•OVERVIEW
The Plura PBM-4K series is a multi-format 4K/UHD capable monitor series. The Plura PBM-4K is a great
tool for all UHD/4K, 3G broadcast systems and all other wide-range industries. The PBM-4K series was
designed and engineered for simple operation and future flexibility. The platform is built around a
powerful FPGA chipset. The core of this platform is based on fully programmable architecture. Future
proof expansion (i.e. additional features and functionalities) can and will be implemented in the field via
the Ethernet interface.
The PBM-4K series comes in multiple sizes 17”, 24”, 32”, 43”, 55” & 65” & 84”, all sizes offer the extensive
and well-know Plura prominent features.
PBM-4K Series, which supports up to 4096 x 2160 resolutions, focuses on delivering the highly detailed,
accurate color representation and stunning picture consistency that high-end production applications
require. The PBM-4K series offers HDR Display capabilities supporting PQ (ST-2084) & HLG standards.
The Plura PBM-4K Series, will support SMPTE 2082 and other earlier industry standards, 2 x 12G/3G/HD-
SDI inputs with active loop, 1 x SFP slot to support multiple IP & fiber I/O standards, 1 x HDMI 2.0, in
addition to all other legacy I/O.
•ADVANCED FEATURES
The new PBM-4K has the following advanced features:-
1 x HDMI 2.0
2 x 12G, 6G, 3G, 1.5G
1 x SFP Slot supporting Multiple Standards
Quad 3G SQ and 2SI with 4KXpress
10 bit panel color depth
Supports up to 4096 x 2160 resolutions
HDR (High Dynamic Range) capabilities
PQ ( SMPTE ST 2084 ) & HLG ( Hybrid Log Gamma )
Side by side HDR / SDR mode
RGB 12 Bit Digital Signal Processing
178° Viewing Angle Display
Gamma Selectable (0.8 – 3.0)
Color Temperature – User, VAR, Adjustable (11000K TO 3200K)
(ICAC) - Plura Intelligent Connection for Alignment & Calibration
3D LUT ( ITU-R BT 2020, Native, BT.709, SMPTE-C, EBU, NTSC, D-Cinema, 709)
Display Advanced Waveform & Vector Scope simultaneously with line select.
Operating Instructions
PBM-4K SERIES
8

Re-imagine Beyond Technology [e-mail]
Various and User defined Markers Display, Safe Area
Programmable 6 User Front Pushbutton Controls & GPI
Closed Caption (608/708) – North American Market
Cutting edge De-interlacing and Scaling Technology
Fast Response Time for high motion video
Internal Monitor Display (IMD)
Ethernet & RS232 Remote Control
Underscan / Overscan / Normal / Zoom
Pixel to Pixel Mode, Tally, DC Operation
False Color and Peaking Filter / Focus Assist
Video Range test with adjustable Y & C values
Display LTC & DVITC time code with line select
Embedded Audio Input, Digital Audio Decoding
Internal Pattern Generator and Wall Control System
Built In Stereo Speaker, 16 CH Audio Metering Display
Operating Instructions
PBM-4K SERIES
9

Re-imagine Beyond Technology [e-mail]
Functional explanation of each part
1. Front Panel
PBM-224-4K
Front Keys Arrangements
Speaker
Front Key
LED
Tally LED
Headphone
Operating Instructions
PBM-4K SERIES
10

