PR Lighting XR130 Beam User manual

1/20
XR130 Beam
PR-2133
This product manual contains important information about the safe installation and use of this projector. Please
read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/20
INDEX
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 5
POWER SUPPLY – MAINS 6
CONTROL CONNECTIONS 6
DMX TERMINATOR 7
SETUP OPTIONS-PROJECTOR CONFIGURATION 7
TO SET THE DMX START ADDRESS 7
OPERATION MENU
ERROR MESSAGE
8
10
REPLACING GOBOS 10
DMX PROTOCOL
LED INDICATION
11
13
MAINTENANCE 13
LUBRICATION 13
KEEPING THE PROJECTOR CLEAN 13
TROUBLESHOOTING 13
TECHNICAL DATA 14
ELECTRICAL DIAGRAM 17
COMPONENT ORDER CODES 18
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice. Whilst
every care is taken in the preparation of this manual we reserve the right to change specifications in the course of product improvement. The
publishers cannot be held responsible for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good condition before
installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the unit. Any damage caused by
improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
G clamps 2 Pcs
XLR connector 1 pc without DMX cable
Safety cord 1 Pc
Power Cable 1 pc
Power-Con 2 Pcs Male and Female one each
User’s manual 1 Pc
Ωclamps 2 Pcs Optional

W
a
T
h
T
T
T
v
D
A
D
E
B
I
D
M
O
K
T
i
n
S
b
E
T
I
A
w
W
hen unpacki
n
a
ny damage ca
u
T
he projector i
s
h
umidity and d
u
T
he projector is
T
he projector is
T
he projector
m
v
entilation slots
D
o not project t
h
A
void direct ex
p
D
o not attempt
t
E
lectrical conn
e
B
efore installat
i
I
t is essential th
a
D
o not connect
M
ake sure that
O
nly handle th
e
K
eep the lamp
c
T
he projector s
h
n
“installing th
e
S
hields and len
s
b
y cracks or de
e
E
xterior surfac
e
T
here is no use
r
I
f you have any
A
lwa
y
s dis
c
w
ork !
n
g and before
d
u
sed by transpo
r
s
for indoor us
e
u
st. Do not allo
w
not designed
o
only intende
d
f
m
ust be install
e
are blocked.
h
e b
e
am onto i
n
p
osure to the li
g
t
o dismantle a
n
e
ction must onl
y
i
on, ensure that
a
t each project
o
this device to
an
the powe
r
-cor
d
e
powe
r
-cord b
y
c
lean. Do not t
o
h
ould always b
e
e
projector” se
c
s
shall be chan
g
e
p scratches.
e
temperatures
o
r
serviceable pa
r
questions or s
u
c
onnection
f
SAF
E
d
isposing of th
e
r
tation, consult
e
only, IP20.
U
w
contact with
w
o
r intended to b
e
f
or installation,
e
d in a locatio
n
n
flammable su
r
g
ht from the la
m
n
d/or modify th
e
y
be carried ou
t
the voltage an
d
o
r is correctly e
a
an
y other types
o
d
is never cri
m
y
the plug. Nev
e
o
uch the lamp
g
e
installed with
c
tion.
g
ed if they hav
e
o
f the luminair
e
r
ts inside the p
r
u
ggestions, don
’
f
rom Powe
r,
E
USAG
E
carton check t
h
your dealer an
d
U
se only in dr
y
w
ater or any ot
h
e
mounted dire
c
operation and
m
n
with adequa
t
r
faces, minimu
m
m
p. The light is
e
projector in a
n
t
b
y qualified p
e
d
frequency of
p
a
rthed and that
e
o
f dimmer app
a
m
ped or damag
e
e
r pull out the
p
g
lass with bare
h
a secondary s
a
e
become visibl
y
e
after 30 minut
e
r
ojector, do not
o
’
t hesitate to co
n
r,
when the
3/20
E
OF THE
h
ere is no trans
p
d
do not use th
e
y
locations. Ke
e
h
er liquids.
c
tly on to infla
m
m
aintenance b
y
t
e ventilation,
a
m
distance is 3
m
harmful to the
e
n
y way.
e
rsonnel.
p
ower supply
m
e
lectrical install
a
a
ratus.
e
d by sharp ed
g
p
lug by tugging
h
and.
a
fety fixing. A
s
y
damaged to s
u
e
s operation is
7
o
pen the housi
n
n
sult your deal
e
device not
i
PROJE
C
p
ortation dam
a
e
apparatus.
e
p this device
a
m
mable surface
s
y
qualified pers
o
a
t least 50cm
f
m
.
e
ye.
m
atch the powe
r
a
tion conforms
g
es. Never let
t
the powe
r
-cor
d
s
afety cord is s
u
u
ch an extent t
h
70
℃, when ste
a
n
g and never o
p
e
r or manufact
u
i
n use or b
e
C
TOR
a
ge before usin
g
a
way from rai
n
s
.
o
nnel.
f
rom adjacent
w
r
requirements
o
to all
r
elevant
s
t
he power-cord
c
d
.
u
ppli
e
d for this;
h
at their effecti
v
a
dy state is ach
i
p
erate the proje
c
u
re
r
e
fore cleani
n
g
the projector.
n
and moisture,
w
all surfaces.
B
o
f the projector.
s
tandards.
c
ome into contac
t
it should be at
t
v
eness is impai
r
i
eved 90℃,
c
tor with the co
v
ng
or an
y
m
Should there b
e
excessive hea
t
B
e sure
t
hat n
o
t
with other cable
s
t
ached as show
n
r
ed, for exampl
e
v
ers removed.
m
aintenanc
e
e
t
,
o
s
.
n
e
e

