Razor E90 Series User manual

OWNER’S MANUAL
Read and understand this entire manual before riding!
DO NOT RETURN TO STORE!
NOTE: The unit must be traveling up to 3mph (5kmh) before motor will engage. Kick
start up to 3mph (5kmh) while applying the throttle to engage motor.
NOTE: Manual illustrations are for demonstration purposes only. Illustrations
may not reflect exactappearance of actual product. Specifications subject to
change without notice.
v.1_03-12
E90/ACCELERATOR SERIES
ELECTRIC SCOOTER
Please have your 19 digit product I.D. code ready before contacting Razor for
warranty assistance and/or replacement parts.
Product I.D. Code: ____________ - ____________ - ____________

SAFETY WARNINGS
Safety Warnings ............................................................ 1
Before You Begin........................................................... 2
Assembly and Set-Up.................................................... 3
Usage ............................................................................ 4
1
Hardware Maintenance ................................................. 4
Repair and Maintenance.............................................5-6
Troubleshooting Guide................................................... 7
Electric Scooter Parts .................................................... 8
Warranty ...................................................................... 10
CONTENTS
WARNING: Riding an electric scooter does present potential risks
and caution is required. Like any riding product, an electric scooter has
inherent hazards associated with its use (for example, falling off or riding it
into a hazardous situation). Like any riding product, electric scooters can and
are intended to move and it is therefore, of course, possible to lose control or
otherwise get into dangerous situations. Both children and adults responsible
for supervising them must recognize that, if such things occur, a rider can
be seriously injured or die, even when using safety equipment and other
precautions. RIDE AT YOUR OWN RISK AND USE COMMON SENSE.
WARNING: PARENTAL AND ADULT
RESPONSIBILTY AND SUPERVISION ISNECESSARY:
Because products like electric scooters can and do present potential hazards
plainly associated with their use, it is well recognized the THE NEED FOR THE
EXERCISE OF PARENTAL RESPONSIBILITY IN SELECTING RIDING PRODUCTS
APPROPRIATE TO THE AGE OF A CHILD, OR PARENTAL SUPERVISION IN
SITUATIONS IN WHICH CHILDREN OF VARIOUS AGES MAY HAVE ACCESS
TO THE SAME RIDING PRODUCTS, IS IMPORTANT. Not every product is
appropriate for every age or size of child and different age recommendations
are found within this category of product, which are intended to reflect the
nature of the hazards and the expected mental or physical ability, or both, of a
child to cope with the hazards.
The recommended rider age is 8 and older. Any rider unable to fit
comfortably on the scooter should not attempt to ride it. A parent’s decision
to allow his or her child to ride this product should be based on the child’s
maturity, skill and ability to follow rules.
Keep this product away from small children and remember that it is
intended for use only by persons who are, at a minimum, completely
comfortable and competent while operating the scooter.
DO NOT EXCEED THE WEIGHT LIMIT OF 120lbs (54kg). Rider weight
does not necessarily mean a person’s size is appropriate to fit or
maintain control of the scooter. Person with any mental or physical
conditions that may make them susceptible to injury or impair their physical
dexterity or mental capabilities to recognize, understand, and follow safety
instructions and to be able to understand the hazards inherent in scooter
use should not use, or be permitted to use, products inappropriate for their
abilities.
CHECK AND MAINTAIN SCOOTER CONDITIONS
Before use, check to confirm that any and all chain guards or other covers or
guards are in place and in serviceable condition, that the brake is functioning
properly, and that tires are inflated properly and have sufficient tread
remaining. The scooter should be maintained and repaired in accordance with
the manufacturer’s specifications and using only the manufacturer’s authorized
replacement parts, and should not be modified from the manufacturer’s original
design and configuration.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Always check and obey any local laws or regulations which may
affect the locations where the electric scooter may be used. Keep
safely away from cars and motor vehicle traffic at all times and only
use where allowed and with caution.
Do not activate the speed control on the hand grip unless you are on the
scooter and in a safe, outdoor environment suitable for riding. The electric
scooter must be moving at 3mph before the motor will engage.
Maintain a hold on the handlebars at all times. Do not touch the brakes or
motor on your scooter with fingers or bare hands when in use or immediately
after riding as these parts can become very hot.
Ride defensively. Be careful to avoid pedestrians, skaters, skateboards,
scooters, bikes, children or animals who may enter your path, and respect the
rights and property of others.
The electric scooter is intended for use on flat, dry surfaces such as
pavement or level ground without loose debris such as sand, leaves, rocks or
gravel. Wet, slick, bumpy, uneven or rough surfaces may impair traction and
contribute to possible accidents. Do not ride your scooter in mud, ice, puddles
or water. Watch out for potential obstacles that could catch your wheel or
force you to swerve suddenly or lose control. Avoid sharp bumps, drainage
grates, and sudden surface changes.
Avoid excessive speeds that can be associated with downhill rides.
Do not attempt or do stunts or tricks on your electric scooter. The scooter is
not made to withstand abuse from misuse such as jumping, curb grinding
or any other type of stunts. Racing, stunt riding, or other maneuvers also
enhance risk of loss of control, or may cause uncontrolled rider actions or
reactions.
Never allow more than one person at a time to ride the scooter.
Do not ride at night or when visibility is limited.
Never use near steps or swimming pools.
Do not allow hands, feet, hair, body parts, clothing, or similar articles to
come in contact with moving parts, wheels, or drivetrain, while the motor is
running.
Never use headphones or a cell phone when riding.
Never hitch a ride with another vehicle.
Do not ride your scooter in wet or icy weather and never immerse the scooter
in water, as the electrical and drive components could be damaged by water
or create other possibly unsafe conditions. Never risk damaging surfaces
such as carpet or flooring by use of an electric scooter indoors.
PROPER RIDING ATTIRE
Always wear proper protective equipment such as an approved safety helmet
(with chin strap securely buckled), elbow pads and kneepads. A helmet may
be legally required by local law or regulation in your area. A long-sleeved
shirt, long pants, and gloves are recommended. Always wear athletic shoes
(lace-up shoes with rubber soles), never ride barefooted or in sandals, and
keep shoelaces tied and out of the way of the wheels, motor and drive
system.
USING THE CHARGER
The charger supplied with the electric scooter should be regularly examined
for damage to the cord, plug, enclosure and other parts, and in the event of
such damage, the scooter must not be charged until the charger has been
repaired or replaced.
Use only with the recommended charger.
Use caution when charging.
The charger is not a toy. Charger should be operated by an adult.
Do not operate charger near flammable materials.
Unplug charger and disconnect from scooter when not in use.
Do not exceed charging time.
Always disconnect from the charger prior to wiping down and cleaning your
scooter with liquid.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE
WARNINGS INCREASES RISK OF SERIOUS INJURY. USE WITH
APPROPRIATE CAUTION AND SERIOUS ATTENTION TO SAFE
OPERATION.

