Polycom MGC+50 ReadiConvene User manual

ReadiConvene™
Getting Started Guide

ReadiConvene Getting Started Guide
ii Polycom, Inc.
Trademark Information
Polycom®, the Triangles logo, ReadiManager®, SoundPoint®, SoundStation®, ViaVideo®,
VoiceStation®, and Vortex are registered trademarks of Polycom, Inc. ConveneT, Global
Management SystemTM, iPowerTM, MGCTM, People+ContentTM, People On ContentTM, Polycom
Conference SuiteTM, Polycom HD VoiceTM, Polycom PathNavigatorTM, Polycom VideoPlusTM,
Polycom VoicePlusTM, PVXTM, RASTM, ReadiConveneTM, RMX 2000TM, RSSTM, V2iUTM, VS4000TM,
VSXTM, and VTXTM are trademarks of Polycom, Inc.
Other product and corporate names may be trademarks of other companies and are only used
as a fair use reference without intent to infringe.
Patent Information
The accompanying product is protected by one or more U.S. and foreign patents and/or
pending patent applications held by Polycom, Inc.
DOC2125C1 (09/2007)
2.0
© 2007 Polycom, Inc. All rights reserved.
Polycom Inc.
1765 West 121st Avenue
Westminster, CO 80234-2301 U.S.A.
No part of this document may be reproduced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of Polycom,
Inc. Under the law, reproducing includes translating into another language or format.
As between the parties, Polycom, Inc. retains title to, and ownership of, all proprietary rights
with respect to the software contained within its products. The software is protected by United
States copyright laws and international treaty provision. Therefore, you must treat the software
like any other copyrighted material (e.g. a book or sound recording).
Every effort has been made to ensure that the information in this manual is accurate. Polycom,
Inc. is not responsible for printing or clerical errors. Information in this document is subject to
change without notice.

Polycom, Inc. iii
Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . v
1 Setting Up a ReadiConvene™ System
Unpacking the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
MGC+50/100 Component Locations . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the ReadiConvene IAM Blade in the MGC+ Unit . . . . . 8
First-Time Setup Worksheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting up the System Through a Serial Port . . . . . . . . . . . . . . . . . 14
Setting up the System Through a Web Interface . . . . . . . . . . . . . . 18
2 Configuring a ReadiConvene™ System
Logging in the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting up the Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting up the LDAP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Obtaining Software Licensing Information . . . . . . . . . . . . . . . . . . 29
Completing the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3 System Specifications
MGC+ Unit Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

ReadiConvene Getting Started Guide
iv Polycom, Inc.

Polycom, Inc. v
About this Guide
The term ReadiConvene™, used in this documentation, refers to the
Polycom® MGC+ that houses the ReadiConvene Integrated Application
Module (IAM). The ReadiConvene IAM is the hardware platform that
runs the ReadiManager® software application. The ReadiConvene
appliance combines the capabilities of the MGC+ appliance and its MGC
Manager with the ReadiManager application.
This document provides the first-time setup information you need to
install and set up the ReadiConvene appliance and ReadiManager
application.
This document includes these chapters:
Chapter 1, “Setting Up a ReadiConvene™ System,” provides information
about the physical ReadiConvene appliance and how to prepare it for use.
Chapter 2, “Configuring a ReadiConvene™ System,”describes how to
complete the First Time Setup screens with information the ReadiManager
software needs, connect the ReadiConvene appliance to your network,
change necessary configuration settings in the MGC+, and obtain
necessary licensing key codes.
Chapter 3, “System Specifications,” provides specifications about the unit.
Other documentation resources describe how to use the ReadiManager
application, including:
•ReadiManager Administrator’s Guide
•ReadiManager Operator’s Guide
•ReadiManager Outlook Scheduling Guide
•ReadiManager Web Scheduling Guide

ReadiConvene Getting Started Guide
vi Polycom, Inc.
The following manuals describe the MGC+ unit and the MGC Manager
application:
•MGC+50/100 Getting Started Guide
•MGC+50/100 Hardware and Installation Manual
•MGC Manager User’s Guide - Volume I
•MGC Manager User’s Guide - Volume II
•MGC Manager User’s Guide - VoicePlus Edition
•MGC Administrator’s Guide

