Pride Rally shopper User manual

Owner’s Manual
The Ultimate In Style & Performance
®
ATTENTION:
Please read the content
of your owners manual
before operating your
scooter.
Exeter, PA
St. Catharines, ON 1-800-800-8586
www.pridemobi ity.com

SAFETY GUIDELINES
Please read and follow all instructions in this owners anual before atte pting to operate your scooter for the first
ti e. If there is anything in this anual you do not understand, or if you require additional assistance for setup,
contact your local authorized Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions, and instructions
in this owners anual. Using your Pride product safely also depends upon your own good judge ent and/or
co on sense, as well as that of your provider, caregiver, and/or healthcare professional. Pride is not responsible
for injuries and/or da age resulting fro any persons failure to follow the warnings, cautions, and instructions in
this owners anual. Pride is not responsible for injuries and/or da age resulting fro any persons failure to
exercise good judge ent and/or co on sense.
The sy bols below are used throughout this owners anual to identify warnings and cautions. It is very i portant
for you to read and understand the co pletely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAU ION! Failure to heed the cautions in this owners manual may result in damage to your
scooter.
Copyright © 2002
Pride Mobility Products Corp.
INFMANU2063/REV B/OCTOBER 2002

3
Rally Shopper
I. INTRODUCTION ......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 6
III. EMI/RFI ........................................................................................................................................ 15
IV. SPECIFICATIONS ................................................................................................................... 17
V. YOUR RALLY SHOPPER ...................................................................................................... 19
VI. BATTERIES AND CHARGING ............................................................................................ 24
VII. OPERATION ............................................................................................................................... 28
VIII. COMFORT ADJUSTMENTS................................................................................................ 30
IX. OPTIONAL ACCESSORIES ................................................................................................. 32
X. TROUBLESHOOTING ............................................................................................................ 33
XI. CARE AND MAINTENANCE ................................................................................................ 34
XII. WARRANTY ................................................................................................................................35
CONTENTS
RALLY SHOPPER

4Rally Shopper
I. INTRODUCTION
Welcome to Pride Mobility Products Corporatio (Pride). Co gratulatio s o the purchase of your ew Pride
Scooter. Your scooter desig combi es the most adva ced state-of-the-art compo e ts with moder , attractive
styli g. We are certai that the desig features a d trouble-free operatio will add co ve ie ce to your daily livi g
a d e sure complete satisfactio .
At Pride, your safety is importa t to us. Please read and follow all of the instructions in this manual before
you attempt to operate your scooter for the first time. These i structio s were produced for your be efit.
Your u dersta di g of these i structio s is esse tial for the safe operatio of your ew Pride Scooter.
Pride is ot liable for damage to property or perso al i jury arisi g out of the u safe use of a Pride Scooter. Pride
is also ot liable for a y property damage or perso al i jury arisi g out of the failure of a y perso a d/or user to
follow the i structio s a d recomme datio s set forth i this ma ual or a y other i structio s or recomme datio s
co tai ed i other scooter related literature issued by Pride or co tai ed o the Pride Scooter itself.
This ow ers ma ual is compiled from the latest specificatio s a d product i formatio available at the time of
publicatio . We reserve the right to make cha ges as they become ecessary. A y cha ges to our products may
cause slight variatio s betwee the illustratio s a d expla atio s i this ma ual a d the product you have purchased.
If you experie ce a y problems with your scooter that your are ot able to solve, or if you do ot feel capable of safely
followi g a y of the i structio s a d/or recomme datio s co tai ed i this ma ual, please co tact your authorized
Pride provider for assista ce.
O ce you u dersta d how to operate a d take care of your scooter, we are certai that it will give you years of trouble-
free service a d e joyme t.
Information Exchange
We wa t to hear your questio s, comme ts, a d suggestio s regardi g this ma ual. We would also like to hear about the
safety a d reliability of your ew Pride Scooter, a d the service you received from your authorized Pride provider.
Please otify us of a y cha ge of address so we ca keep you apprised of importa t i formatio regardi g safety, ew
products, a d ew optio s that ca i crease your ability to use a d e joy your Pride Scooter. Please feel free to write us
at the address below:
Pride Mobility Products Corporatio
Att : Customer Care Departme t
182 Susqueha a Ave ue
Exeter, PA 18643-2694
[e-mail]
1-800-424-8205