Remove contents from box. Remove the foam separators that protect the components from damage during
shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have
occurred during shipping. Because the scooter was 95 percent assembled and packed at the factory, there
should not be any problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult with experience in bicycle mechanics.
Allow up to 10 minutes for assembly, not including initial charge time.
Allow up to 12 hours for charge (see page 3 for charging information).
BEFORE YOU BEGIN
2
WARNING:
DO NOT USE NON-
RAZOR PRODUCTS
WITH YOUR RAZOR
ELECTRIC SCOOTER.
The scooter has been built
to certain Razor design
specifications. The original
equipment supplied at the time
of sale was selected on the
basis of its compatibility with
the frame, fork and all other
parts. Certain aftermarket
products may not be compatible
and will void the warranty.
Required Tools
Need Help? Visitour web site for replacementparts, product support and a list of authorizedservice centers
at www.razor.com or call toll free 866-467-2967Monday - Friday8AM -5PM Pacific Time. Please have the
product I.D. code located on the white label on your product or back of charger available for better assistance.
5mm Allen wrenches
(Included)
Brake
Push Button Throttle
Handlebar
Stem
On/Off Switch
Charger Port
- Battery
- Control Module
Limiter
Charger
(Note: Charger design may vary
from one shown)
Charger
Plug
Charger
Port
10mm and 13mm open
wrenches
(Not included)
Screwdriver
(Not included)
Motor
Note: Electric scooter must
be moving at 3mph/5kmh
while pressing the push
button throttle to engage
motor.
Product ID Locations:
See locations to the left
1. Stem
2. Underneath battery tray
3. Charger
4. Box - side of UPC (not shown)
1.
2.
3.

