Pro-Form PFCCEL1305.0 User manual

CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. PFCCEL1305.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 17h00 EST
(excluding holidays).
USER’S MANUAL
www.proform.com
Visit our website at
Visit our website at

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE ELLIPTICAL EXERCISER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
HOW TO ORDER REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
2
PROFORM is a registered trademark of ICON IP, Inc.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precau-
tions before using the elliptical exerciser.
1. Read all instructions in this manual and all
warnings on the elliptical exerciser before
using the elliptical exerciser.
2. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
3. The elliptical exerciser is intended for
home use only. Do not use the elliptical
exerciser in a commercial, rental, or institu-
tional setting.
4. Keep the elliptical exerciser indoors, away
from moisture and dust. Place the elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around the elliptical exerciser to mount, dis-
mount, and use it.
5. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
6. Keep children under 12 and pets away from
the elliptical exerciser at all times.
7. The elliptical exerciser should not be used by
persons weighing more than 115 kg (250 lbs.).
8. Wear appropriate exercise clothes when
using the elliptical exerciser. Always wear
athletic shoes for foot protection while exer-
cising.
9. Hold the center handlebar or the left and right
handlebars while mounting, dismounting, or
using the elliptical exerciser.
10. The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
11. Keep your back straight when using the ellip-
tical exerciser; do not arch your back.
12. If you feel pain or dizziness while exercis-
ing, stop immediately and cool down.
13. When you stop exercising, allow the pedals
to slowly come to a complete stop. The ellip-
tical exerciser does not have a free wheel;
the pedals will continue to move until the
flywheel stops.
14. Always unplug the power cord immediately
after use and before cleaning the elliptical
exerciser.
15. The decals shown below have been placed
on the elliptical exerciser. If either decal is
missing or illegible, please call the toll-free
telephone number on the front cover of this
manual and order a free replacement decal.
Apply the decal in the location shown.
WARNING: Before beginning this or any exercise program, consult your physician.
This is especially important for persons over the age of 35 or persons with pre-existing health prob-
lems. Read all instructions before using. ICON assumes no responsibility for personal injury or
property damage sustained by or through the use of this product.
210330 209489

4
BEFORE YOU BEGIN
Thank you for selecting the new PROFORM®1280 S
elliptical exerciser. The PROFORM 1280 S elliptical
exerciser is an incredibly smooth exerciser that moves
your feet in a natural elliptical path, minimizing the
impact on your knees and ankles. And the unique
1280 S features adjustable resistance and a state-of-
the-art console to help you get the most from your
exercise.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please call the toll-free
telephone number on the front cover of this manual.
To help us assist you, please note the product model
number and serial number before calling. The model
number is PFCCEL1305.0. The serial number can be
found on a decal attached to the elliptical exerciser
(see the front cover of this manual for the location of
the decal).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handgrip Pulse Sensor
Center Handlebar
FRONT
BACK
RIGHT SIDE
Power Socket
Wheel
Leveling Foot
Flex Bar
Fan
Console
Right Handlebar
CD Holder
CD Player
Left Handlebar
Water Bottle Holder*
Pedal
*No bottle is included
Ramp

5
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included allen wrenches, assembly requires a phillips screwdriver , an adjustable
wrench , and a rubber mallet .
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on pages 24 and 25. The number following the key
number is the quantity needed for assembly. Note: Some small parts may have been pre-assembled. If a
part is not found in the parts bag, check to see if it has been pre-assembled.
Union Bolt Set (27)–2
M4 x 52mm Screw (98)–2
M4 x 16mm Round
Head Screw (45)–1
M4 x 16mm
Screw (66)–6
M8 Split
Washer (94)–10
M8.5 Washer
(53)–2
M6 x 16mm Tapered
Button Screw (107)–8
M8 x 43mm Button
Bolt (50)–4
M8 x 38mm Button
Screw (70)–2
M10 x 35mm Carriage
Bolt (20)–2
M8 x 54mm Button
Screw (33)–4
M8 x 45mm Button
Screw (102)–4
M4 x 14mm Round
Head Screw (93)–2
M8 Nylon
Locknut (46)–4
M10 Washer
(99)–2
M4 x 12mm
Screw (84)–6
M8 x 25mm Patch
Screw (22)–2
M6 x 18mm Button
Screw (67)–4
M6 Washer
(58)–2
M10 Split
Washer (144)–2
Wave Washer
(150)–2

