PR Lighting PR5000 User manual

PR5000 Beam
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/22
INDEX
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
DMX TERMINATOR 6
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
OPERATION MENU 8
ERROR MESSAGES 11
REPLACING GOBOS 11
DMX PROTOCOL 12
LED INDICATION 15
MAINTENANCE 15
LUBRICATION 15
KEEPING THE PROJECTOR CLEAN 15
TROUBLESHOOTING 16
TECHNICAL DATA 17
ELECTRICAL DIAGRAM 20
COMPONENT ORDER CODES 21
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without
notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of
product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence
arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
G clamps 2 Pcs
XLR cable 1 Pc 5-pin plug
Safety cord 2 Pcs
Spare gobos 4 Pcs
This manual 1 Pc
Ωclamps 2 Pcs Options

3/22
SAFE USAGE OF THE PROJECTOR
When unpacking and before disposing of the carton check there is no transportation damage before using the projector.
Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.
The projector is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain and moisture,
excessive heat, humidity and dust. Do not allow contact with water or any other liquids.
The projector is not designed or intended to be mounted directly on to inflammable surfaces.
The projector is only intended for installation, operation and maintenance by qualified personnel.
The projector must be installed in a location with adequate ventilation, at least 50cm from adjacent wall surfaces. Be sure
that no ventilation slots are blocked.
Do not project the beam onto inflammable surfaces, minimum distance is 5m. 5m
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle and/or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the power-cord come into contact
with other cables. Only handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Keep the lamp clean. Do not touch the lamp glass with bare hand.
The projector should always be installed with a secondary safety fixing. A safety cord is supplied for this; it should be
attached as shown in “installing the projector” section.
The lamp used in this projector is a discharge lamp. After switching off don’t attempt to restart the projector until lamp has
cooled, this will require approx 15 minutes. Switching the lamp on and off at short intervals will reduce the life of both the
lamp and the projector. But occasional breaks will prolong the life of the lamp and projector.
Never run the projector without a lamp.
The lamp shall be changed if it has become damaged or thermally deformed.
Shields and lens shall be changed if they have become visibly damaged to such an extent than their effectiveness is
impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 80℃, when steady state is achieved 120℃,
There is no user serviceable parts inside the projector, do not open the housing and never operate the projector with the
covers removed.
Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !
If you have any questions, don’t hesitate to consult your dealer or manufacturer.

4/22
INSTALL THE PROJECTOR
106
256
HANDLE
SAFETY CORD CLAMP
To pass 2 SAFETY CORDS
through 4 HOLES for safety!
WARNING
CONTROL PANEL
CLAMP
Take 2 clamps and 2 safety cords out from the package and mount 2 clamps on the underside of fixture with 2 retainers
attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the
WARNING on the underside of the base as shown above) To pass 2 SAFETY CORDS through 4 HOLES for safety!
Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. Always ensure that
the structure that you are going to mount the projector is secure and is strong enough to support a weight of PR5000
Beam.
WARNING:
1. Unlock the PAN and TILT before the 1st application of projector for safety.
2. The projector MUST be lifted or carried by the HANDLES instead of clamps.
3. For safety the safety cord should afford 10 times of the unit’s weight.
FITTING THE LAMP
LAMP BACK COVER
FAST-FIT SCREWS
Lock the yoke before fitting/replacing the lamp.
Loosen 4 fast-fit screws and remove the back cover, you can see the structure as shown in the figure above.
Rotate the lampholder to the left and take out the worn-out lamp.
Fit new lamp and close the back cover by fastening 4 fast-fit screws. Note: don’t touch the bulb of the new lamp with
bare hand so as not to influence the beam output;
WARNING: The MSR series are high-pressure lamps with external igniters ( ). Care should always be taken
when handling these lamps.Always read the manufacturers "Instructions for use" enclosed with the lamp.

