Rebotec James 150 User manual

Read this User Manual before using the device for the first time and keep it at hand for
the user as well as for future use and subsequent sales.
James 150
20.02.10
150 kg
Affix serial number here
Art
.
BA No.: 02.09.201/2019-06_A01
Standing-up Hoist
User Manual
GB REBOTEC
®
Rehabilitationsmittel GmbH
D-49610 Qua enbrüc , Artlandstr. 57-59
Telephone: [phone]
Fax: [phone]
http://www.rebotec.de
Email: [email protected]

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 2 -
Description of the device
Figure shows:
a Column
b For ed arm
c Base frame members
d Pedal
e Front castors
f Rear castors
g Holder with nee protection
h Foot plates
i Handles
j Linear drive
k Control unit
l Manual switch
m Rechargeable battery unit
n Nameplate
Table of contents
1. General information 2
1.1 Introduction 2
1.2 Pac aging 2
1.3 Symbols & nameplate 2
1.4 Degrees of protection 3
1.5 Intended use 3
1.6 Operating comfort 3
2. Warranty 4
. Safety instructions for use 4
4. Reuse & lifetime 4
5. Disposal 5
6. Scope of delivery 5
7. Setting up for use 5
7.1 Unpac ing 5
7.2 Installing the control unit 5
7.3 Installing the column 6
7.4 Installing the linear drive 6
7.5 Installing the holder with nee pro-
tection
6
7.6 Connecting the electrical system 7
8. Charging the rechargeable battery 7
8.1 Connecting & charging 7
8.2 Charge level & control display 7
8.3 Display symbols 8
9. EMERGENCY OFF function 8
10. Manual switch 8
11. Bra ing function of the rear castors 8
12 Emergency lowering 8
12.1 Electrical emergency lowering 8
12.2 Mechanical emergency lowering 9
1 . Stability & spreading the base 9
14. For ed arm 9
15. Technical data 10
16. Troubleshooting 10
17. Cleaning and care 10
17.1 Emergency lowering 10
18. Maintenance 10
18.1 Scope of maintenance 11
18.2 Repair 11
19. Spare parts & accessories 12
20. Drawing & dimensions 14
1. General information
1.1. Introduction
In this User Manual, you will find information on the
safe and proper initial operation, use, maintenance
and care of this medical device.
Read these operating instructions carefully before
using the device.
Follow the safety instructions in particular and
act accordingly.
1.2. Packaging
We recommend you to eep the pac aging for a
later transport.
1. . Symbols & nameplate
Figure similar.
The nameplate must not be removed!
b
a
l
c
j
i
d
f
e
h
g
k
m
n

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- -
For ordering spare parts and processing
complaints, the device name, serial num-
ber and year of manufacture will be re-
quired.
Symbol Meaning Symbol Meaning
Read the
manual!
Year of
manufac-
ture De-
vice
Serial
number
Important
infor-
mation!
Article
number
Maximum
user
weight in
kg
Care in-
structions
Mainte-
nance in-
structions
Applicable
for indoor
use only.
Manufac-
turer
IP
Degrees of
protection
according
to DIN EN
60529
Protection
class II
Visual sig-
nal
Language
Read the
User Man-
ual!
Do not dis-
pose of as
household
waste.
Device complies with the Medical
Device Directive 9 /42/EEC
Caution!
Observe the safety instructions
1.4. Degrees of protection
Degree of protection, first digit:
No. Meaning
X Not specified
0 No protection
1 Protected against solid foreign bodies
with a diameter ≥ 50 mm
2 Protected against solid foreign bodies
with a diameter ≥ 12.5 mm
Protected against solid foreign bodies
with a diameter ≥ 2.5 mm
4 Protected against solid foreign bodies
with a diameter ≥ 1.0 mm
5 Protected against dust in harmful quanti-
ties
6 Dust-tight
Degree of protection, second digit:
No. Meaning
X Not specified
No. Meaning
0 No protection
1 Protection against vertically falling drops
of water
2
Protection against vertically falling drops
of water when the enclosure is tilted up
to 15°C
Protection against water falling as a
spray at any angle up to 60° from the ver-
tical
4 Protection against water splashed from
any direction
5 Protection against water jets (nozzle)
from any angle
6 Protection against powerful water jets
7 Protection against temporary immersion
8 Protection against continuous immersion
9 Protection against water from high-pres-
sure/steam jet cleaning
Letters
Let-
ter
Meaning
A
Protected against access to hazardous
active parts with the bac of a hand
B
Protected against access to hazardous
active parts with a finger
C
Protected against access to hazardous
active parts with a tool
D
Protected against access to hazardous
active parts with a wire
H
High-voltage equipment
M
Tested when moving parts are active
S
Tested when moving parts are standing
still
W
Tested at defined weather conditions
1.5. Intended use
The article can be used for care purposes in facili-
ties and hospitals as well as for home care pur-
poses.
The sole intended use of the article described
herein is to transport and transfer patients in a sling
and to support them in standing up.
James 150
=150 kg
This medical device is not suitable for longer
transport distances or for travelling over uneven
surfaces. It is not designed for other purposes such
as misusing it for transporting objects or the li e.
The medical device is for indoor use only! The
medical device must not be used near life-sustain-
ing devices.
1.6. Operating comfort
The device is equipped with an electrical lifting
drive, crush protection, emergency lowering,
Art.
GB