5
Rally Shopper
I. INTRODUCTION
Pride Owners Club
As a Pride product ow er, you are i vited to register your products warra ty a d e roll i the Pride Ow ers Club.
You may do so by filli g out a d retur i g your e closed registratio card or by visiti g Prides web site at
www.pridemobility.com. As a registered member, each time you visit our site you will have access to the most
i teractive a d ho est educatio al ve ue available today for people with mobility eeds, their families, a d frie ds.
From our home page, click o the butto that reads Ow ers Club to e ter a page dedicated to curre t a d
pote tial Pride product ow ers. You will gai access to i terviews, stories, recreatio ideas, daily livi g tips,
product a d fu di g i formatio , a d i teractive message boards. Message boards i vite you to speak with other
Pride customers as well as Pride represe tatives who are available to assist you with a y questio s or co cer s
you may have.
My Authorized Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Pho e Number:________________________________________________________________________
Quick Reference Information:
Scooter Model:________________________________________________________________________
Serial Number:__________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or this owners manual, contact us and
we will be glad to send you a new one immediately.

6Rally Shopper
II. SAFETY
GENERAL
WARNING! Do not operate your new scooter for the first time without completely reading
and understanding this owners manual.
Your scooter is a state-of-the-art life-e ha ceme t device desig ed to i crease mobility. Pride provides a exte -
sive variety of products to best fit the i dividual eeds of the scooter user. Please be aware that the fi al selectio
a d purchasi g decisio regardi g the type of scooter to be used is the respo sibility of the scooter user who is
capable of maki g such a decisio a d his/her healthcare professio al (i.e., medical doctor, physical therapist,
etc.).
The co te ts of this ma ual are based o the expectatio that a mobility device expert has properly fitted the
scooter to the user a d has assisted the prescribi g healthcare professio al a d/or the authorized provider i the
i structio process for the use of the product.
There are certai situatio s, i cludi g some medical co ditio s, where the scooter user will eed to practice
operati g the scooter i the prese ce of a trai ed atte da t. A trai ed atte da t ca be defi ed as a family member
or care professio al specially trai ed i assisti g a scooter user i various daily livi g activities.
As you begi usi g your scooter duri g daily activities, you will probably e cou ter situatio s i which you will
eed some practice. Simply take your time a d you will soo be i full a d co fide t co trol as you ma euver
through doorways, o a d off elevators, up a d dow ramps, a d over moderate terrai .
MODIFICATIONS
Your scooter has bee desig ed a d e gi eered to provide maximum mobility a d utility. A wide ra ge of accesso-
ries is available from your authorized Pride provider to further customize your scooter to better suit your eeds
a d/or prefere ces. However, u der o circumsta ces should you modify, add, remove, or disable a y feature,
part, or fu ctio of your scooter.
WARNING! Do not modify your scooter in any way. Unauthori ed modifications may result
in personal injury and/or damage to your scooter.
WARNING! Do not attempt to lift or move a scooter by any of its removable parts. Personal
injury and damage to the scooter may result.
REMOVABLE PARTS