4/20
INSTALL THE PROJECTOR
106
Safety Hook
Handle
Safety Cord
Digital
Control Panel
WARNING
Please run safety cord
through safety hook
!
Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each
clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base
as shown above) To pass the SAFETY CORD through the HOLES forsafety! Always ensure that the projector is firmly anchored to
avoid vibration and slipping whilst functioning. Always ensure that the structure that you are going to mount the projector to is secure and
strong enough to support the weight of a XR 130 Beam
WARNING:
1. The projector MUSTbe lifted or carried by the HANDLES instead of clamps.
2. For safety the safety cord should afford 10 times the Projector’s weight.

5/20
FITTING THE LAMP
Lock the yoke before fitting/replacing the lamp just as Shown by Figure 2, after Opening the head’s cover of a projector by loosening
4fastfit screws.
Pull out the lamp from the bottom of the head after rotating it anti-clockwise after holding the lamp’s bottom.
Installation and removal are in reverse orders.
Tighten the 4 fastfit screws after the cover is installed.
Note: don’t touch the bulb of the new lamp with bare hands so as notto impair the beam output.
Important:Always read "Instructions foruse" enclosed with the lamp.
1.Manually loosen the 2 spring screws
2.Take the lamp out after pushing
it down after loosening the 2
spring screws
PR-2133
XR 130 Beam
DMX

6/20
POWER SUPPLY-MAINS
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Before connection with mains power, make sure that the voltage and frequency marked on the rating plate of the projector match what
are supplied. It is recommended that each projector be supplied separately so that they may be individually switched on and off.
NOTE: If the fixtures’ power outputs and inputs are connected in series, please connect the first fixture’s power input with the external
power supply, and connect its power output with the second fixture’s input and so on till all the fixtures are connected. If the supplied
voltage is 200V~240V, the maximum number of fixtures connected is 10pcs. If it is 100V~120V, the maximum is 8pcs. The diameters of
the wires for the power input and output cables must be equal or bigger than 2.5 mm2.
IMPORTANT
It is essential that each projector is correctly earthed(yellow/green twin wire) and the electrical installation conforms to all
relevant standards.
CONTROL CONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each
wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector)
or 5 pin XLR plugs and sockets. The XLR's are connected as shown in the figure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The XR 130 Beam accepts digital control signals in protocol
DMX512 (1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second fixture’s
DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX terminator as
shown in the figure below.