6
2. Move and lift the left Flex Bar (14) out of the way and
slide the Left Stabilizer Cover (31) onto the Front
Stabilizer (3). Slide the Right Stabilizer Cover (116)
onto the Front Stabilizer in the same way.
While another person lifts the front of the Frame (1),
attach the Left and Right Stabilizer Covers (31, 116) to
the Front Stabilizer (3) with two M4 x 52mm Screws
(98).
14
14
3
1
3
98
94
94
1
4
92
35
102
3. With the help of a second person, carefully tip the
elliptical exerciser onto one side.
Make sure that the Left and Right Stabilizer Endcaps
(35, 92) are on the Rear Stabilizer (4).
Attach the Rear Stabilizer (4) to the Frame (1) with
four M8 x 45mm Button Screws (102) and four M8
Split Washers (94). Note: There are wires (not
shown) inside of the Frame. Be careful to avoid
damaging the wires with the Button Screws.
With the help of a second person, carefully tip the
elliptical exerciser back to the vertical position.
2
31
116
1. While another person lifts the front of the Frame (1),
thread a Leveling Foot (72) fully into the underside of
the Frame.
Next, attach the Front Stabilizer (3) to the front of the
Frame (1) with two M8 x 54mm Button Screws (33)
and two M8 Split Washers (94).
3
94
94
33
1
72
1

7
133
58
137
67
58
123
67
5. Identify the Incline Axle (137), which is the longest
remaining axle. Slide an M6 Washer (58) onto an M6 x
18mm Button Screw (67). Tighten the Button Screw into
one end of the Incline Axle. Apply a small amount of
grease to the Incline Axle.
Raise the Ramp (133). Insert the Incline Axle (137) into
one side of the Ramp, through an Incline Spacer (123),
through the motor screw, through the other Incline
Spacer, and then into the other side of the Ramp. As
you insert the Incline Axle through the motor screw,
make sure that the motor screw does not turn.
Slide an M6 Washer (58) onto an M6 x 18mm Button
Screw (67). Tighten the Button Screw into the other end
of the Incline Axle (137).
Motor Screw
4
133
67
67
132
132
128
130
130 Tube
1
4. Identify the Ramp Axle (128), which is the longest axle.
Slide a Ramp Axle Cover (132) onto an M6 x 18mm
Button Screw (67) as shown. Tighten the Button Screw
into one end of the Ramp Axle. Apply a small amount of
the included grease to the Ramp Axle.
Have a second person hold the two Ramp Spacers
(130) against the sides of the Frame (1) so they cover
the indicated tubes on the Frame. See the inset draw-
ing. Make sure that the Ramp Spacers are oriented
as shown. Next, lift the Flex Bars (not shown) out of
the way and align the round tubes on the Ramp (133)
with the Ramp Spacers. Make sure that the Ramp is
turned as shown. Insert the Ramp Axle (128) into the
Ramp, the Ramp Spacers, and the Frame. Note: It may
be helpful to use a rubber mallet.
Slide the other Ramp Cover (132) onto an M6 x 18mm
Button Screw (67) as shown. Tighten the Button Screw
into the other end of the Ramp Axle (128). Grease
Grease
5
130
Side View
Wide
End
Up

8
8
8. Apply a generous amount of grease to the Pivot Axle
(108) and to the two M8.5 Washers (53). Insert the
Pivot Axle into the Upright (2) and center it. Reapply
grease to both sides of the Pivot Axle.
Identify the Left and Right Handlebars (9, 10), which
are marked with stickers. Slide a Handlebar Spacer
(25) onto the short tube on each Handlebar,and slide
the Handlebars onto the Pivot Axle (108). Make sure
that the Handlebars are on the correct sides.
Place a Wave Washer (150) onto each end of the Pivot
Axle (108). Tighten an M8 x 25mm Patch Screw (22)
with an M8.5 Washer (53) into each end of the Pivot
Axle. Orient the two Handlebar Caps (23) as shown,
and press the small tabs on the Handlebar Caps into
the two Handlebar Spacers (25).
9
23
22
23
22
53
53
150
150 25
10
2
108 Grease
Grease
25
Tube
Tube
7. Identify the Left Handlebar (9), which is marked with a
sticker. Insert the Left Handlebar into one of the
Handlebar Legs (79); make sure that the Handlebar
Leg is turned so the hexagonal holes are on the
indicated side.Attach the Left Handlebar with two M8
x43mm Button Bolts (50) and two M8 Nylon Locknuts
(46). Do not tighten the Button Bolts yet. Make
sure that the Nylon Locknuts are seated in the
hexagonal holes.
Attach the Right Handlebar (not shown) to the
other Handlebar Leg (not shown) in the same way.
7
9
79
Hexagonal
Holes
50
46
6
6. Have another person hold the Upright (2) near the
Frame (1). Connect the Upper Wire Harness (86) to the
Lower Wire Harness (87). Next, slide the Upright onto
the Frame. Be careful to avoid disconnecting or
pinching the Wire Harnesses. Attach the Upright with
two M8 x 54mm Button Screws (33), two M8 x 38mm
Button Screws (70), and four M8 Split Washers (94). Be
careful to avoid damaging the Wire Harnesses with
the Button Screws.
Hold the Left and Right Handlebar Covers (26, 29)
around the Upright (2) and the indicated tube. Press the
Handlebar Covers together and connect them with an
M4 x 16mm Round Head Screw (45).
Hold the Left and Right Upright Covers (34, 38) around
the Upright (2). Attach the Upright Covers with two M4 x
14mm Round Head Screws (93).
26
93
93
34
38
86
2
Tube
1
87
94
70
33
94
94
94
29
45
Make sure
the wire
harnesses
do not get
pinched and
damaged
during this
step.

