RASOR SW100SL User manual

USE MANUAL
SW100
SL CUTTING UNIT

2
EN
COMPANY
ACKNOWLEDGMENT
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended to use only original spare parts and to contact the head
office for any maintenance work.
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by Luigi Spinelli. For more
than sixty years it has been producing automatic cutting systems, cutting units for textile
applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Nowadays Rasor®can rely on the professional continuity of two
generations, with the experience inherited from the promoting partner, with his passion
and dedication.
The main characteristic of Rasor®is that each working phase, starting from the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor®has always considered as essential
since the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of cutting unit SW100SL and must be carefully
read before using it since it gives important indications with regards to its safe
installation, use and maintenance. Keep it with care.
Before using cutting unit SW100SL, read carefully the following general safety
rules.
• PACKAGING.
After taking off the packaging make sure that the cutting unit is intact. In
caseofdoubtdonotuseitandcontactanauthorizedservicecentre.Donot
leave pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within
the reach of children or disabled persons since they are potential sources of
danger.
• AVOID DANGEROUS ENVIRONMENTS.
Prevent the cutting unit SW100SL components from coming in contact with
damp or wet surfaces.
•KEEPCHILDRENAWAY.
Unauthorized persons, especially children, must be kept away from the working
area.
•FEEDCABLE.
Prevent the feed cable from coming in contact with hot objects, pointed
surfaces or sharp edges. Never pull the feed cable of the machine. It must
never be replaced by the user. If necessary contact professionally qualified
staff.
• KEEP THE WORKING AREA ALWAYS IN ORDER.
The workplace must always be kept in order and well lightened; liquids or oil
traces must not be present.
• ALWAYS USE CUTTING UNITS SW100SL PROPERLY.
Use the cutting units only to carry out the works they have been designed
for; do not use them improperly.
• OBSERVE THE USE OF THE TOOLS.
Do not cut excessively thick materials and always check blade conditions.
• AVOID ACCIDENTAL STARTS.
Before connecting cutting unit SW100SL, make sure that everything is installed
properly.
• CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves approved by Rasor®during
use and maintenance operations (according to UNI EN 388:2017 standard).
•SPAREPARTS.
During maintenance and replacement operations use only original spare parts.
Blade maintenance must be only performed by Rasor®technicians.
• INSTALLATION.
Any installation that is not in conformity with these
specifications could jeopardize your safety and cancels the
warranty.

4
EN
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONAL COPYRIGHTCONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without
the prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor®Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of
explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover, they
cannot work in case of rain.
In case of damage or malfunction, cutting unit SW100SL must not be used until the Customer
Care Technical Service has repaired them.
The original configuration of the cutting unit must not be changed at all.
On receiving the machine make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the cutting unit has not been damaged during transport.
Customer Care Technical Service
WARNING
The installer and the maintenance man must know the content of this manual. Although
the main features of the machine described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the machine or to meet manufacturing
or commercial requirements at any time and without being obliged to update this
manual immediately.
Informative letter
Forany information, please contact
® ELETTROMECCANICAS.r.l.
Via V. Caldesi, 6; 20161,MILANO (MI) - ITALY
Tel: [phone]; Fax: [phone]
e-mail: [email protected]
web: www.rasor-cutters.com
WARNING
RASOR

EN
5
SW100SL
220 230 50 60 190
850
2. TRANSPORT AND PACKAGING
The cutting unit is delivered in a cardboard box, inside which there are various options. The
code of the ordered product and its serial number are indicated outside the package (see
picture 1). The following accessories are contained in a bag inside the package:
1) Poligonal blade;
2) Wrench for blade nut disassembly.
3) Shuko cable without plug;
4) Drift for blade disassembly.
2
2
3. PLATE DATA
The manufacturer's identification and CE STANDARD 2006/42/CE conformity plate (see picture
below) is located on the front part of the cutting unit.
The plate must not be removed at all, even if the machine is resold. Always refer to
the serial number (written on the plate itself) when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the cutting unit feeding
cable; such warnings must be strictly followed by everyone dealing with the machine. The
company is not to be held responsible for damage to property or accidents to
people which might occur if the above-mentioned warnings are not observed. In
such a case, the operator is the only person responsible.
3
1
1
Class II double insulation
Serial number
Year of production
Model
Electric data
4
READ
THE
INSTRUCTION
MANUAL
DO NOT
REMOVE
THE
SAFETY
DEVICES
HIGH
VOLTAGE
SHEARING
RISK
USE
METAL
GLOVES
USE
GOGGLES