7/20
DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120Ω(ohm) resistor connected across pins 2 and 3, which is then plugged into
the output socket on the last projector in the chain. The connections are illustrated below.
SETUP OPTIONS-PROJECTOR CONFIGURATION
Projector configuration can be set conveniently via push button and LCD display.
Launch the projector and press button ENTER for more than 5 seconds to unlock the panel, the LCD will show the function menu of the
projector, each main menu has its submenus and each submenu has a specific function. For details, please see the
“OPERATION MENU” section.
Press button UP or DOWN if you want to browse through the various Setup Options.
Press button ENTER to save your settings or enter the submenu.
Press button UP or DOWN to change values(plus or minus)
Press button FUNC, it will return to the upper menu. If button FUNC not pressed, the default will show display status automatically.
TO SET THE DMX START ADDRESS
Each XR 130 Beam must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX
start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The XR 130 Beam has 2 DMX modes. There are standard and short modes. For example standard mode has 16channels, so
set the No. 1 projector’s address 001, No. 2 projector’s address 017, No. 3 projector’s address 033,and No. 4 projector’s address is
049,and so on.
Launch the projector. Press button ENTER more than 5 seconds to unlock panel.
Press button ENTER to display DMX address;
Press button UP and DOWN, you can set the address;
Press button ENTER to confirm; after powered on next time, the default will be last value saved
Press button FUNC, it will return to the upper menu.
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8/20
OPERATION MENU
First Menu Secondary Menu Third Menu Fourth Menu
DMX Address
XXX
（XXX:1~497）
Short 1～501
Standard 1～497
Reset Are You Sure
Config Settings
DMX Channel Mode
（Default：Standard）
Standard16
Short 12
Loss of DMX
When DMX is Lost
Normal Time out
When DMX is Lost
Hold Last value
Lamp Control
By Control Channel
By Power On
By DMX Present
Pan Calibration 0~127
Tilt Calibration 0~127
Parameter Transm YES
Factory Settings YES
Option Settings
Color Wheel Positions
Color Positions
Steeped
Color Positions
Linear
Pan DMX Invert
Pan DMX Invert
OFF
Pan DMX Invert
ON
Tilt DMX Invert
Tilt DMX Invert
OFF
Tilt DMX Invert
ON
Pan Tilt Swap
Pan Tilt Swap
OFF
Pan Tilt Swap
ON
Dimmer Invert
Dimmer Invert
OFF
Dimmer Invert
ON
Pan Angle Range 360 / 720
Defaults YES
Display Options
Language
English
Chinese
Display Mode
Display
On Always
Display
Off After Delay
Display Invert
Display Invert
OFF
Display Invert
ON
Display Dimming 1~10
Display Contrast Display Contrast
XX(1~18),default 9

9/20
Information
Lamp Hours Hours：xx
Reset Lamp Hours Are You Sure
Total Hours Hours：xx
Temperature Temperature
XX℃
Software Version
Display Board Display Board=
X.X.X
Fan Board Fan Board=
X.X.X
View DMX Values DMX Channel
1=XXX
Electronic SN Electronic SN=
********
Test Modes Self Test Yes
Lamp Manual Control
Turn Lamp On Yes
Turn Lamp Off Yes
Wireless Options
(Optional)
Wireless Mode
Wireless Mode
XLR First
Wireless Mode
Wireless First
Wireless Mode
Wireless Only
Wireless Mode
XLR Only
Wireless Mode
Wireless To XLR
Un-Link Wireless YES
Operation Mode
DMX Mode YES
Master Mode
Preset Memory YES
User Memory YES
Memory Edit
Static Scene
（1~16 scenes）
Strobe
Dimmer
Color wheel
Slave Mode
Rotating
Gobo Wheel
Gobo
Rotation
Effect Wheel
Settings
Prism
Rotation
Focus
Pan Location
Pan
Tilt Location
P&T Speeds
Hold Time

10/20
ERROR MESSAGES
In the course of launch, Projector examines automatically whether there are errors and if there are, it will display
information as follows:
Head Fan 1 Fail
Head Fan 2 Fail
REPLACING GOBOS
Disconnect from power ,loosen 4 fastfit screws of the side cover, and open the cover as shown by the figure below.
Replace an old gobo of the rotating gobo wheel with a new gobo.
Tighten the 4 fastfit screws after the side cover is put back.
PR-2133
XR 130 Beam
DMX
Snap rings
Gobo

11/20
DMX PROTOCOL
Short
mode Standard mode Extended Mode FUNCTION DMX DESCRIPTION
1 1 Strobe
000-010 Close
011-025 Open
026-225 Strobe speed from slow to fast
226-239 Macro 1
240-241 Macro 2
242-246 Macro 3
247-255 Open
2 2 Dimmer
000-255 Linear dimming
3 3 Color Wheel
000-008 White
009-016 Color 1
017-024 Color 2
025-032 Color 3
033-040 Color 4
041-048 Color 5
049-056 Color 6
057-064 Color 7
065-073 Color 8
074-082 Color 9
083-091 Color10
092-100 Color11
101-109 Color12
110-118 Color13
119-127 CTO
128-191 Rotation ,Clockwise from slow to fast
192-255 Rotation, Anti-clockwise from slow to fast
4 4 Rotating Gobo
Wheel
000-017 White
018-027 Gobo 1
028-037 Gobo 2
038-047 Gobo 3
048-057 Gobo 4
058-067 Gobo 5
068-077 Gobo 6
078-087 Gobo 7
088-097 Gobo 8
098-107 Gobo 9
108-117 Gobo 10
118-127 Gobo 11
128-147 Rotation （Clockwise From slow to Fast）
148-167 Rotation （Anti-clockwise From slow to Fast）
168-175 Shake of Gobo 1 from slow to fast