9
11. Loosen the eight indicated screws (A) in the Center
Handlebar (63).
Attach the Center Handlebar (63) to the Upright (2)
with eight M6 x 16mm Tapered Button Screws (107).
Do not tighten the Tapered Button Screws yet.
Retighten the eight screws (A) in the Center
Handlebar (63).
11
63
2
107
107
A
10
15
14
20
99
12
13
144
10. Identify the Left Pedal (13). Attach the Left Pedal to
the left Flex Bar (14) with an M10 x 35mm Carriage
Bolt (20), an M10 Washer (99), an M10 Split Washer
(144), and a Pedal Knob (15) as shown. Note: The
Left Pedal can be attached in any of five positions
(see HOW TO ADJUST THE PEDALS on page 11).
Attach the Right Pedal (12) in the same way.Make
sure that both Pedals are in the same position.
See step 7. Tighten the four M8 x 43mm Button Bolts
(50).
9. Remove the Chrome Tube (118) from the left
Handlebar Leg (79). Apply a small amount of the
included high-temperature lubricant to a paper towel,
and rub a thin film of lubricant onto the Chrome Tube.
Then, reinsert the Chrome Tube into the Handlebar
Leg.
See the drawing at the right and the inset drawing.
Apply a thin film of grease to the shaft of a Union Bolt
Set (27). Insert the shaft of the Union Bolt Set into the
side of the left Flex Bar (14) closest to the Upright (2),
and then slide a 4.7mm Spacer (143) onto the shaft.
Next, slide the end of the left Chrome Tube (118) onto
the shaft and onto the Spacer. Then, slide a Wheel
Bushing (28), a Ramp Wheel (119), and another
Wheel Bushing onto the shaft. Make sure that all
parts are oriented exactly as shown. Insert the shaft
completely through the Flex Bar and tighten the screw
of the Union Bolt Set into the shaft.
Repeat this step to attach the right Chrome Tube (118)
to the right Flex Bar (14).
9
2
Lubricate
79
27
118 143
119
118
27
28
28
27
Grease
Shaft
Screw
14
143
28
28
118
119
14
27
14
14

10
14. Plug the Power Cord (96) into the Power Socket (140)
at the rear of the elliptical exerciser.
15. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet, place a mat under the elliptical exerciser.
The elliptical exerciser is now fully assembled. If you have purchased the optional chest pulse sen-
sor (see page 21), follow the instructions on page 21 and install the receiver included with the chest
pulse sensor.
96
140
13
13. Attach the Left Console Cover (109) to the Console (5)
with three M4 x 16mm Screws (66). Attach the Right
Console Cover (110) in the same way.
See assembly step 11. Tighten the eight M6 x 16mm
Tapered Button Screws (107).
5
66
66
109
110
14
12. See step 13. Remove the six M4 x 16mm Screws (66)
and the Left and Right Console Covers (109, 110) from
the Console (5).
Attach the CD Holder (114) to the Console (5) with
two M4 x 12mm Screws (84) as shown.
While another person holds the Console (5) in the
position shown, connect the wire harness on the
Console to the Upper Wire Harness (86). Insert the
excess wire harness down into the Upright (2).
Attach the Console (5) to the Upright (2) with four M4
x12mm Screws (84). Be careful to avoid pinching
the wire harnesses.
84
86
Wire
Harness
2
5
114
12
84