6
EN
4. PRODUCT DESCRIPTION
The fixture described in this manual is a cutting unit model SW100SL which can be assembled
on automatic machines (e.g. spreaders, computerized cutting) by means of proper holes
located in the motor support. SW100SL can operate continuously and it can cut at various
widths by means of multiple installation. By cutting with the blade and the counterblade
always in contact and thanks to the steel upper quality of the blade supplied, SW100SL
guarantees the clean separation without frayings of the two borders of the cut material.
Moreover, the single-phase motor guarantees a blade peripheral speed of 260 m/min allowing
great cutting performances in terms of traversing speed/speed of travel.
The 100 mm blade diameter and the light weight (only 2,7 Kg) of the cutting unit make it ideally
suited forsmall radius cut profiles on materials with thickness up to 3,5 cm. A sharpener assembled
on the cutting unit head allows sharpening the blade at any moment without disassembling it.
After carrying out this operation, it is possible to start cutting again. A high power motor,
perfectly balanced, with a high number of revolutions and totally free of maintenance, reduces
the vibrations to the minimum, thus making the cutting unit comply with Italian Legislative
Decree No. 81 dated 9/4/2008 “Testo Unico sulla Salute e Sicurezza sul Lavoro” (Consolidated
Act on Health and Safety at Work), Title VIII - CHAPTER III (worker protection from
mechanical vibration risks). The mechanical parts are made of high resistance steel, bronze and
aluminium and require lubrication after several working hours.
1
3
4
11
7
810
5
12
13
9
2
14 6
1 Switchprovidedwithlight 7 Aluminium base covered with
Teflon®
2 Motor cover 8 Poligonal blade
3 Connector socket 9 Plate locking the threads
4Motorframe10 Greaser
5 Sharpener push button 11 Carbide counterblade
6Emerygrindingwheel12
Motorlowercoverwith
assembly holes
7 Movable front protection 13 Motor support
Device components

EN
7
7. FIELD OF APPLICATION
6. NOISE LEVEL
NOTE
It is advisable for cutting unit SW100SL owners to verify the compliance with the standard
concerning safety of workers: Italian legislative decree 81/08.
The maximum acoustic pressure level emitted by cutting unit SW100SL is about 60 dB (A).
Noise tests have been carried out in compliance with Standard UNI EN ISO 11202:2010. The
device noise levels, measured at different distances (without any sound wave filtering system),
vary in the extent of few db (A).
Cutting unit SW100SL has been designed, manufactured and assembled to cut every kind of
fabrics or materials, with the exception of metal, plastic or wood, by means of rotary poligonal
blades.
This equipment must not work:
- in areas prone to explosions;
- in presence of fine dust or corrosive gases;
- on wet or damp materials;
- to cut plastic, metal and wooden materials.
It is forbidden to use cutting unit SW100SL for purposes different from the above-
mentioned ones.
5. TECHNICAL FEATURES
This technical data is only indicative and may be subject to change without notice.
100 mm with carbide counter
blade
850 rpm
about 35 mm
Single phase 220 V - 90 W
1 A
2650 g
4750 g
1,5 mt
LUX 200
<2,5m/s
2
0~55°C
10 ~ 95% without condensate
Temperature
Humidity
Weight with package
Electric cable length
Minimum light for working
o
p
erations
Vibrations at the start up
Cutting working depth
Motor power
Weight (with feeding cable)
Cutting unit SW100SL features
Blade diameter
Blade speed
Max. Absorption
6 side blade Ø 100 mm, H.S.S. steel
Circular blade Ø 100 mm, Extra steel
4 side blade Ø 100 mm, Germany Extra
steel
6 side blade Ø 100 mm, H.S.S. steel
covered with Teflon

6 side blade Ø 100 mm, carbide metal
Features of the available blades
10EHSS
10SEXTG
10EMD
10EHSSTF
10CSW