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 4 -
EMERGENCY OFF function and a rechargeable
battery unit.
This rechargeable battery unit allows the device to
be used independently of an external energy
source depending on the charge level of the re-
chargeable battery and thus increases mobility dur-
ing use.
The base frame members can be spread apart eas-
ily by operating the pedal and thus ensure in-
creased stability. The rear castors can easily be
loc ed with the loc ing lever using your foot.
Using the manual switch, the for ed arm can step-
lessly be moved up and down via the linear drive.
2. Warranty
The device has a warranty of 2 years, when re-
specting our general terms and conditions
(https://www.rebotec.de/agbs.html) and the in-
tended use of the device.
Any unauthorised changes to the device without
the consent of the manufacturer will void the war-
ranty.
The delivery date written on the RE O-
TEC delivery note applies as the valid
start date of the warranty period.
. Safety instructions for use
When using the medical device, ob-
serve the following safety instruc-
tions:
Attention - directions for use!
 Before using the device for the first time, the User
Manual must be read completely in order to avoid
damage caused by fault operation or hazards.
 Before each use, chec the device for visible
damage or deficiencies.
 The medical device may only be operated by per-
sons who are familiar with the handling of the de-
vice. This requires the ability to use the device
with patients.
 Standing-up hoists used in wet rooms may be ex-
posed to chlorine, high humidity and heat, which
can lead to oxidation that appears as white coat-
ing.
 In case of malfunctions or damage of any ind,
the device must not be used.
Caution - danger of breakage!
 The max. allowable load must not be ex-
ceeded, as otherwise safe operation can no
longer be guaranteed.
 Whenever using a sling, ma e sure that it is
properly mounted to the for ed arm. Do not use
any sling that shows signs of damage.
 Do not place any objects between the column
and the linear drive. Lateral forces must not be
applied to the linear drive.
 The patient must not hold onto the linear drive.
 Weight loads must not be hung onto the for ed
arm for an extended period of time.
Caution - risk of injury!
 The device must not be operated while it is con-
nected to the mains in order to charge the re-
chargeable battery.
 The device is for indoor use and use on even and
slip-resistant surfaces only. Using the device on
slopes, grades or inclinations must be avoided
due to the increased ris of accidents.
 Caution is required when travelling in confined
spaces. Paths used by the medical device must
be cleared before they are travelled on.
 Sudden movements and pushing as well as
swinging the patient to be moved must be
avoided due to the increased ris of accidents.
 Never leave the patient unsupervised when us-
ing the device! An unforeseen action or move-
ment by the patient may lead to a possible ris of
injury.
 In the event of an emergency lowering of the pa-
tient, proceed with the utmost caution to avoid
putting the patient at ris . In difficult situations,
see the assistance of another person if neces-
sary.
 Chec the hoo s of the for ed arm at regular in-
tervals.
Caution - risk of malfunction!
 It must be assured that no moisture enters the
electrical system.
(Observe the degrees of protection!)
 Do not open the housings of the electronic com-
ponents.
 If the linear drive does not wor (drive must not
start up while it is bloc ed), the device must not
be put into operation.
 Do not charge the rechargeable battery in wet
rooms (e.g.: bathrooms, toilets).
 Pay attention to electromagnetic interference(s)
to other devices (such as mobile phones, medi-
cal devices)!
4. Reuse & lifetime
The device is suitable for reuse. How often the de-
vice can be reused depends on the type and inten-
sity of use. Before reuse, the device must be repro-
cessed hygienically and the technical functional
safety and reliability must be chec ed and restored
if necessary.
If the device is used as intended according to the
safety instructions, its lifetime is 5 years.
The effective lifetime, however, may vary depend-
ing on the frequency and intensity of use and the
general condition.