Polycom, Inc. 1
1
Setting Up a ReadiConvene™
System
This chapter includes the following sections:
•“Unpacking the Unit” on page 1
•“Required Materials” on page 3
•“System Safety” on page 3
•“MGC+50/100 Component Locations” on page 5
•“Installing the ReadiConvene IAM Blade in the MGC+ Unit” on
page 8
•“First-Time Setup Worksheet” on page 12
•“Setting up the System Through a Serial Port” on page 14
•“Setting up the System Through a Web Interface” on page 18
Unpacking the Unit
Review the following information when you unpack the unit:
•Contents of the ReadiConvene Package
•Inspecting the ReadiConvene/ReadiConvene IAM Upgrade Package
Contents
•Disclaimer

ReadiConvene Getting Started Guide
2Polycom, Inc.
Inspecting the Package
The ReadiConvene package includes the MGC+ unit with an installed
ReadiConvene IAM blade.
The ReadiConvene IAM upgrade package is an IAM blade that can be
installed in the MGC+ unit.
Contents of the ReadiConvene Package
The ReadiConvene package includes the following:
•MGC+ unit with the pre-installed ReadiConvene IAM blade
•ReadiManager software
A full documentation set is provided online in PDF format.
•MGC+ Software & Documentation CD
•A set of printed manuals:
—ReadiConvene Getting Started Guide
—MGC+ Getting Started Guide
Contents of the ReadiConvene IAM Upgrade Package
The ReadiConvene IAM Upgrade package contains the following:
•ReadiConvene IAM blade (requires installation from the front of
MGC+)
•I/O card for the ReadiConvene IAM (requires installation from the
rear of MGC+)
•A set of printed manuals:
—ReadiConvene Getting Started Guide
—MGC+ Getting Started Guide

Setting Up a ReadiConvene™ System
Polycom, Inc. 3
Inspecting the ReadiConvene/ReadiConvene IAM Upgrade
Package Contents
You should inspect the shipped box and note if it was damaged in any
way. If the box items show damage, you should file a damage claim with
the carrier who delivered it.
When deciding on a setup location for the ReadiConvene system, refer to
the section “System Safety” on page 3.
Disclaimer
Polycom is not responsible for damage sustained during shipment of this
product.
Required Materials
•Completed First-Time Setup Worksheet (see page 12)
•PC with a serial port. If your PC does not have a serial port, see
“Setting up the System Through a Web Interface” on page 18
•ReadiConvene appliance
System Safety
This section includes the follow topics related to system safety:
•“General Safety Precautions” on page 4
•“Rack Mount Safety Precautions” on page 4
•“ReadiConvene Precautions” on page 5

ReadiConvene Getting Started Guide
4Polycom, Inc.
General Safety Precautions
Follow these rules to ensure general safety:
•Keep the area around the ReadiConvene appliance clean and free of
clutter.
•The MGC+50 weighs approximately 24 kg (53 lbs) and the MGC+100
weighs approximately 48 kg (106 lbs). When lifting the system, two
people at either end should lift slowly with their feet spread out to
distribute the weight. Always keep your back straight and lift with
your legs.
Rack Mount Safety Precautions
The following precautions should be followed with regards to rack mount
safety:
•Decide on a suitable location for the equipment rack that will hold the
ReadiConvene unit. It should be situated in a clean, dust-free area that
is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic fields are generated. You will also need it placed near
a grounded power outlet.
•Ensure that the leveling jacks on the bottom of the rack are fully
extended to the floor with the full weight of the rack resting on them.
•In a single rack installation, stabilizers should be attached to the rack.
•In multiple rack installations, the racks should be coupled together.
•Always make sure the rack is stable before extending a component.
•You should extend only one component at a time - extending two or
more simultaneously may cause the rack to become unstable.
•Before you install the rails, determine the placement of each
component.
•Install the heaviest components on the bottom of the rack first and
then work up.
•Allow the power supply units to cool before touching them.
•Always keep the rack’s front door and all the blade’s panels and
components closed when not servicing, to maintain proper cooling.

