PROAIM P-OHCP-01 User manual

1
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
3 Overhead Plaorm for Camera & Studio Lights (P-OHCP-01 )
Assembly Manua l

2
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
2x foot joints

3
 Slide the Camera Holder onto the Cross Bar.
The Camera Holder can be locked into posion
using the Camera Holder Thumb Screw . Adjust
the height of the Cross Bar by sliding it along
the Side Bar and locking it into posion using
the 2 Height Adjustment Thumbscrew.
 Mount the 2 foot joints on the Ground feet
using M5 screws for each joint, do not over
ghten the screws.
3 Overhead Plaorm Setup
 Slide the Side Bar onto the ground foot. Lock
the Side Bar to the foot using 2 of the 1/4-20
Foot thumbscrew, Repeat Step 1 and Step 2
for the 2 feet.
 Assemble the Support Bar on the Side Bar
using the long M5 Short knob. Assemble the
Support Bar on the foot using the short M5
short knob. Repeat this step for the other
Support Bar.
 Aach the rubber feet on the ground feet
using by thumb screws, ghten the screws
with the provided allen key.

4
 Remove the Knobs onto the Cross bar & aach
the 2 L-brackets using the 1/4-20 thumb
screws onto the cross bar.
 Clamp your backdrop to the brackets using the
2 clips.
The backdrop & other Related Accessories is not
included with the Overhead Camera Plaorm.
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