7
Rally Shopper
II. SAFETY
PRE-RIDE SAFETY CHECK
Get to k ow the feel of your scooter a d its capabilities. It is recomme ded that you perform a safety check before
each use to make sure your scooter operates smoothly a d safely. For details o how to perform these ecessary
i spectio s, see XI. Care a d Mai te a ce.
Perform the followi g i spectio s prior to usi g your scooter:
nCheck for proper tire i flatio . Mai tai 30-35 psi i each tire (if equipped with p eumatic tires).
nCheck all electrical co ectio s. Make sure they are tight a d ot corroded.
nCheck all co troller co ectio s to the utility tray. Make sure they are secured properly.
nCheck the brakes.
nCheck battery charge.
TIRE INFLATION (If Equipped With Pneumatic Tires)
If your scooter is equipped with p eumatic tires, you should check or have the air pressure checked at least o ce
a week. Proper i flatio pressures will prolo g the life of your tires a d help e sure the smooth operatio of your
scooter.
INCLINE INFORMATION
More a d more buildi gs have ramps with specified degrees of i cli atio , desig ed for easy a d safe access.
Some ramps may have tur i g switchbacks (180-degree tur s) that require you to have good cor eri g skills o
your scooter.
nProceed with extreme cautio as you approach the dow grade of a ramp or other i cli e.
nTake wide swi gs with your scooters fro t wheel(s) arou d a y tight cor ers. If you do that, the scooters rear
wheels will follow a wide arc, ot cut the cor er short, a d ot bump i to or get hu g up o a y raili g cor ers.
nWhe drivi g dow a ramp, keep the scooters speed adjustme t set to the slowest speed setti g to e sure a
safely co trolled desce t. See V. Your Rally Shopper.
nAvoid sudde stops a d starts.
WARNING! Exceeding the weight limit voids your warranty and may result in personal
injury and damage to your scooter. Pride will not be held responsible for injuries and/or
property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your scooter. Carrying passengers on your scooter
may result in personal injury and/or property damage.
If you discover a problem, co tact your authorized Pride provider for assista ce.
WEIGHT LIMITATIONS
Your scooter is rated for a maximum weight limit of 400 lbs.
WARNING! It is critically important that 30-35 psi tire pressure be maintained in pneumatic
tires at all times. Failure to maintain 30-35 psi tire pressure in pneumatic tires at all times
may result in catastrophic tire and/or wheel failure, causing serious personal injury and/or
damage to your scooter.
WARNING! Inflate your scooter drive tires from a regulated air source with an available
pressure gauge. Minimum air pressure for scooter drive tires is 30-35 psi. Inflating your
tires from an unregulated air source could overinflate them, resulting in a burst tire and/or
personal injury.

8Rally Shopper
II. SAFETY
Whe climbi g a i cli e, try to keep your scooter movi g. If you must stop, start up agai slowly, a d the
accelerate cautiously. Whe drivi g dow a i cli e, do so by setti g the speed adjustme t to the slowest setti g
a d drivi g i the forward directio o ly. If your scooter starts to move dow the i cli e faster tha you a ticipated
or desired, allow it to come to a complete stop by releasi g the throttle co trol lever. The push the throttle co trol
lever forward slightly to e sure a safely co trolled desce t.
WARNING! When climbing an incline, do not ig ag or drive at an angle up the face of the
incline. Drive your scooter straight up the incline. This greatly reduces the possibility of a
tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially ha ardous incline (i.e., areas
covered with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the scooter in freewheel
mode while seated on it or standing next to it.
Ha dicap public access ramps are ot subject to gover me t regulatio i all cou tries, a d therefore do ot
ecessarily share the same sta dard degree of slope. Other i cli es may be atural or, if ma -made, ot desig ed
specifically for scooters. Figure 1 illustrates your scooters stability a d its ability to climb grades u der various
weight loads a d u der co trolled testi g co ditio s.
These tests were co ducted with the scooters seat i the highest positio a d adjusted backward o the seat base
to its farthest rearward positio . Use this i formatio as a guideli e. Your scooters ability to travel up i cli es is
affected by your weight, your scooters speed, your a gle of approach to the i cli e, a d your scooter setup.
WARNING! Any attempt to climb or descend a slope steeper than that shown in figure 1
may put your scooter in an unstable position and cause it to tip, resulting in personal
injury.
Figure 1. Maximum Recommended RALLY SHOPPER Incline Angle
150 lbs.
5° 200 lbs. 4° 300 - 400 lbs.
2°