5/22
POWER SUPPLY-MAINS
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked
on the panel of the projector. It is recommended that each projector be supplied separately so that they may be
individually switched on and off.
IMPORTANT
It is essential that each projector is correctly earthed and the electrical installation conforms to all relevant
standards.
CONTROL CONNECTION
Connection between controller and projector and between one projector and another must be made with a 2
core-screened cable, with each core having at least a 0.5mm diameter. Connection to and from the projector is via
cannon 3 pin (which are included with the projector) or 5 pin XLR plugs and sockets. The XLR's are connected as shown
in the figure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of
the plug is not connected in any way. The unit accepts digital control signals in protocol DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the second fixture’s input
and connect the rest fixtures in the same way. Eventually connect the last fixture’s output to a DMX terminator as shown
in the figure below.
TO TERMINATER
TO CONTROLLER
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT

6/22
DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This
prevents electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120Ω(ohm) resistor connected across pins 2 and 3, which is
then plugged into the output socket on the last projector in the chain. The connections are illustrated below.
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain.
PIN 3
PIN 2
SETUP OPTIONS-PROJECTOR CONFIGURATION
UP
UP
Projector configuration can be set conveniently via pressbutton switch and LCD display. Turn the projector on and the
LCD display will show DMX address you set and save last time and it can be reset and saved again as you please.
Launch the projector. Press button ENTER more than 5 seconds to unlock panel.
Press button UP or DOWN if you want to browse through the various Setup Options. There are 10 option codes
from DMX Address to Wireless options, and each code has a specific function. If you turn the encoder
knob clockwise, the function like as button UP . On the contrary, the function like as button DOWN .
Press button ENTER to save your settings or enter the next menu. There is same function if you push the encoder knob.
Press button UP or DOWN to shift.
Press button FUNC, it will return to the upper menu one by one. If you stay for minutes defaulted will show display status
automatically.
TO SET THE DMX START ADDRESS
Each projector must be given a DMX start address so that the correct projector responds to the correct control signals.
This DMX start address is the channel number from which the projector starts to “listen” to the digital control information
being sent out from the controller. PR5000 Beam have 3 DMX modes. There are standard mode, extended mode and
short mode. For example standard mode have 24 channels, so set the No. 1 projector’s address 001, No. 2 projector’s
address 025, No. 3 projector’s address 049, No. 4 projector’s address 073, and so on.
Launch the projector. Press button ENTER or encoder knob more than 5 seconds to unlock panel.

7/22
Press button FUNC to display DMX address;
Press button UP and DOWN, you can set the address;
Press button ENTER to confirm; In the same time. The GREEN LED will flash one time. It means the setting has
been enabled.
Press button FUNC, it will return to the upper menu one by one.

8/22
OPERATION MENU
1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL
PR LIGHTING
PR5000 BEAM DMX Address=XXX
DMX Address
DMX Address
Short Mode
Standard Mode
Extended Mode
Reset Rese
t
A
re You Sure?
Config Settings
DMX Mode
DMX M
o
de
Standard
DMX Mode
Extended
DMX Mode
Short
Lamp Control
Lamp Control B
y
Control Channel
Lamp
C
ontrol B
y
Power On
Lamp
C
ontrol B
y
DMX Presen
t
Loss of DMX
When DMX is Los
t
Normal Time Ou
t
When DMX is Los
t
Hold Last Value
Factory Settings
(Press button
DOWN/UP/ENTER at the
same time to enter the
sub-menu)
Fixture type
(WARNING：Never
change the fixture type
or the systemwill be
damaged!)
Option Settings
Colour Positions
Colour Positions
STEPPED
Colour Positions
LINEAR
F-Gobo Positions
F-Gobo Positions
STEPPED
F-Gobo Positions
LINEAR
Pan DMX Invert
Pan DMX Invert
OFF
Pan DMX Invert
ON
Tilt DMX Invert
Tilt DMX Invert
OFF
Tilt DMX Invert
ON
Pan Tilt Swap
Pan Tilt Swap
OFF
Pan Tilt Swap
ON
Dimmer Invert
Dimmer Invert
OFF
Dimmer Invert
ON
Iris Invert
Iris Invert
OFF
Iris Invert
ON

