Rebotec YANO-Walker User manual

„YANO-Walker”with forearm support
BA-No.: 02.05.133/2016-12
User Instructions
REBOTEC®Rehabilitationsmittel GmbH
DE-49610 Quakenbrück, Artlandstr. 57-59
Telephone: [phone]
Telefax: +49(0)5431/9416-66
http://www.rebotec.de
E-mail: [email protected]
GB
Art.-No.: 188.99.10
Serial Number
06/2005 (Th.B.)
User Weight: max. 150 kg
Important advisories!
Read this User Instructions before first-time use of the walker and keep it ready for the user.
Adhere to all advisories, especially the safety advisories.
Keep this User Instructions booklet at hand for future use and subsequent sales.
The user instructions and the maintenance manual are downloadable on our homepage.

REBOTEC / BA-No.: 02.05.133/2016-12 GB
- 2 -
Product Description
Diagram shows:
A
Front wheel bow
B
Rear wheel bow
C
Grip frame / handgrip
D
Front wheel with brake wheel
E
Rear wheel with brake wheel
I
Star grip for adjusting handle height
J
red pull-cord
O
Handle lower arm support
P
Forearm support
Z
Nameplate for product
Nameplate (Z)
Always observe the allowable
maximum patient body weight!
The name-plate is very important for product
identification, and thus must not be removed.
Table of contents
1.
General advisories
2
1.1
Introduction
2
1.2
Intended proper use
2
1.3
Equipment advisories
2
2.
Warranty
3
3.
Spare parts orders, complaints
3
4.
Re-use, lifetime
3
5.
Disposal
3
6.
Symbol advisory
3
7.
Safety advisories for use
3
8.
Scope of delivery
4
9.
Spare parts
4
10.
Setting up for use
4
10.1
Installation of the walker
4
10.2
Adjustment of forearm height
4
10.3
Adjusting of the forearm
cuff/lenght
4
10.4
Adjusting the arm cuff/angle ….
4
10.5
Setting the handles
5
11.
Operation of the walker
5
11.1
Readiness of the walker
5
11.2
Using the walker
5
11.3
Function of the brake
5
11.4
Folding the walker
5
12.
Troubleshooting
6
13.
Care
6
14.
Maintenance
6
15.
Technical specifications
6
We recommend, if possible, keeping
the packaging for later transport. This
will allow secure packaging in the
event of a return transport.
1. General advisories
1.1 Introduction
In this User Instructions booklet, you will find
information and advisories for set-up, use,
operation, maintenance and care of the YANO-
Walker with forearm support.
1.2 Intended proper use
The walker with forearm support is a mobility aid
and is used particularly for arthritis patients. It is
structurally designed for obese individuals and for
resizing the handlebar and forearm support is
adjustable.
The walker should not be used by patients who
suffer from perceptual and strong balance
disorders. It can be used only for indoor use on
firm, level ground. The transport of heavy objects,
attaching loads and use as a stand-up is improper.
The maximum user weight of the
YANO-Walker is 150 kg.
1.3 Equipment advisories
The walker consists of a powder coated frame
(steel pipe) and a grip handle and two padded
forearm support. The tires consist of four plain
bearing wheels; rotatable front and rear 360
degrees and with the parking brake (foot).
A
B
C
I
D
O
J
Z
E
P

