User Guide
SoundPoint® IP 500 for SIP
USER GUIDE
SoundPoint® IP 500 for SIP

Contents
Introduction ............................................... 1
Parts List ................................................... 1
Installing SoundPoint® IP 500 SIP.................. 2
Connecting Network and Power Source................................2
Connecting the Handset and Optional Headset ....................3
Attaching the Base.................................................................3
Features .................................................... 4
Key Descriptions ......................................... 5
Using SoundPoint® IP 500 SIP ....................... 6
Placing a Call ........................................................................6
Answering a Call....................................................................7
Call Hold ................................................................................7
Microphone Mute ...................................................................7
Local Conferencing................................................................8
Transferring a Call .................................................................8
Call Timer...............................................................................8
Ending a Call .........................................................................8
Redial.....................................................................................8
Call Forwarding......................................................................9
Voice Mail ..............................................................................9
Volume Adjustment................................................................9
Do Not Disturb .......................................................................9
Time and Date .......................................................................9
Headset Auto Mode .............................................................10
Display Contrast ..................................................................10
Ring Type.............................................................................10
Call Lists .............................................................................. 11
Local Directory..................................................................... 11
Speed Dial ...........................................................................12
Multiple Lines.......................................................................13
Multiple Call Appearances ...................................................13
Voice and Text Messaging ...................................................14

Distinctive Ringing / Call Treatment.....................................15
Presence / Status / Buddy Lists...........................................15
Instant Messaging................................................................16
Multilingual Support (Localization).......................................16
Phone Reboot......................................................................16
Troubleshooting ........................................ 17
Safety and Compliance............................... 18
Part 15 Rules .......................................................................18
Class B Digital Device or Peripheral....................................18
Modications........................................................................19
Installation Instructions ........................................................19
Plug Acts as Disconnect Device ..........................................19
Industry Canada (IC) ...........................................................19
CE Mark...............................................................................19
Polycom Limited Warranty
and Limitation Liability .............................. 19
Exclusions ................................................ 20
Warranty Exclusive.................................... 20
Service Agreements................................... 20
Limitations of Liability ............................... 21
Disclaimer................................................ 21
Governing Law ......................................... 21
Copyright Notice ....................................... 22

1
Thank you for choosing the SoundPoint®
IP 500 SIP, a full-duplex, handsfree
telephone. This unit provides business
telephony features and functions such as
Multiple Call Appearances, Call Hold,
Transfer, and Conference over an IP
network. In this User Guide, you will
nd everything you need to quickly set
up your new telephone. Be sure to verify
with your System Administrator that your
network is prepared for conguring your
SoundPoint IP 500 SIP telephone or con-
sult the Administrator Guide SoundPoint
IP SIP for more information. As well, be
sure to read the Parts List, and the Safety
Notices section in this guide before you
set up and use the SoundPoint IP 500 SIP
telephone.
Introduction
Parts List
The following items are included in your
SoundPoint IP 500 SIP package. Check
this list before installation to ensure that
you have received each item. If you are
missing any items, please contact your
SoundPoint IP 500 SIP reseller.
Polycom SoundPoint IP 500 SIP
Handset & Handset Cord
Network / Power Cable
Power Adapter
(specication varies according
to country)
Phone Base
User Guide
Hold
Del
Sel
1 3
DEF
5
JKL
4
GHI
6
MNO
8
TUV
7
PQRS
9
WXYZ
0
OPER
*#
2
ABC
Hold
Del
Sel
Menu
Messages
Do Not Disturb
ABC
21
DEF
3
54
MNOJKLGHI
6
TUV
87
WXYZ
9
OPER
PQRS
0
Directories
Services
Call Lists
Conference
Transfer
Redial

2
Installing SoundPoint® IP 500 SIP
This section provides basic installation
instructions and information for obtaining
the best performance with the SoundPoint
IP 500 SIP telephone. If you require addi-
tional information or assistance with your
new telephone, please contact your System
Administrator.
The SoundPoint IP 500 SIP User Guide
includes regulatory compliance infor-
mation that your System Administrator
should review and can also be found at
http://www.polycom.com.
Connecting Network and Power Source
AC Power Option
LAN PC HEADSET HANDSET
LAN PC HEADSET HANDSET
In-Line Power Option
LAN PC HEADSET HANDSET
Cisco™ In-Line Power Cable
(Part No.2457-11014-001)
OR
IEEE 802.3af In-Line
Power Cable
(Part. No 2457-11077-001)
Cisco™Catalyst™ In-Line
Power Switch
IEEE 802.3af compliant
In-Line Power switch
Connect the keyed end of the sup-
plied Network Cable to the LAN
jack on the telephone, and connect
the shorter end to the network
(LAN) port. Connect the DC plug
of the AC wall adapter into the sup-
plied LAN cable as shown.
If the telephone is connected to a compat-
ible ethernet switch that can provide in-line
power, the telephone will use that power
option. Simply plug the keyed end of the In-
Line Power Cable (optional accessory) into
the LAN jack on the telephone and connect
the shorter end of this cable to an available
power and data port on the In-Line Power
switch. The AC wall adapter is not required
when using In-Line power.
(Optional)
Wall network or switch port.

3
LAN PC HEADSET HANDSET
Connecting the Handset and Optional Headset
Attaching the Base
(Optional)
LAN PC HEADSET HANDSET
1. Connect the short straight end
of the telephone cord to the
handset and the corresponding
longer straight end of the cord to
the handset jack on the back of
the telephone.
2. Connect the headset (optional
accessory) to the headset jack on
the back of the telephone.
1. Place all cords in the recessed area
above the modular jacks as shown.
2. Align the two protrusions on the
bracket with their corresponding
holes in the telephone and snap
them together to lock the base to the
telephone.
For a list of currently supported headsets,
go to: http://www.polycom.com

4
Features
Line/Speed Dial Keys