3
ASSEMBLY AND SET-UP
q Attaching the Handlebars
q Charging the Battery
Your electric scooter may not have a fully charged battery. Therefore it is a good idea to charge the battery
prior to use.
2Turn power OFF before
charging. Plug the charger into
the charger port on the electric
scooter.
Charger
Charger
Plug
Charger
Port
2With the front wheel pointed
straight ahead and the handlebars
square to the front wheel, tighten
the clamp as shown. Tighten
securely.
1 Loosen the collar clamp and
slide it upward. With a clock-wise
twisting motion, push and “thread”
the steering tube onto the fork until
it bottoms out on the fork headset
lock nut.
Note: Make sure any cables/
wires are out of the way before
inserting the stem into the fork.
WARNING: Failure
to recharge the battery at least
once a month may result in
a battery that will no longer
accept a charge.
WARNING: Always
disconnect your scooter from
the charger before cleaning with
liquid.
Note: If your charger does not
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifications and charging
procedure would not change.
The charger has a small window
with one LED to indicate the
charge status. Refer to the
illustration on the charger unit
for the actual “charging” and
“charged” status indications for
your model charger.
Chargers have built-in over-
charge protection to prevent
battery from being over-charged.
Charger will get warm during
use. This is normal for some
chargers and is no cause for
concern. If your charger does
not get warm during use, it does
not mean that it is not working
properly.
q Attaching the Handlebar Grip WARNING: Failure to
properly engage the spring-loaded
button may cause the handlebar
to dislodge while riding and may
cause you to lose control and
fall. When correctly engaged, the
handlebar will not rotate nor will
it move sideways. Note that when
properly engaged, the spring-loaded
button is clearly visible in the hole
on the T-tube.
2Make certain the spring-loaded
button engages the hole and is
properly locked into the T-bar.
1Insert and secure the collaps-
ible handlebar by pressing the
spring-loaded button and
inserting it into the T-bar.
1Plug the charger into a wall
outlet. If the lights on charger
do not light up, check the power
to the outlet. If necessary, try a
different outlet.
•Initialchargetime:12hours
•Rechargetime:upto12hours,
even if the light turns green.
•Fullychargebatterybeforestoring.
•Whenthescooterisnotinregularuse,
recharge the battery at least once a
month until normal use is resumed.
•Makesurepoweristurned OFF when
unit is not in use.
•Runtime:Upto40minutesofcontinuousridetime.
Run time may vary depending on riding conditions,
climate and/or proper maintenance.
•Constantstoppingandstartingmayshortenridetime.
•Averagebatterylifeforapoperlymaintainedunitis
approx. 250 charge/discharge cycles.
•Toensurelongbatterylife,neverstoretheproductin
freezing or below freezing temperatures! Freezing will
permanently damage the battery. Failure to recharge
the battery at least once a month may result in a
battery that will no longer accept a charge.
•Continuechargingforthefull12hourseven
if charge light indicates charging complete.

4
CONNECTORS/HARDWARE MAINTENANCE
Need Help? Visit our web site for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code located on the white label on your product or back of charger available for better assistance.
Safety Gear
Always wear proper protective gear such as an approved safety
helmet. Elbow pads and kneepads are recommended. Always
wear athletic shoes (lace-up shoes with rubber soles), never ride
barefooted or in sandals, and keep shoelaces tied and out of the
way of the wheels, motor and drive system.
Battery
Make sure the power switch is turned off whenever the scooter is
not in use. Never store the product in freezing or below freezing
temperatures! Freezing will permanently damage the battery.
Failure to recharge the battery at least once a month may result in
a battery that will no longer accept a charge.
Brake
Check the brakes for proper function. When you step on the brake,
the brake should provide positive braking action. When you apply
the brake with the speed control on, the brake cut-off switch
should cut power to the motor.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames
are rare, it is possible for an aggressive rider to run into a curb
or wall and wreck and bend or break a frame. Get in the habit of
inspecting your scooter on a regular basis.
Wheels
Periodically inspect the tires for excess wear and regularly check
the wheels.
❑
❑
❑
❑
❑
Do not usethis product for the first time until you have
charged the battery for at least 12 hours. Failure to follow
these instructions may damage your product and void your
warranty.
❑ Starting the Scooter
USAGE
To start unit, turn on power switch, press the push button throttle
(A) and kick start up to 3mph (5mh) (B).
❑ Stopping the Scooter
To stop unit, release the push button throttle (A) and step down on
the rear fender brake (B) until the unit comes to a complete stop.
Note: Electric scooter must
be moving at 3mph/5kmh
while pressing the push
button throttle to engage
motor.