8
EN
8. USE WARNINGS
We recommend following the indications below in order to work in safety conditions.
All the operations must be carried out complying strictly with the safety rules of the
country where the device is to be installed.
It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the cutting unit.
The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules and
regulations in force, as well as the special provisions in force in sport and public installations
the Customer declares to know after receiving all the relative necessary information.
The cutting unit also works without its safety protective device. This protective
device must NEVER be removed.
Always check the resistance of the material to be cut and the kind of blade which is being
used.
The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
Do not make any adjustment while the blade is working or while the electric plug is
connected.
Always pay attention to the electric cable position to prevent it from being cut or damaged
by the blade.
It is allowed to assemble cutting unit SW100SL on machines O.E.M. on condition that their
original structure is not modified. Otherwise, the intervention must be certified by Rasor®.
Firstly make sure that the lines and electric systems of the machine, on which the SW100SL
will be installed, are able to supply the cutting unit with power correctly, in compliance with
the safety rules (for the feature required see par. 5).
We suggest installing a magnetothermic safety device before the cutting unit and check
that the ground circuit is effective. Before working on the feeding cable, unplug the unit.
Check that electric connections and protections correspond to the driving force and to the
plate data values (voltage and current), required by the different
electric circuits. Possible faulty ground connections make the working
conditions unsafe. Possible damages are not charged to Rasor®.
Referring to the CEI 11-27/1 standard all the works carried out by
means of electric current must be performed by skilled staff provided
with all the devices required by the above-mentioned standard. For
the works carried out under voltage, it is necessary that the employer
certifies the suitability, against formative processes.Asthecutting
unit SW100SL is supplied without plug, the user must use a plug
homologated in the country in which the cutting unit is used. In the
European Countries a Shuko plug is required (see picture 3). Never
change the lenght of the cable supplied.The cutting unit SW100SL
is a class II electric device; therefore, it does not need earthing.
CUIDADO
3
9. ELECTRIC CONNECTION

EN
9
10. RESIDUAL RISKS
11. INSTALLATION AND USE
Even though the cutting unit is safe, operators must pay attention to preserve their and
other people’s safety.
At the end of the working operations, the metal parts could be very hot.
Thecuttingbladecanworkeveniftheprotectiveguardsaredisassembled.
To install and use the cutting unit manually, proceed as follows:
1) Fix the cutting unit on level squares or angles by means of four 5MA screws, by inserting
them in the four holes located in the motor lower cover (see pictures 4 and 5).
NOTE
The cutting unit can be installed in any position/angle: vertically, laterally and it can be turned
upside down. It is not necessary that the aluminium base touches the machine table.
2) Lay the material to be cut;
3) Plug the cutting unit into the electrical outlet (see picture 6);
4) Put the material on the cutting foot (see picture 7);
5) Adjust the front mobile protection according to the thickness of the material to be cut (see
picture 7);
6) Enable the switch; once it has been enabled, it lights up with a green light (see picture 8).
NOTE
Cutting unit SW100SL can work in a fixed position (the material moves) or it can move
forward while the material is kept in the same position. Make sure the material to be cut is
properly stretched, preventing it from curling.
WARNING
Never use the two bolts which fix the motor to the cutting part to fasten cutting
unit SW100SL. This operation may cause the motor shaft to break. In this case,
warranty is not valid.
45
7
6
8

10
EN
12. BLADE SHARPENING
13. LUBRIFICAZIONE
Every 3-4 working days, it is necessary to lubricate the
pair of gears. To carry out this operation, remove
protective plug “A” located on the motor support of
the cutting unit and fill it with lubricating grease Rasor.
Screw plug “A” again few turns. Screw plug “A” some
turns every 3-4 working days (see picture 11).
The blade must never be dirty with grease or oil.
11
WARNING
A
After many hours of a continuative use of the cutting
unit, or if it would not be able to cut anymore, it is
necessary to sharpen the blade. To carry out this
operation, start the blade and press sharpener “2”
located on it for 3-4 seconds (by pressing push button
“1”, as shown in picture 9). Repeat the operation 2-3
times.
If the sharpening operation is not effective, check the
wear of emery grinding wheel “3” (see picture 10).
If emery grinding wheel “3” is too worn or dirty, replace
it.
1
2
10
3
9
14. MOTOR BRUSH REPLACEMENT
Worn motor brushes could create a cutting unit malfunction (no starting, intermittent
start, etc.), therefore it should be better to verify their wear periodically.
Open the motor cover by unscrewing 4 screws “4” on the cutting unit head (see picture
12). Remove the metal contacts that close the brushes with a slotted screwdriver (see
picture 13). Remove the brushes and check their wear: if the graphite has a length shorter
than 15 mm or it is uneven, replace it (see picture 14).
Close the metal contacts again making sure that they adhere well to the metal part of the
brush. Finally close the motor cover again.
14
12 13
4

