and second level of the menu system will appear on the monitor
screen. The third level can be displayed by pressing SEL/INPUT. If a menu has more than three levels,
the pop-up dialogue box will be displayed as the fourth or fifth level.
1. To show and remove the Menu
Press the MENU button to display the menu. Press the MENU button again to hide the menu.
2. To go to the next level
Press SEL/INPUT button.
Contact Point Switch
Control Terminal: 1 ~ 7 Pin
GND Terminal: 8 Pin of RJ-45
Operating Instructions
PBM-4K-H SERIES
12

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H SERIES
13
3. To go back to the previous level
Press MENU button
4. Typical Menu Operation
1. Press MENU button: The main menu will appear.
2. Use UP/DOWN button to select the desired menu option (icon).
3. While the desired menu option is selected, press SEL/INPUT to move to the second level.
4. Use UP/DOWN button to select the second menu option.
5. Press SEL/INPUT to move to the third level: Some menu options require additional steps.
6. Press MENU to return to the previous menu to return to monitor viewing.
5.BASIC OPERATION
1. Turning On the Monitor
1. Firstly, make sure you have connected the AC power cord or DC XLR connector. The monitor will switch to standby
or power on mode. If the monitor is in standby mode, press the ST-BY button to turn on the monitor.
2. Select the source by using SEL/INPUT button on Keypad in front of monitor
2. Volume Adjustment
1. Press the ADJUST button on Keypad.
2. Press the MENU button on Keypad.
- OSD Audio menu -> Volume menu.
Operating Instructions
PBM-4K-H SERIES
13

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H SERIES
14
6.On Screen Menus Selection and Adjustment
1. How to adjust the OSD screen
1. Press the MENU button and then UP/DOWN button to select each menu.
2. Press the SEL/INPUT button and then use UP/DOWN (SEL/INPUT)/MENU button to display the available
menu.
• The monitor's OSD (On Screen Display) may differ slightly from what is shown in this manual.
Operating Instructions
PBM-4K-H SERIES
14

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H SERIES
15
7.SELECT VIDEO INPUT
1. How to Select Video Source by OSD
1. Press the SET/INPUT button and then UP/DOWN button to select the required video source.
2. Press the SET/INPUT button to go to select the desired video source.
3. If Input Name is enabled, The SET/INPUT button button will show the input name previously programmed
instead of the source name.
8.PICTURE MENU OPTIONS
Operating Instructions
PBM-4K-H SERIES
15

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H SERIES
16
1. Adjust
- Adjust the values of Brightness, Contrast, Color, Tint and Sharpness
directly from -50 to 50
2. Color Temperature Control
- For Setting the Color temperature or adjusting RGB gain value
- User (User setting RGB gain value), VAR(3200K ~ 9300K), Often used value( 9300K, 6500K, 5400K,3200K) and 3D
LUT Calibration value(D-Cinema 6302K)
- Color Space: Native/BT.709/D-Cinema
3. Scan
- Select desired scan mode.
- Zero Scan: 100% of the Input pixel resolution and fits the selected
display size
- Pixel to Pixel: Video input will match the video display resolution (NO
Scaling). If input resolution is higher than panel resolution, the video
will be downscaled to match the panel resolution.
4. Aspect Ratio
- For setting the aspect ratio.
- Full Screen: The video input will be scaled to the max panel resolution.
- Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1: The video will displayed with based on the selected aspect ratio.
- Function key can be assigned to the aspect ratio and will be rotating through this sequence, Pixel to Pixel, Full
Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1
Operating Instructions
PBM-4K-H SERIES
16

Re-imagine Beyond Technology [e-mail]
Operating Instructions
PBM-4K-H SERIES
17
5. Mono/Blue Only
- Mono color: For selecting monochrome images.
- Blue Only: Blue Video channel is enabled
6. Peaking Filter
-Peaking Filter: Peaking Filter On/Off.
-Peaking Color: Red/Blue/White/Violet.
-Peaking Level: 0~100.
7. False Color
- False Color on/off
Operating Instructions
PBM-4K-H SERIES
17

Re-imagine Beyond Technology [e-mail]
8. HDR Mode
- ST 2084-300 / ST 2084-1000 / ST 2084-10000 / HLG
9. Camera Log
- Off, SLog3 To LC-709,Slog3 To LC-709TypeA, Slog3 To Slog2-709,
Slog3 To Cine+709, Slog2 To LC-709, Slog To LC-709TypeA, Slog2 To
Slog2-709, Slog2 To Cine+709, User
- Import User Log: User may import a custom log LUT from a USB memory stick to the monitor.
The saved LUT will be defined as User.
If you insert the USB memory stick which contains the user log data to the monitor, push Enter in [Import Log Data]
menu, the data will be saved to the monitor.
The extension name of the LUT file should be " ***.cube” .
9.AUDIO MENU OPTIONS
1. SDI / SFP Output
Operating Instructions
PBM-4K-H SERIES
18

Re-imagine Beyond Technology [e-mail]
- Select primary or secondary audio group to extract. (Group 1~4)
- Audio output channel source select. (Channel1~4, Channel1/2, Channel3/4, off)
2. Level Meter
- Display the audio level meter on screen in SDI input.
-Pair: Respectively By Audio Pair (L&R) display
-Group: Respectively By Audio Group display
- Level Meter Scale mode selects. (BBC / EBU / VU / NORDIC / DIGITAL / DIN / EXPAND DIN)
Operating Instructions
PBM-4K-H SERIES
19

Re-imagine Beyond Technology [e-mail]
3. Volume
- Adjust the speaker or headphone Volume level. (0~32)
10. Marker MENU OPTIONS
Operating Instructions
PBM-4K-H SERIES
20