9/22
CMY Invert
CMY Invert
OFF
CMY Invert
ON
CTO Invert
CTO Invert
OFF
CTO Invert
ON
Defaults
Defaults
OFF
Defaults
Restore Defaults
Display Options
Display Mode
Display
On Always
Display
Off After Delay
Display Invert
Display Invert
OFF
Display Invert
ON
Display Dimming
Disp Dim Level
Min
Disp Dim Level
1
Disp Dim Level
2
Disp Dim Level
3
Disp Dim Level
4
Disp Dim Level
5
Disp Dim Level
6
Disp Dim Level
7
Disp Dim Level
8
Disp Dim Level
9
Disp Dim Level
Full
Display Contrast Display Contrast
XXX(1~36, Default is 16)
Display Language
Language =
English
Language =
Chinese
Information
Lamp Hours Lamp Hours =
XX Reset Lamp Hours Are You Sure?
Total Hours Total Hours =
XX
Temperature
Display Board Display Board =
XX℃
Driver Board 1 Driver Board 1 =
XX ℃
Driver Board 2 Driver Board 2 =
XX ℃
Driver Board 3 Driver Board 3 =
XX ℃
Pan and Tilt Pan and Tilt =
XX ℃

10/22
Head Sensor Head Sensor=
XX ℃
Software Version
Display Board Display Board =
X.X.X
Driver Board 1 Driver Board 1 =
X.X.X
Driver Board 2 Driver Board 2 =
X.X.X
Driver Board 3 Driver Board 3 =
X.X.X
Pan and Tilt Pan and Tilt =
X.X.X
Power Board Power Board =
X.X.X
View DMX values DMX Channel
1=XXX
Electronic SN Electronic SN=
************
RDM Device Label
RDM Device Label
ANSI E1.20 RDM
Version
Test M o d e s
Factory Setup
Factory Setup
OFF
Factory Setup
ON
Self Test
Self Test
OFF
self test
ON
Lamp Manual
Control
Lamp Status Status = XXX
Control = X
Turn Lamp On
Turn Lamp Off
Wireless Options
Wireless Mode
Wireless Mode
Wireless First
Wireless Mode
XLRFirst
Wireless Mode
Wireless Only
Wireless Mode
XLROnly
Wireless Mode
Wireless To XLR
Un Link Wireless Really Un Link
Enter=Yes

11/22
ERROR MESSAGES
In the course of launch, PR5000 Beam examines automatically whether there are errors and if there are, it will display
information as follows:
Display Message
Sensor Err S1-M1 Colour wheel (1# drive board motor 1) error
Sensor Err S1-M2 CTO (1# drive board motor 2) error
Sensor Err S1-M3 CYM-cyan (1# drive board motor 3) error
Sensor Err S1-M4 CYM-yellow (1# drive board motor 4) error
Sensor Err S1-M5 CYM-magenta (1# drive board motor 5) error
Sensor Err S2-M2 Fixed Gobo wheel (2# drive board motor 2) error
Sensor Err S2-M3 Rotating Gobo wheel 1 (2# drive board motor 3) error
Sensor Err S2-M4 Gobo rotation 1 (2# drive board motor 4) error
Sensor Err S3-M1 Prism (3# drive board motor 3) error
Sensor Err S3-M2 Prism rotation (3# drive board motor 4) error
Sensor Err S3-M3 Focus (3# drive board motor 5) error
REPLACING GOBOS
ROTATIING GOBO WHEEL
PRISM WHEEL
FIXED GOBO WHEEL
Disconnect the fixture from power. Lock Tilt. Carefully lift off the cover by undoing the 6 screws.
For gobos replacement on the fixed gobo: Remove the gobo and insert the new one into the position by hands.
For gobos replacement on the rotating gobo wheel: Remove the gobo holder with gobo from gobo wheel by
hands.
Pull out the spring and drop the old gobo out of the holder.
Insert the new gobo into the holder, and then insert the spring with the narrow end against the gobo.
Push the end of the spring in under lip of the holder.
Pick the spring clip up and put the gobo holder back into the position, if necessary, a small screwdriver will be
helped.
Note: If the gobo is a glass one, it should be touched with glabrous, clean and soft tissue or cloth matted between hand
and glass instead of with bare hand.
Close the rear cover and fasten 6 screws.