11
HOW TO USE THE ELLIPTICAL EXERCISER
HOW TO PLUG IN THE POWER CORD
This product
must be
grounded.
If it should
malfunction
or break
down,
grounding
provides a
path of least
resistance for
electric current to reduce the risk of electric shock.
This product is equipped with a cord having an equip-
ment-grounding conductor and a grounding plug. Plug
the power cord into an appropriate outlet that is
properly installed and grounded in accordance
with all local codes and ordinances. This product
is for use on a nominal 120-volt circuit. Important:
The elliptical exerciser is not compatible with
GFCI-equipped outlets.
A temporary
adapter may
be used to
connect the
power cord
to a 2-pole
receptacle
as shown at
the right if a
properly
grounded
outlet is not
available. The temporary adapter should be used only
until a properly grounded outlet can be installed by a
qualified electrician.
The green-colored rigid ear,lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in
place by a metal screw. Some 2-pole receptacle out-
let box covers are not grounded. Contact a quali-
fied electrician to determine if the outlet box cover
is grounded before using an adapter.
HOW TO ADJUST THE PEDALS
The motion of
the pedals is
determined by
their positions
on the flex
bars. There
are five posi-
tions. To
adjust each
pedal, first
loosen the
knob beneath
the pedal. Next, push the bolt upward, slide the pedal
forward or backward to the desired position, and then
retighten the knob. Make sure that both pedals are in
the same position.
HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
Tomount the
elliptical exer-
ciser,hold the
center handle-
bar and step
onto the pedal
that is in the
lowest posi-
tion. Then,
step onto the other pedal. Push the pedals until they
begin to move with a continuous motion. Note: The
crank arms (inside of the side shields) can be
turned in either direction. It is recommended that
you turn the crank arms in the same direction that
you pedal a bicycle; however, for variety, you can
turn the crank arms in the opposite direction.
To dismount the elliptical exerciser, wait until the ped-
als come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals
will continue to move until the flywheel stops.
When the pedals are stationary, step off the highest
pedal first. Then, step offthe lowest pedal.
DANGER: Improper connection of
the equipment-grounding conductor can result
in an increased risk of electric shock. Check
with a qualified electrician or serviceman if
you are in doubt as to whether the product is
properly grounded. Do not modify the plug
provided with the product—if it will not fit the
outlet, have a proper outlet installed by a qual-
ified electrician.
Grounded Outlet Box
Grounding Plug
Grounded Outlet
Pin
Grounded Outlet Box
Adapter
Lug
Metal Screw
Knob
Pedal
Bolt
Flex
Bar
Pedal
Side
Shields

12
FEATURES OF THE CONSOLE
The advanced console offers a selection of features
designed to make your workouts more enjoyable and
effective. When the manual mode of the console is
selected, the resistance of the pedals and the angle of
the ramp can be changed with the touch of a button.
As you work out, the console will provide continuous
exercise feedback. You can even measure your heart
rate using the built-in handgrip pulse sensor or the
optional chest pulse sensor (see page 21).
The console also offers ten Smart programs. Each pro-
gram automatically changes the resistance of the ped-
als and prompts you to increase or decrease your pace
as it guides you through an effective workout. In addi-
tion, the console features two Heart Rate programs
that change the resistance of the pedals and prompt
you to vary your pace to keep your heart rate near a
target heart rate as you exercise.
The console also features iFIT.com interactive technol-
ogy. Having iFIT.com technology is like having a per-
sonal trainer in your home. Using the built-in CD play-
er, you can play special iFIT.com CD programs.
iFIT.com CD programs automatically control the resis-
tance of the pedals and prompt you to vary your pace
while a personal trainer coaches you through every
step of your workout. High-energy music provides
added motivation. To purchase iFIT.com CDs, call
the toll-free telephone number on the front cover
of this manual.
Using a stereo audio cable (available at electronics
stores), you can also connect the elliptical exerciser to
your VCR and TV and play iFIT.com video programs.
iFIT.com video programs offer the same benefits as
iFIT.com CD programs, and allow you to enjoy breath-
taking scenery while you exercise. To purchase
iFIT.com videocassettes, call the toll-free telephone
number on the front cover of this manual.
You can even connect the elliptical exerciser to your
home computer,go to our Web site at www.iFIT.com,
and access programs directly from our Web site.
Explore www.iFIT.com for more information.