Setting Up a ReadiConvene™ System
Polycom, Inc. 5
ReadiConvene Precautions
When installing the ReadiConvene appliance, use a regulating UPS to
protect the ReadiConvene system from power surges and voltage spike
and to keep it operating in case of a power failure.
MGC+50/100 Component Locations
Figure 1-1 shows part of the front panel of the MGC+50/100. The front
panel provides access to the ReadiConvene IAM blade, the MGC+50/100
Main Control Module, Functional Modules, and Power Supply Modules.
Status LEDs on the ReadiConvene IAM, Main Control Module, Functional
Modules, and Power Supply Modules indicate the status of the system.
The ReadiConvene IAM blade is located on the left side of the appliance.
Figure 1-1 MGC+50/100 Partial Front View
ReadiConvene IAM MGC+ Control
Unit (CU)
MGC+ Functional
Modules
Compact Flash
slot
Shut Down
button
Universal
Serial Bus port

ReadiConvene Getting Started Guide
6Polycom, Inc.
ReadiConvene IAM Front Panel
The following items appear on the ReadiConvene IAM front panel:
Figure 1-2 shows part of the rear panel of the MGC+50/100 with the
ReadiConvene IAM blade and the MGC+ Control Unit (CU) installed. I/O
cards are inserted via the rear panel. The I/O card for the ReadiConvene
IAM is located on the right side of the MGC+50/100 rear panel. In
addition, the rear panels house the main power switch, AC inlet, fans, fuse,
and additional communications ports.
Table 1-1 Polycom ReadiConvene IAM Front Panel
Name LED Color Description
Power LED Yellow ON
Not lit OFF
Flash Memory LED Red Read or write enable. Lit when active.
Shut Down button NA Turns the ReadiConvene IAM blade ON
or OFF.
OFF - Closes all ReadiConvene IAM
processes and applications.
ON - Starts all ReadiConvene IAM
processes and applications.
Compact Flash
Slot
NA Future use.
USB port NA Future use.
HD LED Red Flashes when the hard disk is active.
Remove Server
LED
Green When lit, you can remove the
ReadiConvene IAM blade. This button is
lit when you press the Shut Down button
on the ReadiConvene IAM.

Setting Up a ReadiConvene™ System
Polycom, Inc. 7
Figure 1-2 MGC+50/100 Partial Rear View
ReadiConvene IAM Input/Output (I/O) Connections
The I/O card is connected to the Backplane of the ReadiConvene IAM.
This I/O card enables connections to the ReadiConvene IAM.
The following ReadiConvene IAM I/O connections are available:
•Alarms port (proprietary) - Not connected, DO NOT USE
•COM2—RS-232 port
•COM1—RS-232 port
•Keyboard and Mouse port
•VGA—VGA monitor port
•LAN—Ethernet port
MGC+ CU I/O ReadiConvene IAM I/O

ReadiConvene Getting Started Guide
8Polycom, Inc.
Figure 1-3 ReadiConvene IAM I/O Connections
Installing the ReadiConvene IAM Blade in the MGC+
Unit
This section is relevant only to MGC+ systems that are being upgraded to
the ReadiConvene by installing the ReadiConvene IAM blade.
The ReadiConvene IAM blade can be installed with the MGC+ unit ON or
OFF. Refer to Table 1-2 on page 1-9 for more detailed instructions.
It is important that you follow the sequence of steps as defined in sections
below.

Setting Up a ReadiConvene™ System
Polycom, Inc. 9
Table 1-2 MGC+ Power Setting During ReadiConvene IAM Blade
Installation
MGC+ Power
Setting Do This
OFF 1 Make sure the MGC+ is turned OFF.
2 Remove the blank panel from the front of the MGC+
unit. (This is where the ReadiConvene IAM blade will
be inserted.) See “Removing the Blank Panel from
the MGC+ Unit” on page 10.
3 Remove the rear I/O panel and install the I/O card on
the chassis. See “Installing the I/O Card for the
ReadiConvene IAM Blade” on page 11.
4 Install the ReadiConvene IAM blade. See “Inserting
the ReadiConvene IAM Blade into the MGC+ Unit” on
page 12.
5 Turn ON the Power switch on the MGC+.
ON 1 Remove the rear I/O panel and install the I/O card on
the chassis. See “Installing the I/O Card for the
ReadiConvene IAM Blade” on page 11.
2 Remove the ReadiConvene IAM front panel. See
“Removing the Blank Panel from the MGC+ Unit” on
page 10.
3 Install the ReadiConvene IAM blade. See “Inserting
the ReadiConvene IAM Blade into the MGC+ Unit” on
page 12. The ReadiConvene IAM blade automatically
starts/boots when inserted into its slot on the
backplane.
Note: If you did not follow this procedure and installed the
ReadiConvene IAM blade prior to installing the I/O card
for the ReadiConvene IAM blade, then:
1 Turn the ReadiConvene IAM OFF, by pushing the
SHUT Down button.
2 Turn the ReadiConvene IAM ON, by pushing the
SHUT Down button again.