12/22
DMX PROTOCOL
Short
mode Standard mode Extended mode FUNCTION DMX DESCRIPTION
1 1 1 Strobe
000-010 Black
011-025 Open
026-225 Strobe speed from slow to fast
226-246 Macro
247-255 Open
2 2 2 Dimmer
000-003 Black
004-255 Dimming from dark to light (0-100%)
3 3 Dimmer Fine 000-255 Dimmer in 16 Bit precision
3 4 4 CYM Macro
000-016 White
017-035 Yellow+ Magenta=Red
036-054 Yellow
055-073 Yellow+ Cyan=Green
074-092 Cyan
093-110 Cyan+ Magenta=Blue
111-128 Magenta
129-255 CYM colour mixing from slow to fast
4 5 5 CYM-Cyan 000-255 Cyan (Linear 0-100%)
6
CYM-Cyan
Fine 000-255 Cyan in 16 Bit precision
5 6 7 CYM-Yellow 000-255 Yellow (Linear 0-100%)
8
CYM-Yellow
Fine 000-255 Yellow in 16 Bit precision
6 7 9 CYM-Magenta 000-255 Magenta (Linear 0-100%)
10
CYM-Magenta
Fine 000-255 Magenta in 16 Bit precision
7 8 11 CTO 000-255 Linear adjust from high to low
12 CTO Fine 000-255 CTO in 16 Bit precision
8 9 13 Colour Wheel
000-008 White
009-015 White/colour 1
016-023 Colour 1
024-030 Colour 1/colour 2
031-038 Colour 2
039-045 Colour 2/colour 3
046-053 Colour 3
054-060 Colour 3/colour 4
061-068 Colour 4
069-075 Colour 4/colour 5
076-083 Colour 5
084-090 Colour 5/colour 6
091-098 Colour 6
099-105 Colour 6/ white
106-113 Colour 7
114-120 Colour 7/white

13/22
121-127 white
128-191 Rainbow rotation speed from fast to
slow
192-255 Rainbow reverse rotation speed from
fast to slow
9 10 14 Iris 000-255 Iris from large to small (0-100%)
1
5
Iris Fine 000-25
5
Iris in 16 Bit precision
10 11 16 Iris Macro
000-010 Iris macro function is invalid
011-072 Macr
o
function: Iris from large to small
change with speed from slow to fas
t
073-136 Macro function: Iris from small to large
change with speed from slow to fas
t
137-206 Macro function: Iris retractable speed
from slow to fas
t
207-214 Macro function 1
215-222 Macro function 2
223-230 Macro function 3
231-255 Full open
11 12 17
Fixed Gobo
Wheel
000-016 White
017-032 Gobo1
033-048 Gobo 2
049-064 Gobo 3
065-080 Gobo 4
081-096 Gobo 5
097-112 Gobo 6
113-127 Gobo 7
128-149 Rotation speed from slow to fast
150-171 Reverse rotation from slow to fast
172-183 Gobo 1 shake speed from slow to fast
184-195 Gobo 2 shake speed from slow to fast
196-207 Gobo 3 shake speed from slow to fast
208-219 Gobo 4 shake speed from slow to fast
220-231 Gobo 5 shake speed from slow to fast
232-243 Gobo 6 shake speed from slow to fast
244-255 Gobo 7 shake speed from slow to fast
12 13 18
Rotating Gobo
Wheel
000-018 white
019-036 Gobo1
037-054 Gobo 2
055-073 Gobo 3
074-091 Gobo 4
092-109 Gobo 5
110-127 Gobo 6
128-156 Rotation speed from slow to fast
157-185 Reverse rotation from slow to fast
186-196 Gobo 1 shake speed from slow to fast
197-208 Gobo 2 shake speed from slow to fast
209-220 Gobo 3 shake speed from slow to fast
221-232 Gobo 4 shake speed from slow to fast
233-244 Gobo 5 shake speed from slow to fast
245-255 Gobo 6 shake speed from slow to fast
13 14 19 Gobo rotation
000-127 Index
128 Stop rotating
129-188 Rotation speed from slow to fast
189-195 Stop rotating