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 5 -
5. Disposal
The local disposal regulations must be complied
with. Please contact a disposal company for further
information.
6. Scope of delivery
The device has been carefully inspected in the
factory for freedom from defects. Please chec
the device for any possible transport damage and
the completeness of the scope of delivery upon
receipt .
The device will not be delivered assembled com-
pletely.
 1 Standing-up hoist frame
 1 Holder with nee protection
 1 Linear drive
 1 Control unit
 1 Rechargeable battery unit
 1 Charging cable
 1 Fuse set for charging cable
 1 Manual switch
 1 User Manual
The Maintenance Instructions and Repro-
cessing Instructions are optionally availa-
ble.
7. Setting up for use
Before using the device for the first time, the follow-
ing assembly processes must be carried out:
7.1. Unpacking
Remove the device from its pac aging and place it
on a level floor.
Bring the pedal in the centre position and then ac-
tuate the bra es of the rear castors (see section
11.).
Attention!
Before raising the column, bring the pedal first in
the centre position in order to avoid any damage.
See also notice on the column.
It is recommended to remove the packag-
ing material at the column and forked arm
only after the column has been set up.
7.2. Installing the control unit
Insert the two clamps of the cable holder into the
support.
Remove the rechargeable battery from the control
unit by pressing the button in position 1 and then
carefully remove rechargeable battery.
Use the two M6x16 screws (1) (included in the de-
livery) and an Allen ey (size 5) to screw the control
unit to the column.
The EMERGENCY OFF switch must face down-
wards to the pedal!
Remove the M6x16 screw at the column on the
handle side.
1

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 6 -
Then slide the control unit with the lower guide (2)
over the remaining screw.
Then screw the screw bac in again in pos. 3.
Tighten the screw hand-tight.
Reinsert the rechargeable battery. Ma e sure that
the rechargeable battery in pos. 4 clic s into posi-
tion properly.
7. . Installing the column
Remove the ey ring (1) from the bolt and then pull
the bolt completely out of the hole.
Then raise the column.
Reinsert the bolt in the hole to fix the column in the
support.
Then secure the connection again with the ey ring
(2). Then tighten the M10 (3) cap nut.
Remove the pac aging material afterwards.
7.4. Installing the linear drive
In order to connect the linear drive to the for ed
arm, remove the ey ring (1) and the bolt from the
hole of the for ed arm.
Then lift the for ed arm and bring the hole of the
linear drive (1) and the hole of the for ed arm to the
same height.
By inserting the bolt and securing it with the ey
ring, the for ed arm is securely connected to the
linear drive.
Make sure that the key ring is completely
closed!
7.5. Installing the holder with knee protec-
tion
Unscrew the two screws (1) from the base frame
member (A) and then screw the holder (B) to the
nee protection. By loosening the star grip screw
(2), the nee protection can be adjusted in height.
1
2
4
2
1
1
B