13
To use the manual mode of the console, see the
instructions below. To use a Smart program, see
page 15. Touse a Heart Rate program, see page 16.
To use an iFIT.com CD program, see page 17. To
use an iFIT.com video program, see page 19. To
use a program directly from our Web site, see
page 20.
HOW TO USE THE MANUAL MODE
Turn on the console.
Make sure that the power cord is properly plugged
in (see HOW TO PLUG IN THE POWER CORD
on page 11).
To turn on the console, press the On/Reset button
or begin pedaling. (The On/Reset button is the
button just above the large display.)
Select the manual mode.
Each time the console is
turned on, the manual
mode will be selected. If a
program has been select-
ed, reselect the manual
mode by pressing the
Program button repeatedly
until the letters RPM
appear in the small display.
Change the resistance of the pedals and the
angle of the ramp as desired.
To change the resistance of the pedals, press the
Resistance + and – buttons. There are ten resis-
tance levels; level 10 is the most challenging.
Note: After the buttons are pressed, it will take a
few seconds for the pedals to reach the selected
resistance level.
Tovary the feel of your exercise on the elliptical
exerciser,increase or decrease the angle of the
ramp by pressing the Ramp buttons.
Follow your progress with the large display and
the small display.
The upper sec-
tion of the large
display will show
the distance you
have pedaled and
the numbers of
calories and fat calories you have burned (see
FAT BURNING on page 23). The display will
change from one number to the next every few
seconds. When you use the handgrip pulse sen-
sor or the optional chest pulse sensor, the display
will also show your heart rate (see step 5 on page
14).
The center of
the large display
will show the
elapsed time and
your pedaling
pace (in minutes
per mile). The display will change from one num-
ber to the other every few seconds. Note: When a
program is selected (except for Heart Rate pro-
gram 2), the display will show the time remaining
in the program instead of the elapsed time.
The lower sec-
tion of the large
display will show
your pedaling
speed, your ped-
aling pace (in rev-
olutions per minute), and the resistance level.
The display will change from one number to the
next every few seconds.
Note: The con-
sole can show
speed and dis-
tance in either
miles or kilome-
ters. The letters
MPH or KM/H will appear in the lower section of
the large display to show which unit of measure-
ment is selected. To change the unit of measure-
ment, first hold down the Program button for a few
seconds. An E (for English) or an M (for metric) will
appear in the lower section of the large display.
Press the Resistance + button to change the unit
of measurement. Then, press the On/Reset button.
4
3
2
1

14
The small display will
show your pedaling pace
(in revolutions per minute).
The indicator bar in the
small display will increase
or decrease in length as
you increase or decrease
your pedaling pace. Note:
When you use a Heart Rate program, the small
display will show your heart rate instead of your
pedaling pace.
To reset the displays, press the On/Reset button.
Measure your heart rate if desired.
You can measure your heart rate using the built-in
handgrip pulse sensor or the optional chest pulse
sensor. To use the handgrip pulse sensor, follow
the instructions below. Note: If you wear the
chest pulse sensor and hold the handgrip
pulse sensor at the same time, the console
will not display your heart rate accurately.
If there are
thin sheets of
plastic on the
metal contacts
on the hand-
grip pulse sen-
sor,peel off
the plastic. To
use the hand-
grip pulse sen-
sor, hold the
handgrips with your palms resting against the
metal contacts. Avoid moving your hands or
squeezing the handgrips too tightly; exces-
sive movement or pressure may interfere with
heart rate readings. When your pulse is detect-
ed, the heart-shaped indicator in the large display
will flash each time your heart beats, and your
heart rate will be shown.
For the most accurate heart rate reading, continue
to hold the handgrips for about 30 seconds. Note:
When you first hold the handgrips, the large dis-
play will show your heart rate continuously for 30
seconds. The display will then show your heart
rate along with other feedback modes.
Turn on the fan if desired.
To turn on the
fan at low speed,
press the fan
button. To turn
on the fan at
high speed,
press the fan
button a second
time. To turn off
the fan, press the fan button a third time. Note: If
the fan is turned on but the pedals are not moved
for thirty seconds, the fan will automatically turn
off.
Rotate the thumb wheel on the right side of the
fan to pivot the fan to the desired angle.
When you are finished exercising, the console
will automatically turn off.
If the pedals are not moved for a few seconds,
the displays will pause and the time will flash in
the large display. If the pedals are not moved and
the console buttons are not pressed for a few
minutes, the console will turn off.
7
6
5
Metal
Contacts
Thumb Wheel
Indicator Bar

