PROAIM P-WV-2PP User manual

7' Wave-2 Jib with CST-100 Stand, Portable
Dolly & Jr. Pan Tilt Head
(P-WV-2PP )
All rights reserved
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permied
by the applicable copyright statutes or in wring by the publisher.
I N S TR UC T I O N M A N UA L
For demonstration purpose only

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 2
INTRODUCTION
PROAIM welcomes you to the new and modernized era with its Proaim 7' Wave-2 Jib with
CST-100 Stand, D-77 Dolly & Jr. Pan Tilt Head, a portable lming soluon to increase your
producon value. The Robust jib crane is specically designed travel crane for indoor & outdoor
video producons. Its telescopic arm feature adds exibility to frame perfect shots in indoor and
outdoor spaces. This video producon package includes a rugged camera dolly for smooth,
dynamic moving shots, rock solid aluminum tripod stand for immense support, a rugged panlt
for creave angle shots. Now you can create the visual eects and produce incredibly smooth
oang camera crane shots that add value to your lming producons and bring a quick return
on your investment.
IN THE BOX
Please inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below. The padded shipping /storage container has been especially designed
to protect your purchase while in transit and is a good place to keep your PROAIM 7' Wave -2 Jib
with CST-100 Stand, D-77 Dolly & Jr. Pan Tilt Head are use.
STORAGE BAGS
Wave-2 video crane jib
Plate for mounng
Pan Tilt Head
Weight shank
CST-100mm Bowl tripod stand
Portable Dolly
Allen key
Red Spreader
12V Joysck Controller
Jr Pan-Tilt Head
Zoom Controller
Telescopic knob

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 3
 Posion the height of the tripod by loosening all three adjustment knobs, slide the tripod
up to the desired height and re-ghten the knobs securely.
 Now, place the tripod foot on the dolly
and e it down with the help of elasc
clips as shown in the picture.
 Take out the bolt from the center of dolly and spread it on oor. Then put the bolt back
through the center of dolly again.
ASSEMBLING YOUR PROAIM 7' WAVE -2 JIB WITH CST-100 STAND, PORTABLE
DOLLY & JR. PAN TILT HEAD

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 4
 Now, place the Tripod foot on the
spreader and e down it with the help of
elasc clip downs as shown in the
picture.
 Take out the spreader and posion it’s legs as shown in the image.
IN CASE OF SPREADER, FOLLOW THESE STEPS
 Unscrew the locking lever from the Central Post of the jib. Place the Central Post in the bowl
of Tripod Stand and re-ghten the locking mechanism for a secure t. (as shown in the
picture.)
MOUNTING THE JIB

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 5
 Provided are the jib panning control
knobs (as shown in the picture). Loosen
the knobs for the smooth pan
movement of the jib and ghten these
knobs to lock the pan movement of the
jib.
NOTE: Inbuilt bubble leveler is also
provided to check accurate set-up of jib
on uneven surface areas.
NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That
means perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib.
Also you may need the assistance of a grip stand to hold the camera end of the arm during
installaon prevenng it from falling as it will be front heavy at this point. You may also need
the grip stand or assistance at the rear of the jib when mounng the camera.
 Now to extend the rear secon of the jib, loosen the Allen bolts with the provided Allen key
and then, loosen the knob as shown in the picture.
 Then, loosen the knob provided at the
lower telescopic secon of the jib arm as
shown in the picture to extend the front
secon of the telescopic jib accordingly
to the rear secon.

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 6
 Aach the weight shanks at the rear end
of the jib secon by screwing it in and
then add weights to it.
NOTE: Make sure the opposite end of the jib
arm is secured so that the addion of the
weights does not cause the arm to rise
violently.
 Camera head mount is provided with a
knob to control 90 degree lt movement
of the camera.
 Loosen the knob for the free lt move-
ment of the camera and ghten it to lock
the movement.
 Mount your uid head onto the bowl plate in order to aach the camera. And then nally,
secure your camera properly on the uid Head.

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 7
 Remove the uid head mounng bowl by loosening the bolts as shown and then aach the
pan lt head mounng plate and secure by ghtening the bolts.
 Aach the Pan Tilt Head and secure by
ghtening the bolts.
To mount Jr. Pan Tilt Head, follow these steps:
 Now mount your camera with camera
mounng screw on Pan Tilt Head.
 Mount the Joysck on weight rod & ghten the knob to secure.

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 8
LCD Mounng
 Aach the LCD Mounng Arm to Jib Fork and ghten it properly to secure.
 Now screw in the LCD to arm and ghten it knob aer posioning the angle of LCD Arm.
PROAIM 7' WAVE-2 JIB WITH CST-100 STAND , PORTABLE DOLLY & JR. PAN TILT
HEAD ALL SET AND READY TO USE
NOTE: Add weights to the rear of jib corresponding to the weight of camera aached to balance
the jib arm.
(SHOWN WITH OTPIONAL
ACCESSORIES)
 Now aach the one end of XLR Cable & AC Adapter with Joysck. And second end of XLR
cable with Pan Tilt Head.

Proaim 7' Wave-2 Jib with CST-100 Stand, Portable Dolly & Jr. Pan Tilt Head 9
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
For any other assistance you can reach us via email.