9
Rally Shopper
II. SAFETY
Figure2A.Increased StabilityDrivingPosition
Figure 2. Normal Driving Position
Whe you approach a i cli e, it is best to lea forward. See figures 2 a d 2A. This shifts the ce ter of gravity of
you a d your scooter toward the fro t of the scooter for improved stability.
WARNING! Do not exceed the incline guidelines or any other specifications presented in
this manual.
CORNERING INFORMATION
Excessively high cor eri g speeds ca create the possibility of tippi g. Factors which affect the possibility of
tippi g i clude, but are ot limited to, cor eri g speed, steeri g a gle (how sharply you are tur i g), u eve road
surfaces, i cli ed road surfaces, ridi g from a area of low tractio to a area of high tractio (such as passi g
from a grassy area to a paved area  especially at high speed while tur i g), a d abrupt directio al cha ges. High
cor eri g speeds are ot recomme ded. If you feel that you may tip over i a cor er, reduce your speed a d
steeri g a gle (i.e., lesse the sharp ess of the tur ) to preve t your scooter from tippi g.
WARNING! When cornering sharply, reduce your speed. When using your scooter at
higher speeds, do not corner sharply. This greatly reduces the possibility of a tip or fall.
To avoid personal injury or property damage, always exercise common sense when
cornering.

10 Rally Shopper
II. SAFETY
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs (curbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your scooter climb or descend an obstacle that is
inordinately high. Serious personal injury and/or damage may result.
WARNING! Do not attempt to have your scooter proceed backward down any step, curb, or
other obstacle. This may cause the scooter to tip and cause personal injury.
WARNING! Be sure your scooter is traveling perpendicular to any curb you may be required
to ascend or descend. See figures 3 and 3A.
WARNING! Do not attempt to negotiate a curb that has a height greater than 2 in.
OUTDOOR DRIVING SURFACES
Your scooter is desig ed to provide optimum stability u der ormal drivi g co ditio sdry, level surfaces com-
posed of co crete, blacktop, or asphalt. However, Pride recog izes that there will be times whe you will e cou -
ter other surface types. For this reaso , your scooter is desig ed to perform admirably o packed soil, grass, a d
gravel. Feel free to use your scooter safely o law s a d i park areas.
nReduce your scooters speed whe drivi g o u eve terrai a d/or soft surfaces.
nAvoid tall grass that ca become ta gled i the ru i g gear.
nAvoid loosely packed gravel a d sa d.
nIf you feel u sure about a drivi g surface, avoid that surface.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
figure 3. correct Curb approach Figure 3A. incorrect Curb approach

11
Rally Shopper
BRAKING INFORMATION
Your scooter is equipped with two powerful brake systems:
1. Rege erative: Uses electricity to rapidly slow the vehicle whe the throttle co trol lever retur s to the ce ter/
stop positio ; a d
2. Disc Park Brake: Activates mecha ically after rege erative braki g slows the vehicle to ear stop, or whe
power is removed from the system for a y reaso .
FREEWHEEL MODE
Your scooter is equipped with a ma ual freewheel lever that whe pulled up allows the scooter to be pushed. For
more i formatio about how to place your scooter i to a d out of freewheel mode, see V. Your Rally Shopper.
WARNING! You should not operate your scooter on public roads and parking lots. Be
aware that it may be difficult for traffic to see you when you are seated on your scooter.
Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and then
proceed with extreme caution.
PUBLIC ROADS AND PARKING LOTS
NOTE: afety accessories such as fluorescent flags are available to order from your authorized Pride
provider.
WARNING! Do not use your scooter in freewheel mode without an attendant present.
Personal injury may result.
WARNING! Do not attempt to personally place your scooter in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your scooter in freewheel mode while on an incline. The scooter
could roll uncontrollably on its own, causing personal injury.
INCLEMENT WEATHER PRECAUTIONS
WARNING! It is recommended that you do not operate your scooter in icy or slippery
conditions or on salted surfaces (i.e., walks or roads). Such use may result in an accident,
personal injury, or adversely affect the performance and safety of your scooter.
WARNING! It is recommended that you do not expose your scooter to any type of moisture
at any time (rain, snow, mist, or wash). Such exposure can damage your scooter. Never
operate your scooter if it has been exposed to moisture until it has dried thoroughly.
II. SAFETY