14/22
196-255 Reverse rotation speed from slow to
fas
t
15 20
Gobo rotation
Fine 000-255 Gobo rotation in 16 Bit precision
14 16 21 Prism
000-143 Frosting from slight to strong
144-200 Prism 1
201-255 Prism 2
15 17 22 Prism rotation
000-127 Prism index
128-191 Rotation speed from slow to fast
192-255 Reverse rotation speed from slow to
fas
t
16 18 23 Focus 000-255 Linearly focusing
24 Focus Fine 000-255 Focus in 16 precision
17 19 25 Pan 000-255 Pan rotation
20 26 Pan Fine 000-255 Pan rotation in 16 precision
18 21 27 Tilt 000-255 Tilt rotation
22 28 Tilt Fine 000-255 Tilt rotation in 16 precision
23 29
Pan & Tilt
speed 000-255 Pan&Tilt speed from fast to slow
19 24 30 Control
000-047 Reserved
048-080 Reset
081-112 Reserved
113-144 Lamp off ( stop in DMX value for 10 s)
145-168 Reserved
169-200 Lamp power reduced to 50%
201-223 Reserved
224-255 Lamp on (See remark below)
Remark:
If you intend to turn on/off the lamp via the last channel of the controller, don’t attempt to push the channel to value
224-255 immediately after turning it off, or push the slide bar to value 224-255 to wait it cooling. Under these 2
circumstances, the lamp can not be turned on. The right operation is: turn it off---cool down---push the slide bar to turn it
on.

15/22
LED INDICATION
Green
On DMX signal OK
Off No DMX signal
Flash DMX signal error
Yellow On
Setting the panel
Blue On Power
Red/Green Red Running self test mode
Green Reserved
Green
On Wireless signal OK
Off No connection to any transmitter
Flash Lost contact with the transmitter or linking transmitter
MAINTENANCE
If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in
any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end
of its life and it should be changed at once, aged lamps run to the extremity of their life might explode. If the projector
does not function, check the fuses on the power socket of the projector, they should only be replaced by fuses of the
same specification. Should these be damaged call a qualified technician before replacement. The projector has thermal
protection device that will switch off the projector in case of overheating, should either of these operate, check that the
fans are not blocked, and if they are dirty clean them before switching on the projector again. Check that the fans are
operational, if not call a qualified technician.
Any maintenancework should only be carried out by qualified technicians.
LUBRICATION
To ensure the continuous rotation of the rotating gobos and linear motion of the lens for focusing, it is recommended that
the bearings for the rotating gobos and the 2 shafts for the focusing lens holder be lubricated periodically, preferably
every two months. Use only high quality, high-temperature resistant grease instead of any type of oil. When lubricating
the bearings, a syringe with a fine needle is the easiest way to introduce the grease to the bearings around each gobo.
KEEPING THE PROJECTOR CLEAN
To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every
15 days. The lens and dichroic colour filters should also be regularly cleaned to maintain an optimum light output. Do
NOT use any type of solvent on dichroic colour filters.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or particularly dirty
surroundings can cause greater accumulation of dirt on the unit’s optics. A soft cloth and typical glass cleaning products
should be used in cleaning. It is recommended to clean the external optics at least once every 20 days and clean the
internal optics at least once every 30 / 60 days.
Do not use any organic solvent, e.g. alcohol, to clean the reflector mirror, dichroic colour filters or housing of
the apparatus.