EN
11
If the blade is no more able to cut (even after repeating
the sharpening operation several times) it is necessary to
replace it. To carry out this operation, use wrench “1”
and drift “3” locking the blade (shown in picture 15).
To replace the blade, proceed as follows:
1) Use some protective gloves in compliance with
Italian Legislative Decree 81/08;
2) Remove the mobile front safety protection “A” (see
picture 16) by unscrewing pin “C” and removing
the two washers “D” as shown in picture 17.
Remove the fixed rear safety protection “B” (see
picture 16) by unscrewing the two cross screws
“E” by means of the proper screwdriver (not
supplied by the manufacturer) as shown in picture
18.
3) Insert drift “3” into hole “F” (see picture 19), so
as to lock the blade (the hole on the blade must
correspond to the one on the motor support).
4) Use wrench “1” to unscrew nut “G” and remove
blade “H” (see picture 19).
5) Replace the worn blade with the new one “2”,
being careful to center the blade on the gear, in
the correct position, and remember to assemble it,
so that the Rasor writing can be seen by the
operator.
6) Assemble all the components again and carry out
the sharpening.
15. BLADE REPLACEMENT
115
16
BA
18
H
1
G
19
3
2
F
C
D17
E
3

12
EN
17. SPARE PARTS / EXPLODED VIEW
16. TROUBLESHOOTING
SOLUTION
Check that the blade and the counterblade are in contact
Check the kind of fabric
Sharpen the blade
Check the fabric thickness
Check the compatibility between blade and fabric
Make sure that the motor turns correctly
Reduce the speed of travel
Check the counterblade integrity
Carry out the lubrication
Disassemble the blade and remove the material residues
Check the wear of the pair of gears
Check the electric connections
Check the motor brushes
Check the feeding cable
Check possible electric problems on OEM machine
The cutting unit starts slowly, works
intermittently or it does not start
PROBLEM
The cutting unit is noisy
Thefabricisnotcutoritgetsstuck
between the blade and the counterblade
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
10EHSS 6-SIDE BLADE Ø 100 mm, H.S.S.
STEEL SW107900 SCREW FASTENING THE
COUNTERBLADE HOLDER T 100700 BRUSH HOLDER
CODE DESCRIPTION
SW100500 CORRUGATED THRUST WASHER SW1080S COUNTERBLADE HOLDER T 100800 BRUSH HOLDER SPRING
T 104500 SCREW FASTENING THE FRONT
PROTECTION
SW101800 WORM SCREW - 3P, M 0.9 SW1081S CARBIDE COUNTERBLADE T 100900 SCREW FASTENING THE BRUSH
HOLDER
T104501 CONVEXEDWASHER
SW1018CPL COMPLETE PAIR OF GEAR SW108200 SCREW FASTENING THE
COUNTERBLADE T 101000 MOTOR BEARING Ø 7 mm
T 104700 GREASER CAP
SW1019S MOTOR LOWER COVER SW108600 EMERY Ø 25x9x6 mm T 101200 ANTI-GREASE WASHER
T 104800 GREASER
SW1020S MOTOR UPPER COVER SW1086CPL COMPLETE SHARPENER T 101300 COMPLETE ROTOR 220 V
T 1049S PLATE LOCKING THE THREAD
SW1022S MOTOR FRAME WITH MAGNETS,
WITHOUT HANDLE SW108700 SHARPENER PIN
T 105000 SCREW 2.6MA FASTENING THE PLATE
LOCKING THE THREAD
SW1029S ELECTRONIC FEEDING CIRCUIT SW108800 EMERY SPRING Ø 11 mm
T 105200 MOTOR SUPPORT FIXING BOLT
SW1037S SCREW FASTENING THE FEEDING
CIRCUIT SW108900 SHARPENER BUSH
T 105300 SPLIT WASHER
SW104101 SCREW FASTENING THE REAR
PROTECTION GUARD SW109000 EMERY SPRING Ø 6 mm
T 101301 COMPLETE ROTOR 110 V
T 101500 FAN
T 101600 MOTOR BEARING Ø10 mm T 105400 ANTI-FRICTION BUSH
SW104101S REAR PROTECTION GUARD SW109100 SHARPENER CAP WITH BEARING
T 101700 ADJUSTING RING T 105600 WASHER
SW104101SC
PL REAR PROTECTION SET SW109200 SCREW FASTENING THE SHARPENER CAP
T 101801 ELASTIC PIN T 105700 RING LOCKING THE GEAR BEVEL
BEARING
SW1044S FRONT PROTECTION GUARD SW109300 WASHER
T 102001 SCREW FASTENING THE UPPER
COVER T 105800 GEAR BEVEL BEARING
SW1044SCPL FRONT PROTECTION SET T 100102 MOTOR CAP WITH SLOT
T 102100 SCREW FASTENING THE LOWER
COVER T 106000 LEFT SCREW FASTENING THE GEAR
BEVEL
SW1055SL COMPLETE MOTOR SUPPORT T 100200 SCREW FASTENING THE MOTOR CAP
T 106100 RING UNDER BLADE
SW1059CPL COMPLETE GEAR BEVEL T 100201 SCREW FASTENING THE CONNECTOR
SOCKET
T 102701 THREE-POLE PLUG WITH CABLE
GLAND T 106300 RING NUT FASTENING THE BLADE
SW1074MS LEFT BASE WITH BEVEL T 100300 ADJUSTMENT LOCKING SCREW
T 102702 THREE-POLE SOCKET T 107000 SCREW FASTENING THE
BASE/PLATFORM/SECTOR
SW1074MSC
PL COMPLETE LEFT BASE WITH BEVEL T 100400 MOTOR BEARING ADJUSTMENT
T 1027CPL FEEDING CABLE WITHOUT PLUG T 107500 BLADE ASSEMBLING/DISASSEMBLING
WRENCH
SW1076S SPRING WITH DOWEL T 100600 MOTOR BRUSHES
T 102904 CAP SWITCH WITHOUT LIGHT T 107600 DRIFT LOCKING THE BLADE
T 107900 LUBRICATING GREASE
T 102201 PAIR OF PERMANENT MAGNETS
T 102904L CAP SWITCH WITH LIGHT