REBOTEC / BA-No.: 02.05.133/2016-12 GB
- 3 -
2. Warranty
There is a 2-year warranty on our walker.
A prerequisite for the warranty is use in
accordance to the requirements outlined herein, as
well as conducting regular maintenance. Excluded
are all wear parts.
Not observing the User Instructions, improper
maintenance and unauthorised modifications done
to the product without the manufacturer’s
permission automatically lead to the immediate
nullification of warranty and product liability (see
Maintenance).
The delivery date written on the REBOTEC-
delivery note applies as the valid start date of
the warranty period.
3. Spare parts orders, complaints
To exclude incorrect spare parts deliveries and to
ensure rapid processing of complaints, always
provide the product name, serial number (SN) and
the product’s year of manufacture. You can find
this information on the walker nameplate.
4. Re-use, lifetime
The YANO-Walker is suitable for re-use.
The re-use (lifetime) depends on the product’s
condition. Before re-use, maintenance of the
walker must be conducted and the applicable
instructions concerning safety care and
maintenance must be fully adhered to.
The expected lifetime of the walker can be up to 3
years when used properly and the safety
instructions, maintenance intervals and care
instructions are followed.
Beyond this time period, the walker can be used
further if it is still in a safe condition (after a
complete inspection).
5. Disposal
The walker consists of steel tubing, metal, plastic
and wood which are all recyclable. Products that
can no longer be used are to be disposed of
separately from regular household rubbish. This
must be done according to the local and national
regulations for environmental protection and raw
material recycling. Please contact your local
disposal company or officials for further
information.
6. Symbol advisories
Symbol - nameplate:
Read the User Instructions!
Product conforms to the Medical
Products Directive 93/42/ EEC
Year of Manuf. Serial No.
Product Product
Symbols in the User Instructions:
Important advisory Language
or information!
Caution –Follow safety advisories!
Care Maintenance
7. Safety advisories for use
A walker is a technical aid, and the user must
abide by the following safety advisories and
rules:
Danger of falling!
Read the User Instructions before first-time use
in order to avoid damages through improper use
or other hazards. Be sure the maximum
allowable weight for the product is not exceeded!
Before each use, check for the proper function of
the brakes and the overall stability of the walker.
Start only with running and pushing the walker
when you stand upright, both forearms are
resting on the forearm pads and the handles
detected with both hands, and the brakes are
released.
First begin by walking and push the walker while
standing upright with both hands gripping the
grip handles.
Check to be sure that the star-handles on the
grip bow are tightened.
Always walk inside of the walker and do not push
the walker too far in front of you in order to avoid
incorrect loading and increased risk of falling
down.
Use of the walker by users who do not have
complete physical control and normal movement
must not be done unsupervised.
Danger of breakage!
The walker is not a transportation device for
heavy objects.
Danger of tipping over!
There is an increased risk of pinching limbs and
fingers at all joints and hinges on the walker. Be
extra careful of possible pinching of body parts
or objects when folding and unfolding the walker.
SN
GB

REBOTEC / BA-No.: 02.05.133/2016-12 GB
- 4 -
Danger of injury!
At surface temperatures over 40°C (104°F),
there’s a risk of injury. Therefore do not expose
the walker to any source of heat (exposure to the
sun, storing near a heater, cleaning with hot
water) just before the walker is used. Before
using the walker, allow it to cool down.
8. Scope of delivery
The product has been carefully inspected in the
factory for freedom of defects and for
completeness. After having received it, carefully
check over the product for possible transport
damages and for completeness.
1 YANO-Walker 150
1 User Instructions
9. Spare parts
Article-No.
Name
288.10.45
Front wheel with brake, complete
288.10.46
Rear wheel with brake, complete
231.10.36
Upholstery for arm cuff, black
02.05.133
User Instructions
02.11.149
Maintenance Instructions
10. Setting up for use
The product is delivered pre-assembled in the box.
Before using the product it has to be individually
adjusted by the dealer or nurse for proper
function and user has to be briefed for the use.
10.1 Installation of the walker
Remove the handle rails with the pre-assembled
forearm supports and the walker out of the box.
Put the walker on wheels and fold it by depressing
the rear bracket (C) completely apart, until the
bolts snapped into position (D). Push the handle
bracket (A) with the forearm supports in the front
fork (B)
The height of the forearm support is adjusted via
the adjustable handle rail.
10.2 Adjustment of forearm height
The height of the forearm support is adjusted via
the adjustable handle rail.
The height of the grip handles (A) must match the
user’s height. Adjust the grip handles to the
desired height. Line up the holes (B) and then
tighten together with the star screws.
10.3 Adjusting of the forearm cuff / length
For adjusting the forearm length, there are three
adjustment possibilities (A= normal / B= short / C=
long)
Remove cap nut (1) with an open SW10 spanner
and completely remove screw (2).
Select desired adjustment, insert the screw and
put on the cap nut firmly.
10.4 Adjusting the arm cuff/angle adjustment
Through variable adjustment of the angle of the
arm cuff, the position of the forearm can be
adjusted.
Loosen screw (1) of the clamping journal (2) of
the support clevis using an SW 4 Allen key (3).
With your hand (A), press the arm cuff
downward to the desired position. (max. angle
adjustable until the stop (B)
Tighten screw (1).
2
1
2
1
3
B
C
A
B
A
C
A
D
B
A