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 7 -
7.6. Connecting the electrical system
Insert the plug of the linear drive in the jac (1).
Please pay attention to the positioning of the re-
cess. Then insert the manual switch in the jac (2).
efore using the device for the first time,
the EMERGENCY OFF switch must be
deactivated. See 9.
8. Charging the rechargeable battery
Recharge the discharged rechargeable
battery as soon as possible! This in-
creases the lifetime of the rechargeable
battery. Rechargeable batteries which are not used
for an extended period of time should be recharged
every three months in order to avoid a deep dis-
charge, as this has a negative impact on the charg-
ing capacity of the rechargeable battery.
The lifetime of the rechargeable battery depends
on the intensity of use and the charge level.
8.1. Connecting & charging
Observe the safety instructions
 Chec the cable or plug to be sure that they are
not damaged.
 Do not use any damaged components!
 Pay attention to the power supply voltage (see
15.) and corresponding power supply fuse pro-
tection for the charging unit.
 Do not open the housings of the electronic com-
ponents.
 During the charging process, the medical de-
vice must not be operated! The electrical
functions are then out of operation.
Insert the flat plug of the charging cable in the con-
trol unit (3) and then secure it using the cable clip
(4).
Please pay attention to the positioning of the re-
cesses. Afterwards, insert the power plug into the
wall soc et.
The charging process may ta e up to ten hours de-
pending on the charge level of the rechargeable
battery. During the charging process, the battery
display of the control unit is flashing.
If the battery bar display lights up continuously, the
rechargeable battery is fully charged (see 8. ). If
the charging process ta es longer than 14 hours,
the rechargeable battery or control unit may be de-
fective.
After charging, pull out the power plug from the wall
soc et and wind the charging cable around the ca-
ble holder of the control unit.
Use the seal plug included in the scope of delivery
to close the connection after each charging pro-
cess in order to prevent the ingress of moisture.
After the power plug has been removed,
the function of the control unit will be
blocked for a few seconds.
8.2. Charge level & control display
The charge level of the rechargeable battery can
be read from the control unit. To switch on the dis-
play, the manual switch must be pressed once.
The EMERGENCY OFF switch must be released
(see 9.).
1
2
4

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 8 -
8. . Display symbols:
Symbols
Description
Battery capacity 100%
Battery capacity 75%
Battery capacity 50%
Battery capacity 25%; an
acoustic signal will sound and
the rechargeable battery must
be charged.
Standby mode
Low Batt
Minimum capacity reached
Maintenance or replacement
of the linear drive required.
Linear drive has exceeded the
operating time of 600.000 sec.
System is overloaded.
The rechargeable battery can be re-
moved for the purposes of replacement
or storage.
9. EMERGENCY OFF function
By pressing the EMERGENCY OFF switch, it
loc s into position. The drive unit is interrupted and
can no longer be operated with the manual switch.
It is activated in emergency situations and if the
proper operation of the device is impaired.
By turning the EMERGENCY OFF switch in the
direction of the arrow, it pops bac out and is thus
released. The drive unit can then be operated
again using the manual switch.
10. Manual switch
The manual switch is used to activate the drive unit
(stepless adjustment) and activates the “lifting”
and “lowering” of the for ed arm.
For the desired action, the respective button must
be pressed and held. When releasing the button,
the drive unit stops automatically.
Lifting
Lowering
As an alternative, the linear drive can also be ex-
tended (lifted) using the button (1) on the control
unit and retracted (lowered) with the electrical
emergency lowering (2). See 12.1.
11. Braking function of the rear castors
The two rear castors are provided with an important
safe feature when using the device. The rear cas-
tors are equipped with a loc ing bra e and an anti-
swivel protection.
Attention - risk of tipping over!
Always both rear castors must be
locked.
Press down the lever in
the front area with your
foot. The castors are
then bra ed and se-
cured against swivel-
ling.
Ma e sure that the cas-
tors do preferably not
point inwards.
By actuating the lever in
the rear area, the
bra es are released
again.
12. Emergency lowering
12.1. Electrical emergency lowering
If the manual switch is out of order due to a defect,
but the electrical system is still functioning (battery
is sufficiently charged), the linear drive can be re-
tracted using the EMERGENCY lowering button.
For lowering, keep
and hold the but-
ton.
1
2

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 9 -
12.2. Mechanical emergency lowering
If the patient becomes exposed to an emergency
situation, an electrical defect occurs at the drive
motor, the control unit fails or the rechargeable bat-
tery is completely discharged, it is necessary to
use the mechanical emergency lowering.
efore using the emergency lowering,
press the EMERGENCY OFF switch!
Attention - risk of injury!
When using the mechanical emergency lower-
ing, do not stand under the arm.
Lowering
Grab the red rotary grip with
your hand. For lowering the
drive axis, hold the red ro-
tary grip and turn it in the di-
rection of the arrow.
1 . Stability & spreading the base
The pedal allows spreading the base frame mem-
bers apart and thus facilitates moving the device to
the area of use. Press the foot pedal all the way
down to the stop with your foot.
Attention - risk of tipping over!
Spread the base frame members apart only
when the brakes are released.
Not spread apart
Press the left side of the pedal.
Spread apart
Press the right side of the pedal.
14. Forked arm
The for ed arm (B) is intended for mounting slings
in which the patient can be held, raised and trans-
ferred.
The sling must be mounted to one pair of hoo s (1
or 2) to ensure that the load is evenly distributed.
For the individual areas of application, dif-
ferent types of sling systems are available.
1
B
1
2 2