❑ Chain and Rear Wheel Replacement
Tools required: Phillips screwdriver, 10mm open wrench and two (2) 13mm open wrenches.
1With a Phillips screwdriver,
loosen the two screws and
remove the chain guard.
2Using two 13mm open
wrenches, loosen the locknuts
by turning the wrenches counter
clockwise.
3 To loosen the chain, push the
chain tensioner down to create
some slack in the chain.
5
4 Remove wheel and install
replacement wheel.
(Note the sequence of the
hardware)
REPAIR AND MAINTENANCE
5Push the chain tensioner
down to install the chain on
both sprockets.
6With two 13mm open
wrenches, re-tighten the
locknuts.
Note: Rear wheel hardware
sequence
Left Side
22-1 13mm nut
22-2 Split washer
22-3 Flat washer
Frame
22-4 Long spacer
Right Side
22-1 13mm nut
22-2 Split washer
22-3 Flat washer
Frame
22-5 Short spacer
7Re-attach the chain guard.
1 Using two (2) 5mm Allen
wrenches, loosen the axle bolt.
Remove wheel and install
replacement wheel. (Note the
sequence of the hardware)
❑ Front Wheel Replacement
Tools required: Two (2) 5mm Allen wrenches.
Right Side
11-4 - Center spacer
11-3 - Bearing
11-2 - Spacer
Fork
11-1 - 5mm coupling bolt
Left Side
11-3 - Bearing
11-2 - Spacer
Fork
11-5 - 5mm coupling screw
Note: Front wheel hardware
sequence

6
Need Help? Visit our web site for replacement parts, product support and a list of authorized service centers
at www.razor.com or call toll free 866-467-2967 Monday - Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code located on the white label on your product or back of charger available for better assistance.
q Battery Care and Disposal
Never store the product in freezing or below freezing temperatures! Freezing will permanently damage the battery.
Failure to recharge the battery at least once a month may result in a battery that will no longer accept a charge.
CONTAINS SEALED LEAD ACID BATTERIES. BATTERIES MUST BE RECYCLED.
Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in an
environmentally safe manner. Do not dispose of a lead-acid battery in a fire. The battery may explode or leak. Do not
dispose of a lead-acid battery in your regular household trash. The incineration, land filling or mixing of sealed lead-
acid batteries with household trash is prohibited by law in most areas. Return exhausted batteries to a federal or state
approved lead-acid battery recycler or a local seller of automotive batteries. If you live in Florida or Minnesota, it is
prohibited by law to throw away lead-acid batteries in the municipal waste stream.
q Charger
The charger supplied with the electric scooter should be regularly examined for damage to the cord, plug, enclosure
and other parts and in the event of such damage, the product must not be charged until it has been repaired or
replaced.
Use ONLY with the recommended charger.
q Wheels
Wheels and drive system are subject to normal wear and tear. It is the responsibility of the user to periodically inspect
wheels for excess wear and adjust and replace drive train components as required.
q Replacement Parts
The most frequently requested replacement parts are available for purchase at some Razor retail partners. For the
complete selection of replacement parts visit www.razor.com/shop.
q Repair Centers
For a list of authorized Razor repair centers:
•Checkonlineatwww.razor.com.
•Call866-467-2967forthecenternearestyou.
WARNING: If a battery
leak develops, avoid contact with
the leaking acid and place the
damaged battery in a plastic bag.
Refer to the disposal instructions at
left. If acid comes into contact with
skin or eyes, flush with cool water
for at least 15 minutes and contact
a physician.
WARNING: Battery
posts, terminals and related
accessories contain lead and lead
compounds. Wash your hands
after handling.
REPAIR AND MAINTENANCE