REBOTEC / BA-No.: 02.05.133/2016-12 GB
- 5 -
Settings
The tilt position is adjustable to each anchor point.
10.5 Setting the handles
The handle is continuously rotatable in the range
of 180 degrees.
The standard handle is fitted. The accessories are
alternatively two different handle shapes (ellipse
handle and spade-handle).
“Standard”“Ellipse”“Spaten”
231.10.20 231.10.22 231.10.24
11. Operation of the walker
Before use, it must be assured that the walker is in
a proper condition for safe use.
If defects or malfunctions are detected, then the
walker must not be used. In this case the defect or
malfunction must be removed by a qualified
serviceman.
11.1 Readiness of the walker
The walker must be unfolded and the locking pins
must click into position.
Check the safe standing and the function of the
parking brakes.
11.2 Using the walker
Always run inside the walker and not push it too
far ahead of you.
Do not lean too far over the underarm pads.
When using the walker in the indoor area, do not
drive against thresholds and pay attention for
loose or slippery floor coverings.
While walking all four parking brakes must be
released.
11.3 Function of the brake
The improper use of brakes can lead to unsafe
situations and damage (increased wear, functional
limitations). The walker must not be rolled when
the brakes are applied or when the wheels are
blocked by the permanent brakes.
By pressing down the red lever (A), the wheel is
blocked; by pushing up (B) the lever, the brake is
released again. The wheel can be rotated 360
degrees, in the unlocked position.
11.4 Folding the walker
Unfolding
Place the walker down on its wheels and press the
frame downwards. The folding lock mechanism
(locking pins) must click fully into position.
Folding up
Pull out the two bolts completely and pull the tube
towards you (B).
A
B
A
B

REBOTEC / BA-No.: 02.05.133/2016-12 GB
- 6 -
12. Troubleshooting
Fault
Possible
cause
Correction
Wheels turn
with difficulty
Gummed up
Clean, inspect
regularly
Locking pins
jam
Gummed up
Clean,
Replace locking
pins
No brake
function
Faulty
Maintenance!
Replace item
Reduced brake
function
Generally
defective, wear
Maintenance,
Adjust brake
Wheels are
bent
Impact against
obstacles
Maintenance!
Replace
Armpad
defective
Wear and tear.
Exchange
defective parts
Loose
connections
Wear and tear.
Check and
exchange
defective parts
13. Care
In general the walker can be cleaned using
a mild conventional cleaning and
disinfecting agent. Simply wipe the walker
with clean water and cloth, and then wipe
dry with a clean cloth.
Do not use an abrasive scouring agent or cleaner
(read the product instructions!) that contain
aggressive solvents (acids, thinners, etc.). Do not
use stiff cleaning brushes, as these will damage
the surfaces or cause deposits to build up on the
plastic parts and other materials.
14. Maintenance
The cause of accidents or damage may be due to
the late detection of wear and / or improper use, as
well as irregular maintenance.
For safety reasons and for preventing
accidents, the walker must undergo a
complete maintenance at least once a
year. (Refer to the Medical Products Act and
local requirements).
Special requirements of the product arising
from use by the patient may require more
frequent maintenance intervals.
Maintenance / scope of inspection
Maintenance should include the following checks
and be documented:
Visual check of all frame parts, such as:
(damage, wear and corrosion)
walker frame
Grip handles
Swivel castors
Forearm supports
wheels
Check all connector elements (screws, nuts)
for completeness. Check fit and function.
Check function of the folding mechanism.
Function of the height adjustment.
Function brakes.
If you have questions concerning
maintenance and repairs to the walker,
then contact an authorised dealer or
medical equipment supply outlet.
When making repairs, use only original
spare parts from REBOTEC. Observe all
advisories concerning guarantee and
warranty.
Never make any unauthorised modifications or
conversions to the walker. These will only
adversely affect the safety and function of the
walker.
In such cases REBOTEC overtakes no liability!
Follow all the instructions when ordering spare
parts, re-use and product lifetime of the walker.
After a complete maintenance or repair of the
walker is done, we recommend a complete
cleaning for assuring hygiene. Follow the cleaning
instructions.
15. Technical specifications
Specifications
YANO-Walker
max. user weight
150
kg
Product weight
10,8
kg
Length approx.
720
mm
Width approx.
680
mm
Total height approx.
1200
mm
Hole height adjustment
tenfold
Total length/armrest
260
mm
Turning radius approx.
800
mm
Plain bearing wheels
Ø=125
mm
Type of brakes
4x permanent brakes
Process tolerance: +/-15 mm
Advisory!
We reserve the right to make modifications and
further developments with regards to the illustrated
design and specifications contained in this User
Instructions booklet at any time without the notice.
You can order the User instructions or see via
our website at www.rebotec.de. It is possible to
print out the information and to read it as
needed.