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 10 -
15. Technical data
We reserve the right to ma e technical develop-
ments and improvements with respect to the de-
sign shown in this User Manual.
See also 14.
Parameters James 150
Load Max. 150 g
*Device weight 53 g
*Space require-
ments See 20.
Lifting cycles
Approx. 25 lifting cycles (de-
pending on the intensity of use
and battery charge)
Lifting unit Stepless and without jer ing
Protection class II
Noise level ≤55 dB
Switch-on dura-
tion
2 min operation / 18 min pause
Drive speed 5.2 mm/s
Control unit IP55 100-240V AC / 50-60 Hz
24V DC / 216VA
Linear drive IP54 24V DC / 180VA
Manual switch IP54 5V DC
Rechargeable
battery unit
IP65 24V DC / 5 Ah
Operation/stor-
age
5C to 45C / -10C to 50C
Operation/stor-
age
Humidity ≤ 75%
Safety
Emergency lowering, crush pro-
tection (free running),
EMERGENCY OFF function
*Without accessories
Depending on the application, there are several dif-
ferent types of sling systems offered by REBOTEC.
To assist you in selecting the most suitable sling
system, a Guide is available (see 19.).
16. Troubleshooting
Fault
Possible
cause
Correction
leastDrive unit
does not wor
EMERGENCY OFF
button is activated
Release EMER-
GENCY OFF button
Bad, missing plug
contact Chec plug contact
Defective cable Chec and inspect
the cable
Battery capacity is
too low
Charge rechargea-
ble battery
Lifting unit is
jammed
Chec for freedom
of movement
Rechargeable bat-
tery has no contact
Reinstall rechargea-
ble battery, chec
position
No rechargeable
battery installed
Install rechargeable
battery
Rechargeable
battery does
not charge
Display does not
fully light up, bat-
tery symbol & LED
Chec mains sup-
ply
Chec charging ca-
ble for contact and
damage
Fault
Possible
cause
Correction
Rechargeable bat-
tery defective
Display/LED defec-
tive
Rechargeable bat-
tery not quite or not
fully installed
Reinsert recharge-
able battery, chec
position
Arm does not
drive all the
way up/down
Battery capacity is
too low
Charge rechargea-
ble battery
For ed arm is
jammed
Loosen the screws
at the column
Manual switch
does not wor
Button(s) have no
function
Button(s) defective
Chec cable/plug
contact
Greatly re-
duced speed,
loud noise
Motor, gear unit de-
fective
Put drive out of op-
eration, carry out
maintenance!
17. Cleaning and care
The device can be cleaned using a mild
conventional cleaning and disinfecting
agent. After cleaning, wipe the device with clean
water and a cloth and then wipe it dry with a clean
cloth.
Maximum cleaning temperature of 45  C
must be observed!
The device must not be cleaned in an
automatic cleaning unit!
Do not use scouring or cleaning agents (read and
observe the product information!) that contain ag-
gressive solvents (acids, benzene, thinners) or stiff
cleaning tools (brushes).
Otherwise, this may result in damage to the metal
surface or deposits on the metal parts and other
materials.
17.1. Emergency lowering
The emergency lowering mechanism must not be
treated with oil, grease or other lubricant. This will
lead to malfunctions during the lowering process.
In case of a malfunction of the emergency lowering,
the device must be reset by a maintenance service.
18. Maintenance
Accidents may be caused by the late detection of
wear and/or improper use as well as irregular or no
maintenance.
Please note that, for safety reasons and for
preventing accidents, the medical device
must undergo complete professional
maintenance at least once a year. (Refer to the
German MPG [Medical Devices Act] and German
MP etreibV [Medical Devices Operator Ordi-
nance])