Re-imagine Beyond Technology [e-mail]
Front Keys Operations
Key Name Operation
STANDBY ►Power ON/OFF Button.
SDI 1 ► Select SDI 1.
SDI 2 ► Select SDI 2.
QUAD ► Select QUAD.
2SI ► Select 2SI.
HDMI ► Select HDMI.
SFP ► Select SFP.
F DISPLAY ► Display Functions settings.
F1 ~ F6
► Executes user defined functions i.e.
Undefined, Aspect, Audio LV Meter, Audio Group, Audio Channel, H/V Delay,
Mono/Blue only, Gamma select, Marker size, Safety Maker Size, Marker Preset1,
Marker Preset2.
MENU
►Activates main OSD menu.
►Navigates higher menu levels in main OSD menu.
►►Exit OSD menu.
UP
►Increases speaker volume.
►Increases values for certain menu functions.
►Executes function (by OSD help commands) in main OSD menu.
DOWN
►Decreases speaker volume.
►Decreases values for certain menu functions.
►Executes function (by OSD help commands) in main OSD menu.
SEL/INPUT ►Activates and select input source.
►Changes input source.
►Executes functions (by OSD help commands) in main OSD menu.
Adjust
► Adjust Menu parameters (Volume -> Brightness -> Contrast -> Color -> Sharpness-> &
Tint)
► Turn Right = to UP button
► Turn Left = to DOWN button
Front panel LED Operations
- Stand-by mode = LED is Red
Speaker Out
Interface Description
Speaker R out 8 ohm±15%, Max 2W + 2W
Speaker L out
Operating Instructions
PBM-4K SERIES
11

Re-imagine Beyond Technology [e-mail]
2. Rear Panel
I/O Details
DC Battery IN
PIN NO Description
1 GND
2 , 3
4 12-24V
RJ-45 Connections
1
23
4
DC IN 12V PBM-217-4K ONLY
DC IN 24V PBM-224-4K & PBM-324-4K ONLY
GPI CONTROL LAN 1 RJ 45 Jack FaceCONTROL LAN 2
Ember+
Operating Instructions
PBM-4K SERIES
12

Re-imagine Beyond Technology [e-mail]
- Firmware Upgrade/ System Controller / Ember+ (Ethernet) & GPI
Remote PIN Assignment
8 PIN COMMON(GND) 4 PIN GPI 4 PORT
7 PIN GPI 7 PORT
(STAND BY/POWER ON/OFF) 3 PIN GPI 3 PORT
6 PIN GPI 6 PORT 2 PIN GPI 2 PORT
5 PIN GPI 5 PORT 1 PIN GPI 1 PORT
Interface description
Interface Description
SDI 1 IN 12G/QUAD 3G/2SI/3G/HD SDI Input 1
SDI 2 IN 12G/QUAD 3G/2SI/3G/HD SDI Input 2
SDI 3 IN QUAD 3G/2SI SDI Input 3
SDI 4 IN QUAD 3G/2SI SDI Input 4
SDI 1 OUT 12G/QUAD 3G/2SI/3G/HD SDI Output 1
SDI 2 OUT 12G/QUAD 3G/2SI/3G/HD SDI Output 2
SDI 3 OUT QUAD 3G/2SI SDI Output 3
SDI 4 OUT QUAD 3G/2SI SDI Output 4
SFP SFP Module x 1(SFP 12G Input)
HDMI High Definition Multimedia Input
RS232C Auto color calibration
USB Firmware Upgrade
GPI GPI 1 ~ 7 Control Port
CONTROL LAN1 Network System Control
CONTROL LAN2 Network System Control (EMBER+)
AC IN AC90V ~ 240V, 50Hz/60Hz
DC IN DC 12V PBM-217-4K, DC 24V PBM-224-4K, PBM-324-4K
Control Terminal: 1 ~ 7 Pin
GND Terminal: 8 Pin of RJ-45
Contact Point
Switch
It is possible to attach
Operating Instructions
PBM-4K SERIES
13