12/20
176-183 Shake of Gobo 2 from slow to fast
184-291 Shake of Gobo 3 from slow to fast
192-199 Shake of Gobo 4 from slow to fast
200-207 Shake of Gobo 5 from slow to fast
208-215 Shake of Gobo 6 from slow to fast
216-223 Shake of Gobo 7 from slow to fast
224-231 Shake of Gobo 8 from slow to fast
232-239 Shake of Gobo 9 from slow to fast
240-247 Shake of Gobo 10 from slow to fast
248-255 Shake of Gobo 11 from slow to fast
5 5 Gobo Rotation
000-128 Gobo Indexing (0°-540°)
129-188 Rotation （Clockwise From slow to Fast）
189-195 Stop
196-255 Rotation （Anti-Clockwise From slow to Fast）
6 Gobo Rotation
Fin
e
000-255 Gobo Rotation in 16 Bit
6 7 Effect Wheel
000-063 White
064-127 Prism
128-191 Deep Frost
192-255 Light Frost
7 8 Prism Rotation
000-128 Stop
129-191 Rotation(Clockwise from slow to fast)
192 Stop
193-255 Rotation(Anti- Clockwise from slow to fast)
8 9 Focus 000-255 Linear Focusing
9 10 Pan 000-255 Pan(0°~720°)
11 Pan Fine 000-255 Pan in 16 bit precision
10 12 Continuous Pan
000-127 Stop
128-191 Rotation （Clockwise From slow to Fast）
192-255 Rotation （Anti-Clockwise From slow to Fast）
11 13 Tilt 000-255 Tilt(0°~270°)
14 Tilt Fine 000-255 Tilt in 16 bit precision
15
Pan & Tilt Speeds 000-255 Pan & Tilt Speed from Fast to Slow
12 16 Control
000-047 Reserved
048-080 Reset
081-112 Reserved
113-144 Lamp Off ( Delay for 3 s)
145-168 Reserved
169-200 Lamp Full Power
201-223 Reserved
224-255 Lamp Full Power
Remark:
If you intend to turn on/off the lamp via the last channel of the controller, don’t attempt to push the channel to value
224-255 immediately after turning it off, or push the slide bar to value 224-255 to wait it cooling. Under these 2
circumstances, the lamp can not be turned on. The right operation is: turn it off---cool down---push the slide bar to turn it
on.

13/20
LED INDICATION
Green LED indication
On DMX signal OK
Off No DMX signal
Flash DMX signal error
Blue LED indication
On Wireless Signal OK
Off Not linked with any transmitters
Flash Loss of connection or being linked with a transmitter
MAINTENANCE
If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must
be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be
changed at once, aged lamps run to the extremity of their life might explode. If the projector does not function, check the fuses on the
power socket of the projector, they should only be replaced by fuses of the same specification. The projector has overheat protection
device that will switch off the projector in case of overheating. Should it happen, check if the fans are blocked or not, or if they are dirty,
clean them before switching on the projector again.
Any maintenance work should only be carried out by qualified technicians.
LUBRICATION
To ensure the smooth rotation of the rotating gobos and movement of the lens for focusing, it is recommended that the bearings for the
rotating gobos and the 2 sliding tracks for the focusing lens holder be lubricated every two months. Use only high quality,
high-temperature grease .
KEEPING THE PROJECTOR CLEAN
To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The
lens and dichroic colour filters should also be regularly cleaned to maintain an optimum light output. Do NOT use any type of solvent
containing chemical elements on dichroic colour filters.
Cleaning frequency depends on the environment in which the fixture operates. A soft cloth and typical glass cleaning products should
be used in cleaning. It is recommended to clean the external optics at least once every 20 days and clean the internal optics at least once
every 30 / 60 days.
Do not use any organic solvent, e.g. alcohol, to clean the reflector mirror, dichroic colour filters or housing of the apparatus.
TROUBLESHOOTING
PROBLEM ACTION
The projector doesn’t switch on ¾Check the fuse on the power socket.
¾Check the lamp.
The lamp is on but the projector doesn’t respond
to the controller
¾Make sure that the fixture’s start address is right
¾Replace or repair the XLR signal cable.
The projector functions intermittently ¾Make sure the fan is working well or fans and their shields are not blocked
Beam appears dim, Low in brightness ¾Make sure the lamp is within its lifespan
¾Remove dust or grease from the lenses.
The project image appears to have a halo ¾Carefully clean the lamp, optical lenses and other components.
Heavily Defective Beam ¾Check if lens are in good condition(not cracked)
¾Clean dust or grease on the lens.