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 11 -
18.1. Scope of maintenance
Please check at regular intervals:
The intervals depend on the frequency of use and
the condition of the device.
 Devices for visible damage
(crac s, brea age, loose parts)
 All screw connections for tightness
(especially the castors and holder)
 Emergency lowering at least twice a year
(Carry out maintenance focusing on malfunc-
tions!)
 Rolling smoothness, functioning of the castors
(replace any defective castors)
 Functioning of the drive unit, manual switch
(replace any defective items)
 All cables, connections and plugs for damage
 Sealing edges of control and rechargeable bat-
tery unit
 EMERGENCY OFF function
 Inspect accessories for deficiencies
18.2. Repair
 If you have any questions concerning the
maintenance and repair of the device, please
contact an authorised dealer or a medical and
healthcare supplies store.
 When performing repair wor , please use only
original REBOTEC spare parts. Observe all
guarantee and warranty information.
 Never ma e any unauthorised modifications or
conversions to the device. These will only ad-
versely affect the safety and functioning of the
device. In such cases, REBOTEC will not as-
sume any product liability.
 Follow all the instructions for ordering spare
parts, reuse and the lifetime of the device.
 After maintenance or repair wor has been car-
ried out, we recommend you to clean the device
for hygienic reasons before using it again. Fol-
low the cleaning and care instructions.
For documenting the maintenance and re-
pair work, RE OTEC provides a Mainte-
nance Report.
You can order the User Manual, Maintenance Re-
port and Reprocessing Instructions or find them on
our website at www.rebotec.de.
It is also possible to print the information and read
it when needed.

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 12 -
5a/b
11
4
1
6
12
10
9
8
2
1
7
19. Spare parts & accessories

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 1 -
No.
Art. no.
Designation
-
02.09.201 User Manual for James 150
-
02.10.141 Guide for Slings
-
02.11.152 Maintenance Instructions for Hoist
-
02.12.160 Reprocessing Instructions
1
425.19.71 Linear drive
2
425.19.72 Control unit
425.19.7 Rechargeable battery unit
4
425.19.75 Manual switch
5a
425.19.74 Charging cable, EU plug
-
425.19.76 Charging cable, US plug
-
425.19.78 Charging cable, KR plug
5b
425.19.77 Fuse set for charging cable
6
44 .10.80 Front castor (Ø 75 mm)
7
44 .10.85 Rear castor (Ø100 mm)
8
420.00.15 Rubber cap for pedal
9
420.00.12 Pedal
10 420.28.8 Angle joint rod (L=280 mm)
11
420.99.22 Handles for D22x90mm column
12
85 .08.20 Star grip M8
-
420.95.22 Handles for D22x120mm column
1
420.58.97 SL24/1.5 ey ring
-
420.00.14 Screwing set for centre of rotation
-
20.60 Handles for Standing-up Hoist James
Use only RE OTEC spare parts and accessories to ensure the proper and safe functioning of the
device.

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 14 -
20. Drawing & dimensions

REBOTEC / BA No.: 02.09.201/2019-06_A01 GB
- 15 -
James 150
No. Designation
Dimensions
in mm
1 Highest point
2 Highest point at highest reach
Lowest point
a Highest reach at a height of 600 mm (reference height) 160
b Highest reach from the base frame 400
c Reach from the base frame when expanding the leg supports to 700 mm 350
d1 Front castor diameter 75
d2 Rear castor diameter 100
e Total height (without arm) 1265
f Length of the base frame 970
g Distance of the push handles 480
h Turning diameter 1130
k Maximum height of the CSP 1910
l Minimum height of the CSP 950
m Lifting range 960
n Height of the base frame 120
o Clearance of the base frame 70
p Maximum inner width 815
q Inner width at highest reach 720
r Minimum inner width 530
x Minimum distance from the wall to the CSP at its greatest height (spread apart) 840
y Minimum distance from the wall to the CSP at its lowest height (spread apart) 320
z Minimum distance from the wall to the CSP at its highest reach (spread apart) 240
Dimensions vary depending on the equipment. There might be minor deviations due to production
tolerances. Subject to change without notice.

Read this User Manual before using the device for the first time and keep it at hand for
the user as well as for future use and subsequent sales.
REBOTEC
®
Rehabilitationsmittel GmbH
D-49610 Qua enbrüc , Artlandstr. 57-59
Telephone: [phone]
Fax: [phone]
http://www.rebotec.de
Email: [email protected]
GB