T105300
T105200
SW104101S
SW104101SCPL
T107900
T1027CPL
T107600
T107500
T105000
T105000
T106100
T105400
10EHSS
SW1018CPL
T102100
T101700
T101801
SW1059CPL
SW101800
SW1059CPL
SW1019S
®
dal 1946
T101500
SW100500
T101200
T101600
T101000
SW1029S
SW1037S
SW1020S
T101300 (220-240V, 50-60 Hz) T101301 (110V, 50-60 Hz)
T1049S
T102904
T102904L
T100102
T100400
T100900
T102001
T100900
T102702
T100200
T100201
T100201
T100800
T100600
T100700
T102201
SW1022S
T106000
T106300
T105600
T105700
T105800
T104501
T104501
T104500
SW1044S
SW1044SCPL
T104700
T104800
SW108200
SW1074MSCPL
SW1080S
SW1081S
SW104101
SW104101
SW109300
SW109100
SW109200
SW108900
SW108800
SW108700
SW109000
SW1086CPL
SW108600
T100300
T102701
T107000
SW107900
SW1074MS
SW1076S
SW1055SL

WARRANTY
Rasor®Elettromeccanica S.r.l. cutting unit has a 12 month warranty from the date indicated
on the last page of this manual, except in case of different written agreements.
The warranty covers all manufacturing and material defects. Replacement and repair operations
are covered only if carried out by our company and at our workshop. If in-warranty goods
need to be repaired, the customer must always send the complete machine to Rasor®.
Single units will not be repaired under warranty.
The material to be repaired must be sent CARRIAGE FREE.
Once the machine has been repaired, it will be sent CARRIAGE FORWARD to the customer.
The warranty covers neither technicians' intervention on site nor the machine disassembly
from the installation place.
If for practical reasons, one of our technicians is sent to the premises, the customer will be
charged the costs plus the travelling expenses.
The warranty does not include:
failure caused by wrong use or assembly,
failure caused by external agents,
failure caused by lack of maintenance or neglicence;
blades and parts subject to wear.
WARRANTY FORFEITURE:
in case of arrearage or other breaches of contract,
whenever changes or repairs are carried out on our cutting units without our prior
authorization,
whenever the serial number is tampered with or cancelled,
whenever the damage is caused by improper use, bad treatment, bumps, falls and
other causes not due to normal working conditions,
whenever the unit seems tampered with, dismantled or previously repaired by
unauthorized staff,
in case the cutting units are used for purposes that are different from the ones described
in this manual.
All repair operations carried out under warranty do not interrupt its duration.
All disputes will be settled in the court of justice of Milan (Italy).
We thank you in advance for the attention you will pay to this manual and we invite you to
inform us of any change you deem necessary to improve it and make it more complete.

RASOR ELETTROMECCANICA SRL
Via Vincenzo Caldesi 6
20161 Milan ∙ Italy
ph. [phone]
fax [phone]
[email protected]
www.rasor-cutters.com
FOLLOW US:
