1. GENERAL OUTLINE
Electromechanical operator designed to automate residential-type gates.
The operator keeps the gate blocked on closing and on opening, without
needing an electric lock. The operator has no mechanical clutch. It must be
controlled by an electronic control panel provided with torque setting. The
end-of-stroke operation is managed by the control panel.
2. INSTALLATION
Preliminary checks
Check that:
• The gate structure is sufficiently sturdy.
• Also make sure that the actuator pushes against the leaf reinforced
section.
• The leaves move manually and without effort all along their stroke.
• The door stop plates are fitted at the end of both closing and opening
strokes.
• If the gate has not been recently installed, check the wear condition of
all components.
• Repair or replace faulty or worn parts.
Power supply cable
The board power supply cable must be of the H 05 RN-F type or equivalent.
The equivalent cable must guarantee:
- permanent outside use
- rated voltage of 24 V / 230 V
- maximum temperature on the cable surface of +50° C
- minimum temperature of -25° C
Moreover, it must have a minimum section of 3 x 1.5 mm2 and, for the
cable to hold correctly, it must be provided with an external sheath of Ø =
7.1 to 9.6 mm.
M1= operation 1
M2= operation 2
T= earthing
N = common
WARNING! When the power supply cable is damaged, it must be
replaced by the manufacturer or its technical assistance service, or
else by a person having similar qualification, in order to prevent any
risk.

www.quikoitaly.com
External measures
Fig. 1
3. POSITIONING FOR BASE PLATE
Prepare the sub structure in order to fix
base plate, respecting approximately
measures like Fig. 1
Fig. 2

www.quikoitaly.com
4. POSITIONING OF GEAR MOTOR
Position the gear motors (Fig. 3) on
the great plate, using the appropriate
screws supplied.
The right coupling between rack and
pinion may be carried out by fixing
the small plates to the great plate,
through the eyelets associated.
Unlock the gear motors, through
appropriate release lever (Fig. 4).
Fig.3
Fig. 3
5. MANUAL OPENING
Fig. 4
In case of a power blackout it is possible to operate the gate in manual
mode, as shown in Fig. 4.
To unlock the engine insert the key into the seat and rotate clockwise until it
stops (about 5 laps). To restore the engine block, rotate the key
counterclockwise to its initial position.

www.quikoitaly.com
6. FIXING RACK AND END-RUN DEVICE
Position the first element of rack on
the cogwheel, previously unlocked,
as in Fig. 5. Fix the element to the
gate, in the way you wish, by
applying to it the other elements of
rack necessary, ensure that all be
united and aligned. Locate the
desired position and fix end-run
device (F) on rack as indicated in
the previous Fig. 2, those with
grains included. Close the release
lever and perform the necessary
electrical connections.
Fig. 5
7. CHECKING THE AUTOMATION
Before considering the automation completely operational, the following
checks must be made with great care:
• Check that all the components are firmly anchored.
• Control all the safeties work properly (i.e. photocells, pneumatic skirt,
etc.).
• Check the emergency maneuvers control.
• Check the opening and closing maneuvers using the controls.
• Check the control unit electronic logic in normal (or customized)
operation.
8. THE CONTROLS
Any malfunction should be corrected immediately by a qualified specialist.
Keep children at a safe distance from the field of action of the automation.
With the automation the gate has a power driven opening and closing. The
controls can come in various forms (i.e. manual, remote controlled, limited
access by magnetic badge, etc.) depending on needs and installation
characteristics. For details on the various command systems, consult the
specific instruction booklets.

www.quikoitaly.com
9. MAINTENANCE
When carrying out maintenance operation on the controller, disconnect it
from the mains power supply. The actuator does not require periodical
maintenance operations.
• Check the safety devices of the gate and automation.
• Periodically check the pushing force and correct the value of the electric
torque in the control board if necessary.
• In case of unsolved operation failures, disconnect the unit from the main
power supply and ask for the intervention of qualified personnel (instal-
ler).
When the unit is out of order, activate the manual release to perform
manual opening and closing maneuvers.
Anyone using the automation must be instructed in its operation and
controls.
10. TECHNICAL FEATURES
QK-Z600
QK-Z300B
QK-Z600B
Power
(50/60Hz)
230Vac
24Vdc
24Vdc
Power /
Current
Absorbed
220W
1,1A
100W
4A
210W
8A
Max gate
weight
(kg)
600
300
600
Speed
(m/min)
12
12
12
Protection
rate
(IP)
54
54
54
Thermal
protection
(°C)
140
-
-
Working
temp.
(°C)
-30/+70
-30/+70
-30/+70
Working
Cycle
(%)
60
100
100
Weight
(Kg)
9
8
9

www.quikoitaly.com