12 Rally Shopper
DOORS
nDetermi e if the door ope s toward or away from you.
nUse your ha d to tur the k ob or push the ha dle or push-bar.
nDrive your scooter ge tly a d slowly forward to push the door ope . Or drive your scooter ge tly a d slowly
backward to pull the door ope .
ELEVATORS
Moder elevators have a door edge safety mecha ism that, whe pushed, reope s the elevator door(s).
nIf you are i the doorway of a elevator whe the door(s) begi to close, push o the rubber door edge or
allow the rubber door edge to co tact the scooter a d the door will reope .
nUse care that pocketbooks, packages, or scooter accessories do ot become caught i elevator doors.
LIFT/ELEVATION PRODUCTS
If you will be traveli g with your scooter, you may fi d it ecessary to use a lift/elevatio product to aid i tra spor-
tatio . It is recomme ded that you closely review the i structio s, specificatio s, a d safety i formatio set forth by
the ma ufacturer of the lift/elevatio product before usi g that product.
WARNING! Do not use your scooter to negotiate steps or escalators. You may cause injury
to yourself and to others and damage your scooter.
STAIRS AND ESCALATORS
Scooters are ot desig ed to travel up or dow stairs or escalators. Always use a elevator.
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact. Failure to do so may result in personal injury.
WARNING! 32 AH scooter batteries weigh 24 lbs. If you are unable to lift that much
weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead
compounds. Wash hands after handling.
WARNING! Always protect the batteries from free ing and never charge a fro en battery.
Charging a fro en battery may result in personal injury and/or damage to the battery.
BATTERIES
I additio to followi g the war i gs below, be sure to comply with all other battery ha dli g i formatio . For
more i formatio about your scooters batteries, see VI.  Batteries a d Chargi g.
PREVENTING UNINTENDED MOVEMENT
II. SAFETY

13
Rally Shopper
WARNING! Do not sit on your scooter while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your scooter and its batteries are properly secured when it is
being transported. Failure to do so may result in personal injury and/or damage to your
scooter.
MOTOR VEHICLE TRANSPORT
Curre tly, there are o sta dards approved for tie-dow systems i a movi g vehicle of a y type to tra sport a
perso while seated i a scooter.
Although your scooter may be equipped with a positio i g belt, this belt is ot desig ed to provide proper restrai t
duri g motor vehicle tra sport. A yo e traveli g i a motor vehicle should be properly secured i the motor vehicle
seat with safety belts faste ed securely.
GETTING ONTOAND OFF OF YOUR SCOOTER
Getti g o to a d off of your scooter requires a good se se of bala ce. Please observe the followi g safety tips
whe getti g o to a d off of your scooter:
nPower dow your scooter. See VII. Operatio .
nE sure that your scooter is ot i freewheel mode. See V. Your Rally Shopper.
nMake certai that the seat is locked i to place a d the key is removed from the key switch.
nThe seat armrests ca be flipped up to make getti g o to a d off of your scooter easier.
WARNING! Position yourself as far back as possible in the scooter seat to prevent the
scooter from tipping and causing injury.
WARNING! Avoid using the armrests for weight bearing purposes. Such use may cause the
scooter to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
scooter to tip and cause personal injury.
POSITIONING BELTS
Your authorized provider, therapist(s), a d other healthcare professio als are respo sible for determi i g your
requireme t for a positio i g belt i order to operate your scooter safely.
WARNING! If you require a positioning belt to safely operate your scooter, make sure it is
fastened securely. Serious personal injury may result if you fall from the scooter.
II. SAFETY