16/22
TROUBLESHOOTING
PROBLEM ACTION
The projector doesn’t switch on
¾Check the fuse on the power socket.
¾Replace the lamp.
The lamp comes on but the projector
doesn’t respond to the controller
¾Make sure that the projector is correctly configurated.
¾Replace or repair the DMX cable.
The projector only functions intermittently ¾Make sure the fan is working and not dirty.
Defective projection
¾Check the lenses are not broken.
¾Remove dust or grease from the lenses.
The project image appears to have a halo
¾Make sure the lamp is installed correctly.
¾Carefully clean the optical group lenses and the projector
components.
The beam appears dim
¾Check the optics is clean.
¾Replace with a new lamp of the specified type and rating.

17/22
TECHNICAL DATA
VOLTAGES:
200V/220V/230V/240V AC，50/60Hz
POWER CONSUMPTION:
1800W@220V
LAMP:
OSRAM HTI 1500W/60/P50
Colour Temperature 6000°K
Socket PGJX50，single ended
Manufacturers Rated Lamp Life 750 Hours replacement
Or
PHILIPS MSR Gold 1500FastFit
Colour Temperature 6000°K
Socket PGJX50，single ended
Manufacturers Rated Lamp Life 750 Hours replacement
COLOURS:
Smooth CYM colour mixing system with macro
1 wheel with 7 dichroic colour filters plus white
With variable speed bi-directional rainbow effect
Step/linear colour changing is available
COLOUR TEMPERATURE CORRECTION:
Linearly colour temperature correction
GOBOS:
1 Rotating gobo wheel:
6 interchangeable gobos+ white, glass or metal gobos can be fixed
Indexable, bi-directionally rotatable at variable speeds
1 Fixed gobo wheel :
7 interchangeable gobos+ white
bi-directional wheel scrolling at variable speeds
Gobo diameter: Φ36.3mm
Gobo image diameter: Φ26mm
PRISM/ FROST:
Two groups prisms, indexable, bi-directionally rotatable at variable speeds. linearly frost effect
FOCUS:
DMX linear focus

18/22
DIMMER:
0-100% linearly adjustable
IRIS：
5-100% linearly adjustable
Macro
SHUTTER:
Double shutter blades, 0.3~25 F.P.S
HEAD MOVEMENT:
Pan 540º, Tilt 270º with auto position correction
BEAMANGLE:
Focus 6°in 16 Bit precision
CONTROL:
DMX512, 3 pin and 5 pin interfaces
RDM control protocol
19 channels in short mode, 24 channels in standard mode, and 30 channels in extended mode.
Self-test mode
OTHER FUNCTIONS:
Adjustable Pan & Tilt speed
Fixture and lamp usage time display
LCD display with English and Chinese language menu
Energy saving function of the ballast
Built-in analyzer for easy fault finding, error messages
Modular construction for easy maintenance
Setup options by chargeable battery inside without power connection.
Input signal isolating protection
Network interface
DMX512 wireless receiver
DMX512 wireless transmitter (optional)
HOUSING:
Composite plastic, IP20
WEIGHT:
46Kg
SIZES:
See at below

19/22
889
621
717
544
491
LIGHT OUTPUT:
0m 5m 10m 15m 20m 25m 30m
0.5 0.99 1.49 1.99 2.48 2.98
0
Lux 315033 78758 35004 19690 12601 8751
0
DIAMETER(m)
DISTANCE(m)
5m
5m
4m
2m
4m
2m
0m 1m
1m
3m
3m