15
Each Smart program will automatically change the
resistance of the pedals and prompt you to increase or
decrease your pace as it guides you through an effec-
tive workout.
Follow the steps below to use a Smart program.
Turn on the console.
See step 1 on page 13.
Select one of the Smart programs.
To select a Smart program,
press the Program button
repeatedly until the num-
ber 3, 4, 5, 6, 7, 8, 9, 10,
11, or 12 appears in the
small display.
Begin pedaling to start the program.
Each Smart program consists of either 20 or 30
one-minute periods. One resistance level and one
target pace are programmed for each period.
Note: The same resistance level and/or target
pace may be programmed for two or more con-
secutive periods.
When you begin pedaling, the resistance of the
pedals will automatically change to the resistance
level programmed for the first period. Note: If the
resistance level is too high or too low, you can
change it by pressing the Resistance buttons.
The target pace
for the first period
will appear in the
small display for
afew seconds,
and the arrows in
the small display
will help you to
pedal at the target pace—simply increase or
decrease your pace until one segment of the indi-
cator bar appears at the tip of each arrow (see
the drawing above). Note: When the word TAR-
GET does not appear in the small display, your
actual pedaling pace will be shown. Important:
The target pace is intended only to provide a
goal. Your actual pace may be slower than the
target pace, especially during the first few
months of your exercise program. Make sure
to pedal at a pace that is comfortable for you.
During the last three seconds of each period, a
series of tones will sound and the time will flash in
the large display. The resistance of the pedals will
then change if a different resistance level is pro-
grammed for the next period. In addition, the
number of arrows in the small display will change
if a different target pace is programmed for the
next period.
During the program, the center of the large dis-
play will show the time remaining in the program.
If you stop pedaling for a few seconds, the dis-
plays will pause and the time will flash. To restart
the program, resume pedaling.
Follow your progress with the large display.
See step 4 on page 13.
Measure your heart rate if desired.
See step 5 on page 14.
Turn on the fan if desired.
See step 6 on page 14.
When you are finished exercising, the console
will automatically turn off.
See step 7 on page 14.
7
6
5
4
3
2
1
HOW TO USE A SMART PROGRAM
Arrows
Indicator
Bar

16
Heart Rate program 1 is designed to keep your heart
rate between 60% and 90% of your maximum heart
rate
during your workout. (Your maximum heart rate is
estimated by subtracting your age from 220. For
example, if you are 25 years old, your maximum heart
rate is 195 beats per minute.) Heart Rate program 2 is
designed to keep your heart rate near a target heart
rate that you select.
Follow the steps below to use a Heart Rate program.
Turn on the console.
See step 1 on page 13.
Select one of the Heart Rate programs.
To select a Heart Rate pro-
gram, press the Program
button repeatedly until the
number 1 or 2 appears in
the small display.
Enter your age or a target heart rate.
If program 1 is selected, the word AGE and the
current age setting will appear in the large display.
If you have already entered your age, press the
Enter button. If you have not entered your age,
press the small + and – buttons to enter your age,
and then press the Enter button.
If program 2 is selected, the letters PLS and the
current target heart rate will appear in the large
display. If you do not wish to change the target
heart rate, press the Enter button. If you wish to
change the target heart rate, press the small +
and – buttons, and then press the Enter button.
Hold the handgrip pulse sensor.
Touse a Heart Rate program, you must use the
handgrip pulse sensor or wear the optional chest
pulse sensor. If you use the handgrip pulse sen-
sor,it is not necessary to hold the handgrips con-
tinuously during the Heart Rate program; however,
you must hold the handgrips frequently for the pro-
gram to operate properly. Each time you hold the
handgrips, keep your hands on the metal con-
tacts for at least 30 seconds.
Begin pedaling to start the program.
Heart rate program 1 consists of 20 one-minute
periods. One resistance level and one target heart
rate are programmed for each period. (Note: The
same resistance level and/or target heart rate
may be programmed for two or more consecutive
periods.) Heart Rate program 2 is sixty minutes
long (you may choose to use only part of the pro-
gram). The same resistance level and target heart
rate are programmed for the entire program.
When you begin pedaling, the resistance of the
pedals will automatically change to the resistance
level programmed for the first period.
As you pedal, the
arrows in the
small display will
help you to keep
your heart rate
near the current
target heart rate.
When you hold
the handgrip pulse sensor or wear the optional
chest pulse sensor, the console will compare your
heart rate to the current target heart rate. If your
heart rate is too far above or below the target
heart rate, the number of arrows in the small dis-
play will change to prompt you to increase or
decrease your pace. When the number of arrows
changes, change your pace until one segment of
the indicator bar appears at the tip of each arrow.
Important: The target pace is intended only to
provide a goal. Your actual pace may be slow-
er than the target pace, especially during the
first few months of your exercise program.
Make sure to pedal at a pace that is comfort-
able for you.
During the last three seconds of each period, a
series of tones will sound and the time will flash in
the large display.The resistance of the pedals will
then change if a different resistance level is pro-
grammed for the next period. Note: If the resis-
tance level is too high or too low, you can adjust it
by pressing the Resistance buttons. However,
when the next period begins, the resistance will
automatically change if a different resistance level
is programmed for the next period.
5
4
3
2
1
HOW TO USE A HEART RATE PROGRAM
Arrows
Indicator
Bar