14 Rally Shopper
REACHING AND BENDING
Avoid reachi g or be di g while drivi g your scooter. Whe reachi g, be di g, or lea i g while seated o your
scooter, it is importa t to mai tai a stable ce ter of gravity a d keep the scooter from tippi g. It is recomme ded
that the scooter user determi e his/her perso al limitatio s a d practice be di g a d reachi g i the prese ce of a
qualified healthcare professio al.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
floor by reaching down between your knees. Movements such as these may change your
center of gravity and the weight distribution of the scooter and cause your scooter to tip,
possibly resulting in personal injury. Keep your hands away from the tires when driving.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The scooter user must exercise care a d commo se se whe operati g his/her scooter. This i cludes aware ess of
safety issues whe taki g prescribed or over-the-cou ter drugs or whe the user has specific physical limitatio s.
WARNING! Consult your physician if you are taking prescribed or over-the-counter
medication or if you have certain physical limitations. Some medications and limitations
may impair your ability to operate your scooter in a safe manner.
ALCOHOL
The scooter user must exercise care a d commo se se whe operati g his/her scooter. This i cludes aware ess
of safety issues while u der the i flue ce of alcohol.
WARNING! Do not operate your scooter while you are under the influence of alcohol, as
this may impair your ability to drive safely.
II. SAFETY

15
Rally Shopper
III. EMI/RFI
EMI/RFI WARNINGS
Laboratory tests performed by the Food a d Drug Admi istratio (FDA) have show that radio waves ca cause
u i te ded motio of electric mobility vehicles. Radio waves are a form of electromag etic e ergy (EM). Whe
electromag etic e ergy adversely affects the operatio of a electrical device, that adverse effect is called Electro-
magnetic Interference (EMI) or Radio Frequency Interference (RFI).
EMI/RFI FREQUENTLY ASKED QUESTIONS (FAQS)
The followi g FAQs summarize what you should k ow about EMI/RFI. Use this information to minimize the risk
that EMI/RFI will adversely affect your mobility vehicle.
Where do radio waves come from?
Radio waves are emitted from the a te as of cellular pho es, mobile two-way radios (such as walkie-talkies a d
CBs), radio statio s, TV statio s, amateur radio (HAM) tra smitters, wireless computer li ks, microwave sources,
a d pagi g tra smitters. Radio waves are a form of electromag etic e ergy (EM). EM is more i te se closer to
tra smitti g a te as, which are sources of emissio . The greater the tra smissio stre gth, the greater the co cer
to electric mobility vehicle users.
If E I/RFI affects my mobility vehicle, what kind of motion should I expect?
This is difficult to predict. The a swer would depe d o a umber of factors:
nThe stre gth of the radio waves.
nThe co structio of your particular mobility vehicle.
nThe locatio of your mobility vehicle (whether it is o the level grou d or o a i cli e).
nWhether or ot your mobility vehicle is i motio .
The motio of a y electric mobility vehicle affected by EMI/RFI ca be erratic. The mobility vehicle may come to
a sudde stop or move i a u co trolled ma er. Also, it is possible for EMI/RFI to release the brakes of a
electric mobility vehicle. Some i te se EMI/RFI ca eve damage the co trol system compo e ts of a electric
mobility vehicle.
Is there any way to know for certain whether or not radio waves are the cause of any unintended
mobility vehicle motion?
U fortu ately, EMI/RFI may be difficult to recog ize, because the sig als from radio sources are i visible a d may
be i termitte t. However, the FDA recomme ds that you report all i cide ts of u i te ded motio or u i te ded
brake release of your mobility vehicle to its ma ufacturer a d, if possible, determi e whether or ot there was a
radio wave source earby at the time of the i cide t.
O e precautio you ca take agai st u i te ded motio of your mobility vehicle is to make certai that you or
someo e else is ot the cause of the u i te ded motio .
nTur off your mobility vehicle by removi g the key from the key switch whe you are getti g o to or off of your
mobility vehicle.
nNever leave the key i the key switch of a u atte ded mobility vehicle.
nBy followi g these steps, you greatly reduce the risk of you or a yo e else i adverte tly bumpi g the throttle
co trol levers a d causi g the mobility vehicle to move u i te tio ally.
Has anyone been injured by the erratic, unintended motion of an electric mobility vehicle?
The FDA has reports of i juries that resulted from u co trolled motio of electric mobility vehicles, but it is ot
clear just how ma y of those i juries were actually caused by EMI/RFI.