ReadiConvene Getting Started Guide
10 Polycom, Inc.
Removing the Blank Panel from the MGC+ Unit
To remove the blank panel from the front of the MGC+ unit:
1Remove the left panel (labelled MGC+) from the front of the MGC+
unit.
2Unscrew four screws as shown in the following illustration.
Figure 1-4 MGC+ 50/100 front panels removed
When power on the MGC+ is turned ON, you must install the I/O card for the
ReadiConvene IAM card before installing the ReadiConvene IAM.

Setting Up a ReadiConvene™ System
Polycom, Inc. 11
Installing the I/O Card for the ReadiConvene IAM Blade
To install the I/O card for the ReadiConvene IAM blade:
1Remove the right rear I/O cover by loosening the four screws as
shown in the following illustration.
Figure 1-5 MGC+ 50/100 rear panel detachment
2Remove the I/O card for the ReadiConvene IAM blade from its
package and insert it in its slot as shown in the following illustration.
Figure 1-6 MGC+ ReadiConvene IAM rear I/O Insertion
3Push the I/O card firmly into the MGC+ backplane. Make sure its is
properly seated in its slot.
4Tighten the four screws that secure the I/O card to the MGC+ chassis.
5Attach the required cables or connections to the I/O card for the
ReadiConvene IAM blade.

ReadiConvene Getting Started Guide
12 Polycom, Inc.
Inserting the ReadiConvene IAM Blade into the MGC+ Unit
To insert the ReadiConvene IAM blade:
1After removing the left front panel from the MGC+ chassis, unpack
the ReadiConvene IAM blade.
2Insert the ReadiConvene IAM blade into its slot and carefully slide it
firmly into the backplane, making sure that it is properly seated in its
slot.
Figure 1-7 ReadiConvene IAM blade insertion on the MGC+ unit
3Tighten the four screws, securing the ReadiConvene IAM blade to the
MGC+ chassis.
First-Time Setup Worksheet
Before you begin setup and installation of ReadiManager on the Polycom
ReadiConvene IAM blade, complete the worksheet below, filling in the
entries in the column “My System Values.” If you are not sure what values
to use, contact your IT administrator.
When power on the MGC+ is ON, the ReadiConvene IAM blade automatically
boots when it is inserted into its housing on the backplane. For more
information see Table 1-2 on page 1-10.

Setting Up a ReadiConvene™ System
Polycom, Inc. 13
Information Item My System Values
Default Values
Set at Factory Comments
System Information (See “Verify that the system configuration information is correct.” on
page 24)
System Name NetBIOS name of the Windows
server. Must be between 6 and 15
characters. Dashes and
underscores may be included in the
name.
System IP
Address
192.168.1.254 Static IP address for the unit.
Note: If there is no active network
connection, the IP address will
display
0.0.0.0 instead of the
actual IP address of the device.
System Subnet
Mask
255.255.255.0 Network subnet mask for the
ReadiConvene IP address.
Default Gateway
IP
192.168.1.1 IP address of the gateway to be
used by ReadiConvene.
DNS Server IP 192.168.1.1 IP address of the DNS Server to be
used by ReadiConvene.
Note: This is a required entry. If
there is no DNS Server, enter the
system address or gateway
address.
Current Date
Current Time
Time Zone
Database Information (See “Setting up the Database” on page 26)
Internal
Database
No further information required.
External Database
Server IP
Address
IP address of the database server.

ReadiConvene Getting Started Guide
14 Polycom, Inc.
Setting up the System Through a Serial Port
Follow these instructions to set up your system through a serial port. If
your computer does not have a serial port, see “Setting up the System
Through a Web Interface” for instructions.
To connect a computer to the system using a serial cable
1Using a RS-232 serial cable, connect a computer to the 9-pin, serial
port labeled COM1 on the ReadiConvene appliance, and verify that
the link light for the connection is active.
2Turn on the computer and the ReadiConvene appliance.
Port Port for the database server.
Database Server
Instance Name
Database instance name if you
have one. Please check with your
SQL server administrator.
LDAP Integration (See “Setting up the LDAP Server” on page 28)
IP address of the
LDAP server or
DNS name
User Login ID The user name must have at least
read access to LDAP.
Password
Information Required for Polycom Customer Support
Serial No
License Number
Information Item My System Values
Default Values
Set at Factory Comments