17
The program will continue in this way until the
large display shows that no time remains in the
program. Note: If you stop pedaling for a few sec-
onds, the program will end. To use the program
again, reselect it and start it at the beginning.
Follow your progress with the large display.
See step 4 on page 13.
Turn on the fan if desired.
See step 6 on page 14.
When you are finished exercising, the console
will automatically turn off.
See step 7 on page 14.
HOW TOUSE IFIT.COM CD PROGRAMS
When you use an iFIT.com CD program, a certified per-
sonal trainer will guide you through your workout while
the program interactively controls the resistance of the
pedals and prompts you to increase or decrease your
pace. Topurchase iFIT.com CDs, call the toll-free
telephone number on the front cover of this manual.
Follow the steps below to use an iFIT.com CD program.
Turn on the console.
See step 1 on page 13.
Select the iFIT.com mode.
To use an iFIT.com CD,
press the iFIT.com button.
The iFIT.com indicator will
light and the letters IF will
appear in the small display.
Insert an iFIT.com CD into the CD player.
To open the CD
player, slide the
center button on
the CD player
upward. Carefully
insert an iFIT.com
CD into the CD player and then close the lid.
Press the Play/Pause button to start the
program.
To start the CD
program, press
the play/pause
button on the CD
player. A moment
after the button is
pressed, your personal trainer will begin guiding
you through your workout. Simply follow your per-
sonal trainer’s instructions.
The CD program will function in almost the same
way as a Smart program (see step 3 on page 15).
However, an electronic “chirping” sound will alert
you when the resistance level and/or the target
pace is about to change. Note: If the resistance
level and/or the target pace does not change
when a “chirp” is heard, make sure that the
iFIT.com indicator is lit. In addition, adjust the
volume (see step 5 below). If the volume is too
high or too low, the console may not detect the
program signals.
Tostop the pro-
gram at any time,
press the
play/pause button
and stop pedal-
ing. Torestart the
program, press the play/pause button and begin
pedaling.
Note: To select a
different program
on the CD, press
the skip/search
buttons on the
CD player.
4
3
2
1
8
7
6

18
Adjust the volume if desired.
To adjust the vol-
ume, press the
Volume – and +
buttons on the
CD player.
Follow your progress with the large display.
See step 4 on page 13.
Measure your heart rate if desired.
See step 5 on page 14.
Turn on the fan if desired.
See step 6 on page 14.
When you are finished exercising, the console
will automatically turn off.
See step 7 on page 14. Note: Always remove
iFIT.com CDs from the CD player when you are
finished using them.
HOW TO PLAY MUSIC CDS
If desired, you can play your own music CDs in the CD
player.Before playing music CDs, select the manual
mode of the console (see HOW TO USE THE MANUAL
MODE on page 13).
HOW TO CONNECT TO YOUR VCR
Note: If your VCR has an unused AUDIO OUT jack,
see instruction A below. If the AUDIO OUT jack is
being used, see instruction B. If you have a TV
with a built-in VCR, see instruction B.
A. Plug one end of a 1/8” to RCA stereo audio cable
(available at electronics stores) into the jack
beneath the console. Plug the other end of the
cable into the AUDIO OUT jack on your VCR.
B. Plug one end of a 1/8” to RCA stereo audio cable
(available at electronics stores) into the jack
beneath the console. Plug the other end of the
cable into an RCA Y-adapter (available at electron-
ics stores). Next, remove the wire that is currently
plugged into the AUDIO OUT jack on your VCR
and plug the wire into the unused side of the Y-
adapter.Plug the Y-adapter into the AUDIO OUT
jack on your VCR.
9
8
7
6
5
B
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
A
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
C
AUDIO OUT
RIGHT
LEFT
Audio
Cable
A
B
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
A
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
C
Audio Cable
B
Wire removed from
AUDIO OUT jack
RCA
Y-adapter
HOW TO CONNECT THE ELLIPTICAL
EXERCISER TO YOUR VCR OR COMPUTER