16 Rally Shopper
III. EMI/RFI
Are all electric mobility vehicles susceptible to E I/RFI?
Each make a d model of electric mobility vehicle differs i its ability to resist EMI/RFI. Every mobility vehicle has
a particular level of resista ce to EMI/RFI. This resista ce is measured i volts per meter (V/m). A higher resis-
ta ce level offers greater protectio agai st EMI/RFI. I other words, a electric mobility vehicle with a high
resista ce level is less likely to be affected by a stro g radio source tha is a electric mobility vehicle with a low
resista ce level.
What is the FDA doing about the problem?
The FDA has writte to electric mobility vehicle ma ufacturers a d requested that those ma ufacturers test their
ew mobility vehicle models to be certai that they provide a reaso able degree of resista ce agai st EMI/RFI.
The FDA has stated that all ewly ma ufactured electric mobility vehicle models should have a resista ce level of
at least 20 V/m. This level of resista ce provides a reaso able degree of protectio agai st the commo sources of
EMI/RFI.
The FDA has also requested or recomme ded that:
nElectric mobility vehicle ma ufacturers clearly label ew products with their resista ce level or state that the
resista ce level is ot k ow .
nThe labeli g or i formatio al material supplied with ew electric mobility vehicles must explai what the resis-
ta ce level mea s a d war users about the possibility of EMI/RFI a d how to avoid it.
nElectric mobility vehicle ma ufacturers u dertake a educatio al program to i form electric mobility vehicle
users a d their caregivers about the problems associated with EMI/RFI a d about the actio s they ca take to
mi imize the risk of EMI/RFI.
nWhile there is o exact way to tell if your mobility vehicle is totally safe, a immu ity level of 20 V/m is ge erally
achievable a d useful. This product has bee tested a d passed at a immu ity level of 20 V/m.
What can I do to find out if my mobility vehicle is likely to be affected by E I/RFI?
If you have had your mobility vehicle for some time a d have ot experie ced a y u i te ded motio , it is ot likely
that you will have a problem i the future. However, it is always possible that EMI/RFI problems could arise if you
are close to a source of radio waves. Therefore, it is very importa t for you to be alert to this possibility. The
mobility vehicle meets or exceeds a resista ce level of at least 20 V/m.
What can I do to reduce the risk of my mobility vehicle being affected by E I/RFI?
Here are some precautio s you ca take:
nDo ot tur o or use ha d-held perso al commu icatio s devices, such as citize s ba d (CB) radios a d
cellular pho es, while your mobility vehicle is tur ed o .
nBe aware of earby radio wave tra smitters, such as radio or TV statio s a d ha d-held or mobile two-way
radios. Try ot to operate your mobility vehicle too close to those tra smitters. For example, if you are o a
electric mobility vehicle with a resista ce level of at least 20 V/m, you should remai at least three feet from a
ha d-held two-way radio a d at least te feet from a mobile two-way radio.
nBe aware that addi g accessories a d/or compo e ts, or modifyi g your mobility vehicle i a y way, may
cha ge its EMI/RFI resista ce level a d may make it more susceptible to i terfere ce from radio wave sources.
What should I do if my mobility vehicle moves unexpectedly?
If u i te ded motio or u i te ded brake release occurs, tur off your mobility vehicle (by removi g the key) as
soo as it is safe to do so.
If my mobility vehicle moves unintentionally, where should I report the incident?
Call Pride Customer Care at 1-800-424-8205 to report the i cide t.

17
Rally Shopper
IV. SPECIFICATIONS
Figure 4A. Rally Shopper Wheel Dimensions (Front)
9"
2.5"
Figure 4B. Rally Shopper Wheel Dimensions (rear)
8"
2"
7.5"
13.5"
18.5"16.5"
32" 34"
-
-
80˚
3"
28"
55"
22" - 29"
21"
54"
Turning Radius
16"
18"
Figure 4. Rally Shopper Dimensions