Re-imagine Beyond Technology [e-mail]
•MENU OVERVIEW
In this system menu, there are several ways to maneuver the menu settings.
Most menus consist of three levels to select the necessary option, but some settings require greater
depth. If you press the MENU button, the first and second level of the menu system will appear on the
monitor screen. The third level can be displayed by pressing SEL/INPUT. If a menu has more than three
levels, the pop-up dialogue box will be displayed as the fourth or fifth level.
1. To show and remove the Menu
Press the MENU button to display the menu. Press the MENU button again to hide the menu.
2. To go to the next level
Press SEL/INPUT button.
3. To go back to the previous level
Press MENU button
4. Typical Menu Operation
1. Press MENU button: The main menu will be displayed.
2. Use UP/DOWN button to select the desired menu option (icon).
3. While the desired menu option is selected, press SEL/INPUT to move to the second level.
4. Use UP/DOWN button to select the second menu option.
5. Press SEL/INPUT to move to the third level: Some menu options require additional steps.
6. Press MENU to return to the previous menu to return to monitor viewing.
Operating Instructions
PBM-4K SERIES
14

Re-imagine Beyond Technology [e-mail]
•BASIC OPERATION
1. Turning On the Monitor
1. Firstly, make sure you have connected the AC power cord or DC XLR connector. The monitor will switch to
standby or power on mode. If the monitor is in standby mode, press the ST-BY button to turn on the monitor.
2. Select the source by using SEL/INPUT button on Keypad in front of monitor
2. Volume Adjustment
1. Press the ADJUST button on Keypad.
2. Press the MENU button on Keypad.
- OSD Audio menu -> Volume menu.
Operating Instructions
PBM-4K SERIES
15

Re-imagine Beyond Technology [e-mail]
•On Screen Menus Selection and Adjustment
1. How to adjust the OSD screen
1. Press the MENU button and then UP/DOWN button to select each menu.
2. Press the SEL/INPUT button and then use UP/DOWN (SEL/INPUT)/MENU button to display the
available menu.
• The monitor's OSD (On Screen Display) may differ slightly from what is shown in this manual.
Operating Instructions
PBM-4K SERIES
16

Re-imagine Beyond Technology [e-mail]
•SELECT VIDEO INPUT
1. How to Select Video Source by OSD
1. Press the SET/INPUT button and then UP/DOWN button to select the required video source.
2. Press the SET/INPUT button to select the desired video source.
3. If Input Name is enabled, The SET/INPUT button will show the input name previously programmed
instead of the source name.
Operating Instructions
PBM-4K SERIES
17

Re-imagine Beyond Technology [e-mail]
•VIDEO MENU OPTIONS
1. Adjust
- Adjust the values of Brightness, Contrast, Color, Tint and
Sharpness range from -50 to 50
2. Color Temperature Control
- For Setting the Color temperature or adjusting RGB gain value
- User (User setting RGB gain value), VAR(3200K ~ 9300K), Most common value ( 9300K, 6500K, 5400K,3200K) and
3D LUT Calibration value(D65 – 6504K/C-6774K/D-Cinema 6302K)
- Color Space: Native/BT.709/SMPTE-C/EBU/NTSC/D-Cinema/BT.2020
Operating Instructions
PBM-4K SERIES
18

Re-imagine Beyond Technology [e-mail]
3. Aspect Ratio
- For setting the aspect ratio.
- Pixel to Pixel: Video input will match the video display resolution (NO Scaling). If input resolution is
higher than panel resolution, the video will be downscaled to match the panel resolution.
- Full Screen: The video input will be scaled to the max panel resolution.
- Pixel to Pixel, Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1: The video will displayed with based on
the selected aspect ratio.
- Function key can be assigned to the aspect ratio and will be rotating through this sequence, Pixel to
Pixel, Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1
- AFD (Auto Format Direct) function can be turned ON or OFF
4. Mono/Blue Only
- Mono color: For selecting monochrome images.
- Blue Only: Blue Video channel is enabled
Operating Instructions
PBM-4K SERIES
19

Re-imagine Beyond Technology [e-mail]
5. Peaking Filter
-Peaking Filter: Peaking Filter On/Off.
-Peaking Color: Red/Blue/White/Violet.
-Peaking Level: 0~100.
6. False Color
- False Color on/off
7. HDR Mode
- ST 2084-300 / ST 2084-1000 / ST 2084-10000 /
HLG
Operating Instructions
PBM-4K SERIES
20