7
TROUBLESHOOTING GUIDE
Does not work out of
the box
No longer works
Short run time/runs slow
Runs intermittently
Problem Possible Cause Solution
Unit must be traveling up to 3mph
before motor will engage
Loose connection(s)
Blown fuse
Loose connection(s)
No lights on charger
Undercharged battery
Battery will not hold a charge
Riders weight
Riding conditions
Battery not fully charged
Old/damaged battery
Loose connection(s)
Kickstart to 3mph while pressing the push button throttle to engage
motor.
Check for loose connections/wires underneath the deck plate.
Check fuse; replace if needed.
Check for loose connections/wires underneath the deck plate.
Check power to wall outlet and/or try a different outlet.
Check lights on charger:
Plugged into wall = Green
Plugged into wall & unit = Red
Charging Complete = Green
No lights/Blinking lights - Replace Charger
With no weight on the unit, lift up back end; manually (and carefully,
of course) spin rear wheel and press push button throttle to engage
the motor. If motor engages - replace battery.
Do not exceed 120 lbs maximum weight limit.
Use only on flat, dry surfaces. Avoid inclines and areas with heavy
debris.
Charge unit for a full 12 hours.
With no weight on the unit, lift up back end; manually (and carefully,
of course) spin rear wheel and press push button throttle to engage
the motor. If motor engages - replace battery.
Charge battery at least once a month when not in use.
Do not store unit in freezing or below freezing temperatures. Freezing
will permanently damage the battery and greatly reduce ride time.
Refer to Pg. 3 Charging the Battery
Check the wires around the throttle and connectors underneath the
deck plate.
Replace - push button throttle.
For a list of available replacement parts or to locate an authorized Service Center in your area, visit our website at www.razor.com or call toll
free 866-467-2967 to speak to a live Customer Service Representative.
Unit should be fully charged prior to doing any troubleshooting and must be done by an adult ONLY.

Keep your scooter running for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
E90 ELECTRIC SCOOTER PARTS
8
01 Elastic cord w/end cap
02 Handlebar grips (right/left)
03 Push button throttle
04 Handlebar stem
05 Collar clamp
Front wheel complete
Front fork w/limiter
Headset06 (upper/lower)
07
08
(See pg. 5 for hardware sequence)
09 Battery tray
10 Control module
11 On/off switch
12 Charger port
13 Kickstand
14 Brake fender pedestal
15 Chain tensioner
Motor (12V / 100W)
Rear brake fender
Rear wheel completet
16
17
18
(See pg. 5 for hardware sequence)
19 Chain
20 Chain guard
Battery (1-12V/7Ah) w/fuse21
22 Deck plate
Need Help?Visit our web site for replacement parts,product support and a list of authorizedservice centers
at www.razor.comor call toll free 866-467-2967Monday -Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code located on the white label on your product or back of charger available for better assistance.

9
SB 1918 (CALIFORNIA) DECLARATION
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING THE USE OF THIS SCOOTER/ELECTRIC RIDE-ON PRODUCT. TO
DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR
INSURANCE COMPANY OR AGENT.

Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing defects
for a period of 90 days from date of purchase. This Limited Warranty does
not cover normal wear and tear, tires, tubes or cables, or any damage, failure
or loss caused by improper assembly, maintenance, or storage or use of the
Razor E90/Accelerator series electric scooter.
This Limited Warranty will be void if the product is ever
•used in a manner other than for recreation or transportation
•in any way;
•rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
WARRANTY
Printed in China for:
Razor USA LLC
PO Box 3610
Cerritos, CA 90703
Copyright © 2003-2012 Razor USA LLC. All rights reserved. RAZOR and the Razor Logo Design
are among the registered trademarks of Razor USA LLC in the United States and/or select foreign
countries.
Razor does not offer an extended warranty. If you have purchased an
extended warranty, it must be honored by the store at which it was
purchased.
For your records, save your original sales receipt with this manual and write
the serial number below.
__________________________________________
Need Help? Visitour web site for replacement parts, product support and a list of authorizedservice centers
at www.razor.comor call toll free 866-467-2967Monday -Friday 8AM - 5PM Pacific Time. Please have the
product I.D. code located on the white label on your product or back of charger available for better assistance.
10
03/2012