SENS1
SENS2
SENS3
SENS4
SENS5
SENS6
MOTOR1 MOTOR2 MOTOR3 MOTOR4 MOTOR5 MOTOR6
SLAVE #1 PCB
SENS1
SENS2
SENS3
SENS4
SENS5
SENS6
MOTOR1 MOTOR2 MOTOR3 MOTOR4 MOTOR5 MOTOR6
SLAVE #2 PCB
PAN & TILT PCB
GND
GND
VCC
VCC
DMX-SENS1
DMX-SENS2
GND
GND
VCC
VCC
DMX-SENS1
DMX-SENS2
+
-
TILT ENCODE
+
-
PAN ENCODE
3
12
DMX-IN DMX-OUT
12 3
1
23
4
51
2
3
4
5
DMX-IN DMX-OUT
VGS
AC INPUT
NL
Filter
E
VGS VGS
VGS VGSVGS VGS VGS VGS
VGSVGS VGS
RS232
MOTOR1 MOTOR2 MOTOR3 MOTOR4
SLAVE #3 PCB
GND
GND
VCC
VCC
DMX-SENS1
DMX-SENS2
G
HALL 1-5
View of mark side HALL 1-3 View of mark side
HALL 1-1
View of mark side
HALL 1-4
View of mark side HALL 2-4 View of mark side
PAN TILT
GND GND VCC VCC DMX-SENS1 DMX-SENS2
V
G
S
V
G
V
G
S
V
G
S2
S1 S1 S2
HALL 1-2
View of mark side
LED1 LED2LED3
LED4
LCD DISPLAY
FUNCTION DOWN UP ENTER
GND
GND
VCC
VCC
DMX-SENS1
DMX-SENS2
GND
DATA-
DATA+
FEMALE FEMALEMALEMALE
DC6V
GND
+-
Battery
SWITCH
View side of no axletree
M2-6
STROBE 2
A B C D
A B C D
View side of no axletree
M1-6B
DIMMER
A B C D
A B C D
View side of no axletree
J1
PAN
A B C D
A B C D
View side of no axletree
J2
TILT
A B C D
A B C D
View side of no axletree
M1-6A
DIMMER
A B C D
A B C D
HEAD FAN 1 HEAD FAN n
HEAD FAN
Thermostat
GND
GND
DMX-SENS1
DMX-SENS2
+-
FAN1
FAN2
FAN3
FAN4
DC
FAN & LIGHTING PCB
GG PWM
PWM
FAN
FAN
View side of no axletree
M1-5
MAGENTA
A B C D
A B C D
View side of no axletree
M1-4
YELLOW
A B C D
A B C D
View side of no axletree
M1-3
CYAN
A B C D
A B C D
View side of no axletree
M1-1
COLOUR
A B C D
A B C D
View side of no axletree
M1-2
CTO
A B C D
A B C D
View side of no axletree
M2-5
STROBE 1
A B C D
A B C D
View side of no axletree
M2-4
GOBO ROTATING
A B C D
A B C D
View side of no axletree
M2-3
ROTATING-GOBO
A B C D
A B C D
View side of no axletree
M2-2
FIXED GOBOS
A B C D
A B C D
View side of no axletree
M2-1
IRIS
A B C D
A B C D
View side of no axletree
M3-3
FOCUS
A B C D
A B C D
View side of no axletree
M3-2
PRISM ROTATING
A B C D
A B C D
View side of no axletree
M3-1
PRISM
A B C D
A B C D
S S G V
V S G
HEAD FAN 1 HEAD FAN n
GV
Fuse
TRANSFORMER
ELECTRONIC G
G
+24V
+24V
FG
ACL
ACN
G
+24V
VCC
VCC
SW-PB
162345
IGNITOR
GROUND
N
L
TO IGNITOR
ELECTRONIC
BALLAST
LAMP
12 1 62345
HALL 2-3
View of mark side
HALL 2-2
View of mark side
SENS1
SENS2
SENS3
SENS4
VGS
V
G
S2 S1 V
G
S2 S1
HALL 3-1
View of mark side
HALL 3-2
View of mark side
HALL 3-3
View of mark side
PS
BOX FAN 3
BOX FAN 2
BOX FAN 1
RF
Antenna