18 Rally Shopper
IV. SPECIFICATIONS
Model Number SC151SHP
Available Colors Black (haircell pattern)
Overall Length 55 in.
Overall Width 28 in. at basket
Total Weight Without Batteries 140 lbs.
Heaviest Piece When Disassembled Main frame with seat and batteries removed: 120 lbs.
Turning Radius 54 in.
Maximum Speed Up to 3 mph (dealer adjustable up to 4.5 mph)
Range Per Charge* Up to 20 miles with 32 AH batteries
Ground Clearance 3 in.
Weight Capacity 400 lb. maximum
Standard Seating Type: Molded plastic with removable cover and internal foam padding
Dimensions: width 18 in. x depth 16 in. x height 13.5 in.
Material: Vinyl: Black (standard)
Fabric: Gray
Drive System Rear-wheel drive, 24V sealed transaxle
Dual Braking System Electronic, regenerative, and electromechanical
Wheels Alloy wheels in Black
Tires (front) 8 in. x 2 in.
Tires (rear) 9 in. x 2.5 in.
Battery Requirements Type: 12V deep-cycle (SLA or gel cell)
Size: U-1, 32 AH
Battery Charger Onboard, 3-amp
Warranty 3-year limited
Accessories and Options Single cane/crutch holder, dual cane/crutch holder, double crutch
holder, oxygen tank holder, walker holder, forearm crutch holder, cup
holder, dust cover, safety flag, rear basket, taillight, quad cane holder
*Varies with user weight, terrain type, battery charge, battery condition, and tire condition.

19
Rally Shopper
Your Rally Shopper is a motorized electric scooter desig ed to e ha ce your perso al mobility. Your Rally Shop-
per is a i door/outdoor scooter that was desig ed to travel primarily o smooth surfaces, such as paveme t,
roads, parki g lots, floors, a d driveways. For easy tra sportatio or storage, you ca disassemble your scooter
i to five compo e ts. See figure 5.
CONTROL CONSOLE ASSEMBLY
The co trol co sole assembly houses all of the co trols you eed to drive your scooter i cludi g the key switch, the
speed adjustme t dial, the throttle co trol lever, the battery co ditio meter, a d the hor butto . See figure 6.
WARNING! Do not expose the control console assembly to moisture. In the event that the
console does become exposed to moisture, do not attempt to operate your scooter until
the control console assembly has thoroughly dried.
BATTERYCONDITIONMETER
THROTTLE CONTROL LEVER
(REVERSE)
SPEED ADJUSTMENT DIAL
KEY SWITCH
KEY
HORN BUTTON THROTTLE CONTROL LEVER
(FORWARD)
V. YOUR RALLY SHOPPER
Figure 5. Five Rally Shopper Components
Figure 6. Control console assembly
SEAT
REAR SHROUD
MAIN FRAME
BATTERIES

20 Rally Shopper
Key Switch
nFully i sert the key i to the key switch to power up (tur o ) your scooter.
nPull the key out to power dow (tur off) your scooter.
WARNING! If the key is removed from the key switch while your scooter is in motion, the
electronic brakes engage and your scooter comes to an abrupt stop!
Speed Adjustment Dial
This co trol dial allows you to preselect a d limit your scooters top speed.
nThe image of the tortoise represe ts the slowest speed setti g.
nThe image of the hare represe ts the fastest speed setti g.
Throttle Control Lever
This lever allows you to co trol the forward a d the reverse speed of your scooter up to the maximum speed
preset by the speed adjustme t dial.
nPlace your right ha d o the right ha dgrip a d your left ha d o the left ha dgrip.
nUse your right thumb to push the right side of the lever to dise gage your scooters brake a d move forward.
nRelease the lever a d allow your scooter to come to a complete stop before pushi g the other side of the lever
to move i reverse.
nWhe the throttle is completely released, it automatically retur s to the ce ter stop positio a d e gages your
scooters brake.
Battery Condition Meter
This meter gives a approximate readi g of your scooters battery voltage whe the key is fully i serted i to the
key switch.
Horn Button
nThe key must be fully i serted i to the key switch for the hor to be operatio al.
nThis butto activates a war i g hor .
nDo ot hesitate to use the war i g hor whe its use could preve t accide t or i jury.
V. YOUR RALLY SHOPPER