19
HOW TO CONNECT TO YOUR COMPUTER
Note: If your computer has a 1/8” LINE OUT jack,
see instruction A. If your computer has only a
PHONES jack, see instruction B.
A. Plug one end of a 1/8” to 1/8” stereo audio cable
(available at electronics stores) into the jack
beneath the console. Plug the other end of the
cable into the LINE OUT jack on your computer.
B. Plug one end of a 1/8” to 1/8” stereo audio cable
(available at electronics stores) into the jack
beneath the console. Plug the other end of the
cable into a 1/8” Y-adapter (available at electronics
stores). Plug the Y-adapter into the PHONES jack
on your computer. Plug your headphones or speak-
ers into the other side of the Y-adapter.
HOW TO USE IFIT.COM VIDEO PROGRAMS
To use iFIT.com video program, the elliptical exerciser
must be connected to your VCR. See HOW TO CON-
NECT TO YOUR VCR on page 18. To purchase
iFIT.com videocassettes, call the toll-free tele-
phone number on the front cover of this manual.
Follow the steps below to use an iFIT.com video pro-
gram.
Turn on the console.
See step 1 on page 13.
Select the iFIT.com mode.
To use an iFIT.com video
program, press the
iFIT.com button. The
iFIT.com indicator will light
and the letters IF will
appear in the small display.
Insert the iFIT.com videocassette.
Insert the videocassette into your VCR.
Press the play button on your VCR.
Amoment after the play button is pressed, your
personal trainer will begin guiding you through
your workout. Simply follow your personal trainer’s
instructions.
The video program will function in almost the
same way as a Smart program (see step 3 on
page 15). However, an electronic “chirping” sound
will alert you when the resistance level and/or the
target pace is about to change.
Note: If the resistance level and/or the target
pace does not change when a “chirp” is heard:
•Make sure that the iFIT.com indicator is lit.
•Adjust the volume of your VCR. If the volume
is too high or too low, the console may not
detect the program signals.
4
3
2
1
A
PHONES
LINE OUT
B
Audio
Cable
A
A
PHONES
LINE OUT
B
Audio
Cable
B
1/8”
Y-adapter
Headphones/Speakers

20
•Make sure that the audio cable is properly
connected and that it is fully plugged in.
To stop the program at any time, stop pedaling
and press the pause button on your VCR. To
restart the program, press the play button on your
VCR and begin pedaling.
Follow your progress with the large display.
See step 4 on page 13.
Measure your heart rate if desired.
See step 5 on page 14.
Turn on the fan if desired.
See step 6 on page 14.
When you are finished exercising, the console
will automatically turn off.
See step 7 on page 14.
Our Web site at www.iFIT.com allows you to play
iFIT.com programs directly from the internet. Touse
programs from our Web site, the elliptical exerciser
must be connected to your computer. See HOW TO
CONNECT TO YOUR COMPUTER on page 19. In
addition, you must have an internet connection and an
internet service provider. A list of specific system
requirements is found on our Web site.
Follow the steps below to use a program from our
Web site.
Turn on the console.
See step 1 on page 13.
Select the iFIT.com mode.
To use a program from our
Web site, press the
iFIT.com button. The
iFIT.com indicator will light
and the letters IF will
appear in the small display.
Go to your computer and start an internet
connection.
Start your Web browser, if necessary, and go
to our Web site at www.iFIT.com.
Follow the desired links on our Web site to
select a program.
Follow the on-line instructions to start the
program.
When you start the program, an on-screen count-
down will begin.
Return to the elliptical exerciser and begin
pedaling.
When the on-screen countdown ends, the pro-
gram will begin. The program will function in
almost the same way as a Smart program (see
step 3 on page 15). However, anelectronic “chirp-
ing” sound will alert you when the resistance level
and/or the target pace is about to change.
Follow your progress with the large display.
See step 4 on page 13.
Measure your heart rate if desired.
See step 5 on page 14.
Turn on the fan if desired.
See step 6 on page 14.
When you are finished exercising, the console
will automatically turn off.
See step 7 on page 14.
11
10
9
8
7
6
5
4
3
2
1
8
7
6
5
HOW TO USE PROGRAMS DIRECTLY FROM
OUR WEB SITE