14/20
TECHNICAL DATA
VOLTAGES:
100V~240V AC，50/60Hz
POWER CONSUMPTION:
240W@220V
LAMP:
OSRAM SIRIUS HRI 132W
Colour Temperature 8800K
Manufacturers Rated Lamp Life 6000hours
COLOURS:
1 Color Wheel:13colors +CTO+white
Optional Stepping/linear color changing
ROTATING GOBO WHEEL
1Rotating Gobo Wheel: 11 gobos(8pcs rotatable)+ white
Shake effects with variable speeds, bi-directional wheel scrolling at variable speeds
Gobos replaceable
Gobos’ outer size: ￠11.8mm
Gobos’ Image size: ￠6mm
EFFECT WHEEL:
1pc,8-facet rotating Prism(bi-directional with variable speeds)+ 1Deep Frost filter +1light Frost filter+White
FOCUS:
Linear focusing
DIMMER:
linearly adjustable
STROBE:
Double shutter blades, 0.3~25 F.P.S with macros
HEAD MOVEMENT:
Continuous Pan movement, Tilt 270º with auto position correction
BEAMANGLE:
0°～3°

15/20
CONTROL:
DMX512, 3-pin and 5-pin interfaces
RDM Protocol
12 channels in short mode, 16channels in standard mode
Self-test mode
OTHER FUNCTIONS:
Adjustable Pan & Tilt speed
The display for the fixture’s and the lamp’s hours respectively
English and Chinese LCD display with its brightness and contrast adjustable
Energy saving ballast
Auto-Diagnosis by Sensors
Isolated Input DMX signal
Modular Structure for easy maintenance
HOUSING:
High temperature ABS, IP20
NETWEIGHT:
13.2Kg

16/20
SIZES:
442.4
312
303.6
280
421.9
271
PR-2133
XR 130 Beam
DMX
PR-2133
XR 130 Beam
DMX
LIGHT OUT:
3.0°Diameter(m)
Disrance(m)0m 5m 10m 15m 20m 25m 30m
11565166542602246261104088416352
3.0°lux
1.621.351.080.810.540.270
0
3°

17/20
Electrical Diagram:

18/20
Component Order Code
NAME PART NO. QUANTITY REMARK
PAN MOTOR 030040174 2
TILT MOTOR
STROBE MOTOR 030040220 3
COLOR WHEEL MOTOR
ROTATING GOBO WHEEL MOTOR 030040222 1
GOBO ROTATION MOTOR 030040236 2
PRISM ROTATION MOTOR
EFFECT WHEEL MOTOR 030040154 1
FOCUS MOTOR 030040116 2
TURBO- FAN 030060072 1
LAMP FAN 030060055 1
FAN IN BASE BOX 030060069 2
ELECTRONIC BALLAST OSRAM 040070120 1
LAMP OSRAM 100070036 1
ROTATING GOBO WHEEL
ACCESSORY 120110685 1
COLOR WHEEL ACCESSORY 120110663 1
EFFECT WHEEL ACCESSORY 1120110684 1
POWER SWITCH 190010185 1
THERMAL SENSOR 190010171 1
PAN / TILT DRIVER BOARD 230060356 1
LCD MASTER BOARD 230060357 1
FAN DRIVER BOARD 230060358 1
MOTOR DRIVER BOARD 230060359 1
TILT BELT 290151389 1
PAN BELT 290151390 1
EFFECT WHEEL IN/OUT BELT 290151396 1
GOBO ROTATION BELT 290151409 1
FOCUS BELT 290151410 2
PRISM ROTATION BELT 290151411 1
PRISM IN/OUT BELT 290151412 1

19/20

20/20
PR LIGHTING LTD.
1582 Xingye Avenue, Nancun Panyu
Guangzhou, 511442 China
TEL: [phone]
FAX: [phone]
P/N: 320020264
Version: 20150127 (Preliminary）
